USE AND CARE GUIDE

SARINA 23-INCH CEILING FAN

Questions, problems, missing parts? Before returning to the store,

call Home Decorators Collection Customer Service

8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.

1-800-986-3460

HOMEDEPOT.COM/HOMEDECORATORS

Item#

1008873642, 1008962991

Model# CF1004B, CF1004C

THANK YOU

to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home

improvement needs. Thank you for choosing Home Decorators Collection!

1. To reduce the risk of electric shock, ensure the electricity has been

turned off at the circuit breaker or fuse box before you begin.

2. All wiring must be in accordance with the National Electrical Code

ANSI/NFPA 70-1999 and local electrical codes. Electrical installation

should be performed by a qualied licensed electrician.

3. To reduce the risk of re, electric shock, or personal injury, mount to

outlet box marked acceptable for fan support of 35 lbs (15,9 kg ) on

less and use mounting screws provided with the outlet box. Most

outlet boxes commonly used for the support of lighting xtures are

not acceptable for fan support and may need to be replaced. Consult

a qualied electrician if in doubt. The xing means for attachment to

the ceiling such as hooks or other devices shall be xed with a

sufcient strength to withstand 4 times the weight of the ceiling fan.

4. To reduce the risk of injury to persons,install fan so that the blade is

at least 7 ft (2.1m) above the oor.

5. Do not operate the reversing switch while the fan blades are in

motion. You must turn the fan off and stop the blades before you

reverse the blade direction.

6. Do not place objects in the path of the blades.

7. To avoid personal injury or damage to the fan and other items, use

caution when working around or cleaning the fan.

8. After making electrical connections, spliced conductors should be

turned upward and pushed carefully up into the outlet box. The

wires should be spread apart with the grounded conductor and the

equipment-grounding conductor on one side of the outlet box.

The ungrounded conductor on the other side of the outlet box.

9. All setscrews must be checked and retightened where necessary

before installation.

To reduce the risk of injury to persons, not intended for use by persons

(including children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been given supervision

or instruction concerning use of the fan by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the fan.

WARNING: To reduce the risk ofpersonal injury,

do not bend the blade brackets (also referred toas

anges) during assembly or after installation. Do not

insert objects in the path of the blades.

WARNING: To avoid possible electrical shock,

turn the electricity off at the main fusebox before

wiring. Ifyou feel you donot have enough electrical

wiring knowledge or experience, contact a licensed

electrician.

WARNING: To reduce the risk of re or electric shock,

do not use this fan with any solid state speed control

device.

CAUTION: To reduce the risk of personal injury,

use only the screws provided with the outlet box.

WARNING:

shock, this fan should only be used with fan speed

control part no. D-SLF-A20-01-A, manufactured by

LEEDARSON LIGHTING CO., LTD.

WARNING: To reduce the risk of re or electric shock,

this fan must be installed with an isolating wall switch.

WARNING: All replacement of parts and the mounting

of the safety suspension system device shall be

performed by qualied licensed electricians.

WARNING: To reduce the risk of personal injury, if

unusual oscillating movement is observed, immediately

stop using the ceiling fan and contact with a qualied

licensed electrician.

Table of Contents ................................................................ 2

Safety Information............................................................... 2

Warranty ............................................................................... 3

Pre-Installation .................................................................... 4

Installation............................................................................ 6

Assembly.............................................................................. 7

Operation ........................................................................... 10

Care and Cleaning............................................................. 12

Troubleshooting................................................................. 13

Table of Contents

3HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Warranty

Contact the Customer Service Team at 1-800-986-3460 or visit HOMEDEPOT.COM/HOMEDECORATORS.

The supplier warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a lifetime

after the date of purchase by the original purchaser. The supplier also warrants that all other fan parts, excluding any glass or acrylic blades, to be

free from defects in workmanship and material at the time of shipment from the factory for a period of two years after the date of purchase by the

original purchaser. We agree to correct such defects without charge or at our option replace with a comparable or superior model if the product is

returned. To obtain warranty service, you must present a copy of the receipt as proof of purchase. All costs of removing and reinstalling the product

are your responsibility. Damage to any part, such as by accident, misuse, improper installation, or by afxing any accessories, is not covered by

this warranty. Because of varying climatic conditions this warranty does not cover any changes in brass nish, including rusting, pitting, corroding,

tarnishing, or peeling. Brass nishes of this type give their longest useful life when protected from varying weather conditions. A certain amount of

"wobble" is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is

no other express warranty. Home Decorators Collection hereby disclaims any and all warranties, including but not limited to those of merchantability

and tness for a particular purpose to the extent permitted by law. The duration of any implied warranty, which cannot be disclaimed, is limited

to the time period as specied in the express warranty. Some states do not allow a limitation on how long an implied warranty lasts, so the above

limitation may not apply to you. The retailer shall not be liable for incidental, consequential, or special damages arising out of or in connection with

product use or performance except as may otherwise be accorded by law. Some states do not allow the exclusion of incidental or consequential

damages, so the above exclusion or limitation may not apply to you. This warranty gives specic legal rights, and you may also have other rights that

vary from state to state. This warranty supersedes all prior warranties. Shipping costs for any return of product as part of a claim on the warranty

must be paid by the customer.

