GAS CYLINDER INFORMATION
This appliance is designed to be used with a gas cylinder
not exceeding (Australia 9KG)
► The gas cylinder supply valve must be turned off when
the appliance is not in use.
► Gas cylinders must be stored outdoors, out of reach of
children and must not be stored in a building, garage
or any other enclosed area.
► The gas cylinder used must incorporate a safety collar
to protect the valve assembly.
*Never store a spare cylinder under the barbecue
shelves or inside the trolley housing. Any LPG cylinder
not attached to the BBQ for use should be stored
outdoors and well away from this appliance.
IMPORTANT:
► When disconnecting and removing the gas cylinder for
the purpose of refilling, always observe the following
procedure.
► Ensure that all gas control valves on the appliance and
the gas cylinder are turned off before disconnecting
the regulator from the cylinder.
► Do not smoke or use a naked flame near the appliance
or gas cylinder while disconnecting the gas line
between the appliance and gas cylinder.
► Remove the gas cylinder from the enclosure before
disconnecting the regulator from the appliance.
► Tighten all connections before placing the gas cylinder
back in its enclosure.
► The gas leak testing procedure should be conducted
every time the gas cylinder is refilled and reconnected
to the appliance before using the appliance.
Regulator Connection
1. Check that all control knobs are in the ‘Off’ position.
2. Make sure the cylinder valve is off.
3. Remove the protective cap from the cylinder if present.
4. Leak test the connection with a soapy water solution.
Gas Leak Test Procedure
Never use a naked flame to check for gas leaks.
Always use the following procedure to check for gas leaks.
1. In a small container, mix up a solution of 1/2 water and
1/2 detergent or soap. Mix the solution well.
2. Make sure that the gas supply valve on the gas cylinder
is turned on.
3. Make sure that the gas control valves on the appliance
are all turned off.
4. Using a brush or spray bottle apply the solution to the
gas line and each join in the gas line.
5. Bubbling of the solution will indicate that there is a leak
present.
6. Re-tighten or re-seal any joints that are leaking.
7. If a leak persists then contact your distributor or the
manufacturer for assistance.
LIGHTING YOUR BARBECUE
1. Open the lid and make sure all the knobs are in the OFF
position.
2. Push down the knob and turn the knob anticlockwise
to HIGH position, then keep pressing the igniter for 2-3
seconds (a sound can be heard), thus the burner will
ignite. If the burner does not light, turn off the knob
and wait for 5 minutes then repeat this process.
3. Adjust the heat by turning the knob to the High /Low
position.
4. To light other burners, repeat the same process for the
adjacent burner and continue in sequence until all the
burners are lit.
5. To turn the barbecue OFF, turn the cylinder valve or
regulator switch to the “OFF” position and then turn all
of the control knobs on the barbecue clockwise to the
“OFF” position.
For Match- Lighting:
1. Follow above instruction step 1-3.
2. Place the match into match holder chain and fire the
match, then put the match into the burners
3. Push down and turn the knob anticlockwise to HIGH
position, then the burner can be lit. If the burner does
not light, turn off the gas tap and wait for 5 minutes
then repeat this step 2–3.
Before cooking for the first time, turn on all the main
burners and keep burning for 10 minutes with the lid closed
and knobs at LOW position. This will “heat clean” the
internal parts and dissipate odour from any painted finish.
The color of the cooking area may change a little. This is
normal for stainless steel when subject to high heat.
WARNING
While igniting main burners and infrared rear burner,
please make sure the lid for main burners is in open
position. While cooking with the hood closed and with
all the burners on, please make sure all burners are set to
LOW position.
