Installing SATA Drivers on HP Compaq Notebook PCs

Introduction......................................................................................................................................... 2

Purpose .......................................................................................................................................... 2

Audience ........................................................................................................................................ 2

Benefits of SATA .............................................................................................................................. 2

System Requirements and Prerequisites................................................................................................... 2

System requirements......................................................................................................................... 2

System prerequisites ......................................................................................................................... 2

Transitioning a Sysprep image from IDE to SATA..................................................................................... 3

Where these guidelines are applicable............................................................................................... 3

Steps to add SATA support to the original image................................................................................. 3

Adding SATA drivers to RIS Installation Points ......................................................................................... 4

Where these guidelines are applicable............................................................................................... 4

Steps to add SATA drivers to the distribution point ............................................................................... 5

Adding SATA Drivers to an Installation CD ............................................................................................. 6

Where these guidelines are applicable............................................................................................... 6

Steps to add SATA drivers to the CD .................................................................................................. 6

Using OSCDIMG (or CDIMAGE) and CDBURN (command line utilities from Microsoft) ............................ 8

Adding SATA Drivers to WinPE 2005.................................................................................................... 8

Where these guidelines are applicable............................................................................................... 8

Steps to add SATA drivers to WinPE 2005 ......................................................................................... 8

Modifying a Windows XP installation to support SATA Native Mode......................................................... 9

Where these guidelines are applicable............................................................................................... 9

Steps to modify a Windows XP image to support SATA Native Mode .................................................. 10

For more information.......................................................................................................................... 12

Introduction

Purpose

This white paper provides instructions on how to successfully incorporate SATA drivers into a

Windows XP installation on HP Compaq Notebook PC models. The following guidelines provide

procedures for adding SATA drivers to RIS installation points; adding SATA drivers to installation

CDs; building an image and switching to SATA AHCI mode; using Sysprep with SATA in AHCI or

NATIVE mode; and adding SATA drivers using WinPE.

Audience

This white paper is for use by HP personnel and customers.

Benefits of SATA

SATA Native Mode is a storage interface technology that provides up to 150MB/Sec transfer rate for

disk traffic, and provides link power management with Intel® Application Accelerator drivers. Intel

Matrix Storage Manager Driver provides support for the SATA Advanced Host Controller (AHCI)

Interface.

System Requirements and Prerequisites

System requirements

Information regarding minimum hardware requirements for installing XP Professional is available at

www.microsoft.com.

The following are the supported models for the subject of this white paper:

HP Compaq 6310, 6320 and 6330 Notebook PC models

HP Compaq 9420 and 9440 Notebook PC models

HP Compaq 6400 Notebook PC models

HP Compaq 7400 Notebook PC models

HP Compaq 4400 Notebook PC models

HP Compaq 8400 Notebook PC models

System prerequisites

You will need the following items before installing SATA drivers:

•Microsoft Windows XP Professional Service Pack 2, Certificate of Authenticity and documentation.

•Necessary drivers, especially Intel SATA AHCI Controller Driver (SP32478).

•Proper OS License for each PC

•1.44 MB Floppy Disk and USB floppy drive. For a list of USB floppy drives supported during

Windows XP installation, please see Microsoft knowledge base article 916196.

oThe floppy disk is normally required by the Intel SATA ACHI Controller Driver softpaq

to create an installation disk.

oThe softpaq creates a WinImage self-extractor file that is written to

C:\swsetup\SP32478. Some third-party utilities can extract the drivers from this file

without requiring a floppy drive.

IMPORTANT:

Make sure you have the latest compatible version of Microsoft Windows XP

drivers and enhancements. In addition, you must have a Microsoft OS

license for each system on which you install Windows XP Professional.

Note:

You can also download HP drivers and utilities, including the most current

available ROM for the platform, from the HP website www.hp.com.

Transitioning a Sysprep image from IDE to SATA

Where these guidelines are applicable

IMPORTANT:

Follow the installation instructions in the order provided. Failure to

complete these steps in the proper order can result in an unsuccessful or

unstable installation.

This section provides guidelines for customers who need to add SATA support to a sysprep image.

Sysprep images with no SATA support will display a blue screen and reboot very quickly in an infinite

loop. Adding SATA drivers to the image will allow XP to access the disk and finish booting.

Note:

PCI IDs for current HP desktop and workstation Intel SATA controllers are

included in step 5. Although this whitepaper is intended to cover HP

Compaq Notebook PCs, this section should also be applicable to HP

Compaq desktop and workstation PCs.

