IBM THINKPAD I 1200 - Bedienungsanleitung

Part Number: 04P4963

ThinkPad i Series 1200/1300 Setup Guide

Unpacking checklist

Thank you for purchasing the IBM ThinkPad i Series 1200/1300 computer. Match the items on this list with the items in the box. If any item is

missing or damaged, please contact your place of purchase.

Ø Computer

Ø Battery pack

Ø AC Adapter

Ø Power cord

Ø CDs:

Software Selections CD

Lotus SmartSuite CD or flyer

Recovery CD kit for Windows

Ø Books:

Setup Guide

User's Reference

Ø Manual package for Windows

Ø Telephone cable

Ø Miscellaneous parts:

TrackPoint cap

 Copyright IBM Corporation 2000 1

Setting up your computer

1. Connect power.

a. Turn the computer over. Set the battery pack in the

battery compartment (1), and slide it into place (2).

Secure the battery pack by sliding the battery-pack latch

to the lock position (3).

b. Connect the AC Adapter to the computer's power jack

(at the rear of the computer) in the order shown.

2. Turn on system.

a. Open the liquid crystal display (LCD).

Pull the LCD latches (1) and open the LCD (2). Then

position the LCD so that it is convenient for viewing.

b. Press the power switch (1).

3. Operating controls.

Using the TrackPoint

The TrackPoint is a unique device for moving the cursor on

the screen. You can perform all mouse operations with the

TrackPoint. The left and right click buttons function like the

left and right click buttons on a mouse. For an explanation of

the Internet Scroll Bar, see the

User's Reference

To move the cursor, use the red-topped stick at the center of

the keyboard. Press gently with your left or right index finger

in the direction you want to move the cursor. To select and

drag an object, press and hold one of the click buttons with

either thumb as required by your software.

Click means to press the left click button once. Double-

click means to press the left click button twice within 1

second. Cursor

Stick

Right click button

Internet Scroll Bar

Left click button

For more information about the TrackPoint, see the

User's

Reference

Using the volume control

You can adjust the sound level of the built-in speakers by

using the following three buttons.

(1) Fn+PgUp(Volume up): The volume increases.

(2) Fn+PgDn(Volume down): The volume decreases.

(3) Fn+Backspace(Mute): Sounds turn off.

The mute function is not disabled when you power off

the computer and power it on again. To turn on the

sound, press Fn+PgUp or Fn+PgDn.

123

Fn key

The volume indicator appears on the screen for a few

seconds when you press one of these buttons. For more

details on volume control, see the

Online User's Guide

Using the brightness and contrast controls

Adjust the display's brightness by pressing (1) Fn+Home to

increase or (2) Fn+End to decrease. Press (3) Fn+Insert or

(4) Fn+Delete to increase or decrease the display's contrast.

 Copyright IBM Corporation 2000 3

Fn key

Note: The contrast controls are available on models with

HPA displays. Models with TFT displays have opti-

mized contrast levels.

4. Setting up Windows.

The computer is preloaded with Windows 98 or Windows

2000. Follow the instructions on the computer display to set

up the operating system.

After setting up Windows, take a few moments to complete

the ThinkPad registration. The information provided by you

will help IBM to better serve you in the future. You can reg-

ister your computer at the following web site:

http://www.pc.ibm.com/register

Note: You may connect the telephone cable to the modem

jack and an analog phone jack if you wish to register

electronically. Do not connect if you are in an office

building or hotel with a PBX system.

Service and support information

Getting help around the world

International Warranty Service (IWS) is available for customers

who are moving products or traveling to countries where their

product (as identified by the 4–digit machine type) is sold and

serviced by IBM or IBM authorized representatives. Warranty

service delivery methods of the servicing country will be in effect.

IBM reserves the right to change or modify its service delivery

methods by country at any time without notice. Service proce-

dures vary by country, and some service and parts may not be

available in all countries because of the laws of that particular

country. Some countries have fees that apply where service is

provided on-site in remote locations.

To register, call one of the following IWS offices:

Before you call for service, have on hand:

The exact wording of any error messages

Hardware and software configuration information

A description of the problem

Information and serial numbers of any options installed on

your system

Your Name:

_______________________________

Company Name:

_______________________________

Machine Type:

_______________________________

Serial Number (S/N):

_______________________________

Place of Purchase:

_______________________________

IBM Service Website:

_______________________________

IBM Service Number:

_______________________________

Southeast Asia, Australia, New Zealand, and

Hong Kong: 61-2-9354-4171

Canada, Latin America, and the U.S.: 1-800-497-7426

or 248-740-1215

Europe, Middle East, and Africa: 44-1475-893638

Japan, Korea, China (except Hong Kong), and

Taiwan: 81-46–273-7598

 Copyright IBM Corporation 2000 5
