Quick Specs HP Compaq dx7380 Microtower Business PC

Overview

Dx7380 –Version 1.1 Page 1

HP Compaq dx7380 Microtower Business PC HP recommends Microsoft®

Windows® XP Professional

Microtower

1.Monitor (sold separately) 7.2 PCI 2.2 slots, 2 PCI-Ex1 slot ,1 PCI Ex16 slot

2.2-Button Scroll Mouse 8.6 USB 2.0 ports, 1 serial ports, 1 parallel port, 2 PS/2, 1 RJ-

45, 1 VGA, 1 audio in, 1 audio out, 1 MIC

3.HP Standard Keyboard 9.300-watt max power supply

4.Front I/O –2 USB 2.0 ports & MIC, Headset

10.

2 external 5.25" drive bays for optional optical drives

5.2 internal 3.5" drive bays 11

2 Optional USB ports and 1 Optional Serial port.

6.2 external 3.5" drive bays for optional diskette drive

Quick Specs HP Compaq dx7380 Microtower Business PC

Overview

Dx7380 –Version 1.1 Page 2

At A Glance

•Intel® Pentium D, Pentium 4,Intel Celeron D and Core 2 Duo processors

•Choice of operating systems:

Microsoft Windows XP Home

Microsoft Windows XP Professional

Free DOS for India.

•Red Flag /Redhat Linux

•Windows Vista Basic & Business 32 bit

•Windows VistaBasic & Business 64 bit

•Intel Q965/ICH8 chipset

•Intel Graphics Media Accelerator GMA 3000

•Total 4 PCI slots (2*PCI slot,1 PCIe x1, 1PCIe x 16)

•Integrated SATA II controllers with 6 SATA ports (2 SATA ports can be configured as RAID) , 1 PATA PORT.

•Integrated Broadcom 10/100/1000 Network Connection with WOL.

•Integrated 8 channel HD Audio.

•Choice of hard drives and optical drives

•HP Bizcover Diagnostics and Recovery Manager.

•Desktop management tool.

•Single or dual channel DDRII SDRAM system memory DDR667/DDR 800.

•Protected by HP Services. Terms and conditions vary by country. Certain restrictions & exclusions apply.

•System FCC,UL certified for India and UL, CCC certified for China.

Quick Specs HP Compaq dx7380 Microtower Business PC

Available Technology and Features

Dx7380 –Version 1.1 Page 3

Intel Celeron D Processors:

Intel Celeron D 331 Processor

(2.66-GHz, 256-KB L2 cache, 533-MHz FSB)

Intel Celeron D 336 Processor

(2.80-GHz, 256-KB L2 cache, 533-MHz FSB)

Intel Celeron D 347 Processor

(3.06-GHz, 512-KB L2 cache, 533-MHz FSB)

Intel Celeron D 352Processor

(3.20-GHz, 512-KB L2 cache, 533-MHz FSB)

Intel Celeron D 356 Processor

(3.33-GHz, 512KBL2 cache, 533-MHz FSB)

Intel Celeron D 360 Processor

(3.46-GHz, 512KBL2 cache, 533-MHz FSB)

Intel Celeron D 365 Processor

(3.60-GHz, 512KBL2 cache, 533-MHz FSB)

Intel Pentium 4 Processors with Hyper Threading

Intel Pentium 4 631 Processor

(3.06-GHz, 2-MB L2 cache, 800 -MHz FSB)

Intel Pentium 4 641 Processor

(3.20 -GHz, 2-MB L2 cache, 800-MHz FSB)

Intel Pentium 4 651 Processor

(3.402 -GHz, 21-MB L2 cache, 800-MHz FSB)

Intel Pentium 4 661 Processor

(3.6 -GHz, 2-MB L2 cache, 800-MHz FSB)

Intel Pentium DProcessors

Intel Pentium D915 Processor

(2.8 -GHz, 2x2MB L2 cache, 800-MHz FSB)

Intel Pentium D925 Processor

(3.0-GHz, 2x2MB L2 cache, 800-MHz FSB)

Intel Pentium D935 Processor

(3.20-GHz,2 x 2MB L2 cache, 800-MHz FSB)

Intel Pentium D 945 Processor

(3.40-GHz, 2x2MB L2 cache, 800-MHz FSB)

