HP TOUCHSMART 9100 Gebrauchsanweisung
1.
Touch-enabled 23-inch diagonal widescreen BrightView LCD
with tilt adjustment
9.
Volume buttons
2.
Bluetooth module (optional)
10.
Mute button
3.
Dual wireless antennas
11.
HP TouchSmart button
4.
Dual microphone array
12.
Memory card reader
5.
Webcam
13.
IR Receiver and LED (select models only)
6.
Power button and LED
14.
High-performance 2.0 speakers
7.
Slot-load optical drive (optional)
15.
HP low-profile keyboard with numeric keypad
8.
Drive activity LED
16.
HP optical mouse
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Overview
DA - 13434 North America — Version 8 — December 12, 2011
Page 1
1.
DVI-D video out
10.
IR Emitter (Blaster) output (optional)
2.
IEEE 1394 port
11.
(2) USB ports
3.
(3) USB ports
12.
Line in
4.
RJ-45 Gigabit Ethernet port
13.
Headphone jack
5.
Digital audio out (SPDIF)
14.
Optional wireless keyboard/mouse receiver
6.
Audio line out
15.
Kensington Lock slot
7.
TV coax in (optional)
16.
Power connector
8.
S-video input (optional)
17.
Adjustable tilt stand
9.
Stereo audio in (optional)
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Overview
DA - 13434 North America — Version 8 — December 12, 2011
Page 2
At A Glance
Genuine Windows 7 Professional Edition
Touch-enabled 23-inch diagonal widescreen BrightView LCD with glass covering
Integrated all-in-one form factor
Intel® Core™ 2 Duo processor, NVIDIA MCP7A-J chipset, and NVIDIA integrated or discrete graphics
Integrated Gigabit Network Connection (10/100/1000 NIC)
Wireless connectivity:
Integrated 802.11 b/g/n draft 2.0 wireless LAN module
Bluetooth® 2.1
Integrated webcam, dual microphone array, and premium stereo speakers
Optional TV Tuner
Up to 8 GB of DDR3 SDRAM supported, dual channel memory support
Up to 500 GB hard drive, or 64 GB Solid State Drive
Slot-load Blu-ray Combo Drive (Blu-ray Reader/DVD Burner) or SuperMulti DVD Burner
6-in-1 Media Card Reader
HP TouchSmart software suite for instant access to calendar, internet, notes, and multimedia content
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Overview
DA - 13434 North America — Version 8 — December 12, 2011
Page 3
Processors
Intel Core 2 Duo Processor P7570 (2.26 GHz, 3 MB L2 cache, 1066 MHz FSB)*
Intel Core 2 Duo Processor T6570 (2.10 GHz, 2 MB L2 cache, 800 MHz FSB)*
* Intel's numbering is not a measurement of higher performance.
Operating System
Preinstalled
Genuine Windows 7 Professional Edition 64*
Genuine Windows 7 Professional Edition 32*
* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality.
See
http://www.microsoft.com/windows/windows-7/
for details.
Chipset
NVIDIA MCP7A-J chipset
Graphics
Integrated NVIDIA GeForce G200
or
Discrete NVIDIA GeForce GT230, 1 GB
Display
Touch-enabled 23-inch diagonal widescreen BrightView LCD with glass covering,
tilt adjustment between 10º and 40º from vertical
Resolution
1920 x 1080 resolution (16:9)
Contrast ratio
1000:1
Image brightness
300 nits typical
Vertical viewing angle
160 degrees
Horizontal viewing angle
160 degrees
Memory
Standard
PC3-10600 DDR3 non-ECC SDRAM (runs at 1333 MHz)
Two 200-pin SODIMM slots supporting dual channel memory
2 GB (1 GB x 2)
4 GB (2GB x 2)
8 GB (4GB x 2)
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.
NOTE:
Full availability of 4 GB or more of memory requires a 64-bit operating system. With Windows 32-
bit operating systems, the amount of usable memory is dependent upon your configuration, so that above
3 GB all memory may not be available due to system resource requirements.
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Standard Features
DA - 13434 North America — Version 8 — December 12, 2011
Page 4
Communications
Realtek 8111DL Ethernet Connection
Integrated 10/100/1000 NIC*
802.11 PCIe Mini Wireless Module
Support for 802.11 b, g, and n
Up to 300 mbps data rate
Built-in dual antennas
Bluetooth Wireless Technology (optional)
Bluetooth Specification v2.1 compliant
Works with a wide range of Bluetooth devices
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
Keyboard
Standard HP USB
Keyboard
104 keys plus special keys for Mute, Volume Up, Volume Down. Separate
numeric keypad.
Cable length 51 in (130 cm)
Optional HP Wireless
Keyboard
104 keys plus special keys for Mute, Volume Up, Volume Down
Separate numeric keypad.
