Inaxsys IN-MDRI1MF Gebrauchsanweisung

Model#: IN-MDRI1MF

1MP Indoor Mini Dome with Basic WDR,

Fixed lens

Hardware User Manual

(PoE) Ver. 2013/02/04

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

IN-MDRI1MF Hardware User Manual

Table of Contents

Precautions

Introduction

Package Contents.......................................................................................... 4

Features and Benefits ................................................................................... 5

Safety Instructions........................................................................................ 6

Physical description...................................................................................... 7

Installation Procedure .................................................................................. 8

Surface Mount.................................................................................8

Gang Box Mount............................................................................10

Adjust Viewing Angle and Focus....................................................12

Basic Connections ........................................................................................ 14

Product Specification.................................................................................. .15

2. Accessing Camera 16

If you have DHCPserver / router in your network:................................. 16

If you do NOT have DHCPserver / router in your network:................... 16

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

IN-MDRI1MF Hardware User Manual

0. Precautions

Read these instructions

You should read all the safety and operating instructions before using this product.

Heed all warnings

You must adhere to all the warnings on the product and in the instruction manual. Failure to

follow the safety instruction given may directly endanger people, cause damage to the system or

to other equipment.

Servicing

Do not attempt to service this video device yourself as opening or removing covers may expose

you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

Trademarks

All names used in this manual are probably registered trademarks of respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please inform your local

office if you find any inaccuracies or omissions. We cannot be held responsible for any

typographical or technical errors and reserve the right to make changes to the product and

manuals without prior notice.

FCC/CE Regulation

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the users will be required to correct the interference at their own

expense.

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

IN-MDRI1MF Hardware User Manual

1. Introduction

Package Contents

IN-MDRI1MF Accessories

Lens Focus Tuner Warranty

Card

Quick Installation Guide Drill Template

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

IN-MDRI1MF Hardware User Manual

Features and Benefits

This is a cutting-edge digital video surveillance camera. It can compress and transmit real time

images with outstanding image quality through a standard TCP/IP network. This camera is your

best choice to build an intelligent IP surveillance system.

H.264 High Profile/MJPEG Multi-Codec Dual Streaming

This device supports 2 compression formats, H.264 High Profile and MJPEG. It brings superior

image quality at 30 frames per second up to resolution of 720p (1280 x 720 pixels) and VGA (640

x 480 pixels) resolution the device reaches 30 frames per second.

Built-in Hardware Motion Detection

No more external motion sensors are required. You may assign up to 3 video motion detection

areas. By tuning the object size and sensitivity, it will reliably detect objects passing though is

view. Hardware motion detection also offers better sensitivity and faster response time than

software motion detection.

Powerful Surveillance Software

To extend the capabilities of the IP Camera series, a powerful surveillance program is available to

download for free from our website. http://www.inaxsys.com/en/support/downloads/software-

downloads.html

Users can easily use an existing PC as a digital video recorder. Scheduled recording and manual

recording keep every important video recorded in the local hard disk. Reliable and accurate

motion detection with instant warning enables immediate response in every condition. Quick and

simple search and playback function lets you easily find the images and video you want.

Software Development Kit Support

This IP Camera can be integrated or controlled by applications from third party software

developers. Software developers can save considerable efforts by using our Streaming Library or

ActiveX control. Please contact us for details on integration support.

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

IN-MDRI1MF Hardware User Manual

Safety Instructions

Cleaning

Disconnect this video product from the power supply before cleaning.

Attachments

Do not use attachments not recommended by the video product manufacturer as they may

cause hazards.

Water and Moisture

Do not use this video product near water, for example, near a bathtub, washbowl, kitchen sink, or

laundry tub, in a wet basement, or near a swimming pool and the like.

Don’t use accessories not recommended by the manufacturer

Only install this device in a dry place protected from weather

Servicing

Do not attempt to service this video product yourself as opening or removing covers may expose

you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

Damage Requiring service

Disconnect this video product from the power supply immediately and refer servicing to

qualified service personnel under the following conditions.

1) When the power-supply cord or plug is damaged

2) If liquid has been spilled, or objects have fallen into the video product.

3) If the video product has been directly exposed to rain or water.

4) If the video product does not operate normally by following the operating Instructions in this

manual. Adjust only those controls that are covered by the instruction manual, as an

improper adjustment of other controls may result in damage, and will often require

extensive work by a qualified technician to restore the video product to its normal

operation.

Safety Check

Upon completion of any service or repairs to this video product, ask the service technician to

perform safety checks to determine if the video product is in proper operating condition.

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

IN-MDRI1MF Hardware User Manual

Physical description

1) Power LED

LED light will light up while the power is on. LED light will light off after the unit has successfully

completed the boot process.

2) Ethernet Port

The IP device connects to the Ethernet via a standard RJ45 connector. Supporting NWAY, this IP

device can auto detect the speed of local network segment (10Base-T/100Base-TX Ethernet).

3) Reset Button

Step 1: Press and continue to hold the Reset Button for 15 seconds (with a sharp tipped object,

like a pen.) while the power of the unit is on.

Step 2: The Ethernet LED light will turn off for about 1~2 seconds and flash on for another

second. By this time the reset to default operation is already completed. You may then release the

reset button. This length of time fluctuates slightly with the environment. The unit will come back

on and stay on after a few more seconds. The unit will start up with factory default

settings automatically.

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

IN-MDRI1MF Hardware User Manual

Installation Procedure

Remove the cover of the camera by loosen the 3 screws holding it.

Surface Mount

Drill three holes with φ3.5 on the ceiling according to the marks provided on the template.

Route cables through the ceiling, taking as a reference the Conduit Hole on the drilling template.

Or you may take off the removable part from the cable exit hole at the rear of the cover by sliding

it out from the cover to route the cable from the camera.

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

IN-MDRI1MF Hardware User Manual

Use the camera body and locate the correct three screw holes.

Tighten the camera body to the ceiling using the 3 screws included.

Please make sure the screw is flat on the plate, protruding is incorrect.

Attach the cover back to the camera body and tighten the 3 screws.

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

IN-MDRI1MF Hardware User Manual

Gang Box Adapter Mount

This camera can also be mounted using the Gang Box Converter accessory IN-X0803 used for 3”

and 4” indoor domes. However please note that if used in combination with this accessory, a part

of the plate of IN-X0803 will remain visible after installation as shown in the picture below.

First, locate the three screw holes on the accessory that can be used to attach this camera

model.

Connect cables through the hole on IN-X0803 accessory.
