IBM 3453-F7E Bedienungsanleitung

IBM Cloud Pak for Data system

Customer Install Guide

Connector Node

3453-F7E

Version 1.3

Note

Before using this information and the product it supports, read the information in

“Safety notices” on page 5, “Notices” on page 44, the IBM Systems Safety Notices

manual, G229-9054, and the IBM Environmental Notices and User Guide.

This edition applies to IBM Cloud Pak for Data System Components.

Revised November 2021

US Government Users Restricted Rights –Use, duplication or disclosure restricted by

GSA ADP Schedule Contract with IBM Corp.



© Copyright IBM Corporation 2020, 2021. Customer Install Guide, Connector Node 3
Contents
Safety..............................................................................................................................5
Safety Notices.................................................................................................................6
Publications...................................................................................................................15
Cloud Pak for Data System Connector Node Description.............................................16
Cloud Pak for Data System Connector Node Hardware Specifications ........................17
Operating Environment .................................................................................................18
Rack Requirements.......................................................................................................19
Location in the Rack......................................................................................................20
Connector Node Front and Rear View ..........................................................................21
Package Contents.........................................................................................................22
Chassis Installation Procedure......................................................................................23
Rack rail parts inventory ............................................................................................23
Install the rear mounting bracket................................................................................24
Install the front mounting bracket...............................................................................26
Install the server onto the inner rails..........................................................................27
Slide the server into the rack......................................................................................28
Secure the server before you move the rack .............................................................29
Server removal (optional)...........................................................................................30
Install the CMA onto the Rails.......................................................................................31
Cable management arm parts inventory....................................................................31
CMA orientation.........................................................................................................32
Install the CMA support bar onto the rail....................................................................32
Connect the CMA mounting brackets to the rail.........................................................33
Place the CMA onto the support bar and close the stop bracket. ..............................34
Cabling.......................................................................................................................35
Cable Straps..............................................................................................................36
Assembly Notes ............................................................................................................36
Electronic Emissions Notices........................................................................................38
Regulatory and Compliance..........................................................................................43
Notices..........................................................................................................................44
Copyright License:.........................................................................................................47

Trademarks...................................................................................................................48

Readers’ Comments......................................................................................................49

Safety

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de Segurança.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.

Avant d'installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise lesen.

Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.

Antes de instalar este produto, leia as Informações sobre Segurança.

Antes de instalar este producto, lea la información de seguridad.

Läs säkerhetsinformationen innan du installerar den här produkten

Safety Notices

These statements provide the caution and danger information used in this

documentation.

Important:

Each caution and danger statement in this documentation is labeled with a number.

This number is used to cross reference an English-language caution or danger

statement with translated versions of the caution or danger statement in the Safety

Notices Translation document (PN G229-9054).

For example, if a caution statement is labeled "D005," translations for that caution

statement are in the Safety Notices Translation document under "D005."

Be sure to read all caution and danger statements in this documentation before you

perform the procedures. Read any additional safety information that comes with your

system or optional device before you install the device.

D005

DANGER: When working on or around the system, observe the following precautions:

Electrical voltage and current from power, telephone, and communication cables are

hazardous. To avoid a shock hazard:

If IBM supplied the power cord(s), connect power to this unit only with the IBM provided

power cord. Do not use the IBM provided power cord for any other product.

Do not open or service any power supply assembly.

Do not connect or disconnect any cables or perform installation, maintenance, or

reconfiguration of this product during an electrical storm.

The product might be equipped with multiple power cords. To remove all hazardous

voltages, disconnect all power cords.

For AC power, disconnect all power cords from their AC power source.

For racks with a DC power distribution panel (PDP), disconnect the customer’s DC

power source to the PDP.

When connecting power to the product ensure all power cables are properly connected.

For racks with AC power, connect all power cords to a properly wired and grounded

electrical outlet. Ensure that the outlet supplies proper voltage and phase rotation

according to the system rating plate.

For racks with a DC power distribution panel (PDP), connect the customer’s DC power

source to the PDP. Ensure that the proper polarity is used when attaching the DC power

and DC power return wiring.

