Illustra Pro LT 2MP Bullet IR Camera

Installation and Operation Manual

8200-1129-01 A0

Notice

The information in this manual was current when published. The manufacturer reserves the right to revise and improve its

products. All specifications are therefore subject to change without notice.

Under copyright laws, the contents of this manual may not be copied, photocopied, reproduced, translated or reduced to any

electronic medium or machine-readable form, in whole or in part, without prior written consent of Tyco Security Products. ©

Customer Service

Thank you for using Tyco Security Products. We support our products through an extensive worldwide network of dealers.

The dealer through whom you originally purchased this product is your point of contact if you need service or support. Our

dealers are empowered to provide the very best in customer service and support. Dealers should contact Tyco Security

Products at (800) 507-6268 or (561) 912-6259 or on the Web at www.illustracameras.com.

Trademarks

The trademarks, logos, and service marks displayed on this document are registered in the United States [or other

countries]. Any misuse of the trademarks is strictly prohibited and Tyco Security Products. will aggressively enforce its

intellectual property rights to the fullest extent of the law, including pursuit of criminal prosecution wherever necessary. All

trademarks not owned by Tyco Security Products. are the property of their respective owners, and are used with permission

or allowed under applicable laws.

Product offerings and specifications are subject to change without notice. Actual products may vary from photos. Not all

products include all features. Availability varies by region; contact your sales representative.

ii Installation and Operation Manual

Notice of Use

This manual is designed for administrators and users of the network camera. Please read it carefully before use. All

We are not responsible for any technical or typographical errors and reserve the right to change the product and manuals

Keep this d



We are not responsible for any damage caused by inappropriate use.

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES

ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

FCC Notice

The equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

The limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference, in which case users will be required to correct

the interference at their own expense.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

Modifications not expressly authorized by Tyco Security Products could void the user’s authority to operate the unit.

ICES statement

CAN ICES-3(A) / NMB-3(A)

CE Statement

This is a Class A product. In a domestic environment this product may cause radio interference in which the user may be required to

take adequate measure.

ESD Precautions: With the covers removed during installation and alignment this product is sensitive to electrostatic discharge. The

installer should take appropriate ESD control measures such as the use of a ESD wrist strap connected to the chassis of the camera.

Note to Installer: POE networks that are connected to IP Encoders should not be routed to the exterior or outside of the installed

plant location.

iii

Table of Contents

Product Features .............................................................................................................................................................1

Features .........................................................................................................................................................................1

Dimension.......................................................................................................................................................................1

Controls/Connectors .......................................................................................................................................................2

Part Names.....................................................................................................................................................................2

Specifications .................................................................................................................................................................3

Camera Installation..........................................................................................................................................................7

Package Contents..........................................................................................................................................................7

Mounting the camera......................................................................................................................................................8

Adjusting angle of the camera........................................................................................................................................9

Adjusting zoom and focus..............................................................................................................................................9

Connections ...................................................................................................................................................................10

Peripheral Connection..................................................................................................................................................10

Network Connection.....................................................................................................................................................12

Accessing the Camera for the First Time.....................................................................................................................13

Using the Illustra Connect Tool to Manage Cameras ..................................................................................................15

Live Page Configuration................................................................................................................................................16

ActiveX Installation (AxUMF.cab).................................................................................................................................16

Log In............................................................................................................................................................................18

Live Page Menus..........................................................................................................................................................18

Storage and Recording Configuration.........................................................................................................................20

Storage device settings................................................................................................................................................20

Recording.....................................................................................................................................................................22

Search and Download..................................................................................................................................................24

Setup ...............................................................................................................................................................................26

Basic Configuration ......................................................................................................................................................26

Video ............................................................................................................................................................................30

Event Configuration......................................................................................................................................................40

Applications..................................................................................................................................................................49

Network Configuration..................................................................................................................................................54

Peripheral.....................................................................................................................................................................62

Maintenance.................................................................................................................................................................63

About............................................................................................................................................................................70

iv Installation and Operation Manual

Appendix A: Factory Default.........................................................................................................................................71

Storage Settings...........................................................................................................................................................71

Video Settings ..............................................................................................................................................................71

Event Settings ..............................................................................................................................................................74

Network Settings ..........................................................................................................................................................76

Peripheral.....................................................................................................................................................................78

Maintenance Settings...................................................................................................................................................78

Appendix B: Using VLC Player to View RTSP Streaming..........................................................................................80

Product Features

This Installation & Operation Manual covers the following product code:

IPL02B2BNWIY

Features

Motion detection

High quality compression in real time streaming

Full frame rates @ Maximum resolution 1920x1080 provides superior image quality

Supports simultaneous streaming of H.264 and MJPEG encoded video

Wide Dynamic Range (WDR)

Backlight Compensation

Digital Slow Shutter

IR Illuminator

Remote zoom and focus control

Dynamic 2D Digital Noise Reduction

OSD supported

Analogue Video Output

Digital Input / Output

Weather Proof (IP66)

Event or Continuous recording on microSD card or FTP(microSD media not included)

PoE supported

ONVIF 2.4 Profile S compliant

Dimension

( Unit: mm )

Controls/Connectors

2 Installation and Operation Manual

Controls/Connectors

Part Names

Note

Model herein and its appearance are subject to change without any prior notice.