Changes or modications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate

the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates

uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interfer-

ence by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and

operated with a minimum distance of 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunc-

tion with any other antenna or transmitter.

FCC compliance information is listed as below:

Responsible party: Leedarson America, Inc.

Responsible party address: 300 Technology Court SE Suite 100, Smyrna, GA 30082

Telephone number: (678) 293-8382

FCC Warning

Safety Information

Pre-Installation

SPECIFICATIONS

TOOLS REQUIRED

Phillips

screwdriver

Flat blade

screwdriver

Adjustable

wrench

Electrical

tape

Wire cutter Step ladder

5003280

Size Speed Volts Amps Watts RPM CFM Net

Weight

Gross

Weight Cu. Ft.

23.6 in. 120

0.09

0.13

0.14

4.5

440

700

803

800

1300

1800

9.26lbs

(4.2 kg)

18.25lbs

(8.28 kg) 2.237

NOTE: These are approximate measures. They do not

include the amps and wattage used by the light kit.

HARDWARE INCLUDED NOTE: Hardware not shown to actual size.

Pre-Installation (continued)

Part Description Quantity

AA Combination screw

Screw - 1 (M4*25) (not included)

Washer - D5 (φ5) (not included)

Washer - D15 (φ15) (not included)

Wire nut (P4)

Hex key

Drywall anchor - 6*24

Screw - ST3.0*18

Screw - ST3.5*13

Screw - 6#-32*13

Washer - D4 (φ4) (not included)

Screw - 3(ST4.8*77) (not included)

AAA battery

BB 2

2I I

MM 2

GG HH II JJ KK LL

BB CC DD EE FF

Pre-Installation (continued)

Part Description Quantity

A Mounting bracket

Hanger rod

Canopy

Coupling cover

Fan-motor assembly

IR remote (batteries included)

Remote bracket base

Remote bracket

hitch pin (pre-installed)

lock pin (pre-installed)

B 1

C 1

D 1

I 1

J 1

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

NIGHT LIGHT COLOR TEMP.

FAN DIRECTION

HOLD 3 SEC.

SUMMER WINTER

ON / OFF ON / OFF

3 SPEED BRIGHTNESS

ALL

TIMER

2HR

4HR

If your ceiling fan does not have an existing UL-listed outlet

box, then install one using the following instructions:

Disconnect the power by removing the fuses or turning off

the circuit breakers.

Secure the outlet box directly to the building structure. Use

the appropriate fasteners and materials. The outlet box and

support structure must be securely mounted and capable of

reliably supporting 35 lbs. (15.9 kg). Use only UL Listed

outlet boxes marked“Acceptable for Fan Support of 35 lbs.

(15.9 kg)or less." Do not use a plastic outlet box.

The illustrations below show two different ways to mount the

outlet box.

□

Installation

MOUNTING OPTIONS

WARNING:

personal inju ry, mount to outlet box marked “A cceptable

for fan suppor t of 35 lbs. (15.9 kg) or less”, and use

screws provided with the outlet box. An outlet box

not be acceptabl e for fan supp ort and may need to be

you may need an installation hanger bar as shown above

(available at any Home Depot store).

Outlet Box

Hanger Bar

Align 2 Screw (BB/LL) through Washer (CC/KK) and Washer-

D15 (DD), then install 2 screw assemblies through 2 centered

holes of mounting bracket (A) onto the outlet box. Figure 1.

Tighten the mounting screw assemblies to secure the

mounting bracket (A) to the ceiling.

Figure 1

Install the mounting bracket to

ceiling

WARNING: To reduce the risk of re, electric shock, or other

personal injury, mount the fan only to an outlet box or supporting

system marked acceptable for fan support and use the mounting

screws provided with the outlet box.

□

Assembly - Hanging the Fan

□Remove the hitch pin (I) and lock pin (J) from the bottom of

hanger rod (B). Figure 1.

Put the canopy (C) and coupling cover (D) over the hanger

rod (B). Figure 2.

Align two holes at the bottom of hanger rod (B) with two holes

on the coupling cover (D) to reinstall the hitch pin (I) and lock

pin (J) back to pre-lock the down-rod assembly. Figure3.

Insert combination screw (AA) into the hole beside hitch pin (I)

and lock pin (J), tighten the screw to secure the coupling cover

(D) to the hanger rod (B).

