Huawei Quidway S5000 Series Bedienungsanleitung

HUAWEI

1. Getting Started

2. Port

3. VLAN

4. Multicast Protocol

5. QoS/ACL

6. Integrated Management

7. STP

8. Security

9. Network Protocol

10. System Management

11. Appendix

Quidway S5000 Series Ethernet Switches

Operation Manual

VRP3.10

Quidway S5000 Series Ethernet Switches

Operation Manual

Manual Version T2-081603-20040712-C-1.01

Product Version VRP3.10

BOM 3116A003

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support

and service. If you purchase the products from the sales agent ofHuawei Technologies Co.,

Ltd., please contact our sales agent. If you purchase the products from Huawei

Technologies Co., Ltd. directly, Please feel free to contact our local office, customer care

center or company headquarters.

Huawei Technologies Co., Ltd.

Address: Administration Building, Huawei Technologies Co., Ltd.,

Bantian, Longgang District, Shenzhen, P. R. China

Postal Code: 518129

Website: http://www.huawei.com

No part of this document may be reproduced or transmitted in any form or by any

means without prior written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co.,

Ltd.

All other trademarks and trade names mentioned in this document are the property

of their respective holders.

Notice

The information in this document is subject to change without notice. Every effort

has been made in the preparation of this document to ensure accuracy of the

contents, but all statements, information, and recommendations in this document

do not constitute the warranty of any kind, express or implied.

About This Manual

Version

The product version that corresponds to the manual is VRP3.10.

Related Manuals

The following manuals provide more information about the Quidway S5000 Series

Ethernet Switches.

Manual Content

Quidway S5000 Series Ethernet Switches

Installation Manual It provides information for the system installation.

Quidway S5000 Series Ethernet Switches

Command Manual It is used for assisting the users in using various commands.

Organization of the Manual

Quidway S5000 Series Ethernet Switches Operation Manual consists of the following

parts:

zGetting Started

This module introduces how to access the Ethernet Switch.

zPort

This module introduces Ethernet port and link aggregation configuration.

zVLAN

This module introduces VLAN, GARP, and GVRP configuration.

zMulticast Protocol

This module introduces GMRP and IGMP Snooping configuration.

zQoS/ACL

This module introduces QoS/ACL configuration.

zIntegrated Management

This module introduces integrated configuration.

zSTP

This module introduces STP configuration.

zSecurity

This module introduces 802.1X, AAA & RADIUS, and HABP configuration.

zNetwork Protocol

This module introduces network protocol configuration.

zSystem Management

This module introduces system management and maintenance of Ethernet Switch,

including file system management, system maintenance and network management

configuration.

zAppendix

Intended Readers

The manual is intended for the following readers:

zNetwork engineers

zNetwork administrators

zCustomers who are familiar with network fundamentals

Conventions

This manual uses the following conventions:

I. General conventions

Convention Description

Arial Normal paragraphs are in Arial.

Arial Narrow Warnings, Cautions, Notes and Tips are in Arial Narrow.

Boldface Headings are in Boldface.

Courier New

Terminal Display is in Courier New.

II. Command conventions

Convention Description

Boldface The keywords of a command line are in Boldface.

italic Command arguments are in italic.

[ ] Items (keywords or arguments) in square brackets [ ] are optional.

{ x | y | ... }

Alternative items are grouped in braces and separated by vertical bars. One is

selected.

Convention Description

[ x | y | ... ]

Optional alternative items are grouped in square brackets and separated by

vertical bars. One or none is selected.

{ x | y | ... } *

Alternativeitemsaregroupedinbracesandseparated byvertical bars.Aminimum

of one or a maximum of all can be selected.

[ x | y | ... ] *

Optional alternative items are grouped in square brackets and separated by

vertical bars. Many or none can be selected.

# A line starting with a # mark is comments.

III. GUI conventions

Convention Description

< > Button names are inside angle brackets. For example, click <OK> button.

[ ] Window names, menu items, data table and field names are inside square

brackets. For example, pop up the [New User] window.

/ Multi-level menus are separated by forward slashes. For example,

[File/Create/Folder].

IV. Keyboard operation

Format Description

<Key> Press the key with the key name inside angle brackets. For example, <Enter>,

<Tab>, <Backspace>, or <A>.

<Key1+Key2> Press the keys concurrently. For example, <Ctrl+Alt+A> means the three keys

should be pressed concurrently.

<Key1, Key2> Press the keys in turn. For example, <Alt, A> means the two keys should be

pressed in turn.

V. Mouse operation

Action Description

Click Press the left button or right button quickly (left button by default).

Double Click Press the left button twice continuously and quickly.

Drag Press and hold the left button and drag it to a certain position.

VI. Symbols

Eye-catching symbols are also used in the manual to highlight the points worthy of

special attention during the operation. They are defined as follows:

Caution,Warning: Means reader be extremely careful during the operation.

Note: Means a complementary description.
