HG658 V2 Home Gateway

Quick Start

1 Connecting Cables

Installing the HG658 V2 on a DSL Broadband Network

In some communities, Internet service providers use telephone lines to provide

broadband access services.

If you have subscribed to digital subscriber line (DSL) broadband, you can connect

the HG658 V2 to a telephone port for Internet access.Connect your devices in the

sequence indicated in the following figure.

1 Telephone wall jack 2 Splitter 3 Telephone

4 HG658 V2b 5 Power adapter 6 Desktop computer

When configuring the HG658 V2 for the first time, use an Ethernet cable to

connect the HG658 V2 to a computer.

2 Powering On

To power on the HG658 V2, press its power button.

After the HG658 V2 is powered on, theHG658 V2 indicator turns on. If the indicators

do not behave as expected, ensure that everything is plugged in correctly.

3 Setting the Computer IP Address

Before loggingin to the HG658 V2 web management page, set the IP address of the

computer that will be used for the login.

On Windows 7

1. Choose Start >Control Panel > Network and Internet > Network and Sharing

Center.

2. Choose Change adapter settings. Right-click Local Area Connection and

choose Properties.

3. Double-clickInternet Protocol Version 4 (TCP/IPv4).

4. SelectObtain an IP address automatically and Obtain DNS server

address automatically. Click OK.

7 Set-top Box 8 Laptop computer 9 Smart Phone

10 Pad

a LINE port b PHONE port c MODEM port

4 Setting Network Access Parameters

Configuring an Automatical Connection to Access the

Internet

The HG658 V2supports you to choosethe proper connection mode automatically to

access the Internet, meaning you do not need to install dial-up software or perform

dial-up operations on your computer and just following the wizard page.

To set up an automatical connection to access the Internet:

1. Open a browser onyour computer. In the address box, enter 192.168.1.1.

PressEnter toaccess the webmanagementpage.

2. On the loginpage, enter the login user name(user by default) and password

(HuaweiUser by default). Click Log in.

To protect against unauthorized access, change the user name and

password after the first login.

You can change the account parameters on Maintain > Account

Management page.

3. On the I want to... Start Wizard page, choose Connect automatically, and

click Next.

The HG658 V2 supports DSL uplink mode, meaning you can use the HG658

V2 with a telephone port for Internet access.

After you complete the preceding settings, check the status of the Internet indicator

light. Whenthe Internet indicator light turns steady green, you can start browsing the

Internet.

You need to perform the preceding operations on a computer once only. The next

time you power on your computer, you can browse the Internet without performing

the same configurations.

Configuring a Wireless Account

After you complete the preceding settings, click Set Up WLAN, you will see the I

want to Set Up WLAN page used to configure the wireless account.

The default SSID and WLAN Key printed on the HG658 V2's rear panel are

unique and secure. If you do not want to change them, just turn the WLAN

switch on.

For security reasons or to make the password easy to remember, you can change

the wireless network name and password as follows:

1. On the I want to Set Up WLANpage, switch on the2.4 GHz WLAN network.

2. Enter your desired SSID (WLAN name) and WLAN password.

3. Click Save.

5 Wireless Connection Setup

The wireless configuration software provided by Windows is used as an example to

describe how to set up a wireless connection .

On Windows 7

1. Choose Start >Control Panel > Network and Internet > Network and Sharing

Center > Changeadaptersettings. Right-click Wireless Network

Connection, and select Connect/Disconnect.

2. From the wireless network list, select the WLAN provided by theHG658 V2.

Click Connect.

3. In the displayed dialog box, enterthe WLAN password and click OK.

4. In the wireless network list, check the WLAN connection status. If the status is

Connected,the computer is wirelessly connected to the HG658 V2.

6 Safety information

This section contains important information about the operation of your device. It also contains

information about how to use the device safely. Read this information carefully before using your

device.

Electronic device

Do not use your device if using the device is prohibited. Do not use the device if doing so causes

danger or interference with other electronic devices.

Interference with medical equipment

> Follow rules and regulations set forth by hospitals and health care facilities. Do not use your

device where prohibited.

> Some wireless devices may affect the performance of hearing aids orpacemakers. Consult

your service provider for more information.

> Pacemaker manufacturers recommend that a minimumdistance of 15 cm be maintained

between a device and a pacemaker to prevent potential interference with the pacemaker. If

using a pacemaker, hold the device on the side opposite the pacemakerand do not carry the

device in your front pocket.

Areas with flammables and explosives

> Do not use the devicewhere flammables or explosives are stored (in a gas station, oil depot,

or chemical plant, for example). Using your device in these environments increases the risk of

explosion or fire. In addition, follow the instructions indicated in text or symbols.

