Hawk 3 MKI

Hawk 3D MKI

Installation and Operating Instructions

Please hand these instructions to the stove user when the installation

is complete. Leave the system ready for operation and instruct the

user in the correct use of the appliance and operation of controls.

PLEASE READ THESE INSTRUCTIONS CAREFULLY

It is important that your stove is orre tly installed as Hunter Stoves Limited annot

a ept responsibility for any fault arising through in orre t installation.

HAWK 3 STOVE ASSEMBLY

Flue Collar

Pla e the flue ollar on the top or rear outlet as

required and se ure to the four lo ating tabs inside

the flue outlet using the 6mm nuts & bolts supplied.

Blanking Plate

The blanking plate is also fixed to the lo ating tabs using the 6mm nuts

& bolts supplied.

Throat Plate

The throat plate is supported in the stove via the upper bri k-retaining bar, dire tly below

the outlet in the ba k plate, and the baffle retaining strips on either side.

Slide the right-hand side of the throat plate over the right-hand baffle retaining strip until

the left-hand edge will pass over the other baffle retaining strip. Slide the throat plate

ba k to the left until it is entral in the stove and is supported on both sides.

Removal is the reverse pro ess of fitting.

Firebricks

Multifuel: -

The rear bri k is fa tory fitted. It may be removed by lifting it until the bottom edge an

pass over the rear bri k retaining bar (lower). Tilt the bottom edge of the bri k towards

the front of the stove and slide the bri k out. Fitting is the reverse of removal. The side

bri ks rest on/behind the multifuel side plates whi h themselves are held in position by

the am bar and lower bri k retaining bar.

Woodburner: -

The woodburning version only has a rear firebri k, whi h is held at the ba k of the

firebox by the upper bri k-retaining bar.

After assembly, check that all parts are correctly fitted.

Installation Instructions

These instructions cover the basic principles to ensure satisfactory installation of

the stove, although detail may need slight modification to suit particular local

site conditions. In all cases the installation must comply with current Building

Regulations, Local Authority Byelaws and other specifications or regulations as

they affect the installation of the stove. It should be noted that the Building

Regulations requirements may be met by adopting the relevant

recommendations given in British Standards BS 8303, BS 6461 and BS 7566 as

an alternative means to achieve an equivalent level of performance to that

obtained following the guidance given in Approved Document J.

Health And Safety Precautions

Handling

Adequate facilities must be available for loading, unloading and site handling.

Fire Cement

Some types of fire cement are caustic and should not be allowed to come into contact

with the skin. In case of contact, wash immediately with plenty of water.

Asbestos

This stove contains no asbestos. If there is a possibility of disturbing any asbestos in

the course of installation then please seek specialist guidance and use appropriate

protective equipment.

Metal Parts

When installing or servicing this stove, care should be taken to avoid the possibility of

personal injury.

Important Warning

This stove must not be installed into a chimney that serves any other heating

appliance.

There must not be an extractor fan fitted in the same room as the stove as this can

cause the stove to emit fumes into the room.

Installation

Chimney

The chimney height and the position of the chimney terminal should conform to

Building Regulations.

Check that the chimney is in good condition, dry, free from cracks and obstructions.

The diameter of the flue should not be less than 125mm and not more than 230mm. If

any of these requirements are not met, the chimney should be lined by a suitable

method.

The chimney must be swept before connection to the stove.

Where the chimney is believed to have previously served an open fire installation, it is

possible that the higher flue gas temperature from the stove may loosen deposits that

were previously firmly adhered, with the consequent risk of flue blockage. It is

therefore recommended that the chimney be swept a second time within a month of

regular use after installation.

If you have any doubts about the suitability of your chimney, consult your local

dealer/stockist.

If there is no existing chimney then either a prefabricated block chimney in

accordance with Building Regulations Approved Document J, or a twin-walled

insulated stainless steel flue to BS 4543 can be used. These chimneys must be fitted

in accordance with the manufacturer’s instructions and Building Regulations.

Flue Draught

A flue draught of minimum 1.5mm to a maximum 2.5mm water gauge is required for

satisfactory appliance performance. The flue draught should be checked under fire at

high output and, if it exceeds the recommended maximum, a draught stabiliser must

be fitted so that the rate of burning can be controlled and to prevent overfiring.

Air Supply

If a draught stabiliser is fitted, the room or space containing this appliance should

have a permanent, unobstructed air opening of at least 1200mm

. Due consideration

should be given to air requirements for any other appliances in the same room or

space.

Connection to the Chimney

An existing fireplace opening can be bricked up or sealed with a register plate. A

short length of flue pipe of a minimum 125mm internal diameter may then be used to

connect the stove to the chimney. This flue pipe should be of 316 grade stainless steel

or vitreous enamelled, nominal thickness 1.2mm. Ensure that the pipe end is no

closer than 76mm to the side or rear chimney walls.