Steps to add SATA support to the original image

1) Download the Intel SATA AHCI Controller Driver, SoftPaq SP32478.exe, from www.hp.com.

2) Extract all the files from the SoftPaq. A USB floppy is necessary for this step. Run sp32478;

this will create a floppy disk. The files will be located on this floppy.

3) These files should be located on the floppy disk.

a. iaahci.cat

b. iaahci.inf

c. iastor.cat

d. iastor.inf

e. iastor.sys

f. license.txt

g. readme.txt

h. txtsetup.oem

4) On the system you intend to Sysprep, add the first 5 files (a through e, from above)

to the PnP drivers store (example: c:\drivers\sata).

5) Add the following section to your c:\sysprep\sysprep.inf file:

[SysprepMassStorage]

PCI\VEN_8086&DEV_27C1&CC_0106 = %systemdrive%\drivers\sata\iaahci.inf ; Intel(R)

82801GR/GH SATA AHCI Controller (Desktop ICH7R/DH)

PCI\VEN_8086&DEV_27C5&CC_0106 = %systemdrive%\drivers\sata\iaahci.inf ; Intel(R)

82801GBM SATA AHCI Controller (Mobile ICH7M)

PCI\VEN_8086&DEV_2652&CC_0106 = %systemdrive%\drivers\sata\iaahci.inf ; Intel(R)

82801FR SATA AHCI Controller (Desktop ICH6R)

PCI\VEN_8086&DEV_2653&CC_0106 = %systemdrive%\drivers\sata\iaahci.inf ; Intel(R)

82801FBM SATA AHCI Controller (Mobile ICH6M)

PCI\VEN_8086&DEV_27C3&CC_0104 = %systemdrive%\drivers\sata\iastor.inf ; Intel(R)

82801GR/GH SATA RAID Controller (Desktop ICH7R/DH)

PCI\VEN_8086&DEV_24DF&CC_0104 = %systemdrive%\drivers\sata\iastor.inf ; Intel(R)

82801ER SATA RAID Controller (Desktop ICH5R)

PCI\VEN_8086&DEV_25B0&CC_0104 = %systemdrive%\drivers\sata\iastor.inf ; Intel(R)

6300ESB SATA RAID Controller

PCI\VEN_8086&DEV_2652&CC_0104 = %systemdrive%\drivers\sata\iastor.inf ; Intel(R)

82801FR SATA RAID Controller (Desktop ICH6R)

Please note that each line to be added starts with PCI\. These lines are continued over

to a second row in this paper due to space limitations.

6) Add or edit the following section of sysprep.inf to add the SATA drivers to the PnP

drivers path.

[Unattended]

OemSkipEula=Yes

OemPnPDriversPath=drivers\sata;<your driver list will come

here>

ConfirmHardware=No

OverwriteOemFilesOnupgrade=No

DriverSigningPolicy = Ignore

oempreinstall=yes

updateInstalledDrivers=Yes

7) At this point, the Windows installation is ready for deployment. Run Sysprep on the updated

OS, capture an image, and deploy the image to systems using SATA hardware set to the

default AHCI SATA Native mode.

Adding SATA drivers to RIS Installation Points

Where these guidelines are applicable

IMPORTANT:

Follow the installation instructions in the order provided. Failure to

complete these steps in the proper order can result in an unsuccessful or

unstable installation.

This section provides guidelines for customers who need to add SATA support to a Remote Installation

Service distribution point.

Steps to add SATA drivers to the distribution point

1) Download the Intel SATA AHCI Controller Driver, SoftPaq SP32478.exe, from www.hp.com.

2) Extract all the files from the SoftPaq. A USB floppy is necessary for this step. Run sp32478;

this will create a floppy disk. The files will be located on this floppy.

3) These files should be located on the floppy disk.

a. iaahci.cat

b. iaahci.inf

c. iastor.cat

d. iastor.inf

e. iastor.sys

f. license.txt

g. readme.txt

h. txtsetup.oem

4) Copy all the files above to the following path on the distribution point (on the RIS server):

RemoteInstall\Setup\<Language>\Images\<Dir_name>\i386

5) Also copy the same files (from step 3, above) to

RemoteInstall\Setup\<Language>\Images\<Dir_name>\$oem$\$1\drivers\s

ata

6) Open RemoteInstall\Setup\<Language>\Images\<Dir_name>\i386

\txtsetup.sif in Notepad.

7) Go to the end of the file. There will be several blank lines.

8) Move the cursor up a few lines. This is necessary because there is a hidden marker at the end

of the file.

