IBM DMDM-10340 Bedienungsanleitung

Handling precautions

Follow these suggestions to optimize the usage of your

IBM microdrive,as well as those devices in which it is

installed:

ŸDo not cover the breather hole! Covering the

breather hole may result in loss of data.

ŸDo not press on the drive! Do not apply any force

to the drive during handling or installation.

ŸAlways handle the drive with care to prevent

damage from shock, vibration, or electrostatic

discharge (ESD).

ŸHandle the drive carefully by the edges. Do not

touch any exposed printed circuit board.

ŸDo not write on the label or remove it. Do not apply

additional labels.

ŸAlways carry the drive in its plastic case.

ŸDo not drop the drive.

ŸDo not expose the drive to wet conditions.

ŸDo not place the drive near a strong magnetic

field.

ŸDo not expose the drive to extreme temper-

atures.

ŸDo not use the drive in CF+ II slots without an

ejection mechanism.

ŸBe careful when removing the drive from the

host device immediately after operation. It may

become hot during operation.

Quick installation procedure

Note: Back up all data before beginning installation!

Refer to the manual that came with your computer,

camera, or other device to determine if it is compatible

with the CF+ Type II or the PC card type II drive/ inter-

face adapter and to find instructions on inserting and

removing the IBM microdrive.

Using the IBM microdrive with a PC card adapter

With a PC card adapter the IBM microdrive can be

installed in devices such as digital cameras or PCs that

have a PC card type II slot. If your IBM microdrive did

not come with a PC card, it can be purchased

separately.

1. Align the  mark of the IBM microdrive with that of

the PC card.

2. Insert the IBM microdrive firmly into the PC card.

Note: When inserting or removing the PC card, hold

the PC card, not the IBM microdrive.

Using the IBM microdrive without a PC card adapter

The IBM microdrive is compatible with the CF+TM Type II

standard and can be used in devices with the CF+ II slot

without an adapter card. Refer to the manual shipped

with the device to determine its slot type.

IBM storage products

Page 1

IBM Hard Disk Drive Technical Support Center version3.0

Quick installation guide

IBM family of

microdrives

CF+ Type II

DMDM-10340

DMDM-10170

Models:

If your PC is not recognizing the IBM microdrive

With the Plug & Play feature of Windows® 98 and 95

your PC should automatically recognize the IBM

microdrive. If it does not do so, do the following:

1. In Windows, select Start and Settings.

2. Click Control Panel.

2. Click the Hardware icon, click Next.

3. Select No in the Hardware Wizard, click Next.

4. Select Hard disk controller as the hardware type,

click Next.

5. Specify Standard IDE/ESDI hard disk controller

Operating systems

The IBM microdrive has been tested for general

compatibility with the following operating systems:

•Windows 98

•Windows 95

•Windows CE

•Apple® OS (refer to the URL below for the

applicable operating systems)

Other operating systems may be compatible with the

IBM microdrive but have not been tested.

Product information

The latest product information can be obtained from the

url http://www.ibm.com/storage/microdrive,including

•Technical tips

•Complete product specifications

•List of compatible devices

©International Business Machines Corporation 1999

www.ibm.com/harddrive

IBM Hard Disk Drive Technical Support Center

Dept. WCN

3605 Highway 52 North

Rochester, MN 55901

Telephone: 888.IBM.5214 or 507.253.4110

Fax: 507.253.DRIVE

E-mail: [email protected]

Singapore Technical Support Center

Telephone: 65.1800.840.9292

E-mail: drive@sg.ibm.com

IBM Systems Storage Division

5600 Cottle Road

San Jose, CA 95193

www.ibm.com/storage

Printed in the United States of America

06-99

IBM is the registered trademark of International Business Machines Corporation.

Other company, product, and service names may be trademarks or service marks of others.

Produced by the IBM Hard Disk Drive Technical Support Center.

OEM Hark Disk Drive Specifications for DMDM-10340/10170,microdrive with CompactFlash

Type II, Preliminary revision 0.3.

Product Description data represents IBM’s design objectives and is provided for comparative

purposes; actual results may vary based on a variety of factors. This product data does not

constitute a warranty. Questions regarding IBM’s warranty terms or methodology used to

derive this data should be referred to the IBM Hard Disk Drive Technical Support Center.

Data subject to change without notice.

Date: 17th June 1999

IBM storage products

Page 2

IBM Hard Disk Drive Technical Support Center version3.0