Ideally, the old fireplace should be filled in so that there is a smooth streamlined entry

into the flueway.

The length of any horizontal run of flue pipe must not exceed 150mm.

It is essential that all connections between the stove and chimney-flue are sealed and

made airtight.

Both the chimney and flue pipe must be accessible for cleaning and if ANY parts of

the chimney cannot be reached through the stove (with throat plate removed), a soot

door must be fitted in a suitable position to enable this to be done.

Material Clearances

The stove can be recessed in a standard 16” fireplace opening but a permanent free air

gap of at least 50mm must be left at the back of the stove to obtain maximum heat

output and for access to the rear of the stove.

The thickness of all walls around the stove should comply with Building Regulations

Approved Document J.

In all instances the back wall of the fireplace recess and the hearth should be made of

non-combustible material.

Allow an apron of a least 300mm at the front of the stove and 150mm on either side.

The hearth on which the stove is to be placed should not be less than 125mm thick

and should be in accordance with the current building regulations. Care should be

taken to level the stove.

There should be NO combustible material within a distance of 900mm from any

surface of the stove.

The appliance shall be installed on a floor with adequate load-bearing capacity. If the

existing construction does not meet this prerequisite, suitable measures (e.g. load

distributing plate) should be taken to achieve it.

Commissioning and Handover

Upon completion of the installation, allow a suitable period of time for any fire

cement and mortar to dry out. A small fire may then be lit and checked to ensure the

smoke and fumes are taken from the stove up the chimney and emitted safely to

atmosphere. Do not run the stove at full output for at least 24 hours.

On completion of the installation and commissioning, ensure that the operating

instructions and operating tools for the stove are left with the customer. Be sure to

advise the customer on the correct use of the appliance with the fuels likely to be used

on the stove and warn them to use only the recommended fuels for the stove.

Advise the user on what to do should smoke or fumes be emitted from the stove. The

user should be advised to use a fireguard to BS 6539 in the presence of children, aged

and/or infirm persons.

Operating Instructions

This appliance is not suitable for use in a shared flue

Aerosol Sprays

Do not use an aerosol spray on or near the stove when it is alight.

Air Controls

This stove has been designed to burn cleaner and more efficiently than a conventional

wood burning stove. If used correctly this stove will burn far more efficiently than

normal with the obvious notable feature of CLEAN GLASS.

However, for this product to work properly it must be used correctly.

It is essential that the stove has adequate air supply for combustion and ventilation.

The primary and secondary air inlets must be kept clear from obstruction and

blockage.

Warning! This Appliance will be hot when in operation and due care should be

taken. The riddling tool may be used to operate the door handle and air controls.

Primary Air

Primary air is controlled via the spinner in the bottom of

the door. This provides a conventional air draught to the

bed of the fire. The spinner should be screwed in fully to

close the primary air intake.

Secondary Air

Secondary air is controlled via the slider above and to the right of the door, it is this

“airwash” that keeps a clean and uninterrupted view of the fire, also aiding in good

secondary combustion of the fuel and reducing emissions into the chimney and

environment.

Note: The “airwash” is open when the slider knob is pushed to the right.

Damper Assembly (Optional)

When burning wood, the flue damper assembly may be fitted. When the damper is

set in the open position the chimney draws at full draught, increasing the volume of

airflow through the stove and flue. Shutting the damper restricts the flow, slowing the

rate of burning.

Warning! The flue damper should not be fitted when burning solid fuels.

Multifuel Grate

Your Hunter Herald is fitted with a locomotive type grate.

So that de-ashing can be carried out cleanly and easily, it

is riddled from the outside of the stove with the doors

closed. The grate is designed to burn both wood and solid

fuels.

To burn solid mineral fuels, place the operating tool over

the riddling spigot and pull it down towards you. When

left in that position, air is directed under and up through

the slots in the firebed, giving the optimum conditions for

burning solid fuels.

It is important that the riddler is used to remove the ash to

ensure airflow through the firebed and allow the fire to

burn over the entire area of the grate. The ashpan should

be emptied at least daily and ash should never be allowed

to build up over a period of time as this will result in

damage to the firebars. The flat end of the riddling tool

can be used to carry the ashpan.

To burn wood, push the operating tool up and away from you. When left in this

position, air is directed through the slots now formed behind the door, and not through

the firebed, which now provides a solid base to build up a bed of ash. Surplus ash can

be removed either by gentle riddling or with a shovel.

It might prove beneficial when burning more reactive fuels to leave the grate in a

“neutral” position, thus directing some underfire air and some overfire air to the

firebed.

Notes on solid mineral fuel burning

Solid mineral fuel should be placed in the stove so that there is no more than a 30°

incline of the fuelbed from front to back. It should not be stacked above the level of

the rear firebrick as this may result in damage to the stove.

