HG532e Home Gateway

User Guide

HUAWEI TECHNOLOGIES CO., LTD.

HG532e Home Gateway

V100R001

User Guide

202494_03

Huawei Technologies Co., Ltd. provides customers with comprehensive

technical support and service. Please feel free to contact our local office

or company headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: mobile@huawei.com

rights reserved.

No part of this manual may be reproduced or transmitted in any form or by any means

without prior written consent of Huawei Technologies Co., Ltd. and its affiliates

("Huawei").

The product described in this manual may include copyrighted software of Huawei and

possible licensors. Customers shall not in any manner reproduce, distribute, modify,

decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense

the said software, unless such restrictions are prohibited by applicable laws or such

actions are approved by respective copyright holders.

Trademarks and Permissions

, , and are trademarks or registered trademarks of Huawei

Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned may be the property

of their respective owners.

Notice

Some features of the product and its accessories described herein rely on the software

installed, capacities and settings of local network, and therefore may not be activated or

may be limited by local network operators or network service providers.

Thus, the descriptions herein may not exactly match the product or its accessories which

you purchase.

Huawei reserves the right to change or modify any information or specifications

contained in this manual without prior notice and without any liability.

DISCLAIMER

ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS

REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR

CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT

SHALL HUAWEI BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR

CONSEQUENTIAL DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE,

DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS REGARDLESS OF

WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT.

THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILITY FOR

PERSONAL INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS SUCH A

LIMITATION) OF HUAWEI ARISING FROM THE USE OF THE PRODUCT

DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE AMOUNT PAID BY

CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and be

responsible to obtain all necessary governmental permits and licenses in order to export,

re-export or import the product mentioned in this manual including the software and

technical data therein.

To better understand how we protect your personal information, please see the privacy

policy at http://consumer.huawei.com/privacy-policy.

ErP Product Information

Hereby, Huawei Technologies Co.,Ltd. declares that the product meets the directive

2009/125/EC and its implementation regulation (EC) NO 1275/2008 amended by (EC)

278/2009,(EC) 642/2009,(EU) 617/2013,(EU) 801/2013,and its implementation

regulation (EC) NO 278/2009.

The power consumption of product in networked standby if all wired network ports are

connected and all wireless network ports are activated is 4.6 W.

For the product information displayed on the manufacturers’ freely accessible websites

required by (EU) No 801/2013, please visit http://consumer.huawei.com/certification.

Contents

1Connecting the Cables and Getting Started................................... 1

1.1 Connecting Cables ........................................................................1

1.2 Powering On the HG532e..............................................................2

2Setting Network Access Parameters.............................................. 3

2.1 Logging in to the Web-based Configuration Utility ..........................3

2.2 Configuring a Dial-up Connection to Access the Internet .................4

2.3 Configuring a Wireless Network Name and Password......................4

3Setting Up a Wireless Connection ................................................. 5

3.1 Setting Up a Wireless Connection Using the WPS Button ........6

3.2 Setting Up a Wireless Connection Manually..............................6

4Configuring the HG532e .............................................................. 9

4.1 Changing the User Name and Password for the Web-based

Configuration Utility...........................................................................9

4.2 Enabling or Disabling the Wireless Network Function ...................10

Using the WLAN Button ............................................................10

Using the Web-based Configuration Utility ..................................10

4.3 Changing the Wireless Network Name and Password.....................10

4.4 Changing the PPP Account ..........................................................11

4.5 Restoring Default Settings ...........................................................12

4.6 Restarting the HG532e ................................................................12

5FAQs ......................................................................................... 13

6Technical Specifications.............................................................. 19

6.1 Indicators ...................................................................................19

6.2 Ports and Buttons........................................................................21

6.3 Default Settings ..........................................................................22

6.4 Product Specifications.................................................................22

1 Connecting the Cables and Getting Started

Thank you for purchasing the HG532e Home Gateway (hereinafter referred to

as the HG532e).

1.1 Connecting Cables

The following figure shows an example of how to connect the cables. In this

example, the HG532e is connected to a desktop computer, a laptop computer,

and a telephone.

1. Power adapter

2. Desktop computer

3. Telephone

4. Splitter

5. Telephone wall jack

6. Laptop computer

a. MODEM port

b. PHONE port

c. LINE port

1.2 Powering On the HG532e

After connecting the cables, press the On/Off button on the side panel to power

on the HG532e.

The ADSL indicator lights up and starts blinking. This indicates that the

asymmetric digital subscriber line (ADSL) port activation is in progress. The

blinking may last from 40 seconds to 3 minutes. When the ADSL indicator stops

blinking and remains on, the HG532e is working correctly.

To power off the HG532e, press the On/Off button on the side

panel, and then unplug the power adapter.

2 Setting Network Access Parameters

2.1 Logging in to the Web-based Configuration

Utility

Most parameters of the HG532e are preset before delivery to meet common

application scenarios at homes. To check the HG532e's working status or to

configure certain advanced network functions, use the web-based configuration

utility.

To log in to the web-based configuration utility:

Step 1 Launch a browser on your computer. Enter http://192.168.1.1 in the

address box, and press Enter.

Step 2 On the login page, enter your user name (default is user) and

password (default is user).

For security, you can change the user name and password for

Password for the Web-based Configuration Utility“.

If the user name and password have been changed, use the

correct user name and password for login.

Step 3 Click Login.

After verification, the web-based configuration utility is displayed.

