QUICKSTART GUIDE

LW5-3PT-KIT

Kit with 3 x Lyra Daylight Half x 1 LED Spot Lights

What’s Included

3 x Lyra Daylight Soft Panel Half x 1 LED Light

3 x Gold Mount Battery Plate

3 x V-Mount Battery Plate

1 x Light Kit Bag

1 x Stand Bag

3 x Heavy Duty Stand

Getting to know your LYRA lights

PRECAUTIONS:

• Keep the ﬁxture away from water and all ﬂammable gases or liquids.

• Use only the recommended batteries.

• Handle the unit with care.

• DO NOT attempt to disassemble or repair the unit without ﬁrst contacting service department at

ikancorp.com.

• Keep the unit clean and free of dust. The unit can be cleaned with a soft dry cloth.

• Use only parts provided by the manufacture.

• Always use caution when plugging in the ﬁxture.

Mounting the Lyra to a Stand:

The Lyra LED Soft Light comes with a pre-installed yoke and combo mount. This allows the ﬁxture to easily

sit and adjust on any stand. The 30° yoke gives the light free-range motion without obstructions. The Baby

5/8" and Junior 1-1/8" Combo Pin allows the user a wide range of stands. The light can be mounted either

horizontally or vertically on a 5/8" baby pin.

Power the LEDs:

The Lyra Soft Light comes with an included AC power supply and 6 foot cable. This allows the user to

plug into any standard 120-240v electrical outlet. The Lyra LED Soft Light can be powered from either an

AB Mount pro battery, or a V-Mount battery. The ﬁxture comes standard with either AB-Mount or V-Mount

plates. The plates can be easily removed and replaced for the type of batteries that are available.

Changing the Pro Battery Plate

Adding or removing the pro battery plate on the back of your ﬁxture can be easily achieved.

NOTE: The ﬁxture comes pre-installed with the Gold-Mount battery plate.

The process starts with the removal of the four screws on the four corners of the plate. Once the screws

are removed, separate the plate from the back of the ﬁxture. Unplug the 2-pin connector from the ﬁxture.

Store the screws and the Gold-Mount in a safe place.

Reattaching the V-Mount plate is a simple process. Plug the wired 2-pin connector into the ﬁxture where

we just unplugged the Gold-Mount plate at the back of the light. Orient the holes on the plate to match up

with the screw holes on the back of the ﬁxture. Using the screws supplied with the V-Mount plate, screw

in the plate until it is snug against the back of the ﬁxture. Do not over-tighten the screws.

You’re now ready to install your battery to the V-Mount plate.

Adjusting the Color & Brightness of the Light:

The Lyra LED Soft Light is controlled by the large yellow knob on the rear of the ﬁxture. The knob was

designed with the idea that it could be reached and adjusted when the light is up on a stand. The knob has

three push settings.

1. The default setting is the brightness from 10%-100% brightness.

2. By pressing in on the knob the color temperature can be adjusted. (Bi-Color Lights)

Remote Control

The light can be adjusted also using the RF remote control. The use of the remote allows for multiple lights

to be connected as well as control of the brightness.

Remote Control Button Functions

• Press & Hold “A” for 5 seconds to sync remote control to light(s).

• Press “A” to power ON/OFF

• Press “B” to adjust 4 levels of light intensity in increments of 25%

• Press and Hold “C” & “D” for 5 seconds to Enable/Disable sound

• Hold down “C” to increase light intensity 0%-100%

• Hold down “D” to decrease light intensity 100%-0%

Speciﬁcations

Specs

Head Type Daylight 5600K

Rating 51w ; 14-18VDC

Light Source 510 0.2 watt LEDs

Power Supply Input: 110-220VAC ; Output:15VDC

Lens ½ Stop, Soft Diffusion

Beam Angle 110°

Yoke & Pin 30° Angled yoke w/ Baby 5/8” & 11/8” Combo Pin

Fixture Size 14 x 8 x 3 In.

Fixture Weight 4 lbs

Optional Accessories

Some other products that work well with the Lyra Lights available from Ikan include:

HD-STND

ROLLR-STND10

CP-STND-V3

SW-04

KCP-703

Heavy Duty Light Stand

2 Stage Roller Stand 10 ft 6 in

Compact Light Stand Version 3

Safety Wire

Stage Clamp w/ 16mm Stud

Learn More

More dynamic information at ofﬁcial website: www.ikancorp.com

Support

Contact email: [email protected]

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.

• The components and maintenance service fee will be charged if the warranty period is expired.

Free Service will not be Provided in the Following Situations:(*Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors, etc.
