Huawei MT886 Bedienungsanleitung

MT886 ADSL CPE

User Guide

HUAWEI TECHNOLOGIES CO., LTD.

MT886 ADSL CPE

V100R001

User Guide

Issue

Date

2011-10-29

Part Number

103178

Huawei Technologies Co., Ltd. provides customers with comprehensive

technical support and service. Please feel free to contact our local office

or company headquarters.

Huawei Technologies Co., Ltd.

Address:

Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website:

http://www.huawei.com

Email:

[email protected]

No part of this document may be reproduced or transmitted in any form or by any means

without prior written consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of Huawei

Technologies Co., Ltd and possible licensors. Customers shall not in any manner

reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer,

lease, assign, or sublicense the said software, unless such restrictions are prohibited by

applicable laws or such actions are approved by respective copyright holders under

licenses.

Trademarks and Permissions

, , and

are trademarks or registered trademarks of Huawei

Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the property of

their respective owners.

Notice

Some features of the product and its accessories described herein rely on the software

installed, capacities and settings of local network, and may not be activated or may be

limited by local network operators or network service providers. Thus the descriptions

herein may not exactly match the product or its accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify any information or

specifications contained in this manual without prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED

BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR

IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN

RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL

HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL,

INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,

REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and will

obtain all necessary governmental permits and licenses in order to export, re-export or

import the product mentioned in this manual including the software and technical data

therein.

Contents

1Warnings and Precautions ....................................................................... 1

2Connecting the Cables and Getting Started............................................ 3

2.1 Connecting the Cables..................................................................................3

2.2 Getting Started .............................................................................................3

3Setting the Network-Access Parameters ................................................. 4

3.1 Accessing the Network Through the Embedded PPP Dial-up Software on the

MT886 .................................................................................................................4

3.2 Accessing the Network Through the PPP Dial-up Software on Your

Computer .............................................................................................................5

4Configuring the MT886 ............................................................................ 6

4.1 Changing the Administrator Password Used for Logging In to the

Web-Based Configuration Utility........................................................................6

4.2 Changing the IP Address Used for Logging In to the Web-Based

Configuration Utility ...........................................................................................6

4.3 Restoring Default Settings............................................................................7

5FAQs........................................................................................................... 7

6Appendix .................................................................................................. 10

6.1 Indicators....................................................................................................10

6.2 Interfaces and Buttons................................................................................10

6.3 Default Settings..........................................................................................11

6.4 Technical Specifications.............................................................................11

1 Warnings and Precautions

To use the device properly and safely, read these warnings and precautions carefully

and strictly observe them during operation. Unless otherwise specified, the term

"device" refers to the device and its accessories.

Basic Requirements

During storage, transportation, and operation of the device, keep it dry and prevent

it from colliding with other objects.

Do not dismantle the device. In case of any fault, contact an authorized service

center for assistance or repair.

Without authorization, no organization or individual can change the mechanical,

safety, or performance design of the device.

When using the device, observe all applicable laws and regulations and respect the

legal rights of other people.

Environmental Requirements for Using the Device

Before connecting and disconnecting cables, stop using the device, and then

disconnect it from the power supply. Ensure that your hands are dry during

operation.

Keep the device far from sources of heat and fire, such as a heater or a candle.

Keep the device far from electronic appliances that generate strong magnetic or

electric fields, such as a microwave oven or a refrigerator.

Place the device on a stable surface.

Place the device in a cool and well-ventilated indoor area. Do not expose the device

to direct sunlight.

Use the device in an area with a temperature ranging from 0°C to 40°C.

Do not block the openings on the device with any object. Reserve a minimum space

of 10 cm around the device for heat dissipation.

Do not place any object (such as a candle or a water container) on the device. If any

foreign object or liquid enters the device, stop using the device immediately, power

it off, remove all the cables connected to it, and then contact an authorized service

center.

During thunderstorms, power off the device, and then remove all the cables

connected to it to prevent it from getting damaged due to lightning strikes.

Areas with Inflammables and Explosives

Do not use the device where inflammables or explosives are stored, for example, in

a gas station, oil depot, or chemical plant. Otherwise, explosions or fires may occur.

In addition, follow the instructions indicated in text or symbols.

Do not store or transport the device in the same box as inflammable liquids, gases,

or explosives.

