imilab Home Security Camera Basic Bedienungsanleitung
IMILAB Home Security Camera Basic
User Manual
RESET
Package Contents: IMILAB Home Security Camera Basic, user manual,
wall mounting accessories pack, usb cable
Read this manual carefully before use, and retain it
for future reference
Product Overview
Status Indicator
Lens
MicroSD Slot
（Can be
revealed by
pushing the
lens upward）
MIC
Front View Rear View
Loudspeaker
Reset
Buon
Micro-USB
Charging Port
2. Insert the two plastic anchors into the holes on the wall.
Mounting the Security Camera on a Wall
1. Drill two holes on the wall by using the base of the security camera as a
template. It is recommended that you mark the locations of the holes with a
pencil before drilling. The diameter of each hole is approximately 6 mm, and
the depth is approximately 25 mm.
The IMILAB Home Security Camera Basic can be placed on a number of
horizontal surfaces, such as a writing desk, dining table, and coffee table. It
can also be mounted on the wall.
Product Installation
3. Make sure to position the base unit so that the arrow is pointing up.
Secure the base unit in place by tightening the screws into the plastic
anchors.
4. Match the grooves on the boom of the camera unit with the raised
area on the base unit. Press down until the two surfaces are flush, then
turn the camera unit in either direction to lock it in position.
When mounting the security camera on a wall:
please note that the wall must be able to support at least triple
the product's total weight.
Set up your system
Connect
the
USB
adapter
to
the
device
and
plug
it in.
The
indicator of camera
will turn yellow.
Get the MI Home APP
For the best experience, please Download the Mi Home app for your
smartphone by scanning this QR or search for MI Home in the APP store.
Product Instructions
Yellow
RESET
MicroSD
RESET
Indicator Light
Steady blue on: connected/device status is normal
Flashing blue: network error
Flashing orange rapidly: waiting for connection
Flashing orange slowly: system upgrade in progress
Restore Factory Seings
Press and hold the Reset buon to restore your device to factory seings.
Data stored on the MicroSD card is not erased.
Make sure that the power to the security camera is already disconnected.
Adjust the camera lens upward until the MicroSD slot is revealed, then
insert the MicroSD card into the slot (the side with contact points must
be facing down).
Installing a MicroSD Card
.Saturday
27;32
Nj!Bddpvou!.!Tjho!vq
Foufs!qipof!ovncfs
Zpv!xpo
!
u!cf!bcmf!up!dibohf!zpvs!sfhjpo!bgufs!zpv!dsfbuf
zpvs!bddpvou/
Cz!dsfbujoh!bo!bddpvou-!zpv!bsf!bhsffjoh!up!pvs!Vtfs
Bhsffnfou!boe!
Qsjwbdz!Qpmjdz/
Dsfbuf!Nj!Bddpvou
Dsfbuf!Nj!Bddpvou
,2
Vojufe!Tubuft
Click the Sign up to create your account
You Can using phone number or E-mail to quick sign up
Get an Account
To set up MI Account
Tap the MI Home icon on your mobile device
Your Home
Tap to add a device
My devices
4G
4:19
2.Please click the top right “ ” to scan the QR code on the camera boom,
or search “IMILAB Home Security Camera Basic” to found device.
Connect to the Camera
1.Open MI Home app, Click the top right corner “ + ” to add device.
IMILAB Home Security Camera Basic
Device nearby Add manually
4G
4:19
Add device
Camera
Video camera
Wait until you hear a voice prompt
Next
4G
4:19
Connect to the camera
Press and hold the reset button for 3 seconds.The reset is
IMILAB Home Security Camera Basic
successful once the indicator light turns into yellow
3.Enter to the camera set up page, Hold the reset
buon back of camera 3 Seconds until the indicator
turns yellow, and hear the voice notification “
waiting for connecting” from camera, then click
NEXT.
4.Please Select network to connect (only support
to 2.4GHz network), then click NEXT；
Next
4G
4:19
Select router
ilab2
Connect to another router
Cant find router to connect?
Saved
IMILAB Home Security Ca
...
Heard Scannedsuccessfully
Cant hear sound
4G
4:19
Operation guide
Scan the QR code with camera, and keep the phone at
a distance of about 15 cm
Scan QR code with camera
5.Please using camera to scan the QR code on the mobile phone until hear
“Scanned successfully” from camera, then click NEXT buon to connect.
