Holux GR-239 Bedienungsanleitung

Car Cigarette Lighter Powered Bluetooth GPS Receiver

zItem No.: GR-239

zProduct Name: Car Cigarette Lighter Powered Bluetooth GPS Receiver

zDescription:

The cigarette lighter powered Bluetooth

GPS receiver, GR-239, incorporates the

latest Bluetooth technology and contains

the newest generation SiRFstarIII chipset

for high sensitivity, featuring parallel

tracking of twenty satellites for signal

acquisition greater capability*c. The

stylish and handy cigarette lighter-style

design allows for hours long use in your

car, making your vehicle function as a GPS-embedded system. It uses a car cigarette

lighter socket as a power supply saving the trouble of recharging it. GR-239 brings a whole

new experience of GPS mobility.

zFeature：

1. This handy and stylish cigarette lighter-style design allows hours long- use in your car. It

saves the trouble of recharging to ensure enjoyment of all-round mobility.

2. Use SiRF Star III chipset.

3. Compatible with Bluetooth Serial Port Profile (SPP) completely.

4. Support NMEA0183 v2.2 data protocol or SiRF binary code.

5. Provide expand terminal and can contact to other system without Bluetooth device.

6. 20 - channel GPS Receiver for fast acquisition and reacquisition. *c

zPackage Contents

1. One HOLUX Car Cigarette Lighter Powered Bluetooth GPS receiver

2. One tool CD (with User's Manual inside)

3. One Quick Installation Guide

4. One Warranty card

*Optional

1. USB data cable (Data cable can be used for data transfer between GR-239 and Notebook

PC.)

2. MMCX active antenna

GR-239

zSpecification (Part of the information below is provided by SiRF Technology, Inc.)

Item Description

Specification

•Tracks up to 20 satellites *c

•Receiver : L1, C/A code

•Update rate : 1 HZ.(max.)

•Antenna Type: Built in Patch Antenna

•External Ant type: MMCX

•Minimum signal tracked : -159dBm *c

•Dimension : D 40.4 × 100 L mm (72 L mm)

•Weight : < 56 g

•Operation temperature : -10 ℃ to + 60 ℃

•Store temperature : -20 ℃ to + 70 ℃

•Operation humidity : 5% to 95% no condensing

Position *c

◆Non DGPS (Differential GPS)：

•Position : 5 - 25 m. CEP without SA

•Velocity : 0.1m. / sec.

•Time : 1 µsec. sync GPS time

◆EGNOS/WAAS /Beacon：

•Position : < 2.2 m., horizontal 95 % of time

< 5 m., vertical 95 % of time

Acquisition

Time *c

◆ Acquisition time:

•Reacquisition 0.1 sec. averaged

•Hot start 1 sec. averaged

•Warm start 38 sec. averaged

•Cold start 42 sec. averaged

Protocol

Interface

◆Compatible with Bluetooth devices with Serial Port Profile (SPP)

•Bluetooth™version 1.2 compliant

•Bluetooth™Class 2 operation (10 meter)

•Frequency : 2.400 to 2.480 GHz

•Modulation: FHSS / GFSK

•RF channels: 79

◆Output terminal: Mini-USB (DATA I/O,COMS Level)

•NMEA protocol output : V 2.2

Baud rate : 38400 bps

Data bit : 8

Parity : N

Stop bit : 1

•Output format :

Standard : GGA(1),GSA(5),GSV(5), RMC(1),VTG(1)

Optional : GLL, SiRF Binary

Dynamic

Conditions *c

•Altitude :18,000 m. ( 60,000 feet ) max.

•Velocity : 736 m./sec. ( 1000 knots ) max.

•Acceleration : ±4G, max.

•Jerk : 20 m/sec, max.

Led Function Bluetooth, Navigation Update status Indication

*c：Cit. SiRF’s onginal chipset spec.
