Huawei T330 Bedienungsanleitung
T330
GSM Mobile Phone
Copyright © 2008 Huawei Technologies Co., Ltd.
and other Huawei trademarks are the trademarks or registered trademarks of Huawei Technologies Co., Ltd.
in the People’s Republic of China and certain other countries. All other trademarks mentioned in this manual are the
property of their respective holders. The information in this manual is subject to change without notice. Every effort
has been made in the preparation of this manual to ensure accuracy of the contents, but all statements, information,
and recommendations in this manual do not constitute the warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People's Republic of China
Tel: +86-755-28780808 Global Hotline: +86-755-28560808
E-mail: mobile@huawei.com Website: www.huawei.com
1
Your Phone
Earpiece
Screen
Navigation keys
Left Soft key Right Soft key
Talk Soft key/End Power ke
y
/
OK key
*key #key
Charger interface
Headset jack/
Number keys
2
Keys and Functions
Press… To…
View the dialed, received or missed calls in the idle
mode.
Make or answer a call.
Power on or off the phone (by pressing and holding
it).
End a call or reject an incoming call.
Return to the idle mode.
Confirm a selection.
Select the option displayed on the lower left corner of
the screen.
Select the option displayed on the lower right corner of
the screen.
Display the Shortcuts interface ( ), the FM
Radio interface ( ), the Alarm interface ( ),
and the Inbox interface ( ) in the standby mode.
3
Press… To…
–
Enter numbers and characters.
Speed-dial phone numbers in the idle mode (by long
pressing 2-9 keys).
Select a submenu item labeled with the
corresponding number.
Enter the *symbol.
Enable the Meeting or Outdoor profile (by pressing
and holding it) in the idle mode.
When editing, press it to display the symbol list.
Enter the # symbol.
Lock the keypad in the standby mode (by pressing
and holding it).
Unlock the keypad by pressing and .
Press it to switch between input modes when editing.
Screen Icons
Icon Description Icon Description
Network signal strength Indoor mode
Phone lock enabled Meeting mode
New voice mail Alarm clock on
No service Headset
4
Icon Description Icon Description
Message received Roaming
General mode Battery level
Missed calls Outdoor mode
5
Menu Tree
6
Installing the SIM Card and Battery
Consult the network operator whether a SIM card is needed.
Make sure that the golden area on the SIM card is facing downwards
and the cut-off edge is correctly aligned with the card holder.
Removing the Battery and SIM Card
Make sure that your phone is powered off.
Charging the Battery
1. Connect the charger to the charger interface at the bottom of your
phone.
Make sure that the arrow on the charger connector faces the front
side of the phone.
2. Connect the charger to anAC power socket.
3. During the charging, the charging icon is displaying in animation.
7
4. When the charging icon becomes static, the battery is fully
charged. Disconnect the charger from the AC power socket.
5. Press the gray buttons on both sides of the charger connector
inwards to disconnect the charger from the phone.
Using the Function Menu
1. In the idle mode, press (
Menu) to display the menu
interface.
2. Press to scroll to a menu item.
3. Press (
Ok) to display the menu.
4. Display the submenu in either of the ways:
Press to scroll to a submenu item and press (
Ok)
to display the submenu.
Press the number key corresponding to the number of a submenu
to display it.
5. Press (Back) to return to the previous menu or quit the
function menu.
Press to return to the idle mode.
Making a Call
1. In the standby mode, enter a phone number.
To make a domestic call, enter the area code and phone number. To
edit the number on the screen, press to move the cursor to the
left; press to move it to the right. Press (
Clear) to
delete the digit on the left of the cursor.
8
To make an international call, press and hold to enter the
international long distance code of "+". Then enter the number to
be dialed, in the format of "country code + region code + phone
number".
2. Press to dial the number.
3. Press to end the call.
Note When the phone is locked, enter the lock code to unlock
the phone first; otherwise, you can make emergency calls
or answer calls only.
In the standby mode, press to view the dialed calls.
Select a record and press to dial.
Select a contact from the phonebook and press to
dial.
Select a message in the inbox and press (Option),
then select Use Number, then choose Dial to make a call.
Answering a Call
When there is an incoming call, you can press to answer it;
Press or to reject the call.
If the Any-key Answer function is enabled, you can press any
key except and to answer an incoming call.
If the Headset Auto Answer function is enabled, and the headset
is connected to the phone, the incoming call is answered
automatically.
If the headset is connected to the phone, you can press the button
on the headset cable to answer or end a call.
9
Phone Lock
The phone lock protects your phone from unauthorized use. You can
change it into any numeric string.
If the phone lock function is enabled, you need to enter the correct
phone lock code when the phone is powered on or in the standby
mode.
PIN and PUK
The personal identity number (PIN) protects your SIM card from
unauthorized use. The PIN unlocking key (PUK) can unblock the
blocked PIN. Both PIN and PUK are delivered with the SIM card.
For details, consult your service provider.
If you enter wrong PINs for a specified number of times
consecutively, the phone asks you to enter the PUK code.
If you enter wrong PUKs for a specified number of times
consecutively, the SIM card is invalidated permanently. Contact your
service provider for a new card.
Locking the Keypad
In the standby mode, press for 3 seconds to lock the keypad.
When the keypad is locked, you can press to answer an
incoming call or make emergency calls.
You can press and to unlock the keypad.
When the Auto Keypad Lock function is enabled, if there is no
operation on the phone for a preset period in the standby mode, the
keypad is locked automatically.