Operates at ~ 2.4 GHz and supports a working distance of up to 32 ft (10 m).
Pointing Device
Standard HP USB Optical
Scroll Mouse
Two buttons with scroll wheel acting as third button.
Cable length 69 in (175 cm)
Optional HP Wireless
Optical Scroll Mouse
Two buttons with scroll wheel acting as third button.
Operates at ~ 2.4 GHz and supports a working distance of up to 32 ft (10m).
Storage
Hard Drive
3.5-inch, 7200 rpm, 3.0 Gb/s SATA Hard Drive:
250 GB
500 GB
or 3.5-inch SATA Solid State Drive:
64 GB
Optical Drive
Slot-load Blu-ray Combo Drive
Read: 4x max BD-ROM, 8x max DVD-ROM, 24x max CD-ROM
Write: 8x max DVD±R, 4x max DVD±R DL, 4x max DVD±RW,
5x max DVD-RAM, 16x max CD-R, 10x max CD-RW
Slot-load SuperMulti DVD Burner
Read: 8x max DVD-ROM, 24x max CD-ROM
Write: 8x max DVD±R, 6x max DVD±R DL, 8x max DVD+RW,
6x max DVD-RW, 5x max DVD-RAM, 24x max CD-R,
24x max CD-RW
Option for no optical drive
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Standard Features
DA - 13434 North America — Version 8 — December 12, 2011
Page 5
Interfaces
6-in-1 Media Card Reader
Supports Secure Digital (SD, SDHC), MultiMediaCard,
Picture Card, Memory Stick, Memory Stick Pro
DVI-D Video out
One
IEEE 1394 port
One
USB 2.0
Five (2 front, 3 rear)
Line in
One
Audio headphone jack
One
Audio line out
One
Audio digital out (SPDIF)
One
Power connector
One
RJ-45/Ethernet
One
IR Emitter (Blaster) out
One (with TV tuner option only)
S-Video in
One (with TV tuner option only)
Stereo audio in
One (with TV tuner option only)
TV Coax connector
One (with TV tuner option only)
Audio/Visual
High Definition Audio support
Integrated high-performance 2.0 speakers
Integrated dual-microphone array
Volume control and mute buttons
Stereo headphone jack
Stereo line in
Stereo line out
Audio digital out (SPDIF)
Integrated VGA webcam
Up to 30 frames/sec
640x480 resolution
Designed for low light conditions
Optional TV Entertainment Experience (configurable)
Hybrid ATSC/NTSC, Clear QAM, Over the Air TV Tuner, HW encoded
Hybrid PAL/DVB-T, Over the Air TV Tuner, HW encoded
Hybrid PAL/DMB-T, Over the Air TV Tuner, HW encoded, Hong Kong/China
Dual channel ISDB-T/ISDB-S, Over the Air TV Tuner, HW encoded, Japan
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Standard Features
DA - 13434 North America — Version 8 — December 12, 2011
Page 6
Software
Preinstalled software
(varies by country)
HP Power Manager
HP TouchSmart Browser
HP TouchSmart Calendar
HP TouchSmart Canvas
HP TouchSmart Clock
HP TouchSmart DVD
HP TouchSmart Hulu
HP TouchSmart Live TV
HP TouchSmart Music
HP TouchSmart Video
HP Touch Smart Photo
HP TouchSmart Netflix
HP TouchSmart RSS Reader
HP TouchSmart Twitter
HP TouchSmart Weather
HP TouchSmart Webcam
HP Total Care Advisor
PDF Complete
McAfee Total Protection*
Microsoft Office Ready with 60-day Office Professional 2007 Trial Edition
* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to
receive updates. First update included. Subscription required for updates thereafter.
HP Power Manager
Provides real-time reporting of how system settings impact the energy consumed by the PC and the
potential savings over time.
SMBIOS
System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
Security
Kensington lock
Power Supply
Integrated graphics: external 120-watt power supply, 87% efficiency, active PFC
Discrete graphics: external 150-watt power supply, 87% efficiency, active PFC
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Standard Features
DA - 13434 North America — Version 8 — December 12, 2011
Page 7
Service and Support
On-site Warranty
Note 1:
One-year (1-1-1) limited warranty delivers one year of on-site, next business-
day
Note 2
service for parts and labor and includes free telephone support
Note 3
24 x 7. Global coverage
Note
2
ensures that any product purchased in one country and transferred to another non-restricted country will
remain fully covered under the original warranty and service offering. One-year onsite and labor are not
available in all countries. To choose the right level of service for your HP product, use the HP Care Pack
Services Lookup Tool at:
http://www.hp.com/go/lookuptool
. Additional HP Care Pack Services information
by product is available at:
http://www.hp.com/hps/carepack
.