Intel Core 2 Duo Processor

Intel Core 2 Duo E6300 Processor

(1.86GHz, 2MB L2 Cache, 1066MHz)

Intel Core 2 Duo E6400 Processor

(2.13GHz, 2MB L2 Cache, 1066MHz)

Intel Core 2 Duo E6600 Processor

(2.40GHz, 4MB L2 Cache, 1066MHz)

Intel Core 2 Duo E6700 Processor

(2.66GHz, 4MB L2 Cache, 1066MHz)

Processor and Speed

One of the following

Intel Core 2 Duo E4300 Processor

(1.80GHz, 2MB L2 Cache, 800MHz)

Quick Specs HP Compaq dx7380 Microtower Business PC

Available Technology and Features

Dx7380 –Version 1.1 Page 4

Genuine Microsoft Windows XP Home SP2

Genuine Microsoft Windows XP Professional SP2

Free DOS

Windows Vista, Basic & Business 32/64Bit.

Windows Vista Capable –Not all Windows Vista features are available for use on all Windows Vista

Capable PCs. All Windows Vista Capable PCs will run the core experiences of Windows Vista, such as

innovations in organizing and finding information, security, and reliability. Some features available in

premium editions of Windows Vista -- like the new Windows Aero™ user interface -- require advanced

or additional hardware.

Check http://www.windowsvista.com/getready for details

NOTE: Microsoft Windows NT 4.0 and Microsoft Windows 2000 are not available on these systems.

Some drivers for Windows 2000 are available for download from http://www.hp.com.

Operating Systems and

Application Software

Microsoft Office 2003 Basic (availability varies by region)

Microsoft Office 2003 Small Business (availability varies by region)

Microsoft Office 2003 Professional (availability varies by region)

Microsoft Works 8.5 (availability varies by region)

Microsoft Office 2007

Symantec Antivirus.

HP Insight Diagnostics (on documentation CD)

Desktop Management Tool (availability varies by region) Tool for Health management, Asset

Management and Remote Management

SDM (Tool for pre failure Alert on HDD-Available with Windows XP currently).

80-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)

160-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)

250-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)

NOTE: The Serial ATA interfaces in the HP Compaq dx7380 Micro tower support data transfer rates up

to 3.0 Gb/s.

256-MB DDR II Synch DRAM PC 5300 (667-MHz) Non-ECC (1 x 256-MB)

256-MB DDR II Synch DRAM PC 5300 (800-MHz) Non-ECC (1 x 256-MB)

512-MB DDRII Synch DRAM PC5300 (667-MHz) Non-ECC (1 x 512-MB)

512-MB DDRII Synch DRAM PC5300 (800-MHz) Non-ECC (1 x 512-MB)

System Memory –

Single Channel

Configurations

1-GB DDR II Synch DRAM PC5300 (667-MHz) Non-ECC (1 x 1-GB)

1-GB DDR II Synch DRAM PC5300 (800-MHz) Non-ECC (1 x 1-GB)

512-MB DDRII Synch DRAM PC5300 (667-MHz) Non-ECC (2 x 256-MB)

512-MB DDR II Synch DRAM PC4200 (800-MHz) Non-ECC (2 x 256-MB)

1-GB DDRII Synch DRAM PC 5300 (667-MHz) Non-ECC (2 x 512-MB)

1-GB DDRII Synch DRAM PC 5300 (800-MHz) Non-ECC (2 x 512-MB)

System Memory –

Dual Channel

Configurations

2-GB DDR Synch DRAM PC5300 (667-MHz) Non-ECC (2 x 1-GB)

2-GB DDR Synch DRAM PC5300 (800-MHz) Non-ECC (2 x 1-GB)

Quick Specs HP Compaq dx7380 Microtower Business PC

Available Technology and Features

Dx7380 –Version 1.1 Page 5

2-GB DDR Synch DRAM PC5300 (667-MHz) Non-ECC (4 x 512MB)

2-GB DDR Synch DRAM PC5300 (800-MHz) Non-ECC (4 x 512MB)

4-GB DDR Synch DRAM PC5300 (667-MHz) Non-ECC (4 x 1 GB)

4-GB DDR Synch DRAM PC5300 (800-MHz) Non-ECC (4 x 1 GB)

NOTE: For best performance, memory speeds and sizes should not be mixed. See memory section for

more information.

