IMotion SC312 Bedienungsanleitung

SC312

2D Barcode Scanner

User’s Manual

Version 1.0 10/07/2021

iWaylink Inc.

Table of Contents

Table of Contents ........................................................................2

Chapter 1: ABSTRACT................................................................5

1 Abstract.................................................................................................5

2 Overview...............................................................................................5

Chapter 2: BASIC SPECIFICATIONS..........................................6

Chapter 3: DETAILED OVERVIEW............................................10

Chapter 4: ELETRICAL SPECIFICATIONS ............................... 11

4-1 USB Specification ............................................................................11

4-2 RS-232C Specification.....................................................................11

4-2-1. AC Adapter Input Specifications................................................................11

4-2-2. AC Adapter Output Specifications.............................................................11

4-2-3. Current Consumption............................................................................... 12

Chapter 5: OPTICAL SPECIFICATIONS....................................12

5-1 Basic Optical Specifications.............................................................12

5-2 Aiming Pattern..................................................................................13

Chapter 6: TECHNICAL SPECIFICATIONS...............................14

6-1 Barcode Test Sample.......................................................................15

6-2 Scan Area and Depth of Field..........................................................16

6-2-1 Depth of Field............................................................................................ 17

6-3 Printed Contrast Signal (PCS) .........................................................18

6-4 Minimum Resolution.........................................................................18

6-5 Barcode Width..................................................................................18

6-6 Pitch, Skew and Tilt..........................................................................19

6-7 Curvature.........................................................................................20

6-8 Motion Tolerance..............................................................................20

6-9 Auto trigger.......................................................................................21

Chapter 7: INTERFACE SPECIFICATION .................................22

7-1 USB Interface...................................................................................22

iWaylink Inc.

7-1-1 USB Interface Specifications..................................................................... 22

7-1-2 USB Connector ......................................................................................... 23

7-1-3 Interface Circuit......................................................................................... 23

7-1-4 USB interface cable Weight: approx. 78 g................................................ 23

7-2 RS-232C Interface ...........................................................................24

7-2-1 USB interface cable .................................................................................. 24

7-2-2 Signal Level and Pin Assignment.............................................................. 24

7-2-3 Interface Circuit......................................................................................... 25

7-2-4 RS-232C interface cable........................................................................... 25

Chapter 8: ENVIRONMENTAL SPECIFICATIONS ....................26

8-1 Temperature.....................................................................................26

8-2 Humidity...........................................................................................26

8-3 Ambient Light Immunity....................................................................27

8-4 Dust and Drip Proof..........................................................................27

8-5 Rigger Key Durability .......................................................................28

8-6 Cable Strength.................................................................................28

8-7 Cable Bending Strength...................................................................28

8-8 Vibration Strength (without packaging).............................................29

8-9 Vibration Strength (in individual packing).........................................29

8-10 Drop Impact Strength (without packaging) .....................................29

8-11 Drop Impact Strength (in individual packaging) ..............................29

8-12 Vibration Strength (in individual packing).......................................29

Chapter 9: REGULATORY COMPLIANCE ................................30

9-1 LED Safety.......................................................................................30

9-2 EMC.................................................................................................30

Chapter 10: RELIABILITY..........................................................30

Chapter 11: PRECAUTIONS......................................................30

Chapter 12: PRODUCT DISPLAY..............................................31

12-1 Product Label.................................................................................31

12-2 Product Interface Mark...................................................................31

12-3 Focus Display (HD)........................................................................32

iWaylink Inc.

Chapter 13: PHYSICAL FEATURES..........................................33

13-1 Dimensions....................................................................................33

13-2 Weight............................................................................................33

13-3 Mechanical Drawing.......................................................................33

Chapter 14: FACTORY DEFAULT SETTINGS...........................34

14-1 Default Setting (Part 1: Supported Symbologies)...........................34

14-1-1 1D Barcodes............................................................................................ 34

14-1-2 Postal Codes........................................................................................... 34

14-1-3 GS1 DataBar, Composite Codes ............................................................ 35

14-1-4 2D Codes ................................................................................................ 36

14-1-5 OCR font ................................................................................................. 36