> Do notstoreortransport thedevicein containers with flammableliquids, gases,or explosives.

Operating environment

> Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these

environments may result in circuit malfunctions.

> Beforeconnecting anddisconnecting cables, stop using the device and disconnect it from the

power supply. Ensure that your hands are dry during operation.

> Place the device on a stable surface.

> Keep thedevice away from electronic appliances that generate strong magnetic or electric

fields, such as a microwave oven or refrigerator.

> During thunderstorms, power off your device and remove all cables connected to it to protect

against lightning strikes.

> Do not use your device during thunderstorms to protect your device against any danger

caused by lightning.

> Ideal operating temperatures are 0 °C to 40 °C. Extreme heat or cold may damage your

device or accessories.

> Keep the device and accessories in a well-ventilated and cool area away from direct sunlight.

Do not enclose or cover your device with towels or other objects. Do not place the device in a

containerwith poor heat dissipation, such as a box or bag.

> To protect your device or accessories from fire or electrical shock hazards, avoid rain and

moisture.

> Keep thedevice away from sources of heat and fire, such as a heater, microwave oven,

stove, water heater, radiator, or candle.

> Do not place any object, such as a candle or a water container, on the device. If any foreign

object or liquid enters the device, immediately stop using it, power it off, and remove all cables

connected to it. Then, contact an authorized service center.

> Observe local laws and regulations, and respect the privacy and legalrights of others.

> Do not block device openings. Reservea minimum of 10 cm around the device to dissipate

heat.

> Stop using your deviceor applications for a while if the device is overheated. If skin is

exposed toan overheated device for an extended period, low temperature burn symptoms,

such as red spots and darker pigmentation, may occur.

> Do not touch the device's antenna. Otherwise, communication quality may be reduced.

> Do not allow children or pets to bite or suck the device or accessories. Doing so may result in

damage or explosion.

> The device should be installed and operated with a minimum distance of 20 cm between the

radiator and your body.

> Keep thedevice in aplace withgood reception. The distance between the device and other

metal materials (such as metalbrackets ormetal doors and windows) should be greater than

25 cm and the distance between thedevice should be greater than 30 cm.

Child's safety

> Comply with all precautions with regard to child's safety. Letting children play with the device

or its accessories may bedangerous. The device includes detachable parts thatmay present

a choking hazard. Keep away from children.

Accessories

> Usingan unapproved or incompatible power adapter, charger or battery may cause fire,

explosion or other hazards.

> Choose only accessories approved for use with this model by the device manufacturer. The

use of any other types of accessories may void the warranty, may violate local regulations

and laws, and may be dangerous. Please contact your retailer for information about the

availability of approved accessories in your area.

Power adapter safety

> The power plug is intended to serve as a disconnect device.

> Forpluggabledevices,thesocket-outletshallbeinstallednearthedevicesandshallbeeasily

accessible.

> Unplug the power adapter fromelectricaloutlets and the device when not in use.

> Do not drop or cause animpact to the power adapter. If it is damaged, take it to anauthorized

service center for inspection.

> If the power cable is damaged (for example, the cord is exposed or broken), or the plug

loosens, stopusing it at once. Continued use may lead to electric shocks, short circuits, or

fire.

> Do not touch the power cord with wet hands or pull the power cord to disconnect the power

adapter.

> Do not touch the device or the power adapter with wet hands. Doing so may lead to short

circuits, malfunctions, or electric shocks.

> If your power adapter has been exposed to water, other liquids, or excessive moisture, take it

to an authorized service center for inspection.

> Ensure that the power adaptermeets the requirements of Clause 2.5 in IEC60950-1/

EN60950-1 and has beentested and approved according to national or local standards.

Cleaning and maintenance

> During storage, transportation, and operation of the device, keep it dry and protect it from

collision.

> Keep the device and accessories dry. Do not attempt to dry it with an external heat source,

such as a microwave oven or hair dryer.

> Do not expose your device oraccessories to extreme heat or cold. These environments may

interfere with proper function and may lead to fire or explosion.

> Avoid collision, which may lead to device malfunctions, overheating, fire, or explosion.

> Ifthedeviceisnotgoingto be usedforanextendedperiod of time,poweritoff,andremoveall

cables connected to it.

> If anything unusual occurs (for example, if the device emits smoke or any unusual sound or

smell), immediately stop using it, powerit off, remove all cables connected to it, andcontact

an authorized service center.

> Donottrample,pull,orexcessivelybendanycable.Doingsomaydamagethecable,causing

the device to malfunction.

