Using the CR1000 in a Universal Stand

Hardware Revisions 4+ of the CR1000s have a stand detecon

feature. By default, when the CR1000 is placed in the stand, the

reader will automacally enter into moon detecon mode.

When in this mode, simply place a bar code in the scan eld to

acvate the reader. The CR1000 will beep and ash a green LED

to indicate a ‘good read’ has occurred.

For USB Cable: plug the USB end of the Anity® cable into a USB port on the host device. Aer

several seconds, the reader will beep twice and the LED will turn o to indicate the CR1000 is

ready for use.

For RS232 Cable: plug the power supply into the AC outlet, plug the power supply cord into

the barrel jack of the cable, and connect the RS232 connector to the appropriate serial port on

the host device. Aer several seconds, the reader will beep twice, the reader will vibrate and

the LED will turn o to indicate the CR1000 is ready for use.

Using the CR1000 Out of a Universal Stand

Powering on the CR1000

The default seng on the CR1000 has Sux Enter disabled. To enable Sux Enter, please

scan the following conguraon code:

CR1000 Default Sengs

Aztec

Codabar

Code 39

Data Matrix Rectangle

All GS1 DataBar

Interleaved 2 of 5

Code 93

Code 128

Data Matrix

PDF417

QR Code

UPC/EAN/JAN

The CR1000, out of the box, will read the following bar codes:

To congure a CR1000 to read bar codes not listed, please download the CR1000

Conguraon Guide from www.codecorp.com and scan the appropriate ‘Enable’ bar code

reading symbology conguraon code.

Sux Enter Conguraon

Sux Enter - USB Carriage Return, Line Feed - RS232

For more conguraon opons, download the CR1000 Conguraon Guide from

www.codecorp.com.

Serial #: 20000XXXX

MFG #: CR1011_04

Designed in USA.

Made in Malaysia.

Determining the Hardware Revision of a CR1000

Locate the Serial Label on the reader to idenfy the hardware revision. CR1000 readers with

a MFG # of _04 (or higher) have the stand detecon mode.

_04 indicates

revision 4 hardware

2 3

Hardware Revisions 1-3 of the CR1000s do not have an automac stand detecon feature to

enable moon detecon reading when the CR1000 is in a stand. To congure these hardware

revisions for moon detecon scanning, please refer to the CR1000 Conguraon Guide,

located at www.codecorp.com and scan the appropriate code.

Press and hold the CR1000 trigger buon, the two blue bars

eming from the reader are used for targeng. Center the

blue bars in the middle of a bar code.

The opmal reading distance from reader to bar code is

approximately 4.0” (10 cm).

Once the reader is at the opmal distance, the CR1000 will read the bar code (when the

buon is pressed). The CR1000 will beep and ash a green LED to indicate a ‘good read’ has

occurred.

When the CR1000 is removed from the stand, the reader switches to manual mode and the

buon must be pressed to read a bar code.

www.codecorp.com www.codecorp.com

Quickstart Guide

C005747_06_CR1000_Quickstart_Guide

Code Reader™ 1000 (CR1000)

USB Anity® Cable RS232 Anity® Cable

w/ Power Supply

Aaching/Detaching a Cable

To aach a cable, plug the RJ-50 end of the Anity® cable into boom of the reader

(Figure 1). Firmly push the connector into the reader unl a snap can be heard, to

indicate the cable is properly aached. To detach a cable, press a paper clip into the

hole on the back of the CR1000 (Figure 2), and gently pull the cable from the reader.

Figure 2Figure 1

Included with your CR1000

Depending on the kit ordered, the following may have been shipped with your reader:

Universal Stand

Universal Stand Assembly (included when ordered as a Kit/Package)

Cleaning a CR1000

The following agents are approved to clean a Code bar code reader:

• Alcohol Wipes

• Clorox® Disinfecng Wipes

• Clorox® Bleach Soluon (10% Clorox bleach, 90% tap water)

• Medical DiAirKem

• Sani-Cloth® HB, Super Sani-Cloth® Germicidal, Sani-Cloth® Plus Germicidal

Disposable Wipes

• Virex® II Disinfectant Cleaner
