HP Tower Server tc4100 with

HP Surestore Virtual Array 7100/7400

Windowsâ2000 Advanced Server

Cluster Configuration Guide

Introduction

This document defines the server cluster configurations supported by Hewlett-Packard for interconnection of

two HP tc4100 servers and one or two HP VA 7100 or 7400 disk drive enclosure(s), with MicrosoftâCluster

Server software. These configurations provide high server cluster availability and minimize single points of

failure (SPOFs). Hewlett-Packard will support any cluster configuration that conforms to the guidelines of

this document. Deviations from the supported configurations can result in an inoperative cluster, an

operating cluster with degraded performance, or hidden SPOFs. Therefore, deviations are not supported. For

revision/update information on this document, refer to Versions on page 10.

Cluster Configuration Elements

This section identifies the hardware components, system software, network interfaces, and power distribution

arrangement required to build an operational server cluster supported by Hewlett-Packard. The various

server cluster elements are listed below, and their associated configuration data is detailed in separate tables

and illustrations that follow.

· Server configuration

· Shared storage configuration

· Intra-cluster (heartbeat) LAN configuration

· Client LAN configuration

· FC cabling configuration

· Supported Fibre Channel topologies

· Power distribution configuration

Server Configuration

Parameter Specification

Server

Type HP Tower Server tc4100

Number of nodes Two

Each node must be the same server type, but nodes may differ in their CPU clock

speeds and cache sizes, and amounts of main memory.

Clock speed 1.40 GHz, or any CPU within the same processor family

Number of CPUs Two

BIOS Version 4.06.12 RI, or later

CPU cache Any size

RAM Recommended 512 MB, minimum. Must be HP.

Number of power

supplies

One standard, two required for redundancy

5/2/02 1

tc41002k71-74

Server Configuration

Parameter Specification

I/O slots Added cards may be installed in any appropriate slot, considering the server

default boot order provided below.

Default boot order IDE CD-ROM, FDD, embedded SCSI A, embedded SCSI B, PCI slot 6, PCI slot

5, PCI slot 4, PCI slot 3, PCI slot 2, PCI slot 1, integrated NIC

Local Storage

Controller Embedded SCSI or NetRAID-1M

Driver For embedded SCSI, sym_u3.sys, version 5.07, or later

For NetRAID-1M, mraid2k.sys, version 5.20

(drivers obtained from Navigator CD-ROM, version M.04.60, or later)

Physical drive location Server internal drive bays, or HP external drive cabinet

(e.g., HP Rack Storage/12)

Disk drives Must be HP

SCSI bus Any HP cables that meet SCSI specifications, and any SCSI bus speed

SCSI IDs Any

System software

Navigator CD-ROM Version M.04.60, or later

Operating system

Service pack

Microsoft Windowsâ2000 Advanced Server

Latest service pack

HP Surestore Auto Path

Version 1.03.00 or later.

Required only if two Fibre Channel Host Bus Adapters are configured for shared

storage. No Load Balancing is set for the FC HBA devices on each node. See the

dual HBA diagrams on pages 5 and 7 for more information.

Shared Storage Configuration

Parameter Specification

Controller

Model HP D8602B Fibre Channel Host Bus Adapter

Number of controllers One or two

Dual HBA controller configurations require running HP Surestore Auto Path VA.

Note that the purpose of the second HBA is to provide an alternate path for

automatic failover only.

Driver Afcw2k.sys, version 3.0.4107.0

Registry settings N_Port enabled for Fabric configurations

NL_Port enabled for Arbitrated Loop configurations

Refer to the readme file included with the HBA driver for instructions on

modifying driver parameters.

RAID levels AutoRAID, or RAID 1+ 0

Logical disks Sixteen LUNs, maximum, per cluster

Connection Supports copper or optical GBIC (optical GBIC not included). Optical cable

requires SC connection.

Enclosures HP Surestore Virtual Array 7100, Models A6261A, A6262A, or A6263A

HP Surestore Virtual Array 7400, Models A6264A, A6265A, or A6214A

5/2/02 2

tc41002k71-74

Shared Storage Configuration

Parameter Specification

Number of enclosures One or two per cluster

Number of clusters One or two per Virtual Array enclosure

Consult your HP Reseller or HP storage specialist if planning configurations that

may require support for additional MSCS clusters or additional non-clustered

servers.

