IHome IBT372 Bedienungsanleitung

instruction manual

Model: iBT372

CHARGE

BEFORE

USE

Waterproof & Shockproof

Wireless Stereo Speaker

Introduction

Thank you for purchasing the iHome iBT372. This product is designed to

provide high quality wireless sound for your Bluetooth audio device

wherever you take it. iP67 rating means the unit is tested to be waterproof

and dustproof. It also meets military specs for being shockproof.

This instruction booklet explains the basic operation and care of the unit.

Please read it carefully and keep for future reference.

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or

excessive heat.

• Protect your furniture when placing your unit on a natural wood and

lacquered ﬁnish. A cloth or other protective material should be placed

between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water.

Stronger cleaning agents, such as thinner or similar materials can damage

the surface of the unit.

iBT372

What’s Included

• iBT372 speaker

• USB charging cable

• Carry strap

Carry strap

USB charging cable

iBT372

IMPORTANT INFORMATION ABOUT

WATERPROOF OPERATION

For proper waterproof operation, make sure the waterproof

cover on the right side of the unit is completely ﬂush with the

unit by pressing along the entire edge of the cover until it is

completely and securely in place.

• The unit is IP67 waterproof rated, meaning it is immersible

for up to 30 minutes at a depth of 1 meter (3 feet). It will

typically withstand rain, snow and being submersed in

shallow water. Longer duration or deeper immersion that

exceeds the tested limits may cause product failure and

void the warranty.

• DO NOT immerse the unit in water for extended periods.

• DO NOT immerse the unit in water deeper than 1 meter

(about 3 feet).

• Make sure cover and surrounding surfaces are completely

dry before opening cover to prevent moisture from

damaging the internal electronics.

• Keep rubber cover free of dirt, sand, or other objects that

can interfere with proper sealing. If for any reason the

waterproof cover is not making a tight waterproof seal

water may enter the unit.

• Rinse with tap water after immersion in salt water or

swimming pool.

• DO NOT clean unit with oily soaps or use chemicals or

solvents. Clean with damp cloth.

water

tight

not

water

tight

iBT372

Front

Right Side

(under rubber seal)

Microphone

USB In

Charging Port

Aux-in Jack

Reset Port

Meet Your iBT372

Top

Power Button

Battery Status Indicator Lights

(portable/battery mode only)

Bluetooth Status

Indicator Light

Color Mode/

Battery Review

Button

Lower/Raise

Volume Buttons

Bluetooth/

Speakerphone

Button

Play/Pause/

Button

Getting Started: Carry Strap

The iBT372 has a channel on the left side of the

unit to attach the included carry strap. To attach

the carry strap, form a small loop in one end of

the carry strap. Insert this loop through the

desired channel, then pull the loop back through

the larger loop formed in the carry strap to

tighten.

Charging the Unit

CHARGE UNIT BEFORE USE/KEEP UNIT OFF FOR FASTER CHARGING

1. Connect the micro USB plug on the included USB charging cable to the

micro USB IN Charging USB Port on the right side of the unit under the

rubber seal.

2. Connect the standard USB plug end of the cable to a power USB port

on a computer, a USB AC adaptor or other USB charging device. For

ﬁrst time use, charge unit for about 5 hours. The status indicator LEDs

on front of the unit cycle progressively while charging and turn solid

once unit is fully charged.

iBT372

Charge via computer USB port, USB AC adaptor or other powered USB port

iHome iBT372 USB In

Charging port

USB AC adaptor

(not included)

USB AC adaptor

connected to working outlet

Reviewing Battery Charge Level

(Portable/Battery Mode: Charger is Disconnected and unit is

ON)

When unit is ON but not charging (operating on battery, micro USB

cable not connected) you can review the current battery status on the

Battery Status Indicator Lights (four white LEDs on front of the unit

above the iHome badge) any time a button is pressed.

TIP: On some iOS (Apple)

devices, you can view the

iBT372 battery status on your

device’s screen. When device is

paired and connected, look for a

vertical battery icon next to the

Bluetooth icon on the upper

right corner of the

device’s screen.

iBT372

Battery

dead

(no charge)

Battery

low

(needs

charging)

Battery

half

charged

Battery

good

mostly

charged

Battery

fully

charged

Battery Indication During Charging

While the battery is charging, the Battery Status Indicator Lights

will ﬂash in a continuous cycle showing progressively fuller battery.

The LEDs will stop ﬂashing once the battery is fully charged.

