IFM ANT424 Bedienungsanleitung

Installation Instructions

RF identification system

Read/write head

ANT424

ANT425

80278720 / 00 10 / 2018

Content

1 Preliminary note��4

1�1 Symbols used ��4

2 Safety instructions ��4

2�1 General��4

2�2 Radio equipment ��5

2�3 Interference of electronic and medical devices ��5

3 Functions and features ��5

4 Functions ��5

4�1 Operating principle ��5

4�2 Overview��6

5 Installation��6

5�1 General installation instructions��6

5�2 Notes on ID tag mounting��6

5�3 Avoiding interference ��7

5�4 Mechanical design��7

5�5 Fixing ��7

5�6 Mounting distances��8

5�6�1 ANT424��8

5�6�2 ANT425��8

5�7 Positioning of the ID tags��9

5�7�1 ANT424��9

5�7�2 ANT425��9

6 Electrical connection��10

6�1 Wiring ��10

6�2 cULus ��10

7 Display elements �� 11

8 Operation�� 11

9 Dimensions��12

9�1 ANT424��12

9�2 ANT425��12

10 Technical data��12

11 Maintenance, repair and disposal ��12

12 Approvals/standards ��13

12�1 Radio approvals��13

12�1�1 Overview��13

12�1�2 Europe ��13

12�1�3 EC declaration of conformity ��13

1 Preliminary note

This document is part of the device and contains information about the correct

handling of the product�

This document is intended for specialists� These specialists are people who are

qualified by their training and their experience to see risks and to avoid possible

hazards that may be caused during operation or maintenance of the device�

Read this document before use to familiarise yourself with operating conditions,

installation and operation� Keep this document during the entire duration of use of

the device�

1.1 Symbols used

►Instructions

→Cross-reference

Important note

Non-compliance can result in malfunction or interference�

Information

Supplementary note

2 Safety instructions

2.1 General

Observe the operating instructions� Non-observance of the instructions, operation

which is not in accordance with use as prescribed below, wrong installation or

incorrect handling can affect the safety of operators and machinery�

The installation and connection must comply with the applicable national and

international standards� Responsibility lies with the person installing the device�

The device must only be installed, connected and put into operation by a qualified

electrician as the safe function of the device and machinery is only guaranteed

when installation is correctly carried out�

Disconnect the unit externally before handling it�

In case of malfunction of the device or uncertainties please contact the

manufacturer� Tampering with the device can seriously affect the safety of

operators and machinery� This is not permitted and leads to an exclusion of liability

and warranty�

2.2 Radio equipment

In general, radio equipment must not be used in the vicinity of petrol stations, fuel

depots, chemical plants or blasting operations�

►Do not transport and store any flammable gases, liquids or explosive

substances near the unit�

2.3 Interference of electronic and medical devices

Operation can affect the function of electronic devices that are not correctly

shielded�

►Disconnect the device in the vicinity of medical equipment�

►Contact the manufacturer of the corresponding device in case of any

interference�

3 Functions and features

In connection with the evaluation unit DTE10x the read/write head ANT424/

ANT425 enables non-contact reading and/or writing of the RFID transponders

(ID tags) conforming to the system�

The data is converted into digitally coded values and provided to the evaluation

unit�

4 Functions

4.1 Operating principle

The ID tags are operated passively, i�e� without battery� The energy required for

operation is supplied by the read/write head�

The physical principle of the energy transfer is based on inductive coupling� The

integrated antenna coil in the read/write head generates a magnetic field which

partly penetrates the antenna coil of the ID tag� A voltage is generated by induction

that supplies the data carrier with energy�

4.2 Overview

Art� no�:

Function:

Type designation:

Operating frequency:

Type:

Max� transmission power:

ANT424

Read/write head

DTRHF GBRWIDUS03

13�56 MHz

M18, flush mountable

200 mW

Art� no�:

Function:

Type designation:

Operating frequency:

Type:

Max� transmission power:

ANT425

Read/write head

DTRHF GNRWIDUS03

13�56 MHz

M18, non-flush mountable

200 mW

5 Installation

5.1 General installation instructions

When mounting several read/write heads adhere to the minimum distances

between the systems�

Flush mounting of a read/write head in metal reduces the read/write

distance�

The immediate vicinity of powerful HF emission sources such as welding

transformers or converters can affect operation of the read/write heads�

Information on the available mounting accessories is available on our website at:

www�ifm�com

5.2 Notes on ID tag mounting

If the ID tags are mounted in/on metal, the read/write distance is reduced�

For positioning the ID tags the read/write heads are marked with an

antenna symbol on the active face� It designates the middle of the

integrated antenna coil and has to correspond with the middle of the ID tag�

The orientation of the read/write head antenna axis must correspond with

the axis of the ID tag coil�

The best way to position the available ID tags and on mounting in metal is

available on our website: www�ifm�com

5.3 Avoiding interference

The device generates a modulated electrical field with a frequency of 13�56 MHz�

To avoid interference of the data communication no other devices generating

interference emission in this frequency band must be operated in the vicinity� Such

devices are for example frequency converters and switched-mode power supplies�

5.4 Mechanical design

1: Sensing face (ANT424) 1: Sensing face (ANT425)

5.5 Fixing

►Fix the device using the supplied nuts (M18)�

flush (ANT424) non-flush (ANT425)

5.6 Mounting distances

5.6.1 ANT424

Operating mode Distance side (A) Distance front (B)

For reading and writing ≥ 60 mm ≥ 100 mm

5.6.2 ANT425

Operating mode Distance side (A) Distance front (B)

For reading and writing ≥ 90 mm ≥ 180 mm

5.7 Positioning of the ID tags

5.7.1 ANT424

►Align the ID tag on the antenna central axis�

Distance read/write head (D)

ID tag Type plastics

E80371 16 mm

All indications apply to static read/write operations�

5.7.2 ANT425

►Align the ID tag on the antenna central axis�

Distance read/write head (D)

ID tag Type plastics

E80371 40 mm

All indications apply to static read/write operations�

6 Electrical connection

ATTENTION

The unit must be connected by a qualified electrician�

Device of protection class III (PC III)

The electric supply must only be made via PELV/SELV circuits�

►Disconnect power before connecting the unit�

6.1 Wiring

►Connect the device to the evaluation unit DTE10x using the M12 connection�

Voltage is supplied via the evaluation unit�

L+

DATA

A selection of sockets is available on our website at: www�ifm�com

Cables with the following characteristics are suitable for the connection:

Length Ohmic resistance (feed + return line) Effective cable capacity

< 20 m max. 3Ω max� 3 nF
