Ice-O-Matic IOD 250 Bedienungsanleitung

IOD 250 Series

ICE Dispenser

IOD 250

ICE-O-Matic ®is the Best ICE Making Solution for:

Hard Water, Food Safety and Tight Spaces

✓Stores 250 lbs. (114 Kgs.) of ICE

✓Constructed from sturdy, corrosion-resistant

300 series stainless steel

✓ Only 30 inches (762 mm) wide

Problem

Maximum ICE

Maximum ICE storage in a minimum amount of space -

30 inches wide and holds 250 pounds of ICE

Worry-Free Dispensing

Direct Dispense - ensures that ICE hits the glass every time.

Quick Stop - prevents ICE overflow and waste.

Solution

Tight-Fitting Spaces

Counter space utilization

Sloppy Ice Dispensing

Ice dispenses inaccurately, often

missing or overfilling the glass

Inconsistent Ice Dispensing

Ice congeals in dispenser causing Ice

jams and inconsistent dispensing

Greater Dispensibility

Auto Rotate - turns the ICE for 4 seconds every

hour to consistently provide more dispensible ICE

Ice Melts Too Fast

Inadequate storage bin insulation

causes Ice to melt too quickly

Maximum Preservation

Dispenser bin is insulated with foam for maximum

ICE preservation - 1 inch of insulation

Hard To Clean

Ice cube machine must be lifted off

dispenser for cleaning

Power Clean

Allows access to the dispenser for easy cleaning

without moving the ICE machine

IOD 250 Push Bar 250 (114) 115/60/1 Cord305 15 197 (89)

*Applied capacity refers to actual weight of ice: one cubic foot weighs 32.9 lbs (15 kg).

Call factory for other dispensing options.

ICE-O-Matic’s® machines are not designed for outdoor installations. ICE-O-Matic®remote condensers are designed for outdoor installations.

Machine requires voltage indicated on rating name plate. Failures caused by improper voltage are not considered factory defects. Extended

periods of operation at temperature exceeding limitations constitutes misuse under the terms of ICE-O-Matic®Manufacturer’s Limited Warranty,

resulting in a loss of warranty coverage. Specifications and design are subject to change without notice.

Model Dispenser Bin Storage Voltage Min. Circuit Maximum Shipping

No. Operated by: Applied Capacity* Characteristics No. of Wires Ampacity Fuse Size Weight lbs. (Kgs.)

ORDERING AND SPECIFICATION INFORMATION

39 5/8"

(1006 mm)

30 1/4"

(768 mm)

30"

(762 mm)

3011/16"

(767 mm)

OPERATING LIMITS

Ambient Temp. Range

Air & Water 50° - 100°F (10° - 38°C)

Water Temp. Range 40° - 100°F (4.5° - 38°C)

Water Pressures Min. 20 psi

Max. 120 psi

Electrical Voltage Min. -5% Max. +10%

IOD 250 Series ICE Dispenser

60 Hz

Air-Cooled lbs. (kgs.) 352 (160) 506 (230) 625 (284) 706 (321)

Water-Cooled lbs. (kgs.) 351 (160) 528 (240) 567 (258) 647 (294)

Remote-Cooled lbs. (kgs.) n/a n/a 591 (269) 727 (330)

Voltage Char. 115/60/1 115/60/1 115/60/1 208-230/60/1

1. Tested at 70º Air/50º Water.

2. All specifications and performace data are subject to normal manufacturing variances.

Options:

KWGFID water glass filler kit for 30” IOD 2 (1)

KBT25022 adapter for 22” cubers on 30” IOD 24/11

KBT25030 adapter for 22” cubers on 30” IOD 24/11

Model ICE 0250 ICE 0400 ICE 0500 ICE0606

ICE PRODUCTION FOR OPTIONAL CUBE ICE MAKERS — POUNDS (KILOGRAMS) PER 24 HOURS

Dimensions

We reserve the right to make changes in design and construction at any time

without obligation.

2003 © ICE-O-Matic Rev Code: 4002A-08/03-SS

ICE-O-Matic 11100 E. 45th Avenue, Denver, CO 80239

Tel. 303 371-3737 Fax. 303 371-6296 www.iceomatic.com

30 1/4

768 mm

16 1/4

413 m

7/8

3 mm

Front View

RIGHT

2 3/4

70 mm

10 1/16

256 mm

CUP

CLEARANCE

7 3/4

197 mm 21 1/4

540 mm

737 mm

30 11/16

779 mm

30 7/16

773 mm

39 5/8

1006 mm

Side View

762 mm

7/16 (4) PLCS

11 mm

18 5/8

473 mm

584 mm

3 1/2

89 mm

11 5/8

295 mm

26 7/16

672 mm

9 3/16

233 mm

3011/16

779 mm

REMOVABLE

SINK

TO FRONT OF

DRIP TRAY ON

COUNTER TOP

TO FRONT TOP OF

DRIP TRAY

737 mm

21 1/4

540 mm

305 mm

229 mm

OPENING

MOUNTING

TEMPLATE

RECOMMENDED COUNTER OPENING SIZE 9" X 12" FOR

UTILITIES AND TUBING. OPENING CAN BE LOCATED

ANYWHERE WITHIN THE SHADED AREA.

1 13/16

46 mm

1 5/16

33 mm

Half Cube

7/8" x 7/8" x 3/8"

(22mm x 22mm x 10mm)

Full Cube

7/8" x 7/8" x 7/8"

(22mm x 22mm x 22mm)
