Hisense RIB312F4AW1 Montageanleitung

RIB312F4AW1

Hisense Refrigerator

Contents

_ _ _ _ _ _ _ _ _ _ _

_ _ _ _ _ _ _ _ _ _ _ _

_ _ _ _ _ _ _ _ _ _ _

_ _ _ _ _ _ _ _

Safety and warning information_ __ _ _ _ _ 2

Description of the appliance _ _ _ _ _ _ _ _

Electronic control _ _ _ _ _ _ _ _ _ _ _ _ _ _

First use and installation_ _ _ _ _ _ _ _ _ _

Daily use _ _ _ _ _ _ __ _ _ _ _ _ _ _ _ _ _

Helpful hints and tips

Cleaning and care

Troubleshooting_ _ _ _ _ _ _ _ _ _ _ _ _ _

Reverse the door

Disposal of the appliance

Safety for children and others

who are vulnerable people

For your safety and correct

usage, before installing and

first using the appliance, read

this user manual carefully,

including its hints and

warnings. To avoid

unnecessary mistakes and

accidents, it is important to

make sure that all people

using the appliance are

thoroughly familiar with its

operation and safety

features. Save these

instructions and ensure that

remain them with the

appliance if it is moved or

sold,

For the safety of life and

property, keep the

precautions of these user's

instructions as the

so that anyone using it

throughout its life, will be

properly informed on its

usage and safety notices.

manufacturer is not

responsible for damages

caused by omission.

This appliance can be used

by children aged from 8

years and above, and

persons with reduced

physical, sensory or mental

capabilities or lack of

experience and knowledge

if they have been given

supervision or instruction

concerning use of the

appliance in a safe way and

understand the hazards

involved. Children shall not

play with the appliance.

Cleaning and user

maintenance shall not be

made by children without

supervision.

Keep all packaging away

This appliance is in accordance with the following EU guidelines : LVD

2014/35/EU and EMC 2014/30/EU and 2009/125/EC and 2011/65/EU and

EC.1060/2010 and 2012/19/EU.

_ _

Hisense Refrigerator

from children as there is risk

of suffocation.

If you are discarding the

appliance, pull the plug out

of the socket, cut the

connection cable (as close

to the appliance as you can)

and remove the door to

prevent children playing

from suffering an electric

shock or closing themselves

inside.

If this appliance, featuring a

magnetic door seals, is to

replace an older appliance

having a spring lock (latch)

on the door or lid, be sure to

make the spring lock

unusable before you

discard the old appliance.

This will prevent it from

becoming a death trap for a

child.

General safety

This

appliance is intended

WARNING —

to be used in households

and similar applications

such as

-staff kitchen areas in

shops, offices and other

working environments;

-farm houses and by

clients in hotels, motels

and other residential type

environments;

-bed and breakfast type

environments;

-catering and similar non-

retail applications

WARNING — Do not store

explosive substances

such as aerosol cans with

a flammable propellant in

this appliance.

WARNING — If the supply

cord is damaged, it must

be replaced by the

manufacturer, its service

agent or similarly

qualified persons in order

to avoid a hazard.

WARNING — Keep

ventilation openings, in

the appliance enclosure

or in the built-in structure,

clear of obstruction.

WARNING — Do not use

mechanical devices or

other means to

accelerate the defrosting

process, other than those

recommended by the

manufacturer.

WARNING — Do not

damage the refrigerant

circuit.

WARNING — Do not use

electrical appliances

inside the food storage

compartments of the

appliance, unless they

are of the type

recommended by the

manufacturer.

Hisense Refrigerator

be lengthened.

2. Make sure that the power

plug is not or

damaged. A or

damaged power plug may

overheat to cause a fire.

3. Make sure that you can

plug of the

appliance.

4. Do not pull the main cable.

5. If the power plug socket is

loose, do not insert the power

plug. There is a risk of

electric shock or fire.

6.You must not operate the

appliance without the interior

lighting lamp cover.

7.The fridge is only applied

with power supply of single

phase alternating current of

220~240V/50Hz. If fluctuation

of voltage in the district of

user is so large

The power cord must not

crushed

access the main

Electrical safety

WARNING — The

refrigerant and insulation

blowing gas are flammable.

When disposing of the

appliance, do so only at

an authorized waste

disposal centre. Do not

expose to flame.

The refrigerant isobutene

(R600a) is contained within

the refrigerant circuit of the

appliance, a natural gas

with a high level of

environmental

compatibility, which is

nevertheless flammable.

During transportation and

installation of the

appliance, ensure that

the tubing of the refrigerant

circuit is not damaged

The refrigerant (R600a) is

flammable.

Refrigerant

-Thoroughly ventilate the

room in which the

appliance is situated.

