HOLUX Wireless GPS Logger M-241User’s Manual
Holux
Wireless GPS Logger
M-241
April 2009
Ver.C
Technology, Inc.
No.1-1, I ovatio Road1, Scie ce-based I dustrial Park, Hsi chu 300, Taiwa
TEL: 886-3-6687000 FAX: 886-3-6687111
Website: www.holux.com
All Rights Reserved
User’s Guide
HOLUX Wireless GPS Logger M-241 User’s Manual
2
HOLUX Wireless GPS Logger M-241 User’s Manual
3
Table of Co te ts
Table of Co te ts .....................................................................................................3
1. Overview ...........................................................................................................4
2. Packi g List ......................................................................................................6
3. Mai features ....................................................................................................7
4. Specificatio .....................................................................................................8
5. Ico s & I dicators ..........................................................................................10
6. Product Overview ...........................................................................................11
7. Basic Operatio s............................................................................................12
8. Co ecti g the device to the PC...................................................................24
9. Dow load Log Data to PC..............................................................................25
10. Bluetooth device co ectio i stallatio .....................................................41
11. I stallatio of Mi i GPS Viewer program ......................................................43
12. Execute the Mi i GPS Viewer program .........................................................44
13. Power ..........................................................................................................46
14. Warra ty ..........................................................................................................46
15. Troubleshooti g .............................................................................................47
Federal Commu icatio s Commissio (FCC) Stateme t ....................................48
HOLUX Wireless GPS Logger M-241 User’s Manual
4
1. Overview
The HOLUX M-241 wireless GPS logger provides real time coordinate
logging and easy to use trip guiding service. The M-241 can record up to
130,000 positions, each position including longitude, latitude, time, and altitude.
The log file can be transfered for analysis via USB connection. You can
combine these positions with your Digital camera photos to share the track
histories and photo locations to mapping application software such as Google
Earth.
Position information, moving speed, free logging volume and the date &
time can be shown on the LCD display directly at any time. The M 241
supports distance and time logging modes, kilometer and mile distance units,
and 5 languages (English, Traditional Chinese, Simplified Chinese, German,
and French).
Because the M 241 provides a Bluetooth interface, you can use it freely
while driving without the clutter of cables.
Enjoy the GPS life!
The M-241 is a high performance wireless
GPS logger with the following
features:
1. Dual interface (Bluetooth + GPS mouse by USB cable).
2. Compatible with Bluetooth
Serial Port Profile (SPP) completely.
3. Powered by one AA battery.
4. LCD display (32mm L* 8.9mm W) to show position information, speed,
capable logging memory size, date & time.
5. Capable memory size to record up to 130,000 positions, including longitude,
latitude, time, and altitude.
6. Personal settings to select the logging mode by distance or time, unit by
Kilometer or mile, and 5 languages (English, Traditional Chinese, Simplified
Chinese, German, and French) support.
HOLUX Wireless GPS Logger M-241 User’s Manual
5
Applicatio s:
* Vehicle tracing & Location base services
* Navigation with PDA/Notebook/Smartphone devices
* Car navigation
* Marine navigation
* Distance measurement
* Sports and Recreation
* Fleet Management
Software applicatio program:
A user friendly software utility is provided with the following functions:
* Transfer recorded data to PC.
* Recording mode setting (Time / Distance)
* Erase recorded data
* Output data format
(1) Save exploring data to KML file format (Interface with Google Earth)
(2) NMEA file format (*.txt)
(3) Binary file format
(4) GPX file format
HOLUX Wireless GPS Logger M-241 User’s Manual
6
2. Packi g List
Thank you for purchasing the M-241 wireless GPS logger. Before you start,
make sure that the following items are included in your package. If any of
these items are missing, please contact your original local HOLUX dealer or
distributor.
1. M 241 wireless GPS logger 1 Set
2. AA Battery 1 Set
3. Car Charger *+ USB cable 1 Set
4. User guide and Driver CD 1 Pcs
5. M 241 Quick Guide 1 Pcs
6. Warranty card 1 Pcs
7. Nylon strap 1 Pcs
Optio
1. Travel power supply 1 Set
* Car Charger can only be used as the power supply adapter, it does not
have any battery charging function.
