E5330Bs-6 V200R001 FAQ(EN)

文档密级:内部公开

2014-3-21

华为机密，未经许可不得扩散

第1页, 共15 页

E5330Bs-6 FAQ........................................................2

Q1: Main Features of E5330Bs-6:................................................................................................. 2

Q2: Hardware specifications of E5330Bs-6:................................................................................. 3

Q3: Keys, Interface of E5330Bs-6................................................................................................. 4

Q4: What information displayed of E5330Bs-6’s LED indicator?............................................. 5

Q5: Establish WiFi connection between PC and E5330Bs-6...................................................... 6

Q6: My device connected to E5330Bs-6’s wireless network, but cannot open Web UI............ 7

Q7: E5330Bs-6’s signal is weak and cannot register to 3G network.......................................... 9

Q8: E5330Bs-6’s Wi-Fi signal is always weak............................................................................ 10

Q9: Default encryption method of E5330Bs-6 ........................................................................... 11

Q10: I forget my Wi-Fi key and Web login password I can’t login my E5330Bs-6.............. 11

Q11: How long it may take to fully charge E5330Bs-6 and how long E5330Bs-6 can work by

using the fully charged battery? ...................................................................................................... 12

Q12: I feel my E5330Bs-6 getting hot after long hours usage. Is there safety concern?....... 13

Q13: How can I get version information of my E5330Bs-6？................................................. 13

Q14: Will the Mobile WiFi connect to the Internet automatically if I roam to a different

network? ............................................................................................................................................ 14

Q15: Clients connected to the Mobile WiFi cannot communicate with each other.............. 14

E5330Bs-6 V200R001 FAQ(EN)

文档密级:内部公开

2014-3-21

华为机密，未经许可不得扩散

第2页, 共15 页

E5330Bs-6 FAQ

Q1: Main Features of E5330Bs-6:

The E5330Bs-6 mainly supports the following features:

HSPA+ (DL) data service of up to 21.6 Mbit/s

HSDPA (DL) data service of up to 14.4 Mbit/s

HSUPA (UL) data service of up to 5.76 Mbit/s

UMTS data service of up to 384 kbit/s

EDGE data service of up to 236.8 kbit/s

GPRS data service of up to 85.6 kbit/s

PS domain data service based on UMTS and GSM

SMS based on CS/PS domain of GSM and UMTS

Wi-Fi

Five-second fast boot

Support for HUAWEI Mobile WiFi App

Press and Play

3G/Wi-Fi auto offload

IPv6 /IPv4 dual stack (optional)

Built-in DHCP Server, DNS RELAY and NAT

Online software upgrade

Traffic statistic

Standard Micro USB interface

HiLink features (Driverless, Zero installation)

LED indicators

Built-in UMTS and WLAN high gain antenna

Windows XP SP3, Windows Vista SP1/SP2, Windows 7, Windows 8 (does not support Windows

RT), MAC OS X 10.6, 10.7 and 10.8 with latest upgrades

E5330Bs-6 V200R001 FAQ(EN)

文档密级:内部公开

2014-3-21

华为机密，未经许可不得扩散

第3页, 共15 页

Q2: Hardware specifications of E5330Bs-6:

Item

Specifications

Technical

standard

WAN: HSPA+/HSPA/UMTS/EDGE/GPRS/GSM

WLAN: IEEE 802.11b/g/n

Operating

frequency

HSPA+/HSPA/UMTS: 2100/900 /850 MHz

EDGE/GPRS/GSM: 1900/1800/900/850 MHz

WLAN: 2400–2483.5 MHz

Internal memory

128 MB Flash, 64 MB Memory

Maximum

transmitter power

UMTS: 24 (+1/-3) dBm

WLAN

802.11b: 14 (+/-3) dBm

802.11g: 11 (+/-3) dBm

802.11n: 9 (+/-3) dBm

Receiver

sensitivity

UMTS: Confirm to 3GPP Requirements

WLAN

802.11b: -76 dBm@11 Mbit/s

802.11b: -82 dBm@1 Mbit/s

802.11g: -65 dBm@54 Mbit/s

802.11n: -64 dBm@65 Mbit/s

WLAN speed

802.11b: Up to 11 Mbit/s

802.11g: Up to 54 Mbit/s

802.11n: Support MCS0–MCS7; Up to 72.2 Mbit/s.

Maximum power

consumption

3.5 W

Power supply

AC: 100–240 V

DC: 5 V, 1 A

Battery

Type: Li (rechargeable)

Capacity: 3.7 V, 1500 mAh

Maximum working time: 5–6 hours (depending on the network)

Maximum standby time: 300 hours (depending on the network)

External

Micro USB interface

E5330Bs-6 V200R001 FAQ(EN)

文档密级:内部公开

2014-3-21

华为机密，未经许可不得扩散

第4页, 共15 页

Item

Specifications

interfaces

Standard 6-pin SIM card interface

Indicators

Signal

Green: Strong signal

Orange: Weak signal

Red: No signal

Wi-Fi

Green: Wi-Fi turned on

Blue: Connected to WLAN.