Connect any equipment that will be attached to this product to properly wired outlets.

When possible, use one hand only to connect or disconnect signal cables.

Never turn on any equipment when there is evidence of fire, water, or structural

damage.

Do not attempt to switch on power to the machine until all possible unsafe conditions

are corrected.

Assume that an electrical safety hazard is present. Perform all continuity, grounding,

and power checks specified during the subsystem installation procedures to ensure that

the machine meets safety requirements.

Do not continue with the inspection if any unsafe conditions are present.

Before you open the device covers, unless instructed otherwise in the installation and

configuration procedures: Disconnect the attached AC power cords, turn off the

applicable circuit breakers located in the rack power distribution panel (PDP), and

disconnect any telecommunications systems, networks, and modems.

DANGER:

Connect and disconnect cables as described in the following procedures when

installing, moving, or opening covers on this product or attached devices.

To Disconnect:

Turn off everything (unless instructed otherwise).

For AC power, remove the power cords from the outlets.

For racks with a DC power distribution panel (PDP), turn off the circuit breakers located

in the PDP and remove the power from the Customer's DC power source.

Remove the signal cables from the connectors.

Remove all cables from the devices.

To connect:

Turn off everything (unless instructed otherwise).

Attach all cables to the devices.

Attach the signal cables to the connectors.

For AC power, attach the power cords to the outlets.

For racks with a DC power distribution panel (PDP), restore the power from the

Customer's DC power source and turn on the circuit breakers located in the PDP.

Turn on the devices.

Sharp edges, corners and joints may be present in and around the system. Use care

when handling equipment to avoid cuts, scrapes and pinching. (D005)

C002

CAUTION: Only trained service personnel may replace this battery. The battery

contains lithium. To avoid possible explosion, do not burn or charge the battery.

Do not:

Throw or immerse into water

Heat to more than 100°C (212°F)

Repair or disassemble

Exchange only with the approved part. Recycle or discard the battery as instructed by

local regulations. (C002)

C026

CAUTION: This product might contain one or more of the following devices: CD-ROM

drive, DVDROM drive, DVD-RAM drive, or laser module, which are Class 1 laser

products. Note the following information:

Do not remove the covers. Removing the covers of the laser product could result in

exposure to hazardous laser radiation. There are no serviceable parts inside the device.

Use of the controls or adjustments or performance of procedures other than those

specified herein might result in hazardous radiation exposure.

(C026)

IBM® servers can use I/O cards or features that are fiber-optic based and that utilize

lasers or LEDs.

Laser compliance

IBM servers may be installed inside or outside of an IT equipment rack.

All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR

Subchapter J for class 1 laser products. Outside the U.S., they are certified to be in

compliance with IEC 60825 as a class 1 laser product. Consult the label on each part

for laser certification numbers and approval information.

CAUTION:

Data processing environments can contain equipment transmitting on system links with

laser modules that operate at greater than Class 1 power levels. For this reason, never

look into the end of an optical fiber cable or open receptacle. Although shining light into

one end and looking into the other end of a disconnected optical fiber to verify the

continuity of optic fibers many not injure the eye, this procedure is potentially

dangerous. Therefore, verifying the continuity of optical fibers by shining light into one

end and looking at the other end is not recommended. To verify continuity of a fiber

optic cable, use an optical light source and power meter. (C027)

CAUTION:

This product contains a Class 1M laser. Do not view directly with optical instruments.

(C028)

CAUTION:

Some laser products contain an embedded Class 3A or Class 3B laser diode. Note the

following information: laser radiation when open. Do not stare into the beam, do not

view directly with optical instruments, and avoid direct exposure to the beam. (C030)

CAUTION: To reduce the risk of electric shock or energy hazards:

This equipment must be installed by trained service personnel in a restricted-access

location, as defined by the NEC, IEC 60950 and IEC 62368, The Standard for Safety of

Information Technology Equipment.

(R001 part 1)

DANGER: Observe the following precautions when working on or around your IT rack

system:

Heavy equipment–personal injury or equipment damage might result if mishandled.

Always lower the leveling pads on the rack cabinet.
