HPE ProLiant DL360 Gen11 Bedienungsanleitung

HPE ProLiant DL360 Gen11 Server User GuideHPE ProLiant DL360 Gen11 Server User Guide

Part Number: 30-1311EFD2-001

Published: February 2023

Edition: 1

HPE ProLiant DL360 Gen11 Server User GuideHPE ProLiant DL360 Gen11 Server User Guide

AbstractAbstract

This document is for the person who installs, administers, and troubleshoots servers and storage systems. Hewlett Packard Enterprise

assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy

levels.

Part Number: 30-1311EFD2-001

Published: February 2023

Edition: 1

NoticesNotices

The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and

services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed

as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions

contained herein.

Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or copying. Consistent with

FAR 12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical Data for Commercial Items

are licensed to the U.S. Government under vendor's standard commercial license.

Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard Enterprise has no control over

and is not responsible for information outside the Hewlett Packard Enterprise website.

AcknowledgmentsAcknowledgments

Intel®, Itanium®, Optane™, Pentium®, Xeon®, Intel Inside®, and the Intel Inside logo are trademarks of Intel Corporation or its subsidiaries.

Microsoft® and Windows® are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other

countries.

Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries.

VMware ESXi™ and VMware vSphere® are registered trademarks or trademarks of VMware, Inc. in the United States and/or other

jurisdictions.

Red Hat® Enterprise Linux is a registered trademark of Red Hat, Inc. in the United States and other countries.

microSD® is a trademark or a registered trademark of SD-3D in the United States, other countries of both.

Kensington® is a registered trademark of ACCO Brands.

All third-party marks are property of their respective owners.

Table of contentsTable of contents
Component identification
Front panel components
Front panel LEDs and buttons
UID button functionality
Front panel LED power fault codes
Systems Insight Display LEDs
Systems Insight Display combined LED descriptions
Rear panel components
Rear panel LEDs
System board components
Heatsink and processor socket components
Closed-loop liquid cooling heatsink components
System maintenance switch descriptions
DIMM label identification
DIMM slot locations
Drive boxes and numbering
Hot-plug fans
HPE Basic Drive LED definitions
HPE NS204i-u Boot Device components
HPE NS204i-u Boot Device LED definitions
Setup
Optional services
Setting up the server
Operational requirements
Space and airflow requirements
Temperature requirements
Power requirements
Electrical grounding requirements
Rack warnings and cautions
Server warnings and cautions
Electrostatic discharge
Operations
Server data backup
Power down the server
Extend the server from the rack
Release the cable management arm
Remove the server from the rack
Remove the access panel
Remove the primary PCIe riser cage
Install the primary PCIe riser cage
Removing a hot-plug SAS/SATA/NVMe drive
Accessing the Systems Insight Display

Install the access panel
Power up the server
Hardware options installation
Introduction
Hewlett Packard Enterprise product QuickSpecs
Controllers
Installing a type-p storage controller
Installing a type-o storage controller
Cooling
Installing a high-performance fan
Drive cages
Installing a 2 SFF drive cage
Energy pack options
Minimum firmware versions
HPE Smart Storage Battery
HPE Smart Storage Hybrid Capacitor
Installing a smart storage battery/capacitor
Hard drives
Drive guidelines
Installing a hot-plug SAS, SATA or NVMe drive
Management
Installing the Systems Insight Display
Installing the serial port option
Memory
Memory population information
DIMM-processor compatibility
Installing a DIMM blank
Installing a DIMM
Networking
Installing an OCP network adapter
Installing a PCIe network adapter
Optical drives and media bays
Installing the 8 SFF display port/USB option
Installing an 8SFF optical drive
Installing the 4LFF display port/USB option
Installing the 4LFF optical drive
OS boot device
Installing boot device drives
Installing the HPE NS204i Boot Device
Power supply options
Installing a redundant hot-plug power supply
Processor and heatsink options
Processor cautions
Installing the processor