Diskette Drive

1.44-MB Diskette Drive

Optical Drives (SATA)

52X CD-ROM drive (available in APJ only)

48X/32X/48X CD-RW drive

16X/48X DVD-ROM drive

48X/32X Combo CD-RW/DVD-ROM Drive

Storage Support

One or more of the

following (see Storage

section below)

16X DVD+/-RW

* For Vista OS only DVD/COMBO/DVDRW will be supported.

** PATA ODD not supported on this.

Keyboard –

One of the following HP PS/2 Standard Keyboard

HP USB Standard Keyboard

PS/2 2-Button Scroll Mouse

USB 2-Button Optical Scroll Mouse

PS2 –Optical Mouse

Mouse –

One of the following

USB 2-Button Scroll Mouse

8-channel High definition audio ( Realtek ALC 888)

Audio

Integrated Broadcom 10/100/1000 Network Connection (BCM 5787)

Communication Agere 56K PCI Modem

Graphics On board Intel Graphics Media Accelerator GMA 3000

Quick Specs HP Compaq dx7380 Microtower Business PC

System Details

Dx7380 –Version 1.1 Page 6

Base Unit •Micro ATX Microtower chassis, including power supply and front bezel

•Six (6) drive bays and three expansion slots

•Microsoft operating system CD

•System board with Intel Q965 chipset, integrated Broadcom 10/100/1000 Network Connection,

integrated graphics and audio, 2 PCI slots, 1 PCIEx16 ,1 PCI Express x1 slot, 4DDR II DIMM

memory slots

•2Serial ATA data cable (one for connecting HDD/one for connecting SATA ODD)

•System fan /cooler

•Product documentation on CD

•HP system restore CD

•Power cord

•Chassis intrusion alert

•Recovery Cable.

•300W PSU.

PCI Two (2) PCI 2.2slots on PCA

One (1) PCI Express x1 slot on PCA

One (1) PCI Express x16 slot on PCA

Slots

Memory Expansion Four (4) DIMM slots (4GB maximum memory support)

Internal Two (2) 3.50" internal

Bays External Two (2) 5.25" external

Two (2) 3.50" external

High-speed USB 2.0 controller

USB Support Total : 10 Numbers,Two (2) front ports; Six (6) rear ports: Two (2) Optional .

One (1) parallel port

One (1) serial port , One optional second serial port

One (1) PS/2 keyboard port

One (1) PS/2 mouse port

One (1) analog VGA video port

One (1) line in; one (1) line out; one (1) mic in

Interfaces (Legacy)

One (1) RJ45 network port

Front Audio

One (1) Speaker

One (1) MIC

Châssis Dimensions

(H x W x D) 14.37 x 7.08 x 15.15 in

(36.5 x 18.0 x 38.50 cm)

Packaged Dimensions

(L x W x H) 23.2 x 19.6 x 10.9 in

(58.9 x 49.9 x 27.8 cm)

System Weight ~ 12.0 kg ( depend on configuration)

Weight & Dimensions

Shipping Weight ~ 13.50 kg ( depend on configuration)

Quick Specs HP Compaq dx7380 Microtower Business PC

System Details

Dx7380 –Version 1.1 Page 7

Coprocessor Integrated

CPU Socket

Type/Number Socket T

LGA775 socket

CPU Package LGA775

Front Side Bus Speed 533/800/1066 -MHz

Intel Pentium 4

Processor

Cache Memory 2MB L2 Cache.

Coprocessor Integrated

CPU Socket

Type/Number Socket T

LGA775 socket

CPU Package LGA 775

Front Side Bus Speed 533-MHz

Intel Celeron D

Processor

Cache Memory 256-KB /512 KB L2 Advanced Transfer Cache

Coprocessor Integrated

CPU Socket

Type/Number Socket T

LGA775 socket

CPU Package LGA775

Front Side Bus Speed 800/1066 -MHz

Intel Core 2 Duo

Processor

Cache Memory 2 MB /4 MB L2 Cache

Coprocessor Integrated

CPU Socket

Type/Number Socket T

LGA775 socket

CPU Package LGA775

Front Side Bus Speed 533/800 -MHz

Intel Pentium D

Processor

Cache Memory 2x 2MB Advanced Transfer –depend on CPU

Front Panel •Power button

•Power On LED

•HDD Activity LED

•Biz Cover Switch

Cooling Solutions

Supported •Power Supply Fan

•Active heat sink fan (variable speed)

