HP Compaq Presario Handbuch

Volume Two 3-119

Presario 7900

System Boards Assembly Spare Part System

System Board, PCA, MV4-

CAM 164465-101 166050-101 7922

System Board w/ 1394 165565-101 166049-101 7900, 30, 31, 34, 35,

40, 47, 50, 54, 70,

71, 73, 80, 85, 90,

94, 98

Configuration

Code Assembly System Board

Spare Part Model

DCP3 164465-101 166050-101 7922

DCQ2 165565-101 166049-101 7947

DCQ4 165565-101 166049-101 7940

DCQ5 165565-101 166049-101 7970

DCQ6 165565-101 166049-101 7930

DCQ7 165565-101 166049-101 7950

DCQ8 165565-101 166049-101 7973

DCQC 165565-101 166049-101 7935

DCQD 165565-101 166049-101 7985

DCQE 165565-101 166049-101 7931

DCQF 165565-101 166049-101 7930

DCQG 165565-101 166049-101 7990

DCQH 165565-101 166049-101 7971

DCQJ 165565-101 166049-101 7990

DCQQ 165565-101 166049-101 7934

FG52 165565-101 166049-101 7954

FG54 165565-101 166049-101 7954

FG55 165565-101 166049-101 7980

FG56 165565-101 166049-101 7998

FG57 165565-101 166049-101 7994

Microprocessors Assembly Spare Part System

533, uP, K6-2 330631-015 171704-001 7922

550, K7, w/ No Fix 155214-001 7935

550, K7 187517-001 7930, 31, 34

600, K7, w/ No Fix 155215-001 7940, 47

650, K7 160396-001 7950, 54

700, K7 160397-001 7970, 71, 73

750, K7 168593-001 7980, 85

800, K7 168594-001 7990

900, K7 180161-001 7994

1 GHz, K7 180163-001 7998

Memory DIMMs Assembly Spare Part System

64 MB, 100 MHz 164975-001 179190-001 7922, 30, 54

128 MB, 100 MHz 323013-001 166966-001 7930, 31, 34, 35, 40,

47, 50, 54, 70, 71,

73, 80, 85, 90, 94,

3-120 Volume Two

Presario 7900

Miscellaneous Assembly Spare Part System

Keyboard 341162-XXX 387084-XXX 7922, 30, 31, 34, 35,

40, 47, 50, 54, 70,

71, 73, 80, 85, 90,

94, 98

Mouse, Scroll, Opal 334684-006 334689-002 7922, 30, 31, 34, 35,

40, 47, 50, 54, 70,

71, 73, 80, 85, 90,

94, 98

Front I/O Assembly, USB 158487-002 170077-001 7922

Front I/O Assembly, USB 115772-001 155641-001 7930, 31, 34, 35, 40,

47, 50, 54, 70, 71,

73, 80, 85, 90, 94, 98

Button Board 127738-001 141011-001 7922, 30, 31, 34, 35,

40, 47, 50, 54, 70,

71, 73, 80, 85, 90,

94, 98

Ethernet Card, Homenet 116158-001 120788-001 7922, 47

Controller Boards Assembly Spare Part System

NIC, 10/100 122849-001 123494-001 7930, 31, 34, 50,

54, 71, 73, 80,

Audio Board 102392-002 113897-002 7930, 31, 34, 35,

40, 47, 50, 54,

70, 71, 73, 80,

85, 90, 94, 98

Graphics Boards Assembly Spare Part System

3DX, Voodoo3 3500 16 MB, TV-

out 147286-001 147908-001 7931, 34, 50, 54

Video Card, S3, 16 MB, 4X AGP 166134-002 166385-001 7935, 40, 47, 70,

73, 85, 90, 94,

Video Card, S4, 16 MB, DFP,

TV-out 128503-001 144307-001 7930

NVIDIA TNT2, 32 MB 122650-001 126724-001 7971, 80, 90

Hard Drives Assembly Spare Part System

10.0 GB, 5400 rpm 138224-001 168028-001 7930

13.0 GB, 5400 rpm 158740-001 168030-001 7930, 31, 34

17.0 GB, 5400 rpm 159945-001 168591-001 7954

20.0 GB, 5400 rpm 165133-001 168031-001 7950, 71, 90

