Human Touch HT-Navitas Sleep Bedienungsanleitung

Unpack the box

Extra (in case needed)

Zip ties (4)

Zip ties (2)

Armrests Side panels

Flat washers (8)

Flat washers (2)

5mm Allen screws (8)

5mm Allen wrench (1)

5mm Allen screws (2)

Fasteners (8)

Fasteners (2)

Power cord

Chair base

HT-Navitas Sleep

HT-Novo

DELIVERY AND ASSEMBLY GUIDE

2. Install the side panels.

3. Install the power cord and power on the chair.

4. Press the Power button on the remote control to power it on.

a. Align the four side panel holes with the corresponding mounting holes on the armrest, then push the side panel firmly

into place (Fig.A).

b. Using a flat-head screwdriver, pry the top of one of the fasteners up off of the fastener base and hold it in that position (Fig.B).

c. Using your other hand, locate one of the four side panel mounting holes on the inside of the armrest (Fig.C).

d. Push the base of the fastener firmly and completely into the hole, then push the top of the fastener firmly inward to lock it.

e. Repeat steps (b) and (c) to install the other three fasteners. NOTE: Access the upper rear mounting hole from the inside of

the arm, near the seat cushion. To install the upper front fastener, you may want to rotate the foot and calf massager for easier access.

f. Repeat steps (a) to (e) to install the other side panel.

a. Plug the power cord into the power jack on the back of the chair.

b. Plug the other end of the power cord into a grounded 120V outlet.

c. Turn the power switch on the back of the unit to On (I).

When you have ensured that the area around the chair is free from children and pets

(and will remain that way for the duration of the chair’s use), select CONTINUE.

Power cord Power switch

Side panel

Fig. A Fig. B Fig. C

Fasterner

Mounting holes

When deciding where to place your HT-Navitas, consider the following:

 •Placetheunitonaflatsurface,awayfromdirectsunlightoranyotherdirectheatsource(toavoidfading).

 •Ifyouwishtoplacetheunitonahardsurface,itisrecommendedthatyouplaceapieceofcarpetorasoftmat

underneath it to avoid damaging the floor (minimum 48” x 28”).

 •Toaccommodatethefootrestwhendeployed,makesuretheareainfrontofthechairisclearforatleast32”.

CHOOSE A LOCATION

To move the chair:

1. Carefully push down on the upper part of the backrest to tilt the chair backward, balancing the chair weight

carefully to avoid dropping it.

2. Roll the chair on its casters to the desired location.

 3.Gentlylowerthechairallthewaytothefloor.WARNING: Dropping the front of the chair to the floor may damage

the chair and/or floor.

CAUTION: Use two or more people to lift the chair out of the box or move it, to avoid injury or damage to the chair.

Do not move the chair with anyone seated in it. Do not hold the seat, front of the footrest, or shoulder unit when

moving the chair. Make sure the power cord is secured out of the way before moving the chair.

MOVE THE CHAIR TO THE DESIRED LOCATION

Caster

32”

Clearance

1. Install the armrests.

ASSEMBLE THE CHAIR

a. Align the four holes on the armrest mounting bracket with the corresponding holes on the chair frame.

IMPORTANT: Orient the armrest with the open end facing backward, as shown.

b. Using a 5mm Allen wrench (provided), install one Allen screw with flat-washer into each of the four mounting

holes to secure the armrest to the chair.

c. Connect the air two air tubes on the armrest to the corresponding air tubes on the chair (yellow/yellow, black/black),

then secure each connection tightly using a provided zip-tie.

d. Repeatsteps1–3toinstalltheotherarmrest.

Flat washer

4 mounting holes

Allen screw

Yellow air tubes

Black air tubes

Armrest

Zip ties
