B882 4G LTE Jet Hub

Getting Started Guide

Thank You for Purchasing the B882 4G LTE Jet Hub!

Before You Begin

What’s in the Box :

1. B882 4G LTE Jet Hub

2. Power adapter

3. 1 Ethernet cable (Yellow)

4. Getting Started Guide

5. Safety Information Guide

6. Warranty Information Guide

If anything is missing or damaged, return the entire package to your point of

purchase.

1Getting Started: Setting up your

B882 4G LTE Jet Hub

Follow these simple steps to setup your 4G LTE Jet Hub.

Place the 4G LTE Jet Hub at an indoor open area or close to a window if possible.

Obstructions such as concrete or wooden walls may affect the transmission of

wireless signals.

Keep the 4G LTE Jet Hub away from the household electrical appliances that

produce strong electric or magnetic fields, such as microwaves, refrigerators, or

satellite dish antennas.

Step 1Insert SIM card into the Jet Hub’s SIM Card Slot.

If your SIM card was not activated and inserted into your 4G LTE Jet Hub at your

point of purchase, please call MTS Technical Support at 204-225-5687 or toll free

outside Manitoba at 1-800-883-2054.

Before removing the SIM card, ensure that Jet Hub is powered off and

disconnected from the power outlet.

Step 2Connect the power adapter to the power port and plug into the wall

socket.

The AC power supply included with the Huawei B882 4G LTE Jet Hub is not

compatible with the Huawei B890 4G LTE Jet Hub. Int

erchanging the AC power supply

will cause damage to the AC power supply.

The Jet Hub will power on automatically.

2Getting Started: Setting up an

Internet Connection

Connecting your devices (computer, laptop, tablet, etc.) to the Internet

You are able to connect to the Internet via a wired or wireless (Wi-Fi) connection.

Follow the instructions below to set up your connection of choice.

Wired connection with an Ethernet Cable

Step 1Connect the Yellow Ethernet cable provided to one of the 3 LAN ports

and connect the other end to your computer.

Step 2Wait approximately 30 - 60 seconds for the connection to establish. Check

the indicators on the front panel of your Jet Hub. If they are lit as outlined

you are ready to use the internet with your new Jet Hub!

Do not connect the Yellow Ethernet cable to the WAN port that is closest to the

right hand side of the device.

Power

Solid White: the Jet Hub is powered on.

Wireless Signal

indicator

Solid Blue or Cyan: the Jet Hub is registered

with the wireless network.

If this indicator is red and blinking, power off the

Jet Hub and ensure your SIM card is inserted

correctly.

If this continues after turning the 4G LTE Jet Hub

on again, please contact MTS Technical Support

at 204-225-5687 or toll free outside Manitoba at

1-800-883-2054 to ensure your SIM card is

activated.

Wireless Dial-up

indicator

Solid: the Jet Hub is connected to the wireless

network.

If this indicator is blinking continuously, power

off the Jet Hub for 2 minutes and try again.

/ /

LAN indicators

Solid: 1, 2 or 3 will be lit depending on which

LAN port you are connected to.

Blinking: data is transferring.

Wireless (Wi-Fi) Connection

Follow these simple steps to connect up to 32 Wi-Fi enabled devices to the Internet

through your 4G LTE Jet Hub:

Step 1Ensure that on the front panel is solid and Wi-Fi is enabled on your

device (computer, laptop, tablet, etc.).

Step 2From your device, scan for wireless networks in your area. Connect to the

network name that matches the Wi-Fi Name (SSID) found on the Wireless

Security Sticker.

Step 3When prompted for your wireless security settings, enter the Wi-Fi Password

listed on the Wireless Security Sticker (Wi-Fi Password is case sensitive).

Step 4Wait approximately 30 seconds for the connection to establish. Your Wi-Fi

enabled device will notify you when it is connected.

Step 5You may connect up to 32 Wi-Fi enabled devices. Repeat steps 1 through 4.

The Wi-Fi Name (SSID) and Wi-Fi Password (WIFI KEY) are printed on the

Wireless Security Sticker located on the bottom of your B882 4G LTE Jet Hub.

To protect your wireless network from unauthorized access, change the Wi-Fi

Name (SSID) and Wi-Fi Password (WIFI KEY)

at regular intervals. For details, see

the online help information on the web user interface.

If you are using Windows Vista or later, you can press the WPS button on the top of

your Jet Hub for 6 seconds in lieu of entering the Wi-Fi Password.

3Getting Started: Setting up your

Phone

Follow these simple steps to connect a Phone to your 4G LTE Jet Hub.

Step 1For voice calls, connect a standard telephone to the Telephone Port using

a RJ-11 cable (you will require a voice plan in addition to a data plan

to use this feature).

Step 2Check the indicators on the front panel of your Jet Hub. At minimum the

indicators must be lit as outlined.

You are ready to make your first phone call on your new Jet Hub! Refer to the section

“Using your 4G LTE Jet Hub’s Phone Features” for more help on using a phone with

your Jet Hub.

If the B882 4G LTE Jet Hub is to be connected to the existing wall outlet telephone

wiring, the existing wiring MUST first be disconnected from any outside landline

telephone network. Not disconnecting from any outside landline telephone network

will cause excessive heat or even damage the Jet Hub.

Radio signals can interfere with the telephone call connection and quality. To

eliminate the risk of possible interference, place the telephone at least 1 meter

away from the B882 4G LTE Jet Hub.

Fax is not support on this 4G LTE Jet Hub.

Power

Solid White: the Jet Hub is powered on.

Wireless Signal

indicator

Solid Blue or Cyan: the Jet Hub is registered

with the wireless network.

If this indicator is red and blinking, power off the

4G LTE Jet Hub and ensure your SIM card is

inserted correctly.

If this continues after turning the 4G LTE Jet Hub

on again, please contact MTS Technical Support

at 204-225-5687 or toll free outside Manitoba at

1-800-883-2054 to ensure your SIM card is

activated.

Call status

indicator

Not lit

Solid white when you are on a call.

This indicator will blink when you are receiving a

call in addition to your phone ringing.