9) Add the following lines to the txtsetup.sif file:

[SourceDisksFiles]

iastor.sys= 1,,,,,,4_,4,1,,,1,4

iaAHCI.cat=1,,,,,,,20,0,0

iaAHCI.inf=1,,,,,,,20,0,0

iaSTOR.cat=1,,,,,,,20,0,0

iaSTOR.inf=1,,,,,,,20,0,0

[HardwareIdsDatabase]

PCI\VEN_8086&DEV_27C5&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_27C3&CC_0104 = "iaStor"

PCI\VEN_8086&DEV_27C1&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_2652&CC_0104 = "iaStor"

PCI\VEN_8086&DEV_2652&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_2653&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_24DF&CC_0104 = "iaStor"

PCI\VEN_8086&DEV_25B0&CC_0104 = "iaStor"

[SCSI.Load]

iaStor = iaStor.sys,4

[SCSI]

iaStor = "Intel(R) 82801 SATA RAID/AHCI Controller

(ICH5,6,7)"

10) Save the file and exit notepad.

11) Open any other .sif file(s) in the path:

RemoteInstall\Setup\<Language>\Images\<Dir_name>\i386\xxxx.sif with

notepad

12) In these files, under the section [Unattended], add the following lines:

OemPreinstall=yes

OemPnPDriversPath=drivers\sata

DriverSigningPolicy = Ignore

13) Save all your edited .sif file(s), and close notepad

14) Restart the Remote Installation Service (binlsvc).

Adding SATA Drivers to an Installation CD

Where these guidelines are applicable

IMPORTANT:

Follow the installation instructions in the order provided. Failure to

complete these steps in the proper order can result in an unsuccessful or

unstable installation.

This section provides guidelines for customers who need to add SATA support by creating a custom

Windows XP Service Pack 2 Installation CD.

Steps to add SATA drivers to the CD

1) Copy all the directories and files from the Windows XP CD to a temporary folder (these

guidelines will use c:\xpcd)

2) Download the Intel SATA AHCI Controller Driver, SoftPaq SP32478.exe, from www.hp.com.

3) Extract all the files from the SoftPaq. A USB floppy is necessary for this step. Run sp32478;

this will create a floppy disk. The files will be located on this floppy.

4) These files should be located on the floppy disk.

a. iaahci.cat

b. iaahci.inf

c. iastor.cat

d. iastor.inf

e. iastor.sys

f. license.txt

g. readme.txt

h. txtsetup.oem

5) Create the following path in the temporary folder: c:\xpcd\$oem$\$1\drivers\sata

6) Copy all the files from step 4 to the c:\xpcd\i386 folder.

7) Also copy all the files from step 4 to the c:\xpcd\$oem$\$1\drivers\sata folder.

8) Open the c:\xpcd\i386\txtsetup.sif file in Notepad.

9) Go to the end of the file. There will be several blank lines.

10) Move the cursor up a few lines. This is necessary because there is a hidden marker at the end

of the file.

11)Add the following lines

[SourceDisksFiles]

iastor.sys= 1,,,,,,4_,4,1,,,1,4

iaAHCI.cat=1,,,,,,,20,0,0

iaAHCI.inf=1,,,,,,,20,0,0

iaSTOR.cat=1,,,,,,,20,0,0

iaSTOR.inf=1,,,,,,,20,0,0

[HardwareIdsDatabase]

PCI\VEN_8086&DEV_27C5&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_27C3&CC_0104 = "iaStor"

PCI\VEN_8086&DEV_27C1&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_2652&CC_0104 = "iaStor"

PCI\VEN_8086&DEV_2652&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_2653&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_24DF&CC_0104 = "iaStor"

PCI\VEN_8086&DEV_25B0&CC_0104 = "iaStor"

[SCSI.Load]

iaStor = iaStor.sys,4

[SCSI]

iaStor = "Intel(R) 82801 SATA RAID/AHCI Controller

(ICH5,6,7)"

12) Save the file and exit notepad.

13) Extract the files from c:\xpcd\support\tools\deploy.cab to c:\deploytools

14) Create a new winnt.sif:

a. Execute setupmgr.exe (extracted from deploy.cab in step 13).

b. Select “Create new answer file”

c. Select “Unattended Setup”

d. Select “Windows XP Pro”

e. Select “User Interaction desired”

f. Select “Set up from a CD”

g. Enter desired information under each of the following Settings sections

h. Save the file as c:\xpcd\i386\winnt.sif

15) Open the c:\xpcd\i386\winnt.sif in notepad

16) Under the section [Unattended], add the following lines:

OemPreinstall=yes

OemPnPDriversPath=drivers\sata

DriverSigningPolicy = Ignore

17) Save winnt.sif and close notepad

18) Burn the custom XPCD from the c:\xpcd

folder.

a. Note that the volume label of the CD must be the same as from the original XP CD

b. The custom XPCD must be bootable (with the Microsoft bootblock). There are various

3rd party utilities which can accomplish this. Utilities from Microsoft are available, as

detailed in the following section.