Sunshield: Protects the camera lens against direct sunshine.

Terminal connector: Cable connections for digital input/output. Refer to the section, Connections for more details.

LAN connector: RJ45 LAN connector for 10/100 Base-T Ethernet

microSD/SDHC/SDXC card slot: The camera supports up to 64GB. Class 4 or higher SD card is recommended for HD

recordings.

Video output cable socket: Used for analogues video output by the connection with the provided video output cable

PAL/NTSC button: Pressing the button cycles through no video output mode, the PAL mode, and the NTSC mode for

three minutes in a row.

Reset button: This button will restart the camera or reset it to the factory default settings. Refer to the section of Reboot

and Factory Default respectively for more details.

Video Out

PAL/NTSC

Reset

SD Card

tyco향

Video Out

PAL/NTSC

Reset

SD Card

tyco향

Reset button

PAL/NTSC button

Video output

Cable socket

Terminal Connector

LAN Connector

Sunshield

microSD/SDHC/

SDXC card slot

Controls/Connectors

Specifications

Model List

IPL02B2BNWIY

Camera

Image Sensor

Max. Resolution

1080p (1920x1080)

Pixel Size

3x3 ㎛

Type

CMOS

Active Image Area

5,856 H x 3,276V ㎛

Lens

Type

Built-in Lens

Focal Length

3.0(w) ~ 9.0(t) mm

F No.

F1.2(w) ~ F2.3(w), Optical 3x

Motorized Focus & Zoom lens

IRIS

Auto iris

Format

1/2.9”

Angle of View

Horizontal

Approx. 110.8°(Wide) to 35.5°(Tele)

Vertical

Approx. 57.7°(Wide) to 19.9°(Tele)

Electronic Shutter Time

1/2~1/10,000 seconds

Min. Illumination

Color : 0.5 Lux(30IRE)

B/W: 0 Lux(IR LED On)

CODEC

Video Compression

H.264 Baseline, Main, High profile(MPEG-4 Part 10/ AVC),

MJPEG(Motion JPEG)

Video Streaming

Dual Stream, Configurable streams in H.264, MJPEG

H.264: Controllable frame rate, bandwidth(VBR/CBR),GOP

MJPEG: Controllable frame rate, JPEG quality

Resolutions

1920x1080

1280x720

1120x630

960x540

800X450,

640X360

Controls/Connectors

4 Installation and Operation Manual

480x270

320x180

Max Frame Rate

H.264: Max 30fps in all resolution

MJPEG: Max 30fps in all resolution

Special Features

Image Settings

Configurable brightness, contrast, saturation, sharpness

Orientation Control

Flip & Mirror

Rotation Control

None / Left(-90 degrees) / Right(+90 degrees)

Dynamic 2D Digital Noise

Reduction(DNR)

Supported (1 ~ 15)

Smart Bitrate Control

Supported (in VBR mode)

Exposure Adjustment

+1.0, +0.6, +0.3, 0, -0.3, -0.6, -1.0 EV

White Balance

ATW1 / ATW2 / Push / Manual

Back Light Compensation

On(possible to designate zone) / Off

IR Illuminator Supported

Off / Manual

Wide Dynamic Range

On / Off

Flickerless Control

Normal, 50Hz, 60Hz

DSS (Sens-up)

2X ~ 16X, Off

Day & Night

Removable IR cut filter

OSD

Time stamp and text caption overlay

Privacy Zone

4 configurable regions (Configurable in IE only)

Alarm I/O

Input / Output

1 / 1

Network

Ethernet Standard

10 / 100 / Base-T

Protocol

QoS Layer 3 DiffServ, TCP/IP, UDP/IP, HTTP, HTTPS, FTP,

RTSP, RTCP, RTP/UDP, RTP/TCP, mDNS, UPnP™, SMTP,

DHCP, DNS, DynDNS, NTP, SNMPv1/v2c, IGMP, ICMP,

SSLv2/v3, TLSv1