Battery

Green: Sufficient battery

Blinking green: Charging the battery

Red: Low battery

SMS

Green: New message

Blinking green: Inbox full

Power

Blinks slowly: The Mobile WiFi enters the

standby mode

Button

Power switch, Reset switch

Antenna

Built-in GSM/UMTS main diversity antenna

Built-in UMTS diversity antenna

Built-in WLAN antenna

Dimensions

(W × D ×H)

92.8 mm×60.0 mm×14.0 mm

Weight

about 74 g (including the battery)

Temperature

Operating: 0℃to +35℃

Storage: -20℃to +60℃

Humidity

5% to 95%( non-condensing)

Q3: Keys, Interface of E5330Bs-6

Appearance

E5330Bs-6 V200R001 FAQ(EN)

文档密级:内部公开

2014-3-21

华为机密，未经许可不得扩散

第5页, 共15 页

Key Function

Information

•①Power indicator ②Messages indicator ③Battery indicator ④Wi-Fi indicator ⑤Micro USB

port ⑥Signal indicator ⑦Lanyard hole ⑧Power button

Power Button

•Press and hold to turn on/off E5330Bs-6.

•When the screen lights up, indicating that the E5330Bs-6 is turned on.

Reset Button

•Press and hold the RESET button until the display screen turns off. The E5330Bs-6 is then

restored to its factory settings.

Q4: What information displayed of E5330Bs-6’s LED indicator?

A: Information you can read from the home screen of E5330Bs-6 showed below

E5330Bs-6 V200R001 FAQ(EN)

文档密级:内部公开

2014-3-21

华为机密，未经许可不得扩散

第6页, 共15 页

Q5: Establish WiFi connection between PC and E5330Bs-6

A: Please follow these steps to set up your WLAN

1. Enable your wireless network card and double click icon displayed on windows start bar to open

“Choose a wireless network”dialog

2. Select SSID of E5330Bs-6 in the local wireless device list (The WiFi Key and the SSID can be found on a

label stick inside the back cover), click to connect.

3. Input WiFi Key in the dialog of password input then click to establish connection please

pay attention to the case sensitive of WiFi passwords.

E5330Bs-6 V200R001 FAQ(EN)

文档密级:内部公开

2014-3-21

华为机密，未经许可不得扩散

第7页, 共15 页

4. After the icon of wireless network card turned from (status of acquiring IP address ) into

,your PC has established WiFi connection with E5330Bs-6 successfully, enter http://192.168.8.1

in web browser (ex. IE) to visit Web UI(Double click the web browser and the Web UI will open too).

Q6: My device connected to E5330Bs-6’s wireless network, but

cannot open Web UI

1. Double to check your wireless network connection on windows start bar. Make sure your device is

connected with your E5330Bs-6 not other Wi-Fi device.

2. Open Web Browser from your device (ex. Microsoft Internet Explorer). Go http://192.168.8.1 to open

E5330Bs-6’s Web UI.

3. If Web Browser failed to bring you to Web UI, click “Tool” from Browser then select “Internet Options”.

E5330Bs-6 V200R001 FAQ(EN)

文档密级:内部公开

2014-3-21

华为机密，未经许可不得扩散

第8页, 共15 页

Select “General”tab, then click “Delete Cookies”.

Select “Connections” tab, then click “LAN settings”.

For the “Local Area Network (LAN) Settings” pop-up, uncheck the top three check-boxes. Then click “OK” to

apply changes.

E5330Bs-6 V200R001 FAQ(EN)

文档密级:内部公开

2014-3-21

华为机密，未经许可不得扩散

第9页, 共15 页

Refresh the Web Browser to show E5330Bs-6 management console page.

Q7: E5330Bs-6’s signal is weak and cannot register to 3G network

1. Please check local network condition, check whether there is 3G network which provided by telecom

operator at the moment. Ensure you are not in some close environment. (You may check the signal

strengthen by the icon displayed on Web UI main page)

2. Please move E5330Bs-6 toward to window to get better signal

3. If the network condition is good but still cannot register, please try to reset E5330Bs-6 and try again

4. Sometimes E5330Bs-6 will be rejected by the operator for some reasons. Please reset E5330Bs-6 and check.

If E5330Bs-6 still cannot camp on the network, please contact with your device provider.

5. Login Web UI to check whether E5330Bs-6 has been set to 2G only mode. If your E5330Bs-6 has been set

E5330Bs-6 V200R001 FAQ(EN)

文档密级:内部公开

2014-3-21

华为机密，未经许可不得扩散

第10 页, 共15 页

to 2G only, please select the 3G only option in the drop down menu.

Q8: E5330Bs-6’s Wi-Fi signal is always weak

1. When E5330Bs-6 using it’s battery power, in order to save energy for longer run-time E5330Bs-6 will

lower down its transmit power ,so Wi-Fi signal is weaker compare with powered by USB or power adapter.

Connect E5330Bs-6 to power adapter or with USB cable to a running computer’s USB port will enhance

E5330Bs-6’s Wi-Fi signal strength.

2. Keep E5330Bs-6 at least 3 to 6 feet away from other electrical devices which may create RF signal and

cause interference (for example, microwave oven, TVs, cordless/cellular phones, baby monitors or wireless

speakers). If you needn’t using any of those devices when you want to connect Internet, please turn it off.

3. Wi-Fi covered range of E5330Bs-6 is according to its power supply mode and its using environment. In

Idea clear square area the Wi-Fi covered range of E5330Bs-6 showed below:

Use power adapter: 100m (328ft)

Use USB cable connect: 20m (66ft)

Use battery supply: 10m (33ft)

4. In actual use Wi-Fi covered range maybe different from idea square area, it decided by the environment

you use. The closer to E5330Bs-6, the stronger Wi-Fi signal you get. And every obstacle (walls, ceilings,

furniture) between your device and E5330Bs-6 may decrease Wi-Fi signal strength. Move your device

closer to E5330Bs-6 can avoid obstacles and improve Wi-Fi signal.

5. Change the Wi-Fi channel to fix one other than auto (you can try the available channel one by one and

select the channel with best signal strength)