Using OSCDIMG (or CDIMAGE) and CDBURN (command line utilities

from Microsoft)

Note: You will need the OSCDIMG and CDBURN utilities. OSCDIMG is found in the WinPE

toolkit folder or the OPK. CDBURN is included in the Windows Resource Kits.

1) To create the .iso, use oscdimg –l <your XP cd label> -b ETFSBOOT.COM -n

c:\xpcd c:\xpcd.iso

2) To create the CD, use Cdburn <cd-drive-letter:> c:\xpcd.iso

Adding SATA Drivers to WinPE 2005

Where these guidelines are applicable

IMPORTANT:

Follow the installation instructions in the order provided. Failure to

complete these steps in the proper order can result in an unsuccessful or

unstable installation.

This section provides guidelines for customers who need to add SATA support to a WinPE ISO or

DOK.

Steps to add SATA drivers to WinPE 2005

1) Create the WinPE folder (these guidelines will use c:\winpe)

2) Download the Intel SATA AHCI Controller Driver, SoftPaq SP32478.exe, from www.hp.com.

3) Extract all the files from the SoftPaq. A USB floppy is necessary for this step. Run sp32478;

this will create a floppy disk. The files will be located on this floppy.

4) These files should be located on the floppy disk.

a. iaahci.cat

b. iaahci.inf

c. iastor.cat

d. iastor.inf

e. iastor.sys

f. license.txt

g. readme.txt

h. txtsetup.oem

5) Copy the iaahci.inf and iastor.inf files from the floppy to the c:\winpe\i386\inf

folder.

6) Copy the other files to the c:\winpe\i386\system32\drivers folder.

7) Open c:\winpe\i386\txtsetup.sif in Notepad.

8) Go to the end of the file. There will be several blank lines

9) Move the cursor up a few lines. This is necessary because there is a hidden marker at the end

of the file.

10)Add the following lines to the txtsetup.sif:

[SourceDisksFiles]

iastor.sys= 1,,,,,,4_,4,1,,,1,4

iaAHCI.cat=1,,,,,,,20,0,0

iaAHCI.inf=1,,,,,,,20,0,0

iaSTOR.cat=1,,,,,,,20,0,0

iaSTOR.inf=1,,,,,,,20,0,0

[HardwareIdsDatabase]

PCI\VEN_8086&DEV_27C5&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_27C3&CC_0104 = "iaStor"

PCI\VEN_8086&DEV_27C1&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_2652&CC_0104 = "iaStor"

PCI\VEN_8086&DEV_2652&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_2653&CC_0106 = "iaStor"

PCI\VEN_8086&DEV_24DF&CC_0104 = "iaStor"

PCI\VEN_8086&DEV_25B0&CC_0104 = "iaStor"

[SCSI.Load]

iaStor = iaStor.sys,4

[SCSI]

iaStor = "Intel(R) 82801 SATA RAID/AHCI Controller

(ICH5,6,7)"

11) Save the file and exit Notepad.

12) Create the WinPE .ISO file or DOK from c:\winpe. This is done in the usual manner.

Modifying a Windows XP installation to support SATA

Native Mode

Where these guidelines are applicable

IMPORTANT:

Follow the installation instructions in the order provided. Failure to

complete these steps in the proper order can result in an unsuccessful or

unstable installation.

This section provides guidelines for customers who have built an image with SATA AHCI Native

Mode disabled in F10 Setup, and need to modify the image to support SATA AHCI Native Mode

enabled (the default mode). This section is intended for customers who have not yet modified their

overall process using one of the previous methods, and need an expedient method of imaging a

system.

This section provides guidelines for disabling SATA native mode in F10 setup, building the image,

adding the drivers for SATA AHCI to the image, and re-enabling SATA native mode in F10 setup.

Steps to modify a Windows XP image to support SATA Native Mode

1) Enter F10 Setup, and go to System Configuration/Device Configurations/SATA Native Mode

to Disable.

2) Install Windows XP Service Pack 2 in whatever manner is typical for your organization.

3) Download the Intel SATA AHCI Controller Driver, SoftPaq SP32478.exe, from www.hp.com.

4) Extract all the files from the SoftPaq. A USB floppy is necessary for this step. Run sp32478;

this will create a floppy disk. The files will be located on this floppy.