With a full load of fuel, the stove will need to be refuelled approximately once every

4 hours.

Solid mineral fuel burns most efficiently with the secondary air control in the closed

position. The primary air spinner can then be used to control the burn rate of the

stove.

Always de-ash before refuelling and do not let the ash build up to the underside of the

grate bars. Solid mineral fuel produces ash, which if allowed to build up will stifle

the airflow through the grate and eventually cause the fire to die.

With some solid mineral fuels a residue of burnt fuel or clinker will accumulate on the

grate, allow the fire to go out periodically to remove this.

Important! - We cannot stress firmly enough how important it is to empty the ashpan

regularly. Air passing through the firebed cools the grate bars. Distortion or burning

out the grate bars is nearly always caused by ash being allowed to build up to the

underside of the grate.

Notes on Woodburning

With a full load of wood, the stove will need to be refuelled approximately once every

1.5 hours.

Wood can be stacked higher in the stove than solid mineral fuel but care must be

taken that logs do not touch the throat plate.

Wood burns most efficiently with the primary air closed. The secondary control can

then be used to control the burn rate of the stove.

Note - primary air is needed to light the stove, see section entitled ‘Lighting the

Stove’

Wood burns best on a bed of ash and it is therefore only necessary to remove surplus

ash from the stove occasionally.

Burn only dry, well seasoned wood, which should have been cut, split and stacked for

at least 12 months, with free air movement around the sides of the stack to enable it to

dry out. Burning wet or unseasoned wood will create tar deposits in the stove and

chimney and will not produce a satisfactory heat output.

Lighting the Stove

We re ommend that you have two or three small fires before you operate your stove to

its maximum heat output. This is to allow the paint to ure in steadily and to give a long

servi e life of the paint finish. During this uring in pro ess you may noti e an

unpleasant smell. It is non toxi , but for your omfort we would suggest that during this

period you leave all doors and windows open.

First, load the fire with starting fuel, i.e. paper, dry sti ks and/or firelighters in the mode

hosen, either wood or solid mineral fuel.

Light the fire at the base leaving all air ontrols open. Allow the fuel to rea h a steady

glow and build the fire up gradually. On e you have a good fire established a ross the

grate bed, further fuel an be added as required.

Overnight burning

The stove an be banked up for overnight burning. When burning solid fuel, empty the

ashpan. Open air ontrols and let the fire burn brightly for a short period. Refuel and

lose both air ontrols, the exa t setting required will depend on the fuel used and the

himney draw so some pra ti e may be ne essary. To revive the fire, open air ontrols

until the fire is burning brightly, de-ash if ne essary (solid fuel only) and refuel. Set air

ontrols as required.

Shutting Down

In order to shut down the stove, close the primary air spinner, then close the

secondary air slider by moving the handle all the way to the left. If the controls are

left in this position, the fire will shut down.

Warning!- The stove will remain hot for a considerable time after the fire has been

extinguished.

Recommended Fuels

Anthracite is an approved natural smokeless fuel (not processed) and therefore can

vary greatly in quality and performance. It generally requires excellent air supply and

above average fire-bed temperatures to maintain maximum performance and with

experience we would suggest that it is used in conjunction with other approved

manufactured smokeless fuels as per the HETAS approved list.

The following fuels are suitable for use in this appliance:-

Coalite

Coalite Nuts

Blazebrite

Coalite Firebrite

Phurnacite

Mixed Nuts

Ancit

Taybrite

Sunbrite Doubles

Cosycoke

Pureheat

Supercoke

Jewel

Maxibrite

Newflame

Supacite

Fireglo Ovoids

Anthracite Small Nuts

Wood Logs

Only authorised smokeless fuels may be used in smoke control areas.

Warning!- Petroleum coke fuels or household waste must not be burnt on this

appliance.

Should any difficulties arise over fuel quality or suitability, consult your local

approved coal merchant or:

HETAS Ltd.– Telephone 01242 673257 – www.hetas. o.uk

Solid Fuel Asso iation – Telephone 0800 600 000 – www.solidfuel. o.uk

Safety notes for your guidance

FIRES CAN BE DANGEROUS – Always use a fireguard in the presence of children,

the elderly or the infirm. The fireguard should be manufactured in accordance with

BS 6539 – Fireguards for use with solid fuel appliances.

DO NOT OVERFIRE – it is possible to fire the stove beyond its design capacity, this

could damage the stove, so watch for signs of overfiring – if any part of the stove

starts to glow red, the fire is in an overfire situation and the controls should be

adjusted accordingly. Never leave the stove unattended for long periods without first

adjusting the controls to a safe setting – careful air supply control should be exercised

at all times.

