Huawei 5G CPE WiN H312-371

Operation Guide

ROUTER-SWITCH.COM

CONTENT

Content................................................................................................................................................................................... 1

How to connect the CPE......................................................................................................................................................... 2

How to configure Huawei 5G CPE Win................................................................................................................................... 4

Packing list.............................................................................................................................................................................. 6

How to install the router outdoors.........................................................................................................................................9

Where to Buy........................................................................................................................................................................11

Tel: +1-626-239-8066 (USA) +852-3050-1066 / +852-3174-6166

Fax: +852-3050-1066 (Hong Kong)

Email: sales@router-switch.com (Sales Inquiries)

ROUTER-SWITCH.COM

HOW TO CONNECT THE CPE

1>Prepare a Nano SIM card & Insert SIM card in to the Device

(Please don’t insert or remove SIM card when the router power on/working)

2>Insert Network cable

ROUTER-SWITCH.COM

3>Connect power plug ( Connect the power adapter to CPE device and power outlet)

Take power plug on

Then CPE will working and searching for a usable network.When the signal light is on, it means that it has successfully

connected to the network ( Signal light: GR- strong signal/YW- middle signal/RD-weak signal)

ROUTER-SWITCH.COM

HOW TO CONFIGURE HUAWEI 5G CPE WIN

1) Mobile phone /computer connects to CPE via WLAN

2) Desktop PC need connect internet like below picture

ROUTER-SWITCH.COM

3) Open the browser and into 192.168.118.1 page，log in to the management page( password are on the nameplate

which in the back of the product)

4) Follow the instructions on the management page to setting new password, name and login password( After setting

the new password, you need to reconnect and enter the new password)

ROUTER-SWITCH.COM

PACKING LIST

Huawei 5G CPE Win(standard configuration)

Ethernet cable(standard configuration)

PSU (standard configuration)

PSU power cable(standard configuration)

Adjustable pole strap(standard configuration)

Screw(standard configuration)

Expansion anchor(standard configuration)

Internal hexagon wrench(standard configuration)

Nameplate(standard configuration)

ROUTER-SWITCH.COM

1) Huawei 5G CPE Win Device

1. Network cable cover

2. Network port

3. SIM card port

4. Reset buttom

5. 4G signal light

6. 5G signal light

7&8：For adjustable pole strap

ROUTER-SWITCH.COM

2) PSU

1. Power switch

2. Power signal light

3. LAN port

4. Reset button

5. WAN&Power port

6. Power port

ROUTER-SWITCH.COM

HOW TO INSTALL THE ROUTER OUTDOORS.

1). Installed on the pillar