NOTE 1
: Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other
warranty variations may be offered in your region.
NOTE 2:
On-site service may be provided pursuant to a service contract between HP and an authorized HP
third-party provider, and is not available in certain countries. Global service response times are based on
commercially reasonable best effort and may vary by country.
NOTE 3:
Technical telephone support applies only to HP-configured Compaq and third-party HP-qualified
hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Standard Features
DA - 13434 North America — Version 8 — December 12, 2011
Page 8
Memory
HP 1GB DDR3-1333 (PC3-10600) SODIMM
VH639AA
HP 2GB DDR3-1333 (PC3-10600) SODIMM
VH640AA
HP 4GB DDR3-1333 (PC3-10600) SODIMM
VH641AA
Graphics
HP DisplayPort To DVI-D Adapter
FH973AA
HP DisplayPort To VGA Adapter
AS615AA
HP DisplayPort Cable Kit
VN567AA
HP DisplayPort To HDMI Adapter
BP937AA
HP DisplayPort to Dual Link DVI Adapter
NR078AA
HP USB Graphics Adapter
NL571AA
Internal Storage
HP 250-GB SATA 3.0-Gb/s Hard Drive
PY278AA
HP 500-GB SATA 3.0-Gb/s Hard Drive
KW347AA
HP 1-TB SATA 3.0-Gb/s Hard Drive
VU353AA
HP 500GB SATA 6.0Gb/s Hard Drive
QK554AA
HP 1TB SATA 6.0Gb/s Hard Drive
QK555AA
64 GB Solid State Drive
VG679AA
Input Devices
HP USB 2-Button Optical Scroll Mouse
DC172B
HP USB 2-Button Laser Scroll Mouse
GW405AA
HP Mouse Pad
AT485AA
HP USB PS/2 Washable Scroll Mouse
BM866AA
HP USB Standard Keyboard
DT528A#ABA
HP USB Standard Keyboard with USB Ports
BT330AA#ABA
HP USB CCID Smartcard Keyboard
BV813AA#ABA
HP 2.4GHz Wireless Keyboard & Mouse
NB896AA#ABA
HP USB Mini Keyboard
AS601AA#ABA
HP USB PS2 Washable Keyboard
VF097AA#ABA
HP USB PS2 Washable Keyboard & Mouse
BU207AA#ABA
HP Slim Line 2.4GHz Wireless Keyboard & Mouse
BL549AA#ABA
Multimedia
HP Thin USB Powered Speakers
KK912AA
Security
Kensington Security Lock
PC766A
HP Keyed Cable Lock
BV411AA
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Options
DA - 13434 North America — Version 8 — December 12, 2011
Page 9
Miscellaneous
Belkin Promo 7-Outlet Surge Protector
AG290AA#ABA
Belkin Network Cable
AH122AA
Belkin Firewire (1394) Cable
AH123AA
Belkin Starter Kit: Surge Protector, Patch Cable, Printer Cable
RT174AA
Belkin USB to Serial Adapter
EM449AA
Vesa Wall Mount Adapter
VK554AA
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Options
DA - 13434 North America — Version 8 — December 12, 2011
Page 10
Andere Handbücher für TOUCHSMART 9100
4
Inhaltsverzeichnis
Andere HP Desktop Handbücher
HP
HP T200 Handbuch
HP
HP Pavilion v600 - Desktop PC Bedienungsanleitung
HP
HP Compaq Presario Handbuch
HP
HP ENVY 20-d000 Bedienungsanleitung
HP
HP Kayak XW U3-W3 Handbuch
HP
HP Workstation xw4000 Series Bedienungs- und Wartungshandbuch
HP
HP Compaq Evo d500 SFF Bedienungsanleitung
HP
HP Vectra VL6 8 Bedienungsanleitung
HP
HP Compaq Presario Handbuch
HP
HP Presario SR5100 - Desktop PC Technisches Datenblatt
HP
HP A320m - Pavilion - 256 MB RAM Montageanleitung
HP
HP s3020n - Pavilion - Slimline Gebrauchs- und Wartungshandbuch
HP
HP Pavilion g3500 - Desktop PC Anleitung zur Verwendung
HP
HP A1224n - Pavilion - 1 GB RAM Bedienungsanleitung
HP
HP 4000 - SureStore DLT 40e Tape Drive Betriebsanleitung
HP
HP 742n - Pavilion - 512 MB RAM Technisches Handbuch
HP
HP Compaq 100EU SFF PC Gebrauchsanweisung
HP
HP 300-1020 - TouchSmart - Desktop PC Leitfaden
HP
HP TouchSmart 310-1000 - Desktop PC Anleitung zur Verwendung
HP
HP ENVY Rove 20-k000 Bedienungsanleitung
