IHome IBT8080 Bedienungsanleitung

instruction manual

Model: iBT8080

CHARGE

BEFORE

USE

Color Changing Rechargeable

Bluetooth Wireless Stereo

Speakers with Speakerphone

Introduction

Thank you for purchasing the iHome iBT8080. This product is designed to

provide high quality wireless sound for your iPad, iPhone, iPod, computer,

PDA or other Bluetooth audio device.

This instruction booklet explains the basic operation and care of the unit.

Please read them carefully and keep for future reference.

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or

excessive heat.

• Protect your furniture when placing your unit on a natural wood and

lacquered ﬁnish. A cloth or other protective material should be placed

between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water.

Stronger cleaning agents, such as benzene, thinner or similar materials

can damage the surface of the unit.

iBT8080

What’s Included

• iBT80 speaker X 2

• Combination micro USB to USB charging cable/audio in cable x 2

• Carry strap x 2

Carry strap

iBT80 iBT80

Combination

micro USB to USB cable/audio cable

iBT8080

Front

Microphone

Back

Bluetooth/

Speakerphone

Button

Color Mode Button

(press and hold for

Battery Review)

Lower/Raise Volume

Buttons

Charging/

Aux-in

USB port

Carry Strap

Channel

Meet Your iBT8080

Bottom

Top

Power On/O

Switch

Charging/Bluet

ooth Status

Indicator Light

Carry Strap

Channel

(lantern mode)

Getting Started: Carry Strap

The iBT8080 has two channels to attach the

included carry strap, one on the bottom to hang

the unit like a lantern, and one on the lower back

of the unit. To attach the carry strap, form a small

loop in one end of the carry strap. Insert this loop

through the desired channel, then pull the

loop back through the larger loop formed in the

carry strap to tighten.

Charging the Unit

CHARGE UNIT BEFORE USE/KEEP UNIT OFF FOR FASTER CHARGING

1. Connect the micro USB plug on the included combination cable to the

micro USB Charging/Aux-in USB Port on the side of the unit.

2. Connect the standard USB plug end of the cable to a power USB port

on a computer, a USB AC adaptor or other USB charging device. For

ﬁrst time use, charge unit for about 4 hours. The status indicator LED

on top of the unit turns solid red while charging and turns o once unit

is fully charged.

iBT8080

Charge via computer USB port, USB AC adaptor or other powered USB port

iHome iBT80 USB port

Computer USB port

Computer

connected to

working outlet

iHome iBT80 USB port

USB AC adaptor

(not included)

USB AC adaptor

connected to working outlet

3.To review the charging status of the unit while it is charging, press and

hold the Color Mode Button. The cabinet lights will ﬂash green from

bottom to top for 12 seconds to show unit is charging.

Reviewing Battery Charge Level

(Charger is Disconnected and unit is ON)

1. Press and hold the Color Mode Button when unit is ON but not

charging (micro USB cable not connected) to enter Battery Review

Mode. The cabinet lights will blink and built-in voice will announce the

current battery level.

TIP: On some iOS (Apple)

devices, you can view the

iBT8080 battery status on your

device’s screen. When device is

paired and connected, look for a

vertical battery icon next to the

Bluetooth icon on the upper

right corner of the

device’s screen.

LowVery Low

RED GREEN

Good High

iBT8080

Left Speaker

Right Speaker

Power ON both

speakers

within 10

seconds for

Wireless

Stereo

Getting Started: First Time Use

Wireless Stereo

Each of your iBT8080 speakers are pre-synced to one

another for Wireless Stereo operation. This sync is

permanent (neither speaker can be synced with a

dierent or third speaker).

Slide the Power O/On Switch located on the bottom

of each speaker to ON to turn it on and start Wireless

Stereo link. Tones will sound and each speaker will ﬂash

green while attempting to establish a link. The indicator

on the top of each speaker will glow green when the

Wireless Stereo link is successful and an audio prompt

will identify each speaker as left channel or right

channel. After successful Wireless Stereo linking, the

speakers will enter Bluetooth pairing mode (see below).

After ﬁrst time power on, user must pair manually (see

page 6).

NOTE: Once speakers are linked, powering OFF one

speaker will also turn the other speaker o. To turn

that speaker back on, move the Power O/On Switch

to OFF then back to ON.

