HEATER CONTROL CONSOLE 18kW

Installation And User Instructions

NB! The electrical work described in this manual may be car-

ried out by a certiﬁed electrician.

The devices set includes:

• UKU control panel

• main module

• thermal sensor

• door sensor

• thermal and door sensor cabels (5+5m; 2×0,22 mm2);

• UKU control panel cabel (3m; 4×0,34 mm2).

NB! Keep this operating manual near the device so that at any time

you can get safety and important information for using the device

BEFORE INSTALLATION

• Before installation read the operation manual thoroughly.

This way you can use all the beneﬁts of the device and

prevent damage.

• Only an electrician or a person with equal qualiﬁcations may install

the device.

• Installation and maintenance of the device is only allowed when it

is not under voltage.

• For unique problems that are not covered in the installation

manual, contact your vendor to ensure safety.

• It is not permitted to alter or rebuild the control device without

authorisation.

• The manufacturer has the right to make improvements to the

device. The latest version of the operation manual can be found on

the manufacturer’s webpage (www.huum.eu)

• Make sure that the building’s cables from the main switchboard

to the sauna’s desired location have sufﬁcient a cross section.

In case of an older building, pay attention to the condition of the

connecting boxes and if possible, install a new cable from the

switchboard to the sauna. Install separate protection for the heater.

• It is recommended to connect the unit to the mains without an

earth-leakage circuit breaker.

Symbols used in the installation manual:

WARNING! Not following these instructions may lead to serious or

fatal injuries.

CAUTION! Not following these instructions may lead to minor to

semi-serious injuries or cause damage to objects.

NB! Also follow the special safety requirements given in the individual

chapters. Dispose of the package material according to the applicable

disposal rules and regulations.

In the guide, the following details of the sauna are marked with numbers:

• UKU control panel

• Main controller

• Door sensor

• Temperature sensor

• Heater (not included)

• Vaporiser (not included)

• Light (not included)

INSTALLING UKU ELECTRICAL CONTROL DEVICE

• Before installation disconnect the electric heater from the power

supply in the switchboard.

• The control device must be installed outside the steam

room, at the user’s eye level next to the door or according to the

manufacturer’s recommendations.

• If your main controller supports the use of WIFI or GSM

connections it must be installed where the appropriate reception is

available.

• The device must be installed in a dry place. The protection degree

of the device is IP65.

• Do not exceed an ambient operating temperature of 50°C and

relative humidity of 95%.

CAUTION! The control device must be connected to the mains

permanently without plugs. The power cable of the heater must be at

least H07RN-F or equivalent. The cables cross-section depends on the

power of the heater. See the heater manual.

NB! Measure the lengths of the cables and determine the locations of

the cables and the parts of the device (Figure).

CONTROL PANEL – UKU

With a wooden housing

• Remove the back cover of UKU control panel to attach it to the wall.

• Attach the back cover to the wall so that the upper edge of the

control panel is at eye level.

• Connect the power cable with the screw terminal of the device.

• Attach the device to the back cover that has been placed on the

wall. Secure it with screws from the sides.

With a plastic housing

• Connect the power cable with the cable screws of UKU control panel.

• Pull off the control panel control knob.

• Attach the device with screws to the wall.

• Replace the control knob to the control panel.

MAIN MODULE

• When installing inside the steam room, the enclosure should be

placed 10-50 cm above the ﬂoor.

• Do not attach the main module to the ceiling or inclined surfaces.

• Connect the cables of the UKU control panel, temperature sensor

and door switch through a cable gland to the enclosure and main

module, see ﬁgure.

• Connect the power cable (400/230 V) of the control console through

the cable glands to the main module, see ﬁgure.

DOOR SENSOR

The door switch consists of two parts: a switch and a magnet.

• Open the sensor.

• Connect the cable ends to the terminals of the switch.

• Secure the magnet to the door. It must allow the door to close and

pass directly by the doorpost.

• Secure the sensor to the doorpost so that when the door closes,

both sides of the sensor will be aligned. The maximum distance

between the parts of the door switch must be 5 mm when the door

is closed.

