Huawei Mobius E5330Bs-6 Einrichtungshandbuch

Mobius – Huawei E5330 Training Guide

Mobius – Huawei E5330 Training Guide

Chapter 1 Introduction Page 3 - 13

Chapter 2 Basic Settings Page 14 - 21

Chapter 3 SMS Page 22 - 23

Chapter 4 Advance Settings Page 24 - 47

Chapter 5 FAQ Page 48 - 53

INTRODUCTION

Chapter 1 Introduction

Chapter 1 Introduction

Appearance

Chapter 1 Introduction

Connect to all Wi-Fi devices

Chapter 1 Introduction

HUAWEI E5330Bs-6 Mobile WiFi (hereinafter referred to as the E5330Bs-6) is a high-speed packet access

mobile hotspot.

• The E5330Bs-6 supports the following standards:

• High Speed Packet Access Plus (HSPA+)

• High Speed Uplink Packet Access (HSUPA)

• High Speed Downlink Packet Access (HSDPA)

• Universal Mobile Telecommunications System (UMTS)

• Enhanced Data rates for Global Evolution (EDGE)

• General Packet Radio Service (GPRS)

• Global System for Mobile communications (GSM)

• The E5330Bs-6 provides the following services:

• HSPA+ packet data service of up to 21.6 Mbit/s

• HSPA (HSUPA/HSDPA)/UMTS packet data service of up to 14.4 Mbit/s

• EDGE/GPRS packet data service of up to 236.8 kbit/s

• UMTS/GSM Short Message Service (SMS)

Chapter 1 IntroductionChapter 1 Introduction

• The E5330Bs-6 mainly supports the following features:

• HSPA+ (DL) data service of up to 21.6 Mbit/s

• HSDPA (DL) data service of up to 14.4 Mbit/s

• HSUPA (UL) data service of up to 5.76 Mbit/s

• UMTS data service of up to 384 kbit/s

• EDGE data service of up to 236.8 kbit/s

• GPRS data service of up to 85.6 kbit/s

• PS domain data service based on UMTS and GSM

• SMS based on CS/PS domain of GSM and UMTS

• Wi-Fi

• Five-second fast boot

• Support for HUAWEI Mobile WiFi App

• Press and Play

• 3G/Wi-Fi auto ofﬂ oad

• IPv6 /IPv4 dual stack (optional)

• Built-in DHCP Server, DNS RELAY and NAT

• Online software upgrade

Chapter 1 IntroductionChapter 1 Introduction

• The E5330Bs-6 mainly supports the following features:

• Trafﬁ c statistic

• Standard Micro USB interface

• HiLink features (Driverless, Zero installation)

• LED indicators

• Built-in UMTS and WLAN high gain antenna

• Windows XP SP3, Windows Vista SP1/SP2, Windows 7, Windows 8 (does not

• support Windows RT), MAC OS X 10.6, 10.7 and 10.8 with latest upgrades

Chapter 1 IntroductionChapter 1 Introduction

• Hardware Technical Speciﬁ cations

Item Speciﬁ cations

Technical standard WAN: HSPA+/HSPA/UMTS/EDGE/GPRS/GSM

Operating frequency WLAN: IEEE 802.11b/g/n

HSPA+/HSPA/UMTS: 2100/1900/850 MHz

EDGE/GPRS/GSM: 1900/1800/900/850 MHz

WLAN: 2400MHz 2483.5MHz

Internal memory 128 MB Flash, 64 MB Memory

Maximum transmitter power EDGE/GPRS/GSM: 1900/1800/900/850 MHz

WLAN

802.11b: 14 (+/-3) dBm

802.11g: 11 (+/-3) dBm

802.11n: 9 (+/-3) dBm

Receiver sensitivity UMTS: Conﬁ rm to 3GPP Requirements