Wireless Stereo is not working

If Wireless Stereo link fails or does not work, make sure both speakers are

powered on within 10 seconds. If problem remains, turn both speakers o and

reset the Wireless Stereo sync. Please follow the steps below to reconnect both

speakers:

1 Power On one speaker (Slide Power On/O Switch to ON). The green

cabinet LED will ﬂash.

2 Within 10 seconds, press and hold the Bluetooth Button and Volume "-"

Button at the same time

for 3 seconds. Keep speaker powered on.

3 Repeat above steps with the other speaker and wait for them to

reconnect.

Note: If step 2 is not completed within 10 seconds, please power O the

speaker and repeat.

Using the iBT8080

Pairing Your Device

Pairing is the set-up process to introduce your Bluetooth-capable device to

the iBT8080. Once your device is paired, the iBT8080 can recognize it and

you can play your audio through it.

1. Turn on your Bluetooth device and make it “discoverable”

by turning on Bluetooth mode (check in Options or

Settings).

2. Slide the Power On/O Switch to ON to turn on the

iBT8080. The ﬁrst time the unit is powered on, it will

enter auto-pairing mode: the unit will beep and the

Bluetooth status indicator light on top of the unit will

ﬂash quickly while the unit attempts to pair. (If Color

Mode is on, the cabinet lights will ﬂash blue and red.)

“iHome iBT8080” should appear in your device’s

Bluetooth menu. Select “iHome iBT8080” on device to

begin/complete pairing. If prompted for a passcode, enter

“1234” on your device’s keypad. 1 beep will sound and the

Bluetooth status indicator light will appear solid blue (in

Color Mode, cabinet will ﬂash blue twice), indicating the

iBT8080 paired and ready to play music. There should

also be an indication on your device. If no device is

successfully paired within 3 minutes the iBT8080 will

default to previous mode.

3. To pair with a dierent device or at a dierent time, make

sure unit is powered on, then press and hold the

Bluetooth/Speakerphone Button for 2 seconds. Select

“iHome iBT8080” on device to pair.

Once the iBT8080 is paired to a device, it will attempt to

autolink when the device is within range (about 33 feet).

Manual Pairing

1. Slide the Power O/On Switch on each speaker to ON.

Wireless Stereo linking should take about 10 seconds.

2. Press and hold the Bluetooth/Speakerphone Button

(located on the back) on the left speaker for 2 seconds.

3. Select “iHome iBT8080” on your device’s Bluetooth menu

to complete pairing.

Using the iBT8080

o on

iHome iBT80

o on

Pairing with a Single iBT8080 Speaker (Mono Operation)

To use a single speaker, just turn one on instead of both. To use both speakers

separately, turn on and pair each speaker separately with a dierent device. When

separately paired speakers are returned to within Wireless Stereo range, each will

maintain separate pairing unless one is powered o then powered back on, in which

case it will attempt Wireless Stereo linking.

Note: Each separately paired speaker will appear on your device as “iHome

iBT8080” (just as when you pair both speakers together). You can select the

desired instance or remove “iHome iBT8080” and re-pair unit(s) again.

Playing Audio Via Bluetooth

1. Slide the Power O/On Switch on BOTH speakers to ON within 10 seconds.

Following Wireless Stereo linking,the Bluetooth status indicator will glow solid

blue when a linked device is in range and detected. You can then listen to audio

streamed wirelessly from your paired Bluetooth device.

2. Use controls on your Bluetooth device to adjust volume and to play, pause and

navigate tracks.

3. Press the –or +Button to adjust the iBT8080 volume. You can also adjust

volume on your device.

4. When done listening, slide the Power O/On Switch to OFF on both speakers.

Speakerphone Operation

NOTE: The unit must be powered on and linked to a Bluetooth phone to receive a

call.

1. When a call is received, playing music is muted to hear the ring tone and the

cabinet lights ﬂash green. Press the Bluetooth/Speakerphone Button to

answer the call, or press and hold to reject the call. For call waiting function,

press the button again to answer a second call, and once more to return to the

original call. Press and hold to end the current call and return to a remaining

call.

2. When a call is completed, press the Bluetooth/Speakerphone Button to end

the call and resume previous function.

Using the iBT8080

Playing Audio via Aux In

1. Connect micro USB charging/audio cable to the Charging/Aux-in USB Port on

the side of the unit and connect the 3.5mm audio plug end to the headphone or

line-out jack on your audio device.

