Model

KM-251BAH

Self-Contained Crescent Cuber

Hoshizaki America, Inc.

Number: 71255

Issued: 9-22-2006

PARTS LIST

™

CONTENTS

Auxiliary Codes ...................................................................................................................... 3

Note About Ordering Parts .................................................................................................... 3

Material Abbreviations ........................................................................................................... 4

A. Ice Cuber Assembly .......................................................................................................... 5

B. Refrigeration Circuit ........................................................................................................... 9

C. Water Circuit .................................................................................................................... 12

D. Control Box Assembly ..................................................................................................... 15

E. Electrical Box Assembly .................................................................................................. 16

F. Door Assembly ................................................................................................................. 17

G. Label Location ................................................................................................................. 18

H. Accessories and Packaging ............................................................................................ 20

Auxiliary Codes

KM-251BAH R-0 April 2006

Note About Ordering Parts

Most assemblies cannot be ordered as complete units; parts in the assemblies generally

must be ordered separately.

Material Abbreviations

ALUMINUM

AL = Aluminum

COPPER

CU = Copper

PLASTIC

ABS = Acrylonitrile -butadiene - styrene

AC = Polyacetal

EVA = Ethylene vinyl acetate

PA = Polyamide = Nylon

PC = Polycarbonate

PE = Polyethylene

PES = Polyester

PETP = Polyethylene terephthalate = Tetlon

PP = Polypropylene

PS = Polystyrene

PTFE = Polytetraﬂuoroethylene = Teﬂon

PUR = Polyurethane

PVC = Polyvinyl chloride

RUBBER

VN = Vinyl Nitrile

EPDM = EP rubber

NBR = Nitrile butadiene rubber

NR = Natural rubber

NP = Neoprene

SI.R = Silicone rubber

SY.R = Synthetic rubber

EPH = Epichlorohydrin

STEEL

GS = Galvanized steel

SS = Stainless steel

PS = Plated steel

PAS = Primed steel

AUXILIARY CODE

K-0

Designates the year. "K" indicates the year 2000. Years progress or regress in alphabetical order.

"J" is 1999, "L" is 2001, "M" is 2002, and so on. The letters "I" and "O" were skipped.

Designates signiﬁcant part changes within the same year for this model. Base is 0 and this number

advances for each change.

Example: P-1

"P" indicates 2004.

"1" indicates the ﬁrst signiﬁcant part change for 2004.

A. Ice Cuber Assembly

KM-251BAH

1/2

R-0

25 26 27 28

EE1

17 17a

15 15a

14 14a

Panel shown removed for

clarity.

12 12a

25 26 27 28

A. Ice Cuber Assembly

KM-251BAH

2/2

R-0

10 10a

77a

33a

55a

Title: A. Ice Cuber Assembly Model: KM-251BAH

Index

No. Description

Material or

Model Number Part Number

Required Number

R-0

B Refrigeration Circuit - 1A1035A01 1

B1 T2 Screw 4×12 SS 7P32-0412 2

B2 Truss Head Screw 4×16 SS 7C32-0416 4

C Water Circuit 1A1034A01 1

C1 Thumbscrew - 415949G10 1

C2 T2 Screw (See C. Water Circuit

item 16)