14-2 Default Setting (Part 2: Read setting, trigger, buzzer)....................37

14-3 Default Setting (Part 3: Interface communication setting)..............38

14-3-1 USB......................................................................................................... 38

14-3-2 RS-232C.................................................................................................. 38

Chapter 15: INTERFACE SWITCHING......................................39

15-1 USB multi-interface/ RS-232C model product................................39

15-1-1 Switching to USB-COM from USB-HID................................................... 39

15-1-2 Switching to USB-HID from USB-COM................................................... 39

15-1-3 Switching to RS-232C from USB (HID, COM) ........................................ 40

15-1-4 Switching to USB-HID from RS-232C..................................................... 40

15-1-5 Switching to USB-COM from RS-232C................................................... 41

15-2 USB Interface Force quit start........................................................41

Chapter 16: OPTIONAL ACCESSORIES...................................42

16-1 Stand for SC312.............................................................................42

iWaylink Inc.

Chapter 1: ABSTRACT

1 Abstract

This manual provides specifications for the SC312 2D barcode scanner.

2 Overview

The SC312 is a 2D barcode scanner that enables high speed scanning of high

resolution linear (1D) and 2D symbologies. Main features of the SC312 are as

follows:

•High-speed scanning

Extremely high speed performance ensures stress free scanning and fast

response without being affected by hand movement and light conditions.

•Auto trigger, moving object scanning

Set the auto trigger detection and using the dedicated stand (optional

accessory), the scanner is automatically triggered and a moving target can be

detected automatically and scanned instantaneously.

•Editing function

A new function “Data Editing Program” captures up to 16 codes on multiple

images simultaneously in one go. Output editing process, such as GS1 format,

also can be set easily.

•LED aiming

A sharp single line of green LED makes it easy to aim the scanner while

providing safety and long-life.

•Setting tool

“UniversalConfig” is ready to use and it makes installation easy.

•Various interfaces

SC312 and host is connected by USB (HID or COM) or RS-232C interface.

Exchanging cable and changing setting, RS-232C specification product can be

use as USB specification. And USB multi-interface specification product can

be use as RS-232C specification by exchanging cable and changing setting.

iWaylink Inc.

Chapter 2: BASIC SPECIFICATIONS

Item

Specification

Note

Control

Section

CPU

CPU：ARM Cortex-A7

Core：800 MHz

LPDDR2 RAM

1 Gbits

DDRCLK：400 MHz

Flash ROM

1 Gbits Flash Memory

Inter

face

RS-232C

300 bps to 115200 bps

Default: 9600 bps

USB

Full Speed 12 Mbps ( HID/COM )

Indicator

LED

Upper panel and side bar White LED

Buzzer

Loudness / tone adjustable

Vibrator

Vibration motor (default off)

Option

Optical Section

Scanning method

VGA (0.30 million-pixel) CMOS area sensor

Frame rate: 100 fps

Scanning light source

1 white LED

Aiming light source

1 green LED

Effective pixels

0.30 million pixels (H: 640 x V: 480)

View angle

Horizontal: about 38.0°

Vertical: about 28.9°

Diagonal: about 46.4°

Supported 1D Symbologies

Symbologies

UPC-A,UPC-E, UPC-E1, UPC-A Add-on ,

UPC-E Add-on, EAN-13, EAN-8, EAN-13

Add-on/EAN-8 Add-on, JAN-8, JAN-13, Code

39, NW-7(Codabar), Industrial 2 of 5,

Interleaved 2 of 5, Code 93, Code 128, GS1-

128, MSI/Plessey, Code 11, UK/Plessey,

Telepen, Matrix 2 of 5

Postal

Korean Postal Authority code, Chinese Post

Matrix 2 of 5, Japanese Postal, Intelligent Mail

Barcode, POSTNET, PLANET, Netherlands

KIX Code, Australian Postal, UK Postal, 4-

State Mailmark Barcode

Minimum resolution

Code 39 : 0.076 mm

PCS 0.9

Curvature

Radius ≧20 mm (12-digit UPC)

Wide Bar Code

Possible to read: Code 39 with 80 mm width

and resolution 0.2mm (DOF: 102 mm)

Motion tolerance

Possible to read: UPC moving at 2.54 m/s

(DOF: 82 mm)

Depth of field

(mm)

Code 39

Resolution (0.076)

17 –27 mm

Resolution (0.127)

7 –66 mm

Resolution (0.254)

26 –119 mm

Code 128

Resolution (0.2)

41 –102 mm

UPC

Resolution (0.33)

26 –135 mm

iWaylink Inc.