Rack mounting options
Rack mounting interfaces
Rail identification markers
Installing the rack rails
Installing the server into the rack
Installing the rack rail hook-and-loop strap
Installing the cable management arm
Riser and riser cage options
PCIe5 slot description
Primary PCI riser cage options
Installing an expansion board in slot 1
Installing an expansion board in slot 2
Installing a GPU in the primary riser cage
Secondary PCI riser options
Installing a secondary low-profile riser option
Installing a secondary full-height riser option
Installing an expansion board in the secondary riser cage
Security
Installing the bezel
Installing the Chassis Intrusion Detection switch option
Trusted Platform Module 2.0 guidelines
Cabling
Cabling guidelines
Cabling diagrams
8 SFF drive backplane cabling
2 SFF drive backplane cabling
4 LFF drive backplane cabling
NS204i-u cabling
OCP adapter bandwidth upgrade cabling
Power cabling
IO cabling
Systems Insight Display cabling
Intrusion detection switch cabling
Serial port cabling
Smart storage battery/capacitor cabling
bby_086
Configuration resources
Updating firmware or system ROM
Configuring the server
Configuring storage controllers
Managing the HPE NS204i Boot Device
Deploying an OS
Configuring security
Optimizing the server

Server management
Managing Linux-based high performance compute clusters
Troubleshooting
NMI functionality
Troubleshooting resources
Specifications
Environmental specifications
Mechanical specifications
Power supply specifications
HPE 800 W Flex Slot Platinum Hot-plug Low Halogen Power Supply
HPE 1000 W Flex Slot Titanium Hot-plug Power Supply
HPE 1600 W Flex Slot Platinum Hot-plug Low Halogen Power Supply
Hot-plug power supply calculations
Websites
Support and other resources
Accessing Hewlett Packard Enterprise Support
Accessing updates
Remote support
Customer self repair
Warranty information
Regulatory information
Documentation feedback

Component identificationComponent identification

SubtopicsSubtopics

Front panel componentsFront panel components

Front panel LEDs and buttonsFront panel LEDs and buttons

Rear panel componentsRear panel components

Rear panel LEDsRear panel LEDs

System board componentsSystem board components

Drive boxes and numberingDrive boxes and numbering

Hot-plug fansHot-plug fans

HPE Basic Drive LED definitionsHPE Basic Drive LED definitions

HPE NS204i-u Boot Device componentsHPE NS204i-u Boot Device components

HPE NS204i-u Boot Device LED definitionsHPE NS204i-u Boot Device LED definitions

Front panel componentsFront panel components

SFFSFF

ItemItem DescriptionDescription

1 Serial number/iLO information pull tab

2 Display port (optional)

3 Optical drive (optional)

4 USB 2.0 port (optional)

5 iLO Service Port

6 USB 3.2 Gen 1 port

7 Drive bays

This option can be replaced by 2SFF drive bays.

The operating system does not recognize this port as a USB port.

LFFLFF

HPE ProLiant DL360 Gen11 Server User Guide 7

ItemItem DescriptionDescription

1 Optical drive (optional)

2 Serial number/iLO information pull tab

3 Display port (optional)

4 USB 2.0 port (optional)

5 USB 3.2 Gen 1 port

6 iLO Service Port

7 Drive bays

Front panel LEDs and buttonsFront panel LEDs and buttons

ItemItem DescriptionDescription StatusStatus

1 Power On/Standby button

and system power LED

Solid green = System on

Flashing green = Performing power on sequence

Solid amber = System in standby

Off = No power present

2 Health LED Solid green = Normal

Flashing green = iLO is rebooting.

Flashing amber = System degraded

Flashing red = System critical

HPE ProLiant DL360 Gen11 Server User Guide 8

3 NIC status LED Solid green = Link to network

Flashing green = Network active

Off = No network activity

4 UID button/LED Solid blue = Activated

Flashing blue:

1 Hz = Remote management or firmware

upgrade in progress

4 Hz = iLO manual reboot sequence initiated

8 Hz = iLO manual reboot sequence in progress

Off = Deactivated

ItemItem DescriptionDescription StatusStatus

Facility power is not present, power cord is not attached, no power supplies are installed, power supply failure has occurred, or

the power button cable is disconnected.

If the health LED indicates a degraded or critical state, review the system IML or use iLO to review the system health status.

When all four LEDs described in this table flash simultaneously, a power fault has occurred.