Disk drives 18 GB, 15K rpm, product numbers A6191A or A6228A

36 GB, 10K rpm, product numbers A6192A or A6229A

36 GB, 15K rpm, product numbers A6193A

73 GB, 10K rpm, product number A6194A or A6231A

Firmware HP14

Virtual Front Panel

settings

Topology 1 – Private Loop (default)

4 - Fabric

Host port behavior Win2000

Host FC connector VA 7100 – Requires optical GBIC (not included) and optical SC cable

connection.

VA 7400 – Requires SFP (small form-factor pluggable) optical interface (not

included) and optical LC cable connection.

Optional additional

storage

DS2405 – product numbers A6250A, A6250AZ (factory racked), A6250AE

(without disks)

Up to six DS2405 enclosures can be cascaded from each VA7400 for additional

shared disk storage in a cluster. Requires optical LC cable connection.

Switches

HP Surestore FC 1Gb/

2Gb Entry Switch 8B

HP Surestore FC

1Gb/2Gb Switch 8B

HP Surestore FC

1Gb/2Gb Switch 16B

HP Brocade Silkworm

2800

HP Netserver 8 Port

Fibre Loop Switch

8 port auto-sensing FC fabric switch with single E port, product numbers A7346A

or A7346AZ (factory racked) – Requires SFPs (not included) and optical LC

cable connections.

8 univeral port auto-sensing FC fabric switch, product numbers A7347A or

A7347AZ (factory racked) – Requires SFPs (not included) and optical LC cable

connections.

16 universal port auto-sensing FC fabric switch, product numbers A7340A or

A7340AZ (factory racked) – Requires SFPs (not included) and optical LC cable

connections.

16 port FC switch, product numbers A5624A or A5624AZ (factory racked) –

Requires optical GBICs (not included) and optical SC cable connections.

8 port Fibre Channel loop switch, product number P4459A– Supports copper or

optical GBICs (optical GBICs not included). Optical cable requires SC

connection.

Cables and GBICs

Copper

HBA to 8 Port

Loop switch

Copper cabling is supported from the HBA to the 8 Port Loop Switch only.

3 meter cable, product number D6978A (includes two copper GBICs)

5 meter cable, product number D6979A (includes two copper GBICs)

10 meter cable, product number D7080A (includes two copper GBICs)

5/2/02 3

tc41002k71-74

Shared Storage Configuration

Parameter Specification

Fiber Optic

HBA to Brocade

2800 or loop

switch

(SC to SC)

Only an optical fiber connection is supported to the storage, either directly from

the HBA or from a switch.

50 meter cable, product number D6980A (includes two SW GBICs)

100 meter cable, product number D6981A (includes two SW GBICs)

2 meter cable, product number A3583A (GBICs not included)

16 meter cable, product number A3531A (GBICs not included)

50 meter cable, product number A3735A (GBICs not included)

100 meter cable, product number A3736A (GBICs not included)

From HBA or

Brocade 2800 or

loop switch

To VA 7100

(SC to SC)

To VA 7400

(SC to LC)

From 1Gb/2Gb

switch to VA7100

(LC to SC)

From 1 Gb/2Gb

switch to VA7400,

or between

1Gb/2Gb switches,

or from VA7400 to

DS2405

(LC to LC)

2 meter cable, product number A3583A (GBICs not included)

16 meter cable, product number A3531A (GBICs not included)

50 meter cable, product number A3735A (GBICs not included)

100 meter cable, product number A3736A (GBICs not included)

2 meter cable, product number C7529A (GBIC and SFP not included)

16 meter cable, product number C7530A (GBIC and SFP not included)

2 meter cable, product number C7529A (GBIC and SFP not included)

16 meter cable, product number C7530A (GBIC and SFP not included)

2 meter cable, product number C7524A (SFPs not included)

16 meter cable, product number C7525A (SFPs not included)

50 meter cable, product number C7526A (SFPs not included)

200 meter cable, product number C7527A (SFPs not included)

GBICs

SFPs

Short wavelength optical GBIC (for HBA, loop switch or Brocade 2800 switch),

product numbers A5225A or D6975A

Short wavelength SFP, product number A6515A

Long wave length SFP, product number A6516A

Intra-Cluster (Heartbeat) LAN Configuration

Parameter Specification

Network

Connection HP D5954A crossover cable, or equivalent.

The intra-cluster LAN may only be used for cluster node communication. It may

not be used for client communication.

NIC

Quantity One, minimum

5/2/02 4

tc41002k71-74

Intra-Cluster (Heartbeat) LAN Configuration

Parameter Specification

Model Integrated NIC, HP 10/100 IPSec 3DES, Model P3492A, or any LAN adapter that

is on both the HP Tested Products List and the Microsoft®Hardware

Compatibility List

Driver For integrated NIC or P3492A, latest version from Navigator CD-ROM or HP

technical support web site.

