Welcome.

Thank you for buying an

IBM server.

This server

contains information for setting

up and configuring your server.

For detailed information about

your server, view the publications

on the

You can also find the most

current information about

your server at:

http://www.ibm.com/servers/

eserver/support/xseries/

index.html.

Your server

is based on the X-Architecture

technology, and it features

superior performance, availability,

and affordability.

Documentation CD.

Installation Guide

System x3655

Type 7985

Turn off the server

and install options.

Did the server

start correctly?

Ye s

Go to the Server Support

flow chart on the reverse

side of this page.

Start the server.

Did the server

start correctly?

Ye s

Install the server in the rack cabinet

and cable the server and options;

then, restart the server.

Was the

server setup

completed?

Use

ServerGuide to

install the operating

system?

The server is ready to use.

Go to

to register the server.

http://www.ibm.com/support/mysupport/

Go to the Web for instructions:

http://www.ibm.com/servers/

eserver/support/xseries/

index.html.

Ye s

Use the IBM

ServerGuide program

to set up and

configure hardware.

Go to the Server Support

flow chart on the reverse

side of this page.

Install applications,

such as IBM systems

management software

and IBM ServeRAID

programs

Server Support

Ye s

See the troubleshooting

information that comes with

the server to determine

the cause of the problem

and the action to take.

Update the firmware to the

latest level.

You can download firmware from

http://www.ibm.com/servers/

eserver/support/xseries/

index.html

No Software

Ye s

Hardware

Check all cables for loose connections

and verify that all optional devices you

installed are on the ServerProven list at

http://www.ibm.com/servers/eserver/

serverproven/compat/us/.

Is the server working

correctly?

Is the problem

solved?

Hardware or

software problem?

View support telephone numbers at

http://www.ibm.com/planetwide/.

View information about IBM Support Line at

or view support telephone numbers at

http://www.ibm.com/services/sl/products/

http://www.ibm.com/planetwide/.

http://www.ibm.com/support/mysupport/.

Ye s

Is the problem

solved?

Is the problem

solved?

IBM System x3655 Ty pe 7985

Installation Guide



Note:

Before using this information and the product it supports, read the general information in Appendix B, “Notices,” on page 79 and the

Warranty and Support Information document on the IBM Documentation CD.

Third Edition (February 2007)

US Government Users Restricted Rights –Use, duplication or disclosure restricted by GSA ADP Schedule Contract

with IBM Corp.

Contents

Safety ............................v

Chapter 1. Introduction ......................1

The IBM System xDocumentation CD.................2

Hardware and software requirements ................2

Using the Documentation Browser .................2

Notices and statements in this document ................3

Features and specifications .....................4

Major components of the server ...................6

Chapter 2. Installing optional devices ................9

Installation guidelines .......................9

System reliability guidelines ...................10

Working inside the server with the power on .............10

Handling static-sensitive devices .................11

Removing the cover .......................11

Removing the air baffle ......................12

Installing the air baffle ......................13

Installing amemory module ....................14

Installing ahard disk drive.....................17

Installing an additional microprocessor ................19

Removing the riser-card assembly ..................23

Installing the riser-card assembly ..................25

Installing an adapter .......................26

Installing the Remote Supervisor Adapter II SlimLine ...........28

Replacing the ServeRAID SAS Controller ...............29

Installing an optional tape drive ...................29

Completing the installation.....................29

Installing the cover ......................30

Connecting the cables .....................30

Updating the server configuration .................31

Chapter 3. Server controls, LEDs, and power.............33

Front view ..........................33

Rear view ...........................35

Server power features ......................36

Turning on the server .....................36

Turning off the server .....................37

Chapter 4. Configuring the server .................39

Using the ServerGuide Setup and Installation CD ............39

Using the Configuration/Setup Utility program .............39

Using the ServeRAID configuration programs..............40

Using the IBM ServeRAID Configuration Utility program .........40

Using ServeRAID Manager ...................41

Using the baseboard management controller ..............43

Enabling and configuring SOL using the OSA SMBridge management utility

program .........................43

Installing the OSA SMBridge management utility program ........52

Using the baseboard management controller utility programs .......54

Chapter 5. Solving problems ...................57

Diagnostic tools overview .....................57

©Copyright IBM Corp. 2007 iii

POST beep codes .......................57

POST error codes........................58

Troubleshooting tables ......................61

CD or DVD drive problems ...................61

General problems .......................62

Hard disk drive problems ....................62

Intermittent problems......................63

Keyboard, mouse, or pointing-device problems ............63

Memory problems .......................65

Microprocessor problems ....................66

Monitor problems .......................67

Optional-device problems ....................69

Power problems .......................70

Serial port problems ......................71

ServerGuide problems .....................72

Software problems ......................72

Universal Serial Bus (USB) port problems ..............73

Video problems........................73

Light path diagnostics ......................73

Diagnosing problems using light path diagnostics ...........74

Light path diagnostics LEDs ...................74

Appendix A. Getting help and technical assistance ..........77

Before you call .........................77

Using the documentation .....................77

Getting help and information from the World Wide Web ..........78

Software service and support ...................78

Hardware service and support ...................78

IBM Taiwan product service ....................78

Appendix B. Notices ......................79

Trademarks ..........................79

Important notes.........................80

Product recycling and disposal ...................81

Battery return program ......................82

Electronic emission notices ....................83

Federal Communications Commission (FCC) statement .........83

Industry Canada Class Aemission compliance statement ........83

Australia and New Zealand Class Astatement ............83

United Kingdom telecommunications safety requirement.........83

European Union EMC Directive conformance statement .........84

Taiwanese Class Awarning statement ...............84

Chinese Class Awarning statement ................84

Japanese Voluntary Control Council for Interference (VCCI) statement ...84

Index ............................85

iv IBM System x3655 Type 7985: Installation Guide

Safety

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de Segurança.

Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Lees voordat udit product installeert eerst de veiligheidsvoorschriften.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.

Avant d’installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise lesen.

Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.

Antes de instalar este produto, leia as Informações sobre Segurança.

©Copyright IBM Corp. 2007 v

Antes de instalar este producto, lea la información de seguridad.

Läs säkerhetsinformationen innan du installerar den här produkten.

Important:

All caution and danger statements in this documentation begin with anumber. This

number is used to cross reference an English caution or danger statement with

translated versions of the caution or danger statement in the IBM Safety Information

book.

For example, if acaution statement begins with anumber 1, translations for that

caution statement appear in the IBM Safety Information book under statement 1.

Be sure to read all caution and danger statements in this documentation before

performing the instructions. Read any additional safety information that comes with

the server or optional device before you install the device.

vi IBM System x3655 Type 7985: Installation Guide

Statement 1:

DANGER

Electrical current from power, telephone, and communication cables is

hazardous.

To avoid ashock hazard:

vDo not connect or disconnect any cables or perform installation,

maintenance, or reconfiguration of this product during an electrical

storm.

vConnect all power cords to aproperly wired and grounded electrical

outlet.

vConnect to properly wired outlets any equipment that will be attached to

this product.

vWhen possible, use one hand only to connect or disconnect signal

cables.

vNever turn on any equipment when there is evidence of fire, water, or

structural damage.

vDisconnect the attached power cords, telecommunications systems,

networks, and modems before you open the device covers, unless

instructed otherwise in the installation and configuration procedures.

vConnect and disconnect cables as described in the following table when

installing, moving, or opening covers on this product or attached

devices.

To Connect: To Disconnect:

1. Turn everything OFF.

2. First, attach all cables to devices.

3. Attach signal cables to connectors.

4. Attach power cords to outlet.

5. Turn device ON.

1. Turn everything OFF.

2. First, remove power cords from outlet.

3. Remove signal cables from connectors.

4. Remove all cables from devices.

Safety vii

Statement 2:

CAUTION:

When replacing the lithium battery, use only IBM Part Number 33F8354 or an

equivalent type battery recommended by the manufacturer. If your system has

amodule containing alithium battery, replace it only with the same module

type made by the same manufacturer. The battery contains lithium and can

explode if not properly used, handled, or disposed of.

Do not:

vThrow or immerse into water

vHeat to more than 100°C (212°F)

vRepair or disassemble

Dispose of the battery as required by local ordinances or regulations.

viii IBM System x3655 Type 7985: Installation Guide

Andere Handbücher für x3655 - System - 7985

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere IBM Server Handbücher

IBM

IBM eServer xSeries 305 Type 8673 Bedienungsanleitung

IBM

IBM System x3650 M4 Type 7915 Bedienungsanleitung

IBM

IBM Power 720 Express Installationsanleitung

IBM

IBM X3850 X6 Bedienungsanleitung

IBM

IBM 88553RX Bedienungsanleitung

IBM

IBM eServer xSeries 335 Type 8676 Bedienungsanleitung

IBM

IBM 6C4 Bedienungsanleitung

IBM

IBM AS/400 Gebrauchs- und Pflegehandbuch

IBM

IBM eServer xSeries 225 Type 8647 Bedienungsanleitung

IBM

IBM IntelliStation POWER 285 Bedienungsanleitung

IBM

IBM System x3400 M3 Types 7378 Bedienungsanleitung

IBM

IBM p5 510 Bedienungsanleitung

IBM

IBM eServer 370 xSeries Produktinformationsblatt

IBM

IBM PC Server 520 Bedienungsanleitung

IBM

IBM x3100 M5 Type 5457 Bedienungsanleitung

IBM

IBM BladeCenter HS22 Handbuch

IBM

IBM BladeCenter HS22 Bedienungsanleitung

IBM

IBM System x3620 M3 7376 Bedienungsanleitung

IBM

IBM System x iDataPlex dx360 M2 Bedienungsanleitung

IBM

IBM HS40 - BladeCenter - 8839 Bedienungsanleitung

IBM

IBM pSeries 650 Bedienungsanleitung

IBM

IBM BladeCenter JS21 Types 8844 Bedienungsanleitung

IBM

IBM xSeries 345 Bedienungsanleitung

IBM

IBM Netfinity 5000 Betriebsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung

IBM x3655 - System - 7985 Bedienungsanleitung

Beliebte Server Handbücher anderer Marken