> Beforeyou clean or maintain the device, stopusing it,stop allapplications, and disconnectall

cables connected to it.

> Do not use any chemical detergent, powder, or other chemical agents (such as alcohol and

benzene) to clean the device or accessories. These substances may cause damage to parts

or present afire hazard. Use a clean, soft, and dry cloth to clean the device and accessories.

> Do not place magnetic stripe cards, such as credit cards and phone cards, near the device for

extended periods of time. Otherwise the magnetic stripe cards may be damaged.

> Do not dismantle or remanufacture the device and its accessories. This voids the warranty

and releases the manufacturer from liability for damage. In case of damage, contact an

authorized service center for assistance or repair.

Disposal and recycling information

This symbol (with or without a solid bar) on the device, batteries (if included), and/or the

packaging,indicates thatthedeviceanditselectricalaccessories(forexample,aheadset,adapter,

or cable) and batteries should not be disposed of as household garbage. These items should not

be disposed of as unsorted municipal waste and should be taken to a certified collection point for

recycling or proper disposal.

For more detailed information about device or battery recycling, contact your local city office,

household waste disposal service, or retail store.

Disposal of the device and batteries (if included) is subject to WEEE Directive Recast (Directive

2012/19/EU) and Battery Directive (Directive 2006/66/EC). The purpose of separating WEEE and

batteries from other waste is to minimize the potential environmental impacts and human health

risk of any hazardous substances that may be present.

Reduction of hazardous substances

This device is compliant with the REACH Regulation [Regulation (EC) No 1907/2006] and RoHS

Directive Recast (Directive 2011/65/EU). Batteries (if included) are compliant with the Battery

Directive (Directive 2006/66/EC). For up-to-date information about REACH and RoHS compliance,

please visit the web site www.huaweidevice.com/certification.

EU regulatory conformance

Statement

Hereby, Huawei Technologies Co., Ltd. declares that this device is in compliance with the essential

requirements and other relevant provisions of Directive 1999/5/EC.

For the declaration of conformity, visit the web site www.huaweidevice.com/certification.

The following marking is included in the product:

This device may be operated in all member states of the EU.

Observe national and local regulations where the device is used.

This device may be restricted for use, depending on the local network.

Restrictions in the 2.4 GHz band:

Norway: This subsection does not apply for the geographical area within a radius of 20 km from the

centre of Ny-Ålesund.

FCC Regulatory Compliance

FCC statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

--Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmfulinterference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Caution: Any changes or modifications to this device not expressly approved by Huawei

Technologies Co., Ltd. for compliance could void the user's authority to operate the equipment.

This device is intended to be attached to a receiver that is not used to receive over-the-air

broadcast signals. Connection of this device in any other fashion may cause harmful interference

to radio communications and is in violation of the FCC Rules, part 15.

Consumer Information:

a)This equipment complies with Part 68 of the FCC rules and the requirements

adopted by the ACTA. On the bottom of this equipment is a label that contains,

among other information, a product identifier in the format

1622

US: HAUDL01BHG658V2. If requested, this number must be provided to the

telephone company.

b)An applicable certification jacks Universal Service Order Codes (USOC) for the

equipment is provided (i.e., RJ11C) in the packaging with each piece of approved

terminal equipment.

c)A plug and jack used to connect this equipment to the premises wiring and

telephone network must comply with the applicable FCC Part 68 rules and

requirements adopted by the ACTA. A compliant telephone cord and modular plug is

provided with this product. It is designed to be connected to a compatible modular

jack that is also compliant. See installation instructions for details.

d)The REN is used to determine the number of devices that may be connected to a

telephone line. Excessive RENs on a telephone line may result in the devices not

ringing in response to an incoming call. In most but not all areas, the sum of RENs

should not exceed five (5.0). To be certain of the number of devices that may be

connected to a line, as determined by the total RENs, contact the local telephone

company. [Forproducts approved after July23,2001,theREN forthisproductispart

of the product identifier that has the format

US: HAUDL01BHG658V2. The digits represented by ## are the REN without a

decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is separately

shown on the label.]

e)Ifthis equipment HG658 V2 causesharmtothetelephonenetwork,thetelephone

company will notify you in advance that temporary discontinuance of service may be

required. But if advance notice isn't practical, the telephone company will notify the

customer as soon as possible. Also, you will be advised of your right to file a

complaint with the FCC if you believe it is necessary.

f)The telephone company may make changes in its facilities, equipment, operations

or procedures that could affect the operation of the equipment. If this happens the

telephone company will provide advance notice in order for you to make necessary

modifications to maintain uninterrupted service.

g) Should you experience trouble with this equipment, please contact Futurewei

Technologies, Inc. Phone: +1 469-277-5852 for repair or warranty information. If

the equipment is causing harm to the telephone network, the telephone company

may request that you disconnect the equipment until the problem is resolved.

h) Please follow instructions for repairing if any (e.g. battery replacement section);

otherwise do not alternate or repair any parts of device except specified.

i)Connection to party line service is subject to state tariffs. Contact the state public

utility commission, public service commission or corporation commission for

information.

j)NOTICE: If your home has specially wired alarm equipment connected to the

telephone line, ensure the installation of this device does not disable your alarm

equipment. If you have questions about what will disable alarm equipment, consult

your telephone company or a qualified installer.

k)This equipment is hearing aid compatible.