For other NICs, any vendor-supported driver.

Client LAN Configuration

Parameter Specification

Network

Connection Any LAN

NIC

Quantity One, minimum

Model Any model that is on both the HP Tested Products List and the Microsoftâ

Hardware Compatibility List

Driver Vendor-supported driver

If the NIC used is the same as that of the intra-cluster LAN, then the client LAN

driver must be the same as that of the intra-cluster LAN.

5/2/02 5

tc41002k71-74

Server

Private

Network

FC Hub/Switch

Primary Active Path* Secondary Path for Failover

Public Network

HP Dual HBA Cluster

A 7100

*Preferred path mode only.

FC Hub/Switch

(LUN owner)

5/2/02 6

tc41002k71-74

Server

Private

Network

FC Hub/Switch

Primary path for RG 1*

Secondary path for RG 2 Secondary path for RG 1

Primary path for RG 2*

FC Hub/Switch

Public Network

HP Dual HBA Cluster

A 7400

*Preferred path mode only.

()

Redundancy Group1 owner

()

Redundancy Group 2 owner

HOST FC HOST FC

Performance note:

For best performance, If Server 1 and Server 2 are configured in an active/active cluster

configuration, where each is running a critical application software, each application should

use LUNs owned by a different VA controller, and the primary path of the server running the

application should be to the VA controller owning that application’s LUNs.

5/2/02 7

tc41002k71-74

NL_Port

Direct Connection

Private Arbitrated Loop with Two Switches and Redundant Paths Using AutoPathTwo HBAs -

Switched Fabric with Two Switches and Two HBAs - Redundant Paths Using AutoPath

FL_Port FL_Port

F_Port

VA 7 X 0 0

Brocade or

Loop Switch

Brocade Switch Brocade Switch

NL_Port

N_Port

optical fiber cable

optical fiber or copper cables

NL_Port NL_Port

N_Port N_Port

tc4100 tc4100

tc4100

Brocade or

Loop Switch

(No other servers can be connected to the Virtual Array)

(A second cluster, or additional servers can be connected to the Virtual Array)

Supported Topologies for the HP tc4100, Virtual Array Cluster

5/2/02 8

tc41002k71-74

Power Cabling to Separate Power Circuits

5/2/02 9

tc41002k71-74

Versions

02 May 2002 Added support for DS2405 for additional storage.

25 April 2002 Removed discontinued S10/L10 hub and Brocade 2400 switch.

17 April 2002 Updated topology diagram. Added 2 GB FC switches and cables.

01 April 2002 Initial release

5/2/02 10

Andere Handbücher für Tc4100 - Server - 256 MB RAM

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere HP Server Handbücher

HP D7171A - NetServer - LPr Bedienungsanleitung

HP Tc2110 - Server - 128 MB RAM Technisches Handbuch

HP rp7400 Bedienungsanleitung

HP D7171A - NetServer - LPr Bedienungsanleitung

HP ProLiant XL250a Gen9 Gebrauchsanweisung

HP Sa3110 - VPN Server Appliance Anleitung zur Verwendung

HP ProLiant DL580 Generation 2 Handbuch

HP D7171A - NetServer - LPr Bedienungsanleitung

HP ProLiant ML310e Generation 8 (Gen8) Gebrauchsanweisung

HP T5125 - Compaq Thin Client Service-Handbuch

HP Integrity Superdome X Gebrauchsanweisung

HP Integrity rx4640 Installations- und Betriebshandbuch

HP 127695-B21 - Smart Array 431 RAID Controller Bedienungsanleitung

HP ProLiant DL380 Bedienungsanleitung

HP Cluster Platform Express v2010 Bedienungsanleitung

HP ProLiant SL2x170z - G6 Server Handbuch

HP Compaq t1010 Bedienungsanleitung

HP D5970A - NetServer - LCII Bedienungsanleitung

HP ProLiant ML310 Generation 5p Gebrauchsanweisung

HP Compaq t1010 Installationsanleitung

HP NetServer e 800 Bedienungsanleitung

HP ProLiant ML110 Bedienungsanleitung

HP Integrity rx8640 Bedienungsanleitung

HP mt20 Handbuch

Beliebte Server Handbücher anderer Marken

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung

Planet

Planet NAS-7410 Bedienungsanleitung

Lenovo

Lenovo ThinkSystem SR635 V3 Bedienungsanleitung

Dell

Dell PowerEdge HS5610 Handbuch