It is dangerous to alter the

specifications or modify

this product in any way.

Any damage to the cord

may cause a shortcircuit,

fire, and/or electric shock.

If the refrigerant circuit

is damaged:

-Avoid naked flames and

ignition sources.

Caution:risk of fire

WARNING — To avoid a

hazard due to instability

of the appliance, it must

be fixed in accordance

with the instructions.

Hisense Refrigerator

that the voltage exceeds the

above scope, for safety

sake, be sure to apply A.C.

Automatic voltage regulator

of more than 350W to the

fridge. The fridge must

employ a special power

socket instead of common

one with other electric

appliances. Its plug must

match the socket with

ground wire.

Do not store flammable

gass or liquids in the

appliance. Risk of

explosion!

Do not operate any

electrical appliances in the

appliance (e.g.electric ice

cream makers, mixers

etc.).

When unplugging always

pull the plug from the

mains socket, do not pull

on the cable.

Do not place hot items

near the plastic

components of this

appliance.

Store pre-packed frozen

food in accordance with

the frozen food

manufacture’s

instructions.

The appliances

manufactures storage

Daily use

recommendations should

be strictly adhered

to. Refer to relrelevant

instructions for

Do not place carbonated

fizzy drinks in the freeze

compartment as it creates

pressure on the container,

which may cause it to

explode, resulting in

damage to the appliance.

storage.

Keep buring candles,

lamps and other items

with naked flames away

from the appliance so that

do not set the appliance

on fire.

The appliance is intended

for keeping food stuff

and/or beverages in

normal household as

explained in this

instruction booklet The

appliance is heavy.Care

should be taken when

moving it.

Do not remove or touch

items from the freezer

compartment if your hands

are damp/wet,as this could

cause skin abrasions or

Frozen food can cause

frost burns if consumed

straight from the freezer

compartment.

Do not place the appliance

in direct sunlight.

frost/freezer burns.

Hisense Refrigerator

Unpack the appliance and

check if there are damages

on it. Do not connect the

appliance if it is damaged.

Report possible damages

immediately to the place

you bought it. In this case

retain packing.

It is advisable to wait at

least four hours before

connecting the appliance to

allow the oil to flow back in

the compressor.

Adequate air circulation

should be around the

appliance, lacking this leads

to overheating. To achieve

sufficient ventilation, follow

the instructions relevant to

installation.

The appliance must not be

locate close to radiators or

cookers.

Wherever possible the back

of the product should not be

too close to a wall to avoid

touching or catching warm

parts (compressor,

condenser) to prevent the

risk of a fire, follow the

instructions relevant to

installation.

For electrical connection

carefully, follow the

instructions given in this

manual.

Installation Important!

Never use the base,

drawers, doors etc. to

stand on or as supports.

Frozen food must not be

refrozen once it has been

thawed out.

Do not consume ice

popsicles or ice cubes

straight from the freezer

as this can cause freezer

burn to the mouth and

lips.

To avoid items falling and

causing injury or damage

to the appliance, do not

overload the door racks

or put too much food in

the crisper drawers.

Never cover or obstruct

the ventilation slats on

Caution!

Care and cleaning

Before maintenance, switch

off the appliance and

disconnect the mains plug

from the mains socket.

Do not clean the appliance

with metal objects, steam

cleaner, ethereal oils,

organic solvents or abrasive

cleansers.

Do not use sharp objects to

remove frost from the

appliance. Use a plastic

scraper.

the appliance.

Hisense Refrigerator

Service

Make sure that the mains

plug is accessible after the

installation of the appliance.

Any electrical work required

This product must be

serviced by an authorized

Service Center, and only

genuine spare parts must

be used.

1)If the appliance is Frost

Free.

2)If the appliance contains

freezer compartment.

to do the servicing of the

appliance should be carried

out by qualified electrician

or competent person.

Hisense Refrigerator

Description of the appliance

Note: Due to constant modification of our products, your refrigerator may be slightly different

from this Instruction Manual, but its functions and using methods remain the same.

View of the appliance

1. Electronic control

2. Storage shelves

3. Bottle rack

4. Vegetable drawer cover

5. Vegetable drawer

6. Freezer drawers

Note: To get the best energy efficiency of this product, please place all shelves, drawer and

baskets on their original position as the Instruction Manual.

7. Freezer glass

However, the exact setting should be

room temperature

quantity of food stored

To ensure the normal operation of the

refrigerator, we recommend that when

you start your refrigerator for the first

depends on:

how often the door is opened

refrigerator is set to 5 ℃.

chosen keeping in mind that the

time, the temperature for the

appliance location

temperature inside the appliance

All functions and controls of the unit are

accessible from a control panel conveniently

located on the roof of the cabinet. A display

circuit board allows easy configuration of

features and settings in a simple and intuitive

manner.

sound of “beep” when you press the buttons.

pilot lights will turn on for 3 sec and you will

When the refrigerator is energized, all the

display board consists of four buttons and

also heard a long sound of “beep”. The

eight pilot lights. You will heard a short

Electronic Control

8. Upper rack

9. Middle rack

10. Lower rack

Hisense Refrigerator

2.Super Cool

“Super Cool” can refrigerate

the food quicker and keep

food fresh for a long period.