NOTICE: According to telephone company reports, AC electrical surges, typically

resulting from lightning strikes, are very destructive to telephone equipment

connected to AC power sources. To minimize damage from these types of surges, a

surge arrestor is recommended.

Applicable for Coin or Pay Phone Only

To comply with state tariffs, the telephone company must be given notification prior

to connection for customer-owned coin or credit card phone. In some states, the state

public utilitycommission, publicservice commission or corporation commissionmust

give prior approval of connection.

7 Obtaining More Information

Thanks for purchasing the HG658 V2 Home Gateway (HG658 V2 for short).

This quick startguide will show you how to connect your HG658 V2 to a network and

access the Internet. The figures in this guide are for reference only. The appearance

and display features may vary slightly depending on the actual product version.

For more information, visit http://consumer.huawei.com/en/.

Please visit www.huaweidevice.com/worldwide/support/hotline for recently updated

hotline and email address in your country or region.

8 Legal Notice

rights reserved.

THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND DOES NOT

CONSTITUTE ANY KIND OF WARRANTIES.

To better understand how we protect your personal information, please see the

Andere Handbücher für HG658 V2

Inhaltsverzeichnis

Andere Huawei Tor Handbücher

Huawei

Huawei E960 HSDPA Bedienungsanleitung

Huawei

Huawei HG532f Bedienungsanleitung

Huawei

Huawei HG659B Bedienungsanleitung

Huawei

Huawei ICE D-20 EC506 Bedienungsanleitung

Huawei

Huawei DG8245V Bedienungsanleitung

Huawei

Huawei HG532D Bedienungsanleitung

Huawei

Huawei HG630 Bedienungsanleitung

Huawei

Huawei HG532t Bedienungsanleitung

Huawei

Huawei ME60 Series Gebrauchsanweisung

Huawei

Huawei eA680-950 Bedienungsanleitung

Huawei

Huawei HG530 Bedienungsanleitung

Huawei

Huawei EchoLife HG532 Bedienungsanleitung

Huawei

Huawei OptiXstar B850G-8E8P3W3 Bedienungsanleitung

Huawei

Huawei eSpace EGW1530B Bedienungsanleitung

Huawei

Huawei RRU3262 Bedienungsanleitung

Huawei

Huawei HG630 Bedienungsanleitung

Huawei

Huawei Echolife HG8245Q5 Bedienungsanleitung

Huawei

Huawei USG6305 Bedienerhandbuch

Huawei

Huawei HG630 Bedienungsanleitung

Huawei

Huawei B970b Bedienungsanleitung

Huawei

Huawei E960 HSDPA Bedienungsanleitung

Huawei

Huawei B222s Bedienungsanleitung

Huawei

Huawei IAD108A Bedienungsanleitung

Huawei

Huawei eSpace IAD208E(M) Bedienungsanleitung

Beliebte Tor Handbücher anderer Marken

LST

LST M500RFE-AS Bedienungsanleitung

Kinnex

Kinnex Media Gateway Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace 2N StarGate Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Bedienungsanleitung

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Bedienungsanleitung

Telsey

Telsey CPVA 500 - SIP Bedienungsanleitung

RTA

RTA 460A-NNA4 Technisches Datenblatt

Shaw

Shaw Gateway HDPVR Bedienungsanleitung

ABB

ABB VSN900 Kurzanleitung

Commander

Commander Pulse Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Bedienungsanleitung

NETGEAR

NETGEAR C6300BD Bedienungsanleitung

Amit

Amit CDW531AM Bedienungsanleitung

HMS

HMS Netbiter EasyConnect EC150 Bedienungsanleitung

AT&T

AT&T U-verse 3801 Gebrauchs- und Pflegehandbuch

Logic IO

Logic IO RTCU MX2 turbo Bedienungsanleitung

Suttle

Suttle MediaMAX MXM-521 Bedienungsanleitung

RTA

RTA 460MCBC-N2E Technisches Datenblatt
