Huawei E2010 Montageanleitung

Thank you for choosing the Mobile Broadband USB

Modem. With your USB Modem, you can access a

wireless network at high speed.

Note:

This manual describes the appearance of the USB Modem, as well as the procedures for

preparation, installation, and removal. For operation details about the management

program, see the online help included in the management program.

Getting to Know Your USB Modem

The following figure shows the appearance of the USB Modem. It is provided only for your

reference. The actual product may be different.

nStrap Hole

You can tie a strap to the USB Modem through the strap hole.

oPush Button

You can press the push button to open the USB Modem Cover.

pIndicator

It indicates the status of the USB Modem.

zGreen, blinking twice every 3s: The USB Modem is powered on.

zGreen, blinking once every 3s: The USB Modem is registering with a 2G network.

zBlue, blinking once every 3s: The USB Modem is registering with a 3G/3G+ network.

zGreen, solid: The USB Modem is connected to a 2G network.

zBlue, solid: The USB Modem is connected to a 3G network.

zCyan, solid: The USB Modem is connected to a 3G+ network.

zOff: The USB Modem is removed.

qUSB Connector

It connects the USB Modem to a PC.

rBolt

It holds the USB Connector when the USB Modem Cover is closed.

sSIM/USIM Card Slot

It holds a Subscriber Identity Module (SIM)/Universal Subscriber Identity Module (USIM)

card.

tMicroSD Card Slot

It holds a microSD card.

Getting Your USB Modem Ready

1. Press the push button and then open the USB Modem Cover.

2. Insert the SIM/USIM card and the microSD card into the corresponding card slots, as

shown in the following figure.

3. Close the USB Modem Cover.

Note:

zThe microSD card is an optional accessory. If it is not provided in the package, you can

buy one yourself.

zEnsure that the beveled edge of the SIM/USIM card is properly aligned with that of the

SIM/USIM card slot and the microSD card is inserted according to the direction as

labeled on the microSD card slot.

zDo not remove the microSD card or SIM/USIM card when the card is in use. Otherwise,

the card as well as your USB Modem may get damaged and the data stored on the card

may be corrupted.

Installation/Removal Guide

The procedure for installing the management program depends on the operating system

(OS) installed on your PC. The following sections take Windows XP as an example.

Connecting the USB Modem to a PC

Plug the USB Modem into the USB port of your PC.

Installing the USB Modem Management Program

1. Connect the USB Modem with the PC.

2. The OS automatically detects and recognizes the new hardware and starts the

installation wizard.

Note:

If the auto-run program does not respond, find the AutoRun.exe file in the driver path.

Then double-click AutoRun.exe to run the program.

3. Follow the on-screen instructions of the installation wizard.

4. After the program is installed, a shortcut icon for the management program appears on

the desktop.

Starting the Management Program

After being installed, the management program starts automatically. Then every time the

USB Modem is connected to the PC, the management program starts automatically.

You can also double-click the shortcut icon on the desktop to start the management

program.

Removing the USB Modem

1. Double-click in the notification area. Then the Unplug or Eject Hardware dialog

box appears.

2. Select the corresponding hardware and then click Stop.

3. When the message "It is safe to remove the device" appears, remove the USB Modem.

Uninstalling the Management Program

1. Choose Start > Control Panel > Add or Remove Programs.

2. Find the management program and click Remove to uninstall the management

program.

Note:

Exit the management program before uninstalling it.

Version: V100R001_01 Part Number: 31010CMD