HOLUX Wireless GPS Logger M-241 User’s Manual
7
3. Mai features
1. Built in MTK Low power consumption GPS chipset.
2. 32 parallel satellite searching channels for fast acquisition and
reacquisition.
3. Superior sensitivity, up to 159 dBm.
4. Built in WAAS/EGNOS/MSAS Demodulator without any additional
hardware.
5. Completely compatible with Bluetooth Serial Port Profile (SPP).
6. Provide expanded terminal contact to other systems without the
Bluetooth device.
7. Support NMEA0183 V 3.01 data protocol
8. Compact and lightweight design for ease of use.
9. LCD display (32mm * 8.9mm /128 * 32 pixels) to show position
information, speed, capable logging memory size, date & time.
10. Capable memory size to record up to 130,000 position data, including
longitude, latitude, time, and altitude.
11. Personal setting to choose the logging mode by distance or time, unit
by Kilometer or mile, and 5 languages (English, Traditional Chinese,
Simplify Chinese, German, and French) support.
HOLUX Wireless GPS Logger M-241 User’s Manual
8
4. Specificatio
Specificatio s
‧32 parallel satellite searching channels
‧Receiver: L1, 1575.42 MHz
‧Frequency: 1.023 MHz
‧Update frequency: 1 Hz.
‧Antenna type: Built in
‧Satellite signal reception sensitivity: 159dBm
‧Dimensions: 32.1mm X 30mm X 74.5mm
‧Weight (excluding battery): < 39g.
‧Switch: Slider switch
‧Operating temperature: 0 ℃ to + 50 ℃
‧Storage temperature: 10 ℃ to + 60 ℃
‧Operating humidity: 5% to 90%
Positio i g
◆
◆◆
◆ No DGPS (Differe tial GPS)：
：：
：
‧Position : 3.0 M CEP excluding SA
‧Velocity: 0.1M / sec.
‧Interval: 0.1 sec to Sync GPS
◆
◆◆
◆ DGPS (EGNOS/WAAS/MSAS)：
：：
：
‧Position: < 2.2 M., Horizontal deviation 95% time
< 5 M., Vertical deviation 95 % time
*The above data is based on the specifications of the MTK GPS chip
Positio i g
Timi g
‧Time to reposition < 0.1 sec average
‧Hot boot 1 sec
‧Warm boot 33 sec
‧Cold boot 36 sec
*The above data are based on specifications of the MTK GPS chip
Protocol a d
I terface
◆
◆◆
◆ Bluetooth compatible serial specificatio s (SPP)
‧Bluetooth V1.2 compatible
‧Bluetooth class 2 (within 10m of range in open space)
‧Frequency: 2.400 to 2.480 GHz
‧Modulation: FHSS / GFSK
‧RF channels: 79
‧Input sensitivity: 85dBm
‧Output power: +2dBm
◆
◆◆
◆Output port: Mi i-USB (CMOS Level)
HOLUX Wireless GPS Logger M-241 User’s Manual
‧NMEA protocol output: V 3.01
Baud rate: 38400 bps
Data bits: 8
Sync bits: N
End bit: 1
‧Output i terface:
Standard: GPGGA (1 time per second), GPGSA (1 time per second),
GPGSV (1 time per second), GPRMC (1 time per second), GPVTG (1
time per second).
Physical
Specificatio s
‧Sea level: Max 18,000 M (60,000 feet)
‧Velocity: Max 515 M./sec ( 1000 knots)
‧Acceleratio : Max 4G
‧Vibratio : 20 M/ second
3
, Max.
Butto s 1 Power switch, 2 Buttons (Menu and Confirm)
LCD display
page
‧System and satellite positioning status
‧Time
‧Position
‧Velocity
‧Distance measurement
‧Setup
HOLUX Wireless GPS Logger M-241 User’s Manual
10
5. Ico s & I dicators
Position
PositionPosition
Position
Icon
IconIcon
Icon
Descriptions
DescriptionsDescriptions
Descriptions
Position
PositionPosition
Position
Icon
IconIcon
Icon
Descriptions
DescriptionsDescriptions
Descriptions
1
Log by Time
2
Measure Distance On
1
Log by Distance
4
Lock On
3
Log On
7
Device & PC Connected
4
Waypoint
8
Battery is Full
6
GPS Fix
8
Battery is exhausted
5
Bluetooth Connection
