User manual
VCast Control Station for Live Streaming
Important Safety Instructions
1. Read this manual thoroughly before using this unit.
2. Keep this manual for future reference.
3. Take notice of and comply with all warnings included in the user's manual or indicated on the
appliance.
4. Follow all instructions included in this manual.
5. Do not expose this unit to rain or moisture. Avoid having water or other liquids spilled on this
unit.
6. When cleaning the cabinet or other parts of this appliance, use only a dry or slightly damp soft
cloth.
7. Do not block any ventilation openings or interfere with the proper ventilation of this unit. Install
in accordance with the manufacturer's instructions.
8. Do not use or store near any heat sources such as radiators, heat registers, stoves, or other heat-
producing appliances.
9. Do not interfere with the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding-type plug has two blades and a third
grounding prong. These are designated for your safety. If the provided plug does not fit into your
outlet, consult an electrician.
10. Protect the power cord from being walked on or otherwise damaged by items placed on or
against them. Particular attention should be given to the plugs, receptacles, and the point where
the cord exits the appliance.
11. To avoid the risk of electrical shock, do not touch any exposed wiring while the unit is in
operation.
12. Only use attachments/accessories specified by the manufacturer.
13. Unplug this unit and all connected electrical equipment during lightning storms or when left
unused a long period of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the appliance has
been damaged in any way or fails to operate normally.
WARNING: To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture
Overview...................................................................................................4
Introduction...............................................................................................5
What’s in the package? ............................................................................5
Registration .............................................................................................6
Features ...................................................................................................7
Top Panel Layout......................................................................................8
Gerenal settings .....................................................................................12
Rear Panel Layout..................................................................................13
Import Audio Files...................................................................................14
Getting Started .......................................................................................15
Set up the iMap ......................................................................................16
Installing iMap Software for Mac OS .....................................................16
Installing iMap Software for Windows.....................................................19
Firmware upgrade ..................................................................................21
Hardware Connections (with PC/Mac only)............................................25
Specications .........................................................................................26
Services..................................................................................................27
Contents
Overview
The live streaming revolution has been growing in popularity and scope for a number
of years, with live streaming apps taking it to a new level, providing platforms for
debate, sharing information, talent and fun in a global arena with potential audiences of
thousands!
Live broadcasters love being ‘in the moment’, equipped with the right sounds, the right
effects and the right functionality, whether they are interacting with their audience or
family and friends.
Broadcasters look for the very best available quality, resources and value for money to
enable the very best quality productions.
Please step forward, the Icon Pro Audio VCast! The VCast is a powerful control station
for live streaming , utilising a myriad of sounds, functions and effects to enable the
highest quality broadcasts featuring not only reverb and delay, but EQ and vocal tuning.
With exemplary architecture and build quality, the Icon Pro Audio VCast will provide
years of outstanding service.
Let’s begin the journey...
5
Introduction
What’s in the package?
●VCast Control Station for Live Streaming x1
●USB cable (Type C) x1
●2.4GHz USB dongle for wireless transmitting
Firstly, congratulations on your purchase of the ICON Pro Audio VCast Control
Station for Live Streaming! In these pages, you'll nd a detailed description of the
features of the VCast Control Station for Live Streaming, as well as a guided tour
through its front and rear panels, step-by-step instructions for their setup and use
and a full list of specications. As you read through the manual, you will spot orange
boxes - these denote actions for you to complete which will help you get underway.
As with most electronic devices, we strongly recommend you retain the original
packaging. In the unlikely event that the product is returned for servicing, the original
packaging (or reasonable equivalent) is required. With proper care and adequate
air circulation, your VCast Control Station will operate awlessly for many years to
come.
We trust that this product will provide years of excellent service and in the unlikely
event that your product does not perform to the highest standard, every effort will be
made to address the issue.
6
Registration
●Please follow the step-by-step procedures.
●Input the device’s serial number and your personal information as per
the instructions.
●By registering your product online, you are entitled to service and after-
sales support at our HelpCenter, which you can access by visiting our
website at www.iconproaudio.com.
●All the registered products in your account will be listed on your
personal product page where you can nd up to date information for
your device, such as rmware/driver upgrades, software bundles and
user manual downloads.
First Things First - Let’s Get You Registered!
Please register the product on our website at the link below;
http:// iconproaudio.com/registration
7
Features
●Extremely compact, durable and versatile design
●Superior build quality and robust metal casing with Kensington lock port
●1 touch-sensitive motorized fader with 10-bit resolution
●12 LED channel level metering
●Backlit LCD to display channel name, control values, etc.