□

Prepare the down-rod assembly

Outlet Box

BB/LL

CC/KK

Figure 1

Figure 2

Figure 3

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

B B

Attaching fan-motor assembly to

the down-rod assembly

Pre-lock two combination screws (AA) into two

opposite holes on the outer race of the coupling cover (D).

Align two pre-locked combination screws (AA) with two

slots on the housing of fan-motor assembly (E). Rotate the

down-rod assembly in place until it is secure. Figure 1.

Identify the wiring located on the fan-motor assembly (E):

black-line voltage, white-neutral, green-ground. Feed the

wires from the fan-motor assembly (E) through the hanger

rod (B). Figure 2.

Tighten pre-locked combination screws (AA) and another

two combination screws (AA) to secure the down-rod

assembly to the fan-motor assembly (E). Figure 3.

Connecting the wires

□

Carefully lift the whole xture to hang the ball head of hanger

rod (B) onto the mounting bracket (A) previously installed on

ceiling. Rotate the hanger rod (B) until it snap in place. Figure 1.

Connect the white (N), black (L) and green wires from the

xture to their corresponding wires from the junction box using

wire nuts (EE). Figure 2.

Assembly - Hanging the Fan (continued)

□

□Outlet Box

White

(N)

Black

(L)

Green

L&N

Figure 2

Figure 1

Outlet Box

White

（N）

Black

（L）

Green

Figure 3

□

Align two key holes of canopy (C) with the pre-installed

screws under the mounting bracket (A). Push up the canopy (C)

until the screws heads engage to the key holes

on the canopy (C), and rotate the canopy (C) counterclockwise

until it is attached to the bottom of the mounting bracket (A)

tightly. Figure 1.

Tighten two preinstalled screws to secure the canopy

5Install the canopy

Assembly - Hanging the Fan (continued)

Figure 1

Install the remote bracket

□

Using the remote bracket base (G) as a guide, mark the two holes

locations.

Drill the two holes at the marked locations and install two drywall

anchors (GG) in each of the marked locations. Figure 1.

Insert screw (II) into anchor and tighten each screw to secure the

remote bracket base (G). Use screw (HH or JJ) to tighten remote

bracket on the housing. Figure 2.

Figure 1

Figure 2

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

HH / JJ

Remote Operation

Warm weather

Cool weather

Remote control

Your fan isequipped with a remote control to operate the speed and

lightsfor your new ceiling fan.

effect. This allows you to set your air conditioner on a warmer setting

without affecting your comfort.

the

ceiling. This allows you to set your heating unit on a cooler setting

without affecting your comfort.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Home Decorators Collection Lüfter Handbücher

Home Decorators Collection

Home Decorators Collection 56047 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection BENTLEY III Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection TRENTINO II YG475-BN Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection MERCER 54725 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection BELFORD Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection 51860 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection DELMORE 56054 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection DOWNEY 56043 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection AM589H-EB Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection Bentley II 129828 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection CARDEN AM852-BN Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection YG583-WH Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection HAVERBROOK AM634-PN Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection RAINA Series Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection INTERVALE N609A-BN Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection WINDWARD IV Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection MONTEL Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection AK83-EB Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection CLERMONT Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection FELDNER 56055 Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection PARKRIDGE YG614-NI Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection Easton Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection AM630-BN Bedienungsanleitung

Home Decorators Collection

Home Decorators Collection DANIEL 52179 Bedienungsanleitung

Beliebte Lüfter Handbücher anderer Marken

ELTA FANS

ELTA FANS H03VV-F Bedienungsanleitung

Hunter

Hunter 20714 Gebrauchsanweisung

Emerson

Emerson CARRERA VERANDA CF542ORB00 Bedienungsanleitung

Hunter

Hunter Caraway Gebrauchsanweisung

Panasonic

Panasonic FV-15NLFS1 Bedienungsanleitung

Kompernass

Kompernass KH 1150 Bedienungsanleitung

VES

VES FALA100/12V/TR Bedienungsanleitung

Vertiv

Vertiv Liebert DCD Bedienungsanleitung

Westinghouse

Westinghouse GFP Series Bedienungsanleitung

Venmar

Venmar KUBIX HRV PLUS Series Bedienungsanleitung

Maico

Maico ECR 31 Bedienungsanleitung

Sonnenkonig

Sonnenkonig Dinky Bedienungsanleitung

S&P

S&P ECOWATT HXBR Bedienungsanleitung

Wider

Wider IMP03369BH Bedienungsanleitung

Panasonic

Panasonic F-60DHN Bedienungsanleitung

Hinkley

Hinkley HIGHLAND Bedienungsanleitung

Broan

Broan 766BN Bedienungsanleitung

Premium

Premium PFS16022 Montageanleitung
