Huawei MT886 Bedienungsanleitung

MT886 ADSL CPE

Quick Start

1 Connecting the Cables

The following figure shows how to connect the cables of the MT886.

####

1. Power adapter

2. Computer

3. Telephone

4. Splitter

5. Telephone jack on the wall

To connect the cables, do as follows:

Step 1 Connect the telephone jack on the wall to the LINE interface on the splitter

with a telephone line. Connect the telephone to the PHONE interface on the

splitter with a telephone line.

####

########

Step 2 Connect the ADSL interface on the MT886 to the MODEM interface on the

splitter with a telephone line.

####

########

Step 3 Connect the LAN interface on the MT886 to the Ethernet interface on your

computer with a network cable.

Step 4 Connect the POWER interface on the MT886 to the power socket with the

power adapter.

2 Getting Started

To power on the MT886, press the power button on the top of the MT886.

After you power on the MT886, the ADSL indicator blinks (for less than three minutes),

which indicates that the MT886 is being activated. After the ADSL indicator stops

blinking, the POWER and ADSL indicators turn solid on, which indicates that the

MT886 is working properly.

3 Configuring the MT886

Power off the MT886 if the embedded dial-up function is enabled but

the MT886 is not used for network access. Otherwise, even if you have

shut down your computer, the network operator may still charge you for

network access.

To configure the MT886, do as follows:

Step 1 Log in to the Web-based configuration utility of the MT886.

1. Launch the Internet Explorer on your computer. Enter http://192.168.1.1 in

the address bar, and then press Enter.

2. In the displayed dialog box, enter the user name and the password, and then

click OK.

By default, the user name is admin and the password is admin. After the

user name and the password are verified, you can access the Web-based

configuration utility.

Step 2 Enable the embedded dial-up function.

1. In the navigation tree on the left of the Web-based configuration utility,

choose Basic > WAN Setting.

2. Select a PVC number, such as 1, from the PVC drop-down combo box.

3. Enter the VPI and VCI that are provided by the network operator in the VPI

and VCI text boxes.

4. Select Yes from the Active drop-down combo box.

5. Select Routing from the Mode drop-down combo box.

6. Select PPPoE from the Encapsulation drop-down combo box.

7. Enter the user name and password that are provided by the network operator

in the Username and Password text boxes, and keep the default settings of

other parameters.

8. Click Submit to save the settings.

After you complete the preceding settings, you can surf the Internet.

You need to perform the preceding operations on a computer once only. The next time

when you power on your computer, you can surf the Internet without any configuration.

4 Indicators

Indicator

Status

Description

POWER

Solid on

The MT886 is powered on.

Off

The MT886 is powered off.

ADSL

Blinking

The MT886 is being activated.

Solid on

The MT886 is activated.

Off

The MT886 is powered off.

LAN1, LAN2

Blinking

Data is being transmitted through the Ethernet

interface.

Solid on

The Ethernet connection is set up.

Off

The Ethernet connection is not set up.

Trademarks and Permissions

, , and

are trademarks or registered trademarks of Huawei

Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the property of their respective

owners.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY

APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,

INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE

ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL

HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL,

INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE,

DATA, GOODWILL OR ANTICIPATED SAVINGS.

Issue: 03 (2011-10-29)

Part Number: 102158