●8 x dual-function encoder knobs for controlling different plug-in parameters with
page "Up" and "Down" buttons
●Individual control knobs for controlling "Reverb" & "Delay"
●16 individually illuminated trigger buttons for importing user samples/jingles
●12 different presets for different applications with individually illuminated trigger
buttons
●Individually illuminated function buttons including "Voice-Over", “BGM (Background
Music) key", "Vocal Tune semi-tone", "BGM (Background Music) On/Off", "Mute"
and "Master"
●6 illuminated transport buttons including Play, Stop, Rec, Rewind, Fast Forward
and Loop
●Control knob is equipped for switching different media player
●5 illuminated transport buttons including Play/Stop, Rewind, Fast Forward,
Previous & Next song (Media Player control)
●USB 2.0 high-speed connectivity
●Firmware upgrade available via USB connection and iMapTM software
●2.4 GHz wireless connectivity with rechargeable battery
●2.4GHz USB dongle wireless unit included
●User A & User B 1/4 inch inputs for connecting footswitch pedals
●Platform D3 LCD display connector available (Optional)
●Class-compliant with Windows 10, Windows 8 (32-bit & 64-bit), Windows 7 (32-bit
& 64-bit)
8
1
9
7
10
8
13
5
6
17
12
4
15
14
16
3
11
2
Top Panel Layout
1. LCD backlit display
The backlit LCD display shows the parameter values as you adjust them and
also provides feedback about channel selection, operating modes, and more.
2. Preset/Mode or Master fader
The touch sensitive motorized fader can be used to adjust the parameters of
different channels, the "Preset/Mode" parameters, (relative to the “Preset/Mode”
button selected) and adjust output volume. Additionally, when the “Master”
button is activated, the fader will control the master channel.
The touch sensitivity of the high quality fader allows the user to override
automation, the second the fader is touched. Furthermore, because it is
motorized, it will automatically move to reect the current level of the selected
"Preset/Mode" in Bitwig 16Track . Any parameter adjustments made with the
fader will be displayed immediately on the LCD display.
3. 8xDual function encoders
The dual function encoder knob acts as a push-button and a rotary control.
These are used to control the selected plug-in parameters.
4. Page Up & Down buttons
Press these buttons to scroll across different parameter pages of the selected
plugin.
9
5. Sample / Jingles buttons
There are 16 preloaded sample/jingle buttons. You may overwrite these samples
by importing your own preferred audio les in Bitwig 16 Track software. Please
refer to "How to import audio le for samples/jingles" in P14.
Factory preloaded samples included:
LOL a Laugh Out Loud effect sample
Shocking a shocking sound effect sample
Fun a crowd laughing effect sample
Innocent a innocent sound effect sample
Helpness a helpness sound effect sample
OMG a Oh My God sample
Curosity a curosity sound effect sample
What a What sample
Birdy a bird y over sound effect sample
Sword fencing a sword fencing sample
Beat Up a beat up sound effect sample
Slap a face slapping sample
Laugh a group laughing effect sample
Hello a Hello sound sample
Air Horn a series of air horn sound sample
Horrify a horrify sound effect sample
6. Preset / Mode buttons
There are 12 different "Preset/Mode" buttons for different applications. Each
"Preset/Mode" setting is congured with different plug-in effects/parameters,
ideal for each particular application. Activating each "Preset/Mode" button will
select its track, then adjust the "Preset/Mode" volume by sliding the fader and
mute it by pressing the "Mute" button. Additionally, adjust different effects such
as ‘reverb’ and ‘delay’ etc. by rotating their corresponding knobs.
12 Presets/Modes
Chat for chatting when live streaming
Radio a radio sound effect emulation when live streaming
Gaming the monitor channel is muted while live streaming
10
Concert effects are congured for professional singers when live
streaming
Karaoke effects are congured for karaoke when live streaming
Hip-hop effects have been congured for the hip-hop song genre
Hi-Tone
(Reverb) congured for singers with a higher tone
Low-Tone
(Reverb) congured for singers with a lower tone
Hi-Tone
(Vocal Tune) congured for singers who perform with a high tone
Low-Tone
(Vocal Tune) congured for singers who perform with a low tone
Vocal Tune congured with vocal tuning
Pitch Shift congured with pitch shifting effects
7. BGM [background music] Key control button & knob
Activate the "BGM Key" button and adjust the control knob [11] to adjust the key
of the BGM.
8. Vocal Tune Semi-Tone button & Knob
Activate the "Vocal Tune Semi-Tone" button and adjust the control knob [11] to
select the semi-tone of the vocal tuning function.
9. Reverb adjust knob
Rotate the knob to adjust the reverberation parameters. Its value will be
displayed on the LCD in blue digits.
10. Delay adjust knob
Rotate the knob to adjust the delay parameters. Its value will be displayed on
the LCD in purple digits.
11. Media Player switching knob
Press this knob once to enter into the "Media Player"select mode. Then rotate
this knob again to switch to a different media player. Press the knob to conrm
the selected media player.
12. Media Player Transport buttons
These 5-function buttons control the selected media player.
13. Voice-Over function button
Press this button for the voice-over function. The BGM will lower in volume when
the mic signal has detected activation.