Item

Specification

Note

GS1/Composi

Symbologies

GS1 DataBar , GS1 DataBar Limited , GS1

DataBar Expanded

Composite GS1 DataBar , Composite

GS1-128 ,

Composite EAN , Composite UPC ,

GS1 DataBar:

formerly called “RSS”

Minimum resolution

GS1 DataBar : 0.127 mm

Composite Code : 0.127 mm

PCS 0.9

Supported 2D Symbologies

Symbologies

PDF417 , MicroPDF417 , Codablock F , QR

Code , MicroQR Code ,

Data Matrix (ECC 200 ) ,MaxiCode, Aztec

Code ,Chinese-sensible code

Disable Code 128

when Codablock F is

enabled.

Minimum resolution (mm)

PDF417 : 0.127 mm

QR Code : 0.127 mm

Data Matrix : 0.127mm

PCS 0.9

Depth of

field (mm)

PDF417

Resolution (0.127)

Resolution (0.254)

QR Code

Resolution (0.127)

Resolution (0.381)

Data Matrix

Resolution (0.127)

Resolution (0.254)

Common

Scan angle

Pitch : ±60°

Skew : ±65°

Tilt : 360°

Minimum PCS

0.2 or more

MRD: 0.1 or more

OCR

OCR font

Machine Readable Travel Documents、

ISBN(OCR-B)

Imager

Image data format

Windows Bitmap, JPEG

Black spot may appear

on images, however, it

does not affect the

scanning performance.

Shades of gray

1024, 256, 16, 2

Range of output image

Select top/bottom (column) and left/right (row)

Resolution of output image

Full,1/2, 1/4

Interface of output image

RS-232C, USB-COM

Baud rate

USB-COM

(full speed)

About 3 sec

Resolution: Full

RS-232C

(baud rate: 115200 kbps)

About 40 sec

iWaylink Inc.

Item

Specification

Note

Power

Range of operating voltage

4.5 - 5.5 V: USB

4.5 - 6.5 V: RS-232C

RS-232C:

Dedicated AC adapter

5.0 V ±5%

Current

consumption

Reading

Standby

RS-232C：400 mA / USB：400 mA (typ)

Ambient

Temperature:

25°C

RS-232C：165 mA / USB：175 mA (typ)

RS-232C：50 mA / USB：60 mA (typ)

Environmental Specifications

Temperature

Operating

-5 to 50 °C

AC adapter: 0 to 40°C

Storage

-30 to 60 °C

AC adapter:-20 to 85°C

Humidity

Operating

5 to 90% (no condensing, no frost)

Storage

5 to 90% (no condensing, no frost)

Ambient light

immunity

Fluorescent

10,000 lx or less

UPC

Optical axis angle: 75°

Distance: 92 mm

Sunlight

100,000 lx or less

Vibration

10 Hz to 100 Hz, acceleration of 19.6 m/s2,

60 minutes per cycle, repeat once in each X, Y

and Z-direction

Drop

Drop 3 times, at each 5 faces (right, left, front,

back and top), from a height of 150 cm onto a

concrete surface.

*Excluding the part where

the interface

cable is attached

Dust and drip proof(*1)

IP42 equivalent

Regulatory(*1)

This scanner is an Exempt Risk Group LED product.

LED safety

IEC 62471 Exempt_Group

Peak Wavelength:

624 nm

EMC

VCCI クラス B / FCC Class B / EN 55032

Class B, EN 55024

For residential,

Commercial and light-

industrial environments

Product safety

CE Marking

iWaylink Inc.

