PPFD MAP...........................................................
Important Cautions & Warranty ...........................
2
3
4
5
6-7
8-9
10
1-877-540-5588
iluminarlighting.com
© Copyright 2022, ILUMINAR Lighting
Subject to change without notice.
Minimum
46-122cm / 18-48”
TECHNICAL SPECS
iL1c LED SPECTRUM
MOUNTING & COVERAGE
PHYSICAL SPECIFICATIONS
VOLTAGE AND AMPERAGE
VOLTAGE:
SKU:
WATTS:MODEL: 330W
2.6
100-277V
IL-A133026-FSG-120
iluminarlighting.com
Toll Free: 1-877-540-5588
129mm / 5.1”
90mm / 3.5”
200mm / 7.9”
1000mm / 39.38”
1.2m / 4’
0.91m / 3’
PPF 858 μmol/s
Efficacy 2.6 μmol/J
Min Power Factor >0.9
<20%
THD
0.99
1122
Crest Factor
120-277V AC
Heat Output (BTU/h)
Rated Voltage
100-277V
Voltage Range (+/-10%)
Frequency 50 / 60Hz
Dimmable 0-10V Controllable
Ambient Temperature 0 - 35°C / 32-95°F
Relative Humidity 98%
Plug Type Power Cord Sold Seperately
Color Temperature
Length 1000mm
2.85A
39.38”
5.1”
7.9”
18.3lbs
341W
4000k
Color Rendering Index
Width
208V
120V
129mm
1.63A 335W
88
Minimum Mounting Height
Height
240V
200mm
1.41A 332W
18-48” to top of Canopy
Emitter Cooling
Light Distribution +/- 5%
Waterproof Rating
LED Lifespan (90% of Life)
Weight
277V
347V
480V
8.3kg
0.22A 330W
0.99A 340W
0.71A 331W
Passive Thermal Management
125º
iP65 for Damp/Wet Conditions
54,000+ hours
WAVELENGTH NM
LED Lighting Solution