Accessory Requirements

Use only the accessories supplied or authorized by the device manufacturer.

Otherwise, the performance of the device may get affected, the warranty for the

device or the laws and regulations related to telecommunications terminals may

become null and void, or an injury may occur.

Do not use the power adapter if its cable is damaged. Otherwise, electric shocks or

fires may occur.

Ensure that the power adapter meets the specifications indicated on the device

nameplate.

Ensure that the power adapter meets the requirements of Clause 2.5 in

IEC60950-1/EN60950-1 and it is tested and approved according to national or local

standards.

For pluggable device, the socket-outlet shall be installed near the device and shall

be easily accessible.

Safety of Children

Keep the device and its accessories out of the reach of children. Otherwise, they may

damage the device and its accessories by mistake, or they may swallow the small

components of the device, causing suffocation or other dangerous situations.

Maintenance

If the device is not used for a long time, power it off, and then remove all the cables

connected to it.

If any exception occurs, for example, if the device emits any smoke or unusual

sound or smell, stop using the device immediately, power it off, remove all the

cables connected to it, and then contact an authorized service center.

Do not trample, pull, or overbend any cable. Otherwise, the cable may get damaged,

causing malfunction of the device.

Before cleaning the device, stop using it, power it off, and then remove all the

cables connected to it.

Use a clean, soft, and dry cloth to clean the device shell. Do not use any cleaning

agent or spray to clean the device shell.

2 Connecting the Cables and Getting

Started

2.1 Connecting the Cables

The following figure shows how to connect the cables of the MT886.

####

1. Power adapter 2. Computer 3. Telephone

4. Splitter 5. Telephone jack on the wall

2.2 Getting Started

To power on the MT886, press the power button on the top of the MT886.

After you power on the MT886, the ADSL indicator blinks (for less than three minutes),

which indicates that the MT886 is being activated. Later, the ADSL indicator turns

solid on. The POWER indicator is also solid on, which indicates that the MT886 is

working properly.

3 Setting the Network-Access Parameters

By configuring the MT886 and your computer, you can choose any of the following

methods to surf the Internet:

Accessing the Network Through the Embedded PPP Dial-up Software on the

MT886

Accessing the Network Through the PPP Dial-up Software on Your Computer

3.1 Accessing the Network Through the

Embedded PPP Dial-up Software on the

MT886

If you select this method for accessing the network, the MT886 starts to set up a dial-up

connection automatically after the startup. You can access the network after you power

on your computer. You do not need to install any special dial-up software on your

computer or perform dial-up operations on your computer. To configure the MT886

and your computer for the network access, do as follows:

Step 1 Log in to the Web-based configuration utility of the MT886.

1. Launch the Internet Explorer on your computer. Enter http://192.168.1.1

in the address bar, and then press Enter.

2. In the displayed dialog box, enter the user name and the password, and

then click OK.

By default, the user name is admin and the password is admin. After the

user name and the password are verified, you can access the Web-based

configuration utility.

Step 2 Enable the embedded dial-up function.

1. In the navigation tree on the left of the Web-based configuration utility,

choose Basic > WAN Setting.

2. Select a PVC number, such as 1, from the PVC drop-down combo box.

3. Enter the VPI and VCI that are provided by the network operator in the

VPI and VCI text boxes.

4. Select Yes from the Active drop-down combo box.

5. Select Routing from the Mode drop-down combo box.

6. Select PPPoE from the Encapsulation drop-down combo box.

7. Enter the user name and password that are provided by the network

operator in the Username and Password text boxes, and keep the default

settings of other parameters.

8. Click Submitto save the settings.

After you complete the preceding settings, you can surf the Internet.

You need to perform the preceding operations on a computer once only. The next time

when you power on your computer, you can surf the Internet without any configuration.

3.2 Accessing the Network Through the PPP

Dial-up Software on Your Computer

If you select this method for accessing the network, you need to install and configure

the dial-up software on your computer. In addition, you need to perform dial-up

operations on your computer upon each startup. To configure the MT886 and your

computer for the network access, do as follows:

Step 1 Set the working mode of the MT886 to Bridge.

For details, refer to the procedure for enabling the embedded dial-up function

described in Step 2 in section 3.1 "Accessing the Network Through the

Embedded PPP Dial-up Software on the MT886." Note that Bridge is

selected from the Mode drop-down combo box.