Press “Super Cool” button to activate

the super cool function. The Super icon

will light up and the fridge temperature

indicator will display 2℃.

Super cool automatically switches off

after 3 hours.

The alarm light on and a buzzing sound

indicate abnormal conditions, such as

accidentally a door left open.

Leaving the door of refrigerator open

for over 2 minutes will activate a door

alarm and buzzer. The buzzer will beep

3 times per minute for 10 minutes.

Closing the door cancels the door

alarm and buzzer.

When super cool function is on, you

can switch off super cool function by

pressing “Super Cool” or “Temp” button,

then the fridge temperature setting or

function mode will revert back to the

previous setting.

Press “Alarm” button to stop alarm and

buzzing then “Alarm” icon will turn off.

Door Alarm

To save energy, please avoid keeping

the door open for a long time when using

refrigerator.

When the refrigerator is working, you

can switch the appliance off by pressing

“Power” button for above 3 seconds,

meanwhile the display panel will be

turned off.

Important ! Do not store any food in the

fridge during this time. If you will not

use the refrigerator for a long time,

please pull the plug.

4. Power

If you want to stop using it,

you can turn the appliance

off by pressing “Power”

When the appliance is power off, you

can switch the appliance on by pressing

“Power” button for 1 second, and the

button.

refrigerator returns to previous

temperature setting.

1.Temp

the light of the comparable temperature will

be lighten corresponding values according

to the following sequence.

Press “Temp” button to set

fridge temperature between

8 and 2 as needed, and ℃ ℃

obtain a colder fridge temperature and a

Note!

Settings may be made from 2 to 8. You will

Electronic Control (located at the top of appliance)

3. Alarm

In case of alarm, “Alarm”

icon will light up and a

buzzing sound will start.

“Temp” towards 2 position:

lower freezer temperature by adjusting

A medium setting is generally the most

Warmest setting: 8 ℃.

Coldest setting: 2℃.

suitable.

Free

Hisense Refrigerator

First use and installation

listed are only for reference.

there will be a slight deviation between actual dimension and design parameter. The data

Note: Parameters provided in table are design parameters. Because of the various reasons,

RIB312 1772 540 990 632 71 ≦95°

Parameters of appliance abcdef

Built-In Fridge Freezer

the User Instructions provided.

be correctly installed, located and operated in accordance with the instructions contained in

Note: Your product is designed and built for domestic household use only. The product must

x 4

x 2

Door-opening angle

Profundity

fFreezer door height

Refrigerator door height

Width

Height

(UK)(EU)

560-568

1772-1780

550

200

cm2

200 cm2

1772

(mm)

2100

Inhaltsverzeichnis

Andere Hisense Kühlschrank Handbücher

Hisense

Hisense H299BME Bedienungsanleitung

Hisense

Hisense PureFlat RB22A2FSE Montageanleitung

Hisense

Hisense RS840N4WBE Montageanleitung

Hisense

Hisense RS-36DR series Bedienungsanleitung

Hisense

Hisense HRQ215N6BVD Bedienungsanleitung

Hisense

Hisense RD-65WR4SB Montageanleitung

Hisense

Hisense RC-70WS4S Bedienungsanleitung

Hisense

Hisense HRBM417S Montageanleitung

Hisense

Hisense RIB291 Montageanleitung

Hisense

Hisense RB400N4ACD Montageanleitung

Hisense

Hisense H6500TS Montageanleitung

Hisense

Hisense H670SIB Montageanleitung

Hisense

Hisense RD-31WC4S series Bedienungsanleitung

Hisense

Hisense HRSBS652B Montageanleitung

Hisense

Hisense RB645N4BFE Montageanleitung

Hisense

Hisense H310BIT Montageanleitung

Hisense

Hisense BCD-720WP1BF1Z9/HC1(H) Bedienungsanleitung

Hisense

Hisense RT641N4WIE Bedienungs- und Wartungshandbuch

Hisense

Hisense FMN530WFI Montageanleitung

Hisense

Hisense RF208N6ASE Montageanleitung

Hisense

Hisense HRCD585BW Montageanleitung

Hisense

Hisense RT18N6AWD Bedienungsanleitung

Hisense

Hisense RF697N4ZS1 Montageanleitung

Hisense

Hisense H415BITF-WD Montageanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
