DC-C4212RX

Quick Guide

FCC Compliance Statement

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL

ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO

FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH

THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO

COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA

IS LIKELY TO CAUSE HARMFUL INTERFERENCE, IN WHICH CASE USERS WILL BE

REQUIRED TO CORRECT THE INTERFERENCE AT THEIR OWN EXPENSE.

WARNING

: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE

PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY

TO OPERATE THE EQUIPMENT. THIS CLASS OF DIGITAL APPARATUS MEETS ALL

REQUIREMENTS OF THE CANADIAN INTERFERENCE CAUSING EQUIPMENT

REGULATIONS.

WEEE (Waste Electrical &

Electronic Equipment)

Correct Disposal of This Product

(Applicable in the European Union and other European countries

with separate collection systems)

This marking shown on the product or its literature, indicates that

it should not be disposed with other household wastes at the end

of its working life. To prevent possible harm to the environment or

human health from uncontrolled waste disposal, please separate this

from other types of wastes and recycle it responsibly to promote the

sustainable reuse of material resources.

Household users should contact either the retailer where they

purchased this product, or their local government oce, for details

of where and how they can take this item for environmentally safe

recycling.

Business users should contact their supplier and check the terms and

conditions of the purchase contract. This product should not be mixed

with other commercial wastes for disposal.

Body

Top Cover

Accessories

1. Network Camera

2. Quick Guide

3. Screws and Anchors (each 2ea)

4. Guide Pattern

IR LED Lens

Network Port Wall/Ceiling Installation Hole

Cable Access Hole Factory Reset Button

Body

Dimension

58mm

30mm

86mm

26mm

2mm

Camera Installation

1. Turn the top cover counterclockwise.

2. Use the screws, anchors provided with the camera to secure the

body on a wall or a ceiling.

3. Connect the network cable like the following picture.

4. Attach the top cover to the bottom cover. Turn the top cover

clockwise to fasten it.

*If the network cable comes out as shown below, use a nipper to cut out the cable

access hole in the top cover.

• Check the wall or ceiling to see if it needs to be

reinforced. The camera may fall o if the wall or

ceiling is not strong enough to support its weight.

• Install the camera in a shaded area. If the camera

is installed in direct sunlight, it may be aected

adversely.

Specications

Supported

Resolution

1920x1080, 1280x720, 704x480, 640x360, 352x240

Image Sensor 1/2.8” CMOS

Lens 2.8mm Fixed-focal lens

Video

Compression

H.265, H.264 Main Prole, M-JPEG

Power Source PoE

Power

Consumption

PoE, IEEE 802.3af(Class1), 3.3W

5. Adjust the angle.

8 V1.1

※ Please download software (IDIS Discovery, IDIS Center, IDIS Solution Suite

Compact) and product manual from this link :

- IDIS Website (www.idisglobal.com)