TEMPERATURE SENSOR WITH OVERHEATING PROTECTION

• Connect the cable to the temperature sensor’s plug, see ﬁgure.

• Screw the temperature sensor onto the wall, see ﬁgure.

• The temperature sensor cannot be placed above the heater, it must

be at least 50 cm away from it.

• The temperature sensor must be 15 - 20 cm from the ceiling.

• The temperature sensor must be at least 50 cm from any air ope-

ning (ventilation, door, window).

VAPORISER

• A vaporiser is connected to an output A shown in the ﬁgure. If a

vaporiser is connected, a vaporiser function must also be selected

from the control console settings. See User instructions.

NB! When connecting the control console with an electrical heater

with vaporiser function ensure that the water tank is always ﬁlled

with water. When the water tank is empty, the vaporiser function is

disabled and there is a risk that the heating element my burn out.

CONNECTION OF A LIGHTING SYSTEM

• Lighting/ventilation can be connected to the output B of the control

console. In that case it is possible to switch on/off the connected

lighting/ventilation system from the control console.

• To use a lighting function, the lighting function must be selected

from the control console settings. See User instructions.

Connecting the WIFI controller to the network

• Wiﬁ modem complies with 802.11 b / g / n standard.

• With the UKU control panel go to the settings menu (hold down

button 10s).

• Go to “WIFI settings”.

• Go to “SSID” and select it.

• Next, select the correct wiﬁ network from the menu.

• You can continue to enter the password after selecting a Wiﬁ

network.

• After entering the password, choose connect and follow the inst-

ructions in the wizard.

• Follow the instructions in the “UKU Mobile App” section

Connecting the GSM controller to the network

• After connecting the sauna to your user account in the app, the SIM

card is activated

• The SIM card and sauna will come online in 30 min. NB! Before the

user account is connected to the sauna, the sauna will not come

online!

• Because the GSM remote is using mobile data, it comes with a

yearly fee. The ﬁrst year is free to test the features. After that, the

remote control of the suana costs € 29 per year. If you do not want

the mobile app after the free year you don’t have to pay and can

use the sauna only manually, through the control panel. Payment is

made by credit card in the mobile app.

• Follow the instructions in the “UKU Mobile App” section.

UKU mobile app

The UKU WIFI or GSM device can also be controlled by a smartphone

with a special mobile application in addition to the control panel. This

way you can put the sauna to work being far from home.

Download the HUUM application from the application page of your

mobile phone’s operating system:

• IOS – App Store

• Android – Google Play

• Create a user account.

• Link the control console’s ID (1XXXXX) to your user account. The

ID number and code of the sauna are on the sticker of the main

module.

• After the sauna has been connected with your user account, the

SIM is activated and the sauna will be connected to the network

within 30 minutes.

• Check whether all the functions of the mobile application are wor-

king properly and your commands actually reach the sauna. Com-

mands should be executed within 60 seconds. In case the functions

of the mobile application do not work, contact the manufacturer:

[email protected].

NB! In case the control console is not connected to the user account

in the mobile application, the sauna will not be connected with the

network.

TESTING

NB! Have a qualiﬁed electrician make the tests.

WARNING! Risk of electric shock. Tests must be carried out while the

power is on.

• Check the power terminals of the circuit breaker and main

module. Bad connections may cause a ﬁre. Switch the power on

from the switchboard on by using the circuit breaker. The screen

will ﬂash for a moment. The device is ready for use.

• Check the door switch: close the steam room’s door. Turn the

control console on. Set the temperature. Turn the heating on. Con-

tactors must switch on. Open the door. Contactors must switch off

in 5-10 seconds. Close the door. Contactors must switch on again.

• Check the temperature sensor:

• Install the protection. Switch the power off from the sauna’s

switchboard for quarter of minute and then on again. The

control console must have turned off and when it is turned on,

it must show the current temperature.

• The temperature is renewed periodically, one degree at a time

– therefore it may take some time to reach the actual tempera-

ture reading.

• Set the desired temperature to 50 °C. Turn the sauna on. Check

that desired temperature is maintained. Turn the heating off.

• Set the desired temperature. Turn the heating on. Check that

the temperature is achieved and maintained.