WARNING – FUME EMISSION

Properly installed and operated, this appliance will not emit fumes. Occasional fumes

from de-ashing and refuelling may occur. Persistent fume emission must not be

tolerated.

If fume emission does persist, then the following immediate action should be taken: -

1. Open doors and windows to ventilate room.

2. Let the fire out, or eject and safely dispose of fuel from the appliance.

3. Check for flue chimney blockage and clean if required.

4. Do not attempt to re-light the fire until the cause has been identified and

corrected.

If necessary, seek professional advice.

Important! – Do not fit an extractor fan in the same room as this appliance.

IN THE EVENT OF A CHIMNEY FIRE

•Raise the alarm to let others in the house know.

•Call the Fire Brigade.

•Reduce the appliance burning rate by closing all air controls.

•Move furniture and rugs away from the fireplace and remove any nearby

ornaments.

•Place a fire guard or spark guard in front of the stove.

•Feel the chimney breast for signs of excessive heat.

If the wall is becoming hot, move the furniture away. Ensure that the Fire Brigade

can gain access to your roof space in order to check this area for signs of fire spread.

Andere Handbücher für Hawk 3 MKI

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Hunter Stoves Herd Handbücher

Hunter Stoves

Hunter Stoves Hawk Benutzerhandbuch

Hunter Stoves

Hunter Stoves Inglenook Stove Bedienungsanleitung

Hunter Stoves

Hunter Stoves Di Lusso Series Betriebsanleitung

Hunter Stoves

Hunter Stoves Hawk Bedienungsanleitung

Hunter Stoves

Hunter Stoves HERALD 8 SLIMLINE CE vII Bedienungsanleitung

Hunter Stoves

Hunter Stoves Herald 8 Double-Double CE Bedienungsanleitung

Hunter Stoves

Hunter Stoves HS Gas SELENE 6 D Benutzerhandbuch

Hunter Stoves

Hunter Stoves Double Hawk 4 CE Bedienungsanleitung

Hunter Stoves

Hunter Stoves Herald 5 Bedienungsanleitung

Hunter Stoves

Hunter Stoves HERALD SERIES Bedienungsanleitung

Hunter Stoves

Hunter Stoves HAWK 4 Bedienungsanleitung

Hunter Stoves

Hunter Stoves Hawk Benutzerhandbuch

Hunter Stoves

Hunter Stoves HERALD 5 SLIMLINE CE VII Bedienungsanleitung

Hunter Stoves

Hunter Stoves Double Hawk 4CE Bedienungsanleitung

Hunter Stoves

Hunter Stoves Herald 8 CE V.11 Bedienungsanleitung

Hunter Stoves

Hunter Stoves Hawk Bedienungsanleitung

Hunter Stoves

Hunter Stoves HERALD 5 SLIMLINE Bedienungsanleitung

Hunter Stoves

Hunter Stoves Double Herald 14 CE Bedienungsanleitung

Hunter Stoves

Hunter Stoves Telford Inset 20DB CVWSTI08DBFM Bedienungsanleitung

Hunter Stoves

Hunter Stoves Hawk 3 MKI Bedienungsanleitung

Hunter Stoves

Hunter Stoves HUNTER HAWK 4 MKII Bedienungsanleitung

Hunter Stoves

Hunter Stoves Telford Inset 5 MKII Bedienungsanleitung

Hunter Stoves

Hunter Stoves Inglenook CEV. II Bedienungsanleitung

Hunter Stoves

Hunter Stoves Herald 80B CE V.II Bedienungsanleitung

Beliebte Herd Handbücher anderer Marken

Arada

Arada Cassette Stove Bedienungsanleitung

Parmco

Parmco FS 600 Bedienungsanleitung

MCZ

MCZ SUITE AIR 10 M2 Bedienungsanleitung

HearthStone

HearthStone Stowe DV 8321 Fehlerbehebungshandbuch

Cattara

Cattara FAMILY Bedienungsanleitung

Stanley

Stanley Argon F500 OVAL Bedienungsanleitung

Avalon

Avalon B-VENT Bedienungsanleitung

Nordpeis

Nordpeis Vega Bedienungsanleitung

Exquisit

Exquisit EKC601-5 Bedienungsanleitung

Stanley

Stanley Oisin Oil MK II Betriebsanleitung

Thermocet

Thermocet Brookfield S/CC Bedienungsanleitung

HASE

HASE delhi Bedienungsanleitung

Vermont Castings

Vermont Castings Intrepid 2 Bedienungsanleitung

Italiana Camini

Italiana Camini CLASSICA Kurzanleitung

Avalon

Avalon Vashon Avanti DVS FS Bedienungsanleitung

Spartherm

Spartherm ambiente a1 Bedienungsanleitung

Dimplex

Dimplex MCFSTV12AU Bedienungsanleitung

Warmlite

Warmlite WL46040 Bedienungsanleitung