20.0 GB, 7200 rpm 144369-001 157403-001 7954

30.0 GB, 5400 rpm 165134-001 168628-001 7922, 35, 40,

47, 73, 85

30.0 GB, 7200 rpm 167961-001 173343-001 7980

40.0 GB, 5400 rpm 171457-001 173342-001 7970, 90, 94, 98

CD-ROM Drive Assembly Spare Part System

DVD, 10X 155669-812 157784-001 7922, 30, 31, 34,

35, 40, 47, 50,

54, 70, 71, 73,

80, 85, 90, 94,

DVD, 40X, Stone 388770-806 134125-001 7994

RW 147290-001 120893-001 7922, 34, 35, 40,

47, 50, 54, 70,

71, 73, 80, 85,

90, 94, 98

Volume Two 3-121

Presario 7900

Diskette Drives Assembly Spare Part System

1.44 MB, Stone 388617-802 136436-001 7922, 30, 31,

34, 35, 40,

47, 50, 54,

70, 71, 73,

85, 90, 94, 98

Modems Assembly Spare Part System

V.90, PCI, DT/FA 146139-001 166386-001 7922, 35, 40,

47, 70, 73,

85, 94, 98

V.90, PCI, Lucent 155817-001 166358-002 7930, 31, 34,

50, 54, 71,

80, 90

V.90, DSL 152687-001 157041-001 7990

Cables Assembly Spare Part System

Telephone L/Line 112666-003 137256-001 7930, 31, 34,

35, 47, 50,

54, 70, 71,

73, 94

Audio, CD-ROM 387527-001 149806-001 7930, 31, 34,

35, 47, 50,

54, 70, 71,

73, 80, 90, 94

Cable Assembly, Dual

Connector, IDE, 18” 167344-001 171290-001 7922

Cable Assembly, Hard Drive

Data, uATA, 18” 108950-014 171289-001 7922

Cable Assembly, Data, Floppy 238078-003 327770-001 7922

Cable, Miscellaneous 122240-001 171291-001 7922

Modem Cables Assembly Spare Part System

Modem Cable, Ferrite, United

Kingdom 165227-033 161779-033 7970

Modem Cable/Linefilter -

Switzerland 334792-111 334815-111 7970

Modem Cable Adapter –

Belgium 234441-181 304398-181 7970

Modem Cable Adapter –

Denmark 234441-081 304398-081 7970

Modem Cable Adapter - France 234441-051 304398-051 7970

Modem Cable Adapter - Italy 234441-061 304398-061 7970

Modem Cable Adapter –

Netherlands 234441-331 304398-331 7970

Modem Cable w/ Adapter,

Norway 165227-091 304398-091 7970

Modem Cable Adapter –

Sweden 234441-101 304398-101 7970

Modem Cable Adapter –

Switzerland 234441-112 304398-112 7970

3-122 Volume Two

Presario 7900

Power Supply/Battery Assembly Spare Part System

Power Supply, 145 W 174048-001 127999-001 7922

Power Supply, 200 W 152769-001 153652-001 7930, 31, 34,

35, 40, 47,

50, 54, 70,

71, 73, 80,

85, 90, 94, 98

Power Supply Assembly, ATX,

200E 152769-002 180562-021 7930, 31, 34,

50, 54, 71,

80, 90

Volume Two 3-123

Presario 7900

Presario 7930, 31, 34, 35, 40, 47, 50, 54, 70, 71, 73, 80, 85, 90, 94

Memory Upgrade Chart

64-MB 100MHz SDRAM DIMM - OPTION PN 170895-B21

128-MB 100MHz SDRAM DIMM - OPTION PN 309037-B21

384-MB 100MHz SDRAM DIMM - OPTION PN 170896-B21

SYSTEM BOARD

165565-101

128 MB

3-124 Volume Two

Presario 7900

Presario 7922

Memory Upgrade Chart

32-MB 100MHz SDRAM DIMM- OPTION PN 308875-001

64-MB 100MHz SDRAM DIMM- OPTION PN 308877-001

128-MB 100MHz SDRAM DIMM- OPTION PN 308878-001

256-MB 100MHz SDRAM DIMM- OPTION PN 171558-B21

MAXIMUM MEMORY 512 MB

SYSTEM BOARD

164465-101

64 MB
