Quick Specs HP Compaq vc4725 Thin Client

System Details

Overview

1.Foot stand 1.Kensington Cable Locking slot

2.Microphone 2.Power connector

3.Speaker 3.Ethernet RJ-45 connector

4.USB connectors (two in front) 4.USB connectors (two in rear)

5.Flash Activity LED 5.Serial connector

6.Power ON LED 6

Parallel connector

7.Power button 7. Monitor connector

8.Bio metric sensor (optional) 8.PS/2 connectors (Keyboard and mouse)

At A Glance

•Chipset integrated S3 Graphics UMA Core.

•VIA C7 CPU 1.0GHz.

•Single channel DDRII SDRAM system memory.

•CF card / uDOC Flash memory support.

•Optional internal HDD support for data storage.

•Integrated Realtek Audio.

•Integrated Realtek 10/100 Network connection.

•Internal speaker (Optional).

•Linux Operating System customized for customer needs.

•Simplified design for enterprise and SMB customers.

•HP’s “Invisible Thin Client” with the innovative HP Quick Release.

•Designed and Tested forHP quality standards & Indian harsh environmental conditions.

Quick Specs HP Compaq vc4725 Thin Client

System Details

•Desktop like features at compelling prices.

•Lower ownership costs and increased resource efficiency for each end-user.

•Protected by HP Services. Terms and conditions vary by country. Certain restrictions & exclusions apply.

Standard Features-Models

Processor VIA C7 (1.0GHz).

Operating System Thin client Linux Image.

Flash memory CF Card/uDOC

Memory •DDRII SDRAM

•2x DIMM slots

•Support for single channel configuration

•Supports up to 2GB

Integrated Graphics •Chipset integrated S3 Graphics UMA Core

Audio •Front Audio with Realtek ALC655 CODEC Chip.

LAN •Integrated Realtek 10/100 (RTL 8100C) network controller

SATA •Internal two Serial ATA interfaces

Expansion Slots •1 x mini PCI Slot (Optional )

Keyboard •USB or PS/2 (both supported)

•Keyboard included with every thin client. Type of included

keyboard (USB or PS/2).

Mouse •USB or PS/2 (both supported)

•Mouse included with every thin client. Type of included mouse

(USB or PS/2).

Adaptor •65W AC Adaptor.

Quick Specs HP Compaq vc4725 Thin Client

Technical Specifications -Environmental Data

Options Part Number

Accessories HP Quick Release Kit to connect HP LCD Monitor.

Monitors EOL Touch 1529L Flat panel

EOL Touch 1515L Flat panel

EOL Touch 1725C CRT

EOL Touch 1526C CRT

HP w19 LCD Monitor

HP L1750 17” LCD Monitor

HP L1506s LCD Monitor ALL

HP L1908w Wide LCD Monitor

HP L1908wi Wide LCD Monitor

HP L1710 17-inch LCD Monitor ALL

HP L1910 19-inch LCD Monitor

HP w17e 17 Inch LCD Monitor

HP v7650 CRT Monitor ALL

HP s7540 CRT Monitor ALL

HP s5502 CRT Monitor ALL

L1506 LCD Monitor ALL

HP L1706 LCD Monitor ALL

HP L1906 LCD Monitor ALL

HP LP1965 LCD Monitor ALL

HP L2045w LCD Monitor ALL

E926109

E849124

E248189

E833965

EM885AA#ACJ

GF904AA#ACJ

GL831AA#ACJ

GP536AA#ACJ

GP537AA#ACJ

GS917AA#ACJ

GS918AA#ACJ

GV537AA#ACJ

PF996AA#ACJ

PF997AA#ACJ

PQ560AA#ACJ

PX848AA#ACJ

PX849AA#ACJ

PX850AA#ACJ

RA373AA#ACJ

RA374AA#ACJ

RB145AA#ACJ

Technical Specifications

Processor VIA C7 (1.0GHz)

Memory •Single channel DDRII SDRAM system memory, 2X DIMM, supports up

to 2GB.

•uDOC/ CF Card: Supports from 512MB up to 4GB.

•HDD: 80GB, 160GB (Optional).

Graphics Chipset integrated S3 Graphics UMA Core.

Keyboard HP PS2/USB Standard Keyboard

Mouse HP PS2/USB Optical mouse

Input/Output

Peripheral Support

Printer Local and/or network printers (RDP, ICA,

LPD) as per the printer support statement

Security Three layers of hardware security (Password protection, Chassis intrusion switch

(Optional) , Bio-metric finger print device on chassis front bezel (Optional).

HP/Kensington Cable Lock (Optional).

Networking 10/100 BaseT Fast Ethernet, twisted pair (RJ-45)

I/O ports and connectors Four USB ports (two in front, two in rear), 2 Front Audio Ports (Mic and

Headphone), 2 * PS2 KBD /Mouse Ports , One LPT Port , One COM port (

optional second com port ) , 1 VGA port , 1* RJ 45 Port.

Server OS Compatibility support

Window

s NT 4.0 Terminal Server Edition, Windows 2000/2003 Server families,

Windows 2000/2003 Server Terminal Services, Windows 2000 Advanced Server,

Quick Specs HP Compaq vc4725 Thin Client

Technical Specifications -Environmental Data

Windows 2000 Advanced Server Terminal Services, Citrix Presentation Server

4.0, Citrix Metaframe Presentation Server 3.0,Virtual Desktop Infrastructure using

RDP.

Languages English

Dimensions H x W x D (approximante) Height 7.56in 192mm

Width 2.00in 51.08mm

Depth 11.36in 288.4mm

Weight (approximate) 3.7lb 1.7kg

Température Range Operating 50’ to 140’F 10’ to 40’C

No operating -22’ to 140’F -30’ to 60’C

Relative Humidity (non-condensing) Operating 10-90% 10-90%

Non-operating 5-95% 5-95%

Power Supply Operating Voltage Range 100-240VAC 100-240VAC

Related Line Frequency 50-60Hz 50-60Hz

Output Voltage 19VDC

Rated Output Current (max) 3.42Amp

Warranty Warranty as per the terms and conditions mentioned in the warranty manual.

Memory:

Possible Memory Configurations

Option CF Card uDOC Hard Drive Result

1Yes No No Supported

2No Yes No Supported

3No Yes Yes Supported

4Yes No Yes Not Supported

5Yes Yes Yes Not Supported