Item

Specification

Note

Immunity Test(*1)

ESD immunity

destruction

Air discharge (direct):±15 kV

Condition:

IEC:61000-4-2

compliant

malfunction

Contact discharge (direct / indirect): ±6 kV Air

discharge (direct):±8 kV

Radio-

frequency

electromagnetic

field. Amplitude

modulation

Frequency

80 to 1000 MHz

Condition:

IEC61000-4-3

compliant

Level

3 V/m

80% (AM)

Fast transient

Voltage

Alternating-current input cable: ±1 kV

Condition:

IEC61000-4-4

compliant

Pulse

5 / 50 ns (Tr / Tw)

Frequency

5 kHz

Surge

Pulse

1.2 / 50 ns (Tr / Th)

Condition:

IEC61000-4-5

compliant

Voltage

From L to P : ±2 kV (closed-loop voltage)

From L to L : ±1 kV (closed-loop voltage)

Radio-

frequency

common mode

Frequency

0.15 to 80 MHz

Condition:

IEC61000-4-6

compliant

Level

3 V

80% (AM)

Power

frequency

magnetic field

Frequency

50 and 60 Hz

Condition:

IEC61000-4-8

compliant

Level

3 A/m

Voltage dip,

momentary

voltage drop,

fluctuation

Dip 1

Drop 30%, 0.5 cycles

Condition:

IEC61000-4-11

compliant

Dip 2

Drop 60%, 5 cycles

Momentary

drop

Drop > 95%, 250 cycles

Physical

Features

Dimensions

Approx. 121.2 × 75.4 × 169.5 (DWH mm)

Not include projection

Weight

Approx. 145 g

Excluding the interface

cable

*1 The specified value is under the condition of the scanner’s standard accessory cable connected.

iWaylink Inc.

Chapter 3: DETAILED OVERVIEW

Figure 1: Detailed View of SC312

No.

Name

Description

Trigger Key

By pressing this key, the scanner starts taking an image from the scanning

window and LED illumination is emitted to read 1D/2D codes.

Scanning

Window

Light paths of the imager, LED illumination and LED aiming. Ensure that the

lens is not exposed to dust and dirt before scanning.

Status LED

White LED light indicates good read. If Auto trigger detection is enabling,

placing SC312 to the dedicated stand, status LED light on to indicate auto

trigger mode.

Buzzer Hole

A sound from a built-in buzzer comes out through these holes. When they

are covered, the buzzer sound may not be able to be heard. The sound

varies depending on the status. Buzzer settings are configurable for

volume and duration.

Cable removal

Hole

To remove cable, insert paperclip and pull out cable.

Inhaltsverzeichnis

Andere iMotion Barcode-Lesegerät Handbücher

iMotion

iMotion SC111 Bedienungsanleitung

iMotion

iMotion MP121 Bedienungsanleitung

iMotion

iMotion MP121 Bedienungsanleitung

iMotion

iMotion SC511 Bedienungsanleitung

Beliebte Barcode-Lesegerät Handbücher anderer Marken

POSMicro

POSMicro Datalogic PowerScan D7100 Bedienungsanleitung

Marson

Marson MT780 Kurzanleitung zur Einrichtung

NCR

NCR RealPOS Bedienungsanleitung

Motorola

Motorola SE3300 Kurzanleitung zur Einrichtung

Element

Element P130BT Bedienungsanleitung

Motorola

Motorola Symbol LS3008 Installations- und Betriebshandbuch

Meec tools

Meec tools OBD-II / VAG Bedienungsanleitung

SICK

SICK CLP 100 Bedienungsanleitung

Royal Tag SA

Royal Tag SA I-Read Bedienungsanleitung

Welch Allyn

Welch Allyn IMAGETEAM 3800 Bedienungsanleitung

Meteor

Meteor 8310 Bedienungsanleitung

Denso

Denso BHT-500B Bedienungsanleitung

Datalogic

Datalogic Heron HD3130 Bedienungsanleitung

Motorola

Motorola MP6000 Montageanleitung

Newland

Newland NLS-HR15-BT Bedienungsanleitung

ARTDEV

ARTDEV AS-1310 Bedienungsanleitung

Aopos

Aopos AS290 Bedienungsanleitung

ENS

ENS 367-5455 Bedienungsanleitung

iMotion SC312 Bedienungsanleitung

Beliebte Barcode-Lesegerät Handbücher anderer Marken