Pairing Your Device

Pairing is the set-up process to introduce your Bluetooth-capable device to

the iBT372. Once your device is paired, the iBT372 can recognize it and you

can play your audio through it.

1. Turn on your Bluetooth device and make it “discoverable”

by turning on Bluetooth mode (check in Options or

Settings).

2. Press and hold the Power Button for 2 seconds to turn on

the iBT372. The ﬁrst time the unit is powered on, it will

enter auto-pairing mode: the unit will beep, the

Bluetooth status indicator light on front of the unit will

ﬂash quickly and a voice will announce “PAIRING” while

the unit attempts to pair. (If Color Mode is on, the accent

lights will ﬂash blue and red.)

3. “iHome iBT372” should appear in your device’s Bluetooth

menu. Select “iHome iBT372” on device to complete

pairing. If prompted for a passcode, enter “1234” on your

device’s keypad. 1 beep will sound, the voice will

announce “CONNECTED” and the Bluetooth status

indicator light will appear solid blue (in Color Mode,

cabinet will ﬂash blue twice), indicating the iBT372 is

paired and ready to play music. There should also be an

indication on your device. If no device is successfully

paired within 3 minutes the iBT372 will default to previous

mode.

4. To pair with a dierent device or at a dierent time, make

sure unit is powered on, then press and hold the

Bluetooth/Speakerphone Button for 2 seconds. Select

“iHome iBT372” on device to pair.

Once the iBT372 is paired to a device, it will attempt to

autolink when the device is within range (about 33 feet).

To delete all Bluetooth paired devices from the iBT372,

press and hold the Bluetooth/Speakerphone Button for

10 seconds.

Using the iBT372

iHome iBT372

Playing Audio Via Bluetooth

1. Press and hold the Power Button for 2 seconds to turn on the unit. The Bluetooth

status indicator will glow solid blue when a linked device is in range and detected.

You can then listen to audio streamed wirelessly from your paired Bluetooth

device.

2. Press the Play/Pause/Voice Command Button to play and pause tracks.

3. Press the or Button to adjust the iBT372 volume. You can also adjust

volume on your device.

4. When done listening, press and hold the Power Button for 2 seconds to turn the

unit OFF.

Speakerphone Operation

NOTE: The unit must be powered on and linked to a Bluetooth phone to receive a

call.

1. When a call is received, playing music is muted to hear the ring tone and the

cabinet lights ﬂash green. Press the Bluetooth/Speakerphone Button to

answer the call, or press and hold to reject the call. For call waiting function,

press the button again to answer a second call, and once more to return to the

original call. Press and hold to end the current call and return to a remaining

call.

2. When a call is completed, press the Bluetooth/Speakerphone Button to end

the call and resume previous function.

Voice Commands

NOTE: The unit must be powered on and linked to a Bluetooth phone to use voice

commands.

Press and hold the Play/Pause/Voice Command Button to access the voice

command protocol associated with your device’s operating system (Siri for iOS

devices, “OK, Google” for Android devices, etc.

Using the iBT372

Playing Audio via Aux In

1. Connect a standard stereo audio cable (not included) to the Aux-in Jack on the

right side of the unit and connect the other end to the headphone or line-out jack

on your audio device.

2. Press and hold the Power Button for 2 seconds to turn on the unit.

3. Power on the audio device and use the controls on the device to play or pause

audio and to navigate tracks.

4. Press the or Button to adjust the iBT372 volume. You can also adjust

volume on your device.

5. When done listening, press and hold the Power Button for 2 seconds to turn o

the unit. Remember to turn o your device, too.

NOTE: Any Bluetooth audio must be paused or you will not hear Aux-in audio.

Using Color Modes

There are six color modes, which you cycle through in this order:

a. Slow Fade (colors slowly fade from one into the next

b. Fast Change (colors change rapidly)

c. One Color (select a favorite color)

d. Pulse to Music (lights ﬂash to the beat of the music)

e. Preset Pulsing (each light array pulses through its own preset pattern of colors)

f. O (no display)

1. Press and hold the Power Button for 2 seconds to turn on the unit

2. Press the Color Mode Button repeatedly to cycle to the desired color mode.

For One Color mode, ﬁrst cycle to Fast Change mode and press the Color Mode

Button when the desired color appears. For Pulse to Music, make sure the

volume on your connected Bluetooth device is above 30%.

3. Press and hold the Power Button for 2 seconds to turn the unit o.

Using the iBT372