•System fan (variable speed)

Slots Supported Four (4) PCI & PCIe expansion slots

Front I/O Two (2) USB 2.0 ports

Two (2) Front Audio ports (1 Headphone, 1 MIC)

Quick Specs HP Compaq dx7380 Microtower Business PC

System Details

Dx7380 –Version 1.1 Page 8

Rear I/O Standard Micro ATX I/O connectors, including four (6) USB 2.0 ports

Drive Bays •Two (2) 5-1/4" external

•Two (2) 3-1/2" external

•Two (2) 3-1/2" internal

Power Supply 300-watt ATX Power Supply –non-PFC (for India)

300W ATXP –PFC (for China)

General Unit Operating Guidelines

Unit Environment and

Operating Conditions •Keep the computer away from excessive moisture, direct moisture and the extremes of heat and

cold, to ensure that unit is operated within the specified operating range.

•Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required

airflow.

•Never restrict airflow into the computer by blocking any vents or air intakes.

•Do not stack computers on top of each other or place computers so near each other that they are

subject to each other's re-circulated or preheated air.

•Occasionally clean the air vents on the front, back, and any other vented side of the computer.

Lint, dust and other foreign matter can block the vents and limit the airflow.

•If the computer is to be operated within a separate enclosure, intake and exhaust ventilation

must be provided on the enclosure, and the same operating guidelines listed above will still

apply.

Temperature Range Operating Temperature: (5°C to 45 ° C)

Non-operating Temperature: (-30° to 60° C)

Relative Humidity Operating Humidity: 10% to 90% (non-condensing at ambient)

Non-operating Humidity: 5% to 90% (non-condensing at ambient)

NOTE: Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea

level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be

limited by the type and number of options installed.

Socket LGA775 industry standard Micro ATX form factor

Processor •Socket T; LGA775

•Support single Intel Pentium 4, Celeron D, Pentium D or Core 2

Duo.

Chipset •Intel Q965

•Intel ICH8

Super I/O •ITE IT8718

Front Side Bus Frequency •533/800/1066-MHz

System Board

Memory •DDR2 x4 DDR800/667 max 4GB

•4x DIMM slots

•Support for single or dual-channel configurations

Quick Specs HP Compaq dx7380 Microtower Business PC

System Details

Dx7380 –Version 1.1 Page 9

Clock Generator •Realtek RMT876-660

Integrated Graphics •Intel Graphics Media Accelerator (GMA) 3000

Audio •Realtek ALC888 High definition audio

LAN •Integrated Broadcom 10/100/1000 ( BCM5787 ) network

controller

IDE •Support all PIO modes

•1 x IDE ports support up to 2 devices

•Support Ultra ATA 33/66/100

•No PATA Drive is validated for this.

SATA/RAID •Six Serial ATA interfaces support data transfer rates up to 3.0 Gb/s

•Port 4 &5 can be configured for RAID 0 and RAID 1 configuration.

Expansion Slots •2 x PCI 2.2slots

•1 x PCI Express x1 slot

•1 x PCI Express x 16 slot

BIOS •8Mbit flash EEPROM

Manageability •WfM 2.0, SMBus,, WOL , DMI 2.0 , PXE support

Industrial Standard •PCI 2.2compliant

•USB 2.0

Rear Side I/O Ports •1 x PS/2 keyboard port

•1 x PS/2 mouse port

•6x USB 2.0 ports

•1 x RJ-45 10/100/1000 port

•1 x serial port ( second serial port optional)

•1x parallel port

•1 x DB 15 pin analog VGA port

•3 x audio ports

On Board I/O Interfaces •1 x ATX power connector

•1 x +12V power connector

•1 x Floppy connector

•1 x Front panel connector, Switch, LED (ON/Flash/OFF)

•2 x Fan headers for CPU, chassis, with voltage/fan speed control

•1 x header to support 2 USB 2.0 ports at front side

•1 x Second Serial Port header

•Biz Cover Recovery Switch Cable

•1 x header to support 2 USB 2.0 ports for USB internal USB

interface devices.

•1 x PATA to support 2 IDE ports.

Quick Specs HP Compaq dx7380 Microtower Business PC

System Details

Dx7380 –Version 1.1 Page 10

•1 x Audio port to support front Audio.

