ÉÂÔ Installation Instructions

Installation of

Field Feature Bill of Material (FFBM)

PN 26L0451

Install Network Node Control Point (NNP-B)

Type 3

(Based on 6275)

Feature Code 5423

on IBM 3746-900.

Written by: C. Vallee

Checked by: C. Franoux

Approved by: A. Badino

Reviewed by: R. Lympany

3746 PN 42L2445 EC F52322 EC F12701A EC F70078

FFBM 1 of 10 09 Oct 1998 14 DEC 1998 22 APR 1999

 Copyright IBM Corp. 1998, 1999 1

ÉÂÔ Installation Instructions

3746 PN 42L2445 EC F52322 EC F12701A EC F70078

FFBM 2 of 10 09 Oct 1998 14 DEC 1998 22 APR 1999

ÉÂÔ Installation Instructions

Before Installation (Steps 1-8)

1.0 Machines Affected

3746 Model 900 with service processor and network node processor type:

6275-56U, 6275-83U, 7585-P02, or 3172-P90.

This feature should only be applied on the machine serial number for which it is

specified

2.0 Related BMs and ECs

2.1 Prerequisites

(Must be installed prior to this installation)

Feature Title

5053 Service Processor type 6275-56U or 6275-83U or

5052 Service Processor type 7585-P02 or

5021 Service Processor type 3172-P90

5423 Network Node Processor-A type 6275-56U or 6275-83U or

5122 Network Node Processor-A type 7585-P02 or

5022 Network Node Processor-A type 3172-P90

EC Title

F12720 Licensed Internal Code (Minimum level)

Checkpoint: Check that the APPN EC Level is F12721.000 or higher.

Note: Refer to the

SPIM

or the

Service User's Guide

shipped with the

service processor, verify that the code is at EC F12720 or above.

Use the procedure: Displaying the EC Level of the Code installed

on the hard disk. If the EC of the code installed is prior to F12720,

use the installation instructions to install the new level of code shipped.

3746 PN 42L2445 EC F52322 EC F12701A EC F70078

FFBM 3 of 10 09 Oct 1998 14 DEC 1998 22 APR 1999

ÉÂÔ Installation Instructions

2.2 Concurrent ECs

(Must be installed together)

None.

2.3 Companion ECs

(May be installed together)

None.

3.0 BMs to be Installed

Feature

B/M Title

26L0451 Network Node Processor B (NNP-B) Feature Code 5423

4.0 Preparation

1. Familiarize yourself with the purpose and details of the installation instruction

before negotiating machine time with the customer.

2. Check all items listed on the BM(s) to determine that all parts have been

received. Refer to chapter 1 in the

Network Node Processor Installation and

Maintenance (Based on 6275)

, SY33-2126.

3. The set up of the NNP-B has no impact on customer operations.

4. Obtain from the customer the Parameter worksheet.

5.0 Programming

None.

6.0 Purpose and Description

6.1 Purpose To increase the reliability of the 3746-9X0 by adding a backup NNP.

3746 PN 42L2445 EC F52322 EC F12701A EC F70078

FFBM 4 of 10 09 Oct 1998 14 DEC 1998 22 APR 1999

ÉÂÔ Installation Instructions

6.2 Description

The installation of the NNP-B is divided into two main steps:

1. Installing the 6275-56U or the 6275-83U system unit

2. Loading the code on the NNP-B.

Note: These steps are documented in the

Network Node Processor Installation

and Maintenance (Based on 6275)

, SY33-2126.

3746 PN 42L2445 EC F52322 EC F12701A EC F70078

FFBM 5 of 10 09 Oct 1998 14 DEC 1998 22 APR 1999

ÉÂÔ Installation Instructions

7.0 Installation Time

Note: To reduce the MES installation time it is recommended that you load the

Network Node Processor Code on the Service Processor and install the system

unit at the same time.

No impact on 3745 customer operations.

FFBM Machine Hrs. System Hrs. Nbr of CEs

26L0451 0.2 0.0 1

8.0 Tools/Material Required

None.

Installation (Steps 9-12)

9.0 Safety

Review the Safety Notices and the Safety Inspection Procedures located at the

beginning of the

IBM 3745 Communication Controller All Models

IBM 3746

Expansion Unit Model 900

IBM 3746 Nways Multiprotocol Controller Model 950

Safety Information

, GA33-0400.

10.0 Details of Installation.

10.1 Installing and Connecting the NNP

Note: For any unexpected message or error concerning the NNP-B, go to

Chapter 3. Network Node Processor Problem Determination of the

Network

Node Processor Installation and Maintenance (Based on 6275)

, SY33-2126.

1. Using the

Network Node Processor Installation and Maintenance (Based

on 6275)

, SY33-2126., go to chapter 1 and install the NNP following the

instructions to install a NNP-B. When completed go to next step.

2. Ask the customer for a maintenance window on 3746-900 with traffic deac-

tivated.

3746 PN 42L2445 EC F52322 EC F12701A EC F70078

FFBM 6 of 10 09 Oct 1998 14 DEC 1998 22 APR 1999

ÉÂÔ Installation Instructions

3. Shutdown and restart the Service Processor and re-iml the 3746-9x0

10.2 Enabling the NNP Back-up Function

Important

It's a customer task, but ask the customer if he wants you to perform this task.

1. On the 3746-9X0 main menu, Click on Network Node Processor Man-

agement.

2. Double click on Manage Control Point on NNPs.

3. Click on Enable the CP/NNP back-up.

4. Click on Close to exit from the function.

Note: For details refer to chapter Working with the NNP Functions on the

3746-950 User's Guide

, SA33-0356, or the

3745-17A to 61A and 3746-900

Basic Operation Guide

, SA33-0177.

3746 PN 42L2445 EC F52322 EC F12701A EC F70078

FFBM 7 of 10 09 Oct 1998 14 DEC 1998 22 APR 1999

ÉÂÔ Installation Instructions

10.3 Log Off the MOSS-E

1. On the 3746-9x0 Menu window, click on Function, then click on Exit.

2. On the MOSS-E View window, click on Program.

3. Click on LOG OFF MOSS-E.

4. Close the front and rear doors of the controller expansion.

10.4 Returning the Machine to the Customer

Inform the customer that the NNP backup is installed and operational.

11.0 Test Procedures

No test required.

12.0 Field Updating

None.

After Installation (Steps 13-15)

13.0 Field Updating

None.

14.0 Publications Update

None.

15.0 Parts Disposition

3746 PN 42L2445 EC F52322 EC F12701A EC F70078

FFBM 8 of 10 09 Oct 1998 14 DEC 1998 22 APR 1999

ÉÂÔ Installation Instructions

15.1 Purchased Machines

Refer to the parts ownership matrix to determine the correct owner of

removed/unused parts.

¹For EMEA/APG/AG Areas, refer to

Hardware and General Service Code

Description

¹For Domestic Areas, return parts to the customer.

16.0 Machine Records

¹Install the new MACHINE HISTORY supplied.

¹Report installation and quality problems using existing procedures.

End of instructions.