5) These files should be located on the floppy disk.

a. iaahci.cat

b. iaahci.inf

c. iastor.cat

d. iastor.inf

e. iastor.sys

f. license.txt

g. readme.txt

h. txtsetup.oem

6) Download and run the Intel Chipset Installation Utility for ICH7, SoftPaq SP32781, from

www.hp.com.

7) In Device Manager, right-click the IDE ATA/ATAPI controllers/Intel ® 82801 GBM/GHM

(ICH7-M Family) Serial ATA Storage Controller and select ‘Update Driver’.

8) Follow these steps to complete the Hardware Update Wizard:

a. At the first dialog, select ‘No, not this time’ when prompted to connect to Windows

Update.

b. At the next dialog, select ‘Install from a list or specific location (Advanced).

c. At the next dialog, select ‘Don’t search. I will choose the driver to install’.

d. When prompted to select the device driver you want to install for this hardware,

choose the first one in the list: Intel® 82801GBM/GHM (ICH-7M Family) Serial ATA

Storage Controller – 27C4.

e. When prompted to insert the manufacturer’s installation disk, browse to

c:\SWSetup\SATA AHCI Drivers\, and click OK.

f. When prompted to select the device driver you want to install for this hardware,

select the Intel® 82801GBM SATA AHCI Controller

g. A warning that Windows cannot verify that the device is compatible with your

hardware will appear. When asked if you want to continue installing the driver,

select Yes.

h. The installation will complete.

9) Shut down Windows and restart the computer. Enter F10 setup when prompted during the

boot.

10) Go to System Configuration/Device Configurations/SATA Native Mode and change it to

Enable, then save settings and exit F10 Setup.

11) After Windows restarts, the additional SATA components will be updated. A System Settings

Change will appear. When asked “Do you want to restart your computer now?” click Yes.

Andere Handbücher für Compaq nx6310

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere HP Laptop Handbücher

HP Pavilion 11 x360 PC Handbuch

HP 8510w - Mobile Workstation Handbuch

HP G6000 - Notebook PC Bedienungsanleitung

HP 2230s - Compaq Business Notebook Montageanleitung

HP Pro x2 410 G1 Handbuch

HP PAVILION G6 Handbuch

HP ZHAN X 13 G2 Handbuch

HP Pavilion dv6-6000 Bedienungsanleitung

HP 2000-216 Handbuch

HP Pavilion 11 x360 PC Montageanleitung

HP Pavilion 15 Handbuch

HP Compaq Notebook Betriebsanleitung

HP Mini 5101 Installationsanleitung

HP ProBook 4230s Handbuch

HP Compaq NC4400 Gebrauchsanweisung

HP Pavilion N3310 Anleitung zur Verwendung

HP ProBook 5320m - Notebook PC Bedienungsanleitung

HP EliteBook x360 830 G5 Montageanleitung

HP Pavilion 15-e000 Bedienungsanleitung

HP Pavilion Media Center dv9590ea Bedienungsanleitung

HP EliteBook 8470b Handbuch

HP Pavilion DV6-1050 Bedienungsanleitung

HP Compaq nw9440 Bedienungsanleitung

HP OmniBook 800CT Bedienungsanleitung

Beliebte Laptop Handbücher anderer Marken

Velocity

Velocity NoteMagix M10 Bedienungsanleitung

Dell

Dell Alienware 17 R2 Bedienungsanleitung

Toshiba

Toshiba A105-S2236 Bedienungsanleitung

Winbook

Winbook LM Bedienungsanleitung

Dell

Dell Inspiron 1464 Bedienungsanleitung

Dell

Dell Inspiron 15R 5537 Bedienungsanleitung

Dell

Dell Latitude ATG D620 Bedienungsanleitung

Sony

Sony VAIO PCG-FX270 Bedienungsanleitung

Dell

Dell Latitude 7310 Bedienungsanleitung

Dell

Dell Precision GU806 Bedienungsanleitung

Sony

Sony VAIO PCG-R505JLK Bedienungsanleitung

Lenovo

Lenovo THINKPAD X32 Bedienungsanleitung

Toshiba

Toshiba mini NB300 Bedienungsanleitung

Lenovo

Lenovo ThinkPad X201 Tablet Handbuch

Lenovo

Lenovo THINKPAD X31 Handbuch

Sony

Sony VGN-T240P VAIO Bedienungsanleitung

Compaq

Compaq Armada E700 Series Bedienungsanleitung

Fujitsu

Fujitsu Lifebook A6230 Bedienungsanleitung