2. Slide the Power On/O Switch to ON turn the unit ON.

3. Power on the audio device and use the controls on the device to play or pause

audio and to navigate tracks.

4. Press the –or +Button to adjust the system volume. You can also adjust

volume on your device.

5. When done listening, slide the Power On/O Switch to OFF turn the unit OFF.

Remember to turn o your device, too.

Using Color Modes

There are six color modes, which you cycle through in this order:

a. Slow Fade (colors slowly fade from one into the next

b. Fast Change (colors change rapidly)

c. One Color (select a favorite color)

d. Pulse to Music (lights ﬂash to the beat of the music)

e. Preset Pulsing (each light array pulses through its own preset pattern of colors)

f. O (no display)

1. Slide the Power On/O Switch to ON turn the unit ON.

2. Press the Color Mode Button repeatedly to cycle to the desired color mode.

For One Color mode, ﬁrst cycle to Fast Change mode and press the Color Mode

Button when the desired color appears. For Pulse to Music, make sure the volume

on your connected Bluetooth device is above 30%.

3. When done, slide the Power On/O Switch to OFF turn the unit OFF.

Using the iBT8080

Inhaltsverzeichnis

Andere iHome Sprecher Handbücher

iHome

iHome iBT55 Bedienungsanleitung

iHome

iHome iBT371 Bedienungsanleitung

iHome

iHome iBT10 Bedienungsanleitung

iHome

iHome iBN27 Bedienungsanleitung

iHome

iHome iBT15 Bedienungsanleitung

iHome

iHome iBT56 Bedienungsanleitung

iHome

iHome iDM8N Bedienungsanleitung

iHome

iHome PLAYGLOW MINI iBT800 Bedienungsanleitung

iHome

iHome PLAYGLOW MINI iBT810 Bedienungsanleitung

iHome

iHome iHPA-1500LT Bedienungsanleitung

iHome

iHome iBT372 Bedienungsanleitung

iHome

iHome PetMedics 2P1S0005 Bedienungsanleitung

iHome

iHome iBT36 Bedienungsanleitung

iHome

iHome iAVS16 Bedienungsanleitung

iHome

iHome iHRK-500S-PR Bedienungsanleitung

iHome

iHome iZ20 Bedienungsanleitung

iHome

iHome iW3 air series Leitfaden

iHome

iHome iBT24 Bedienungsanleitung

iHome

iHome iBT371 Bedienungsanleitung

iHome

iHome iW1 air series Bedienungsanleitung

iHome

iHome iBN10 Bedienungsanleitung

iHome

iHome iHome iDM8N1 Bedienungsanleitung

iHome

iHome TIMEBOOST iBTW41 Bedienungsanleitung

iHome

iHome iDM3 Bedienungsanleitung

Beliebte Sprecher Handbücher anderer Marken

argon audio

argon audio IE20 Bedienungsanleitung

Denon

Denon SC-N7 Bedienungsanleitung

Gemline

Gemline Ace 3952 Bedienungsanleitung

Focal

Focal ON WALL 300 Bedienungsanleitung

HEADRUSH

HEADRUSH Maximus HRSP 5024 Bedienungsanleitung

SoundLogic

SoundLogic BCCS-6/6395 Bedienungsanleitung

Peavey

Peavey DTH 218 Bedienungsanleitung

Avantree

Avantree Pluto Air Bedienungsanleitung

Morel

Morel Integra Series INTEGRA OVATION 4 Bedienungsanleitung

Oppo

Oppo SONICA Bedienungsanleitung

Bose

Bose SoundLink Wireless Music System Bedienungsanleitung

Rocksteady

Rocksteady Stadium Bedienungsanleitung

Bowers & Wilkins

Bowers & Wilkins 4 Bedienungsanleitung

Sonance

Sonance SONOS OUTDOOR Series Bedienungsanleitung

Electro-Voice

Electro-Voice EVID FM4.2 Bedienungsanleitung

Pioneer

Pioneer XW-HTD630 Bedienungsanleitung

Onn

Onn BWA16AA002 Bedienungsanleitung

HP GL313AA - USB Speakers PC Multimedia Bedienungsanleitung

iHome iBT8080 Bedienungsanleitung

Beliebte Sprecher Handbücher anderer Marken