Board Size •Micro-ATX,

Additional Features •Support S3, S4 and S5

•ACPI status

•Hardware monitor capability

•CPU fan speed control

•Wake on LAN

Integrated Broadcom Gigabyte Ethernet Controller BCM5787

Hardware Highlights

/Features •Integrated 10/100/1000BASE-T Transceiver.

•Automatic MDI crossover function

•PCIe v1.1 compliant.

•10/100/1000BASE-T full-duplex/half-duplex MAC

•Wake on LAN (WOL) support meeting the ACPI requirements.

•Statistics for SNMP MIB II, Ethernet like MIB and Ethernet MIB

(IEEE 802.3z,Clause 30)

•JTAG support

•Hot plug support

•PCI Express #CLKREQ support.

•Energy Detect/Cable Sense.

Power Supply •ATX Power Supply - non-PFC (for India) –PFC (for China).

•220 to 230VAC input voltage range

•50-60 Hz rated line frequency

•300 watt maximum power

•power supply fan

•Over Voltage Protection

•Over Current Protection

•Short Circuit Protection

•FCC ,UL ,approved for India.

•FCC,UL and CCC approved for China.

Power Conservation

‘Energy Saver‘ •Screen blanking

•Hard drive 'Idle' mode

•System Idle mode

•Processor/Cache memory power-down (S3)

System Environmental

Specs •Values are subject to change without notification and are for reference only.

•Performance of system, options, and ancillary equipment will vary depending on the system

configuration.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere HP Desktop Handbücher

HP Elite 7500 Microtower Handbuch

HP Compaq dc7800 Small Form Factor Business Montageanleitung

HP Pavilion t400 - Desktop PC Bedienungsanleitung

HP Model 745 - VME Workstation Referenzhandbuch

HP Workstation xw4100 Handbuch

HP Evo D510 e-pc Produkthandbuch

HP Net PC 20 Handbuch

HP s3700f - Pavilion - Slimline Montageanleitung

HP Pavilion d4000 - Desktop PC Handbuch

HP Xw9400 - Workstation - 16 GB RAM Referenzhandbuch

HP Media Center m400 - Desktop PC Technisches Datenblatt

HP Pavilion v600 - Desktop PC Bedienungsanleitung

HP Compaq Pro 6305 Handbuch

HP Xw4400 - Workstation - 2 GB RAM Gebrauchsanweisung

HP Pavilion g3700 - Desktop PC Anleitung zur Verwendung

HP dx2480 - Microtower PC Gebrauchsanweisung

HP Compaq Presario Technisches Datenblatt

HP Pavilion w1100 - Desktop PC Bedienungsanleitung

HP Pavilion Slimline s3401f Technisches Datenblatt

HP D7171A - NetServer - LPr Bedienungsanleitung

HP Pavilion t300 - Desktop PC Montageanleitung

HP Compaq d330 ST Bedienungsanleitung

HP TouchSmart 600-1000 - Desktop PC Bedienungsanleitung

HP Vectra VL400 Bedienungsanleitung

Beliebte Desktop Handbücher anderer Marken

Asus

Asus E210 Series Bedienungsanleitung

Dell

Dell Inspiron 600m Bedienungsanleitung

Dell

Dell Inspiron 3662 Bedienungsanleitung

TotalFlow

TotalFlow uFLO Bedienungsanleitung

Logitech

Logitech MK320 Bedienungsanleitung

Dell

Dell XPS 730 H2C Bedienungsanleitung

Sony

Sony Vaio Series Bedienungsanleitung

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Bedienungsanleitung

Alto

Alto MD 250 Bedienungsanleitung

Lenovo

Lenovo ThinkCentre Edge 72 Handbuch

Lenovo

Lenovo ThinkStation D20 Handbuch

Arbor Technology

Arbor Technology FPC-7800 Series Bedienungsanleitung

Sony

Sony VAIO VGX-TP1 Series Bedienungsanleitung

Asus

Asus Eee Box B204 Bedienungsanleitung

Dell

Dell Optiplex 9010 All In One Bedienungsanleitung

Everex

Everex eXplora Bedienungsanleitung

Lenovo

Lenovo ThinkCentre M75e Bedienungsanleitung

Dell

Dell Alienware Area-51 R4 Bedienungsanleitung

HP dx7380 - Microtower PC Gebrauchsanweisung

Beliebte Desktop Handbücher anderer Marken