4×8 SS 7P32-0408 2

D Control Box Assembly - 3A3413A01 1

D1 T2 Screw 4×8 SS 7P32-0408 4

E Electrical Box Assembly - 3A3400A02 1

E1 T2 Screw 4×8 SS 7P32-0408 2

F Door Assembly - 3A3415A02 1

G Label Location - 3A3429A01 1

1 Body Assy - 1A1043G01 1

1a T2 Screw 4×8 SS 7P32-0408 9

2 Grommet/Pipe - 3A3387-01 1

3 Bracket/Cleaning Valve - 4A3703-01 1

3a T2 Screw 4×8 SS 7P32-0408 2

4 Grommet/Cleaning Valve - 3A3390-01 1

5 Bracket/Water Inlet - 4A4120G01 1

5a T2 Screw 4×8 SS 7P32-0408 2

6 Top Frame - 2A3369-02 1

6a Truss Head Screw 4×12 SS 7C32-0412 4

7 Rear Panel - 3A3397-02 1

7a T2 Screw 4×8 SS 7P32-0408 3

8 Bushing SR-7K-2 420472-02 1

9 Power Supply Cord 15 AMP 125V 4A1773-01 1

10 Rear Cover - 3A3399-01 1

10a T2 Screw 4×8 SS 7P32-0408 2

11 Top Insulation Assembly - 2A3833G02 1

12 Top Panel - 1A1026-02 1

12a Truss Head Screw 4×12 SS 7C32-0412 2

13 Slope - 3A4121-02 1

14 Hinge (L) - 4A3690-01 1

14a Hex Bolt 5×20 SS (LF) 7B0230520 2

15 Hinge (R) - 4A3690-02 1

15a Hex Bolt 5×20 SS (LF) 7B0230520 2

16 Hinge Guide - 3A4159-01 2

17 Front Panel - 2A3376-01 1

17a Truss Head Screw 4×12 SS 7C32-0412 1

18 Louver (A) - 1A0547-01 1

19 Push Retainer PS125306PG 4A2414-01 3

Title: A. Ice Cuber Assembly Model: KM-251BAH

Index

No. Description

Material or

Model Number Part Number

Required Number

R-0

20 Insulation/Front Panel - 4A3706-01 1

21 Air Filter (A) Large - 2A2062G01 1

22 Bushing OCB-875 428394-04 2

23 Screw - Ground 4×8 7C32-0408 1

24 Screw - Ground Pump Motor 4×8 7C32-0408 1

25 Door Spacer (A) SS (0.5)mm 4A4124-01 As Required

26 Door Spacer (B) SS (0.6)mm 4A4124-02

27 Door Spacer (C) SS (0.8)mm 4A4124-03

28 Door Spacer (D) SS (1.0)mm 4A4124-04

B. Refrigeration Circuit

KM-251BAH

R-0

17 18

3526

38 32 33

27a

10a

11a

22a

13a

16 16a 16b 16c 16d

29b

28 29 29a

15 15a

14a

22a

DETAILED THERMISTOR ATTACHMENT

Title: B. Refrigeration Circuit Model: KM-251BAH

Inde×

No. Description

Material or

Model Number Part Number

Required Number

R-0

1 Evaporator Assembly - 1A1033G01 1

2 Base - 3A3447G02 1

3 Expansion Valve - 4A1838-02 1

4 Expansion Valve Cover - 4A1168-01 1

5 Holder Exp. Valve - 3/8 - 3A0107-01 1

6 Clamp - 443461-02 1

7 Fan Motor - 4A3158-01 1

7a Self-Locking Nut NO.8-32 7N21I0832 4

8 Fan Motor Bracket - 3A3436-01 1

8a Hex Bolt 5×12 SS 7B0230512 4

9 Fan Blade - 444898-01 1

10 Fan Capacitor 5.0MFD, 250V 443192-02 1

10a T2 Screw 4×8 SS 7P32-0408 1

11 Shroud - 3A3435G02 1

11a T2 Screw 4×8 SS 7P32-0408 4

12 Pressure Switch - 433441-07 1

13 Pressure Switch Bracket GS 434938-01 1

13a T2 Screw 4×8 SS 7P32-0408 1

14 Base/Compressor - 3A3412G01 1

14a T2 Screw 4×8 SS 7P32-0408 2

15 Clamp/Copper Tube - 4A3708-01 1

15a T2 Screw 4×8 SS 7P32-0408 1

16 Compressor SC12MLX 4A3677-01 1

16a Rubber Grommet - 4A1452-01 4

16b Sleeve - 4A1451-01 4

16c Washer - 4A1450-01 4

16d Bolt - 4A1459-01 4

17 Protector - 4A3679-01 1

18 Protector Holder - 4A3680-01 1

19 Cover - Compressor 117U1021 4A2141-01 1

20 Copper Tube-High Side (includes

items: 28, 29,

29a, 30, 31)

2A3381G01 1

21 Copper Tube-Access Valve - 3A3403G01 1

22 Condenser - 2A3404-01 1

22a T2 Screw 4×8 SS 7P32-0408 2

23 Separator - 2A3356-02 2

24 Heat Exchanger - 2A3388G01 1

25 Drier DY-15QHD-5 458776-01 1

26 Copper Tube (J)-High Side - 4A3697-01 1

27 Plate/Inlet Fitting - 4A3701-01 1

27a T2 Screw 4×8 SS 7P32-0408 1

28 Valve Body (hot gas) (included

in item 20:

2A3381G01)

4A3978-01 1