Step 2 Install and configure the PPP dial-up software on your computer.

The PPP dial-up software is pre-installed on certain computer operating

systems. To create a dial-up connection, do as follows (taking the Windows

XP operating system as an example):

1. Choose Start > All Programs > Accessories > Communications >

Network Connections.

2. Click Create a new connection in Network Tasksto display the New

Connection Wizard window, and then click Next.

3. Select Connect to the Internet, and then click Next.

4. Select Set up my connection manually, and then click Next.

5. Select Connect using a broadband connection that requires a user

name and password, and then click Next.

6. Enter the name (as desired) of the dial-up connection in ISP Name, and

then click Next.

7. Select Anyone's use or My use only, and then click Next.

8. Enter the user name and password provided by the network operator and

used for the dial-up connection, and then click Next.

9. Select Add a shortcut to this connection to my desktop, and then click

Finish.

An icon for the dial-up connection is displayed on the desktop of your

computer.

You need to perform the preceding operations only once for creating a network

connection. After the network connection is created, to access the network,

double-click the icon for the dial-up connection, and then click Connect in the

displayed dialog box.

4 Configuring the MT886

4.1 Changing the Administrator Password Used

for Logging In to the Web-Based

Configuration Utility

For safety reasons or to make the password easy to remember, you can change the

administrator password for login after logging in to the Web-based configuration

utility.

To change the password, do as follows:

Step 1 Log in to the Web-based configuration utility.

Step 2 Choose Tools > System Management in the navigation tree to display the

system management page.

Step 3 Select the admin from the User name text box.

Step 4 Enter the Current password in the Old Password text box. Enter the new

password in the New Password text box. Then enter the new password again

in the Retype to confirm text box for confirmation.

Step 5 Click Submit to save the settings.

After you change the password successfully, the current page jumps to the page for

logging in to the Web-based configuration utility. To log in to the Web-based

configuration utility, enter the new password, and then click OK.

If you forget the password that has been changed, you can restore the

default settings of the MT886 by pressing and holding the RESET button

for over six seconds. Then, the password that is used for logging in to the

Web-based configuration utility are restored to default values. After you

restore the default settings, however, your customized data is lost.

Therefore, use this function with caution.

4.2 Changing the IP Address Used for Logging

In to the Web-Based Configuration Utility

To make the login IP address easy to remember, you can change the IP address after

logging in to the Web-based configuration utility.

To change the IP address, do as follows:

Step 1 Choose Basic > LAN Setting in the navigation tree to display the LAN

settings page.

Andere Handbücher für MT886

Inhaltsverzeichnis

Andere Huawei Modem Handbücher

Huawei

Huawei HiLink K3773 Bedienungsanleitung

Huawei

Huawei EC168C Bedienungsanleitung

Huawei

Huawei E170 HSPA Bedienungsanleitung

Huawei

Huawei SoftBank 005HW Bedienungsanleitung

Huawei

Huawei E156B Bedienungsanleitung

Huawei

Huawei EC1261 Bedienungsanleitung

Huawei

Huawei E169 Bedienungsanleitung

Huawei

Huawei E5573CS-509 Bedienungsanleitung

Huawei

Huawei E3272 Gebrauchsanweisung

Huawei

Huawei Hilink E3276s Bedienungsanleitung

Huawei

Huawei E600 Bedienungsanleitung

Huawei

Huawei Maxis E5832 Bedienungsanleitung

Huawei

Huawei EC152 Bedienungsanleitung

Huawei

Huawei WiMAX CPE Bedienungsanleitung

Huawei

Huawei EC 121 Bedienungsanleitung

Huawei

Huawei Vodafone USB Extreme Installations- und Betriebshandbuch

Huawei

Huawei R227h Bedienungsanleitung

Huawei

Huawei HiLink E3131 Installationsanleitung

Huawei

Huawei E1556 Bedienungsanleitung

Huawei

Huawei E397 Bedienungsanleitung

Huawei

Huawei E585 Bedienungsanleitung

Huawei

Huawei Mobile Broadband USB Stick Bedienungsanleitung

Huawei

Huawei E1615 Bedienungsanleitung

Huawei

Huawei E270 Bedienungsanleitung

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Zte

Zte WiMAX Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Zte

Zte MF823 Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