SubtopicsSubtopics

UID button functionalityUID button functionality

Front panel LED power fault codesFront panel LED power fault codes

Systems Insight Display LEDsSystems Insight Display LEDs

Systems Insight Display combined LED descriptionsSystems Insight Display combined LED descriptions

UID button functionalityUID button functionality

The UID button can be used to identify a specific server in a rack or display the Server Health Summary when the server will not power

on. For more information, see the latest HPE iLO User Guide on the Hewlett Packard Enterprise websiteHewlett Packard Enterprise website .

Front panel LED power fault codesFront panel LED power fault codes

The following table provides a list of power fault codes, and the subsystems that are affected. Not all power faults are used by all

servers.

SubsystemSubsystem LED behaviorLED behavior

System board 1 flash

Processor 2 flashes

Memory 3 flashes

Riser board PCIe slots 4 flashes

OCP adapter 5 flashes

Storage controller 6 flashes

System board PCIe slots 7 flashes

Power backplane 8 flashes

Storage backplane 9 flashes

Power supply 10 flashes

PCIe expansion cards installed in riser board 11 flashes

HPE ProLiant DL360 Gen11 Server User Guide 9

Chassis 12 flashes

GPU card 13 flashes

SubsystemSubsystem LED behaviorLED behavior

Systems Insight Display LEDsSystems Insight Display LEDs

The Systems Insight Display LEDs represent the system board layout. The display enables diagnosis with the access panel installed.

DescriptionDescription StatusStatus

Processor LEDs Off = Normal

Amber = Failed processor

DIMM LEDs Off = Normal

Amber = Failed DIMM or configuration issue

DIMM group LEDs Off = Normal

Amber = Failed DIMM or configuration issue

Fan LEDs Off = Normal

Amber = Failed fan or missing fan

NIC LEDs Off = No link to network

Solid green = Network link

Flashing green = Network link with activity

If power is off, the front panel LED is not active. For status, see Rear panel LEDs.

Power supply LEDs Off = Normal

Solid amber = Power subsystem degraded, power supply failure, or input power lost.

PCI riser LED Off = Normal

Amber = Incorrectly installed PCI riser cage

Over temp LED Off = Normal

Amber = High system temperature detected

Power cap LED Off = System is in standby, or no cap is set.

Solid green = Power cap applied

HPE ProLiant DL360 Gen11 Server User Guide 10

Andere Handbücher für ProLiant DL360 Gen11

Inhaltsverzeichnis

Andere HPE Server Handbücher

HPE

HPE Edgeline EL4000 Bedienungsanleitung

HPE

HPE ProLiant DX380 Gen10 Bedienungsanleitung

HPE

HPE ProLiant DL380 Gen10 Plus Bedienungsanleitung

HPE

HPE Apollo 4500 Bedienungsanleitung

HPE

HPE ProLiant DL160 Gen10 Bedienungsanleitung

HPE

HPE ProLiant MicroServer Gen10 Bedienungsanleitung

HPE

HPE ProLiant DL180 Gen9 Montageanleitung

HPE

HPE Integrity rx2800 i2 series Bedienungsanleitung

HPE

HPE ProLiant DL560 Gen9 Handbuch

HPE

HPE Cloudline CL2200 Gen10 Bedienungsanleitung

HPE

HPE ProLiant DL325 Gen11 Handbuch

HPE

HPE Apollo pc40 Bedienungsanleitung

HPE

HPE ProLiant DL345 Gen11 Installations- und Benutzerhandbuch

HPE

HPE ProLiant Thin Micro TM200 Bedienungsanleitung

HPE

HPE ProLiant ML150 Gen9 Bedienungsanleitung

HPE

HPE ProLiant DL560 Gen10 Handbuch

HPE

HPE ProLiant DL160 Gen10 Montageanleitung

HPE

HPE ProLiant Bedienungsanleitung

HPE

HPE ProLiant DL580 Gen10 Bedienungsanleitung

HPE

HPE Apollo z70 Handbuch

HPE

HPE ProLiant MicroServer Gen10 Bedienungsanleitung

HPE

HPE ProLiant BL660c Gen9 Montageanleitung

HPE

HPE ProLiant BL660c Handbuch

HPE

HPE ProLiant DL325 Gen10 Plus Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