The first time you log in to the web-based configuration utility, a

configuration wizard is displayed. To skip the wizard and further

configure your HG532e, click Here when the following message

displays: Click Here to enter the advanced configuration page.

2.2 Configuring a Dial-up Connection to Access the

Internet

The HG532e works in PPP mode by default. The HG532e starts to set up a

dial-up connection automatically after starting up, meaning you do not need to

install dial-up software or perform dial-up operations on your computer.

To set up a dial-up connection to access the Internet:

Step 1 Log in to the web-based configuration utility.

Step 2 On the Quick Configure Home Gateway: PPP Account page, enter

the user name and password provided by your service provider for

dial-up connections in Username and Password, and click Next.

This page is displayed only when the gateway is working in

factory setting mode.

You can also configure the user name and password by

choosing Basic >WAN. For details, see section 4.4

"Changing the PPP Account."

After you complete the preceding settings, check the status of the Internet

indicator light. When the Internet indicator light turns steady green, you can

start browsing the Internet.

You need to perform the preceding operations on a computer once only. The

next time you power on your computer, you can browse the Internet without

performing the same configurations.

2.3 Configuring a Wireless Network Name and

Password

After you complete the preceding settings in PPP mode, you will see a

configuration wizard page used to configure a wireless account. The

configuration wizard page is displayed when you have not modified

any wireless parameters.

The default SSID and WLAN Key printed on the HG532e's rear

panel are unique and secure. If you do not want to change them,

click Next.

For security reasons or to make the password easy to remember, you can

change the wireless network name and password on the wizard page as

follows:

Step 1 Log in to the web-based configuration utility.

Step 2 On the Quick Configure Home Gateway: Wireless Network page is

displayed. Set WLAN SSID and Key, and click Next.

After you set WLAN SSID and Key, the home page of the web-based

configuration utility is displayed. A navigation menu is displayed on the left. You

can click a link to display the relevant page on the right.

3 Setting Up a Wireless Connection

If a wireless network adapter is available on your computer, you can connect

your computer to the HG532e over a wireless connection.

The method for installing the wireless adapter and its driver varies

according to different vendors. For details, see the installation guide

provided by the vendor of your wireless adapter.

The wireless network function is enabled on the HG532e before delivery. To

check the function status, see section 4.2 "Enabling or Disabling the Wireless

Network Function."

There are two methods for setting up a wireless connection between the

HG532e and your computer.

The preceding configuration needs to be performed only once.

You can also configure the WLAN SSID and key by choosing

Basic > WLAN. For details, see section 4.3 "Changing the

Wireless Network Name and Password".

Andere Handbücher für HG532e

Inhaltsverzeichnis

Andere Huawei Tor Handbücher

Huawei

Huawei Echolife EG8245Q Bedienungsanleitung

Huawei

Huawei EchoLife BM635 WiMAX CPE Bedienungsanleitung

Huawei

Huawei HG630 Bedienungsanleitung

Huawei

Huawei BTS3902E WCDMA Leitfaden

Huawei

Huawei HG530 Bedienungsanleitung

Huawei

Huawei HG256s Bedienungsanleitung

Huawei

Huawei HG659B Bedienungsanleitung

Huawei

Huawei HG659 Bedienungsanleitung

Huawei

Huawei HG523 Bedienungsanleitung

Huawei

Huawei HG532e Bedienungsanleitung

Huawei

Huawei HG630B Bedienungsanleitung

Huawei

Huawei RRU3262 Bedienungsanleitung

Huawei

Huawei EchoLife HG520 Bedienungsanleitung

Huawei

Huawei H350L/B890-66s Bedienungsanleitung

Huawei

Huawei E960 HSDPA Bedienungsanleitung

Huawei

Huawei HG552d Bedienungsanleitung

Huawei

Huawei eSpace IAD208E(M) Bedienungsanleitung

Huawei

Huawei eLTE2.2 eA660 Series Bedienungsanleitung

Huawei

Huawei Sunrise Internet Box 5G Bedienungsanleitung

Huawei

Huawei HG523a Bedienungsanleitung

Huawei

Huawei HG655d Bedienungsanleitung

Huawei

Huawei HG659B Bedienungsanleitung

Huawei

Huawei E960 HSDPA Bedienungsanleitung

Huawei

Huawei HG532c Bedienungsanleitung

Beliebte Tor Handbücher anderer Marken

LST

LST M500RFE-AS Bedienungsanleitung

Kinnex

Kinnex Media Gateway Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace 2N StarGate Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Bedienungsanleitung

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Bedienungsanleitung

Telsey

Telsey CPVA 500 - SIP Bedienungsanleitung

RTA

RTA 460A-NNA4 Technisches Datenblatt

Shaw

Shaw Gateway HDPVR Bedienungsanleitung

ABB

ABB VSN900 Kurzanleitung

Commander

Commander Pulse Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Bedienungsanleitung

NETGEAR

NETGEAR C6300BD Bedienungsanleitung

Amit

Amit CDW531AM Bedienungsanleitung

HMS

HMS Netbiter EasyConnect EC150 Bedienungsanleitung

AT&T

AT&T U-verse 3801 Gebrauchs- und Pflegehandbuch

Logic IO

Logic IO RTCU MX2 turbo Bedienungsanleitung

Suttle

Suttle MediaMAX MXM-521 Bedienungsanleitung

RTA

RTA 460MCBC-N2E Technisches Datenblatt
