FunTrek 130 Quick Guide

1. Appearance

FunTrek 130

HO L UX

Button Functions

Name Function

Touch Screen

The device uses touch screen controls

Right /

Power Button

When device is on, press right button to open

shortcut enu

When device is off, hold down right button for 3

seconds to power on

When device is on, hold down right button for 3

seconds to power off

Left Button When device is on, press the left button to

change the Main Menu, Trip Co puter and

Navigation screens

LED Status

Light

 Charging: Blinks red

 Full charged: Constant red light; red light

turns off when USB cable is disconnected

 When powering up, the LED will light for 1

second and the display will turn on

2. Screen Operations

3. Mount Insta ation

(1) Please co bine the brackets and ake sure that the two ends are clipped together.

(2) Screw holder fir ly to the bracket.

(3) Open the other end of the bracket and clip it to the handlebar. Place rubber padding underneath the holder.

Adjust the thickness of the rubber padding to atch the actual thickness of the handlebar then tighten screws to

install the bicycle ount fir ly.

(4) Insert GPS into holder. When it click into place, tighten the screw on the back of the holder.

(5) To re ove the GPS, loosen the screw on the back of the holder, press lightly on the pressure tab protruding

fro the botto of the holder then re ove GPS.

(1) (2) (3) (4) (5)

Touch

Screen

Left

Button

LED Status

Light

Right/

Power

Button

Left

Right

Left

Right

4.Status Bar and Icons

Sate ite Info

Icon Description

Satellite info

Strong signal/no signal

Cold start

Time

Icon Description

Ti e infor ation including clock, date

and day of the

week

Alar setup shortcut; indicates alar

is on

Indicates alar is off

Charge Info

Icon

Description

Charge full

Battery low, 1/3 re aining

Battery low

Memory Card

Icon

Description

Tracks and waypoints are stored in

SD card

Tracks and waypoints stored in

internal e ory

Compass

Icon

Description

Co pass is calibrated

Co pass requires calibration

A arm

Icon

Description

Indicates alar is on

Indicates alar is off

Back ight

Icon

Description

Backlight is on

Backlight is off

Screen Lock

Icon

Description

Screen is locked

Screen is not locked

Track Log

Icon

Description

Recording track

Track recording paused

Basic Button Functions

Icon Description

Create new file

Display 3 Trip Co puter pages

Pause (used by Alar and Track Log)

Trip Co puter setup

Confir

Icon Description

Back

Display 6 Trip Co puter pages

Start (used by Alar and Track Log)

※ Note: Please use the bundled USB cable to connect the device to the PC/Notebook and access stored data.

The bundled charger should be used for charging.

※ New product fir ware updates and aps will be available on our co pany website.
