HPRT MT810 Bedienungsanleitung
MT810
Quick Start Guide ---------------------------------
取扱説明書 ------------------------------------------
使用说明书 ------------------------------------------
01
09
17
Content
EN
JP
CN
Product Introduction
01
Accessories
Operational
Status LED
Cover-opening
Button
Power
Button
Cover-opening
Button
USB Interface
Front View：
Rear View：
USB Cable×1
Connection
Status LED
EN
Loading Paper Roll
02
01 Open the top cover
cover-opening button
Push the cover-opening buttons on both sides,and open the top cover.
02 Remove the paper roll
Remove the supplied paper roll and tear it apart along the edge.
03 Load the paper roll
04 Close the top cover
Please use HPRT official thermal paper for a better printing experience.
Separator
03
Loading Paper Roll
Close the top cover after loading paper. Please make sure both sides click
into place.
Load the paper roll to the paper compartment again and pull some extra
paper. Please adjust the separator according to the paper width.
Power On
01 Power on
Hold down the power button for 3 seconds to start the printer.
Printing from Windows PC
04
Tip: Default printing mode is page by page. You need to click the power button
to continue printing after one page is printed. If you want to change default
printing mode to continuous printing mode, please set it in the printer driver.
Connect one side of the USB cable to the PC and the other side to the printer.
Turn on the printer.
Download the printer driver from the website:
https://www.hprt.com/HPRT-MT810
And then install it on the PC.
Choose the document you want to print from the PC and print it via printer
“HPRT MT810”.
Printing Wirelessly from Mobile Phone
Scan the QR code below to download App.
01 Download App
02 Connect with the printer
Note: App operation shall be subject to the latest version.
Open App, click “+” in the top right corner, choose MT series, and then“Con-
nect via 'settings'”. Turn on Bluetooth on the mobile phone, select “MT810-
XXXX”(XXXX are last four digits of Bluetooth address), click it to connect.
Return to App, click the same model “MT810-XXXX” to connect.
Open the document you want to print, and copy/share it to App.
（Or select document printing on the App home page）.
Adjust it in the print preview, and click the print icon on the top right corner
to print.
03 Print
05
Battery Charging
Precau�ons
When the battery is low, the operational status LED will flash (red light flashes
quickly). Please use the matching USB cable to charge in time. If you continue
printing, the printer may shut down automatically.
charging by PC
charging by power adapter
06
The best operating temperature is 0℃~40℃, if the environmental tempera-
ture is too low or too high, the print quality may be affected.
Please do not use the unofficial paper roll to ensure the print quality.
During printing, the printer head will heat up,do not touch it to avoid burns.
Do not pull out the paper by force during printing, or else it may damage the
printer.
LED Indicator and Buzzer Definitions
01
02
07
Status LED Indicator Buzzer
Print head temperature is too high
Out of paper/paper jam/
abnormal paper loading
Red LED flashes rapidly “Beep-beep beep-”
In Bluetooth connection
Status LED Indicator
Status LED Indicator
Power on White LED is lighting
Red LED flashes slowly
Red LED flashes rapidly
Red LED is lighting
“Beep beep beep-”
“Beep-beep-beep-”
⸺ ⸺
Power off
Printing White LED flashes slowly
Sleeping Blue LED is lighting
Printer cover is not closed
Voltage/Battery is too low
Blue LED is lighting
Bluetooth data receiving Blue LED flashes rapidly
In USB connection Green LED is lighting
USB data receiving Green LED flashes rapidly
No connection currently Light off
Light off
Weight： About 1kg (without accessories)
Battery Parameter： 7.4V, 2500mAh
Operating Temperature： 0℃~40℃
Executive Standard： GB4943.1-2011, GB/T9254-2008, GB 17625.1-2012
Product Name： Mobile Printer
Product Model： MT810
Dimensions： 280 x 95 x 51.4mm
Product Parameters
08
