infobit iWall X Series Bedienungsanleitung
2
Content
1. Interface introduction......................................................................................................................................................3
2. Features ..........................................................................................................................................................................4
3. Spec ................................................................................................................................................................................5
4. Wiring instructions ..........................................................................................................................................................6
5. Install the iWall X software ............................................................................................................................................10
6. IP setting .......................................................................................................................................................................10
7. Software connection......................................................................................................................................................10
8. Device activation ...........................................................................................................................................................11
9. Switching languages ......................................................................................................................................................12
10. LCD Videowall settings.................................................................................................................................................12
11. LED wall settings..........................................................................................................................................................13
12. Source management....................................................................................................................................................14
13. Preset..........................................................................................................................................................................18
14. Audio switching ...........................................................................................................................................................20
15. Background image .......................................................................................................................................................21
16. Change IP address........................................................................................................................................................21
17. User management and password.................................................................................................................................22
18. License ........................................................................................................................................................................23
19. Screen ON/Off .............................................................................................................................................................24
20. Crop the input .............................................................................................................................................................24
21. Rename the input ........................................................................................................................................................25
22. App control..................................................................................................................................................................26
23. Central Control ............................................................................................................................................................27
24. Attention .....................................................................................................................................................................30
3
1. Interface introduction
Model: iWall X404
Model: iWall X408
Model: iWall X808
4
Model: iWall X412
No.
Description
1
12V Power supply
2
Dial switch
3
IR receiver (Reserved for future)
4
Audio Out (3.5mm)
5
RS232
6
10/100M LAN
7
HDMI output (Blue light)
8
HDMI input (Green light)
9
Chassis foot pad
10
GND
11
Handle
12
Power switch
2. Features
•Advanced CrossBar technology
•Robust FPGA video data process technology
•No PC vulnerabilities
•1 to 12 display outputs
5
•4x video overlay windows per display
•Video windows zoom in, zoom out, moving, overlay, roaming, resizing and switching
•With 4x4, 4x8, 4x12 and 8x8 HD graphics inputs and outputs
•Low power consumption
•Low capture & display latency
•Support both LCD and LED videowall
•Presets saving and auto switching
•Video cropping
•Scrolling text*
•Embedded HDMI audio in all inputs
•1x de-embedded audio from any input
•One-touch audio switching, mute or unmute
•Drag-and-Drop software operation
•One-touch Power On/ Off the whole videowall
•Seamless switching without any blank intervals
•Both videowall and matrix mode
•TCP/IP, RS232 Control
•Multiple user levels management
•Background picture
3. Spec
Series
iWall X
Name
1080P HDMI Video Wall Controller
Models
iWall X404
iWall X408
iWall X808
iWall X412
Video Inputs
4x HDMI
4x HDMI
8x HDMI
4x HDMI
Video Outputs
4x HDMI
8x HDMI
8x HDMI
12x HDMI
HDMI version
HDMI 1.3
HDMI distance
15 meters via good quality copper cable
HDCP version
Not support HDCP
Size
1U
I/O resolutions
Max. 1920x1080 60Hz, support customize resolutions
Audio Inputs
Embedded HDMI audio in all inputs
Audio Outputs
1x 3.5mm de-embedded audio from any input, stereo 192K sampling rate, 32bit
Video windows
4x video overlay windows per display
zoom in, zoom out, moving, overlay, roaming, resizing and switching
Presets
Saving and auto switching
Video Cropping
Support
LCD videowall
Support
LED videowall
Support
6
Seamless Switching
Support
Operating System
FPGA pure hardware architecture, no OS
Videowall and Matrix
Supports both Videowall and Matrix modes
OSD text
Fixed OSD text* (the scrolling feature will be ready in Q3, 2023)
Background picture
Support
Control
TCP/IP, RS232 Control
Software
Windows PC, Android tablet
Net Dimension WHD
44*6*25 cm without Ear, 48.5*6*25 cm with Ear
Gross Dimension
WHD
605*165*455 cm
Net Weight
2.5kg
2.6kg
2.7kg
2.7kg
Gross Weight
5.1kg
5.2kg
5.2kg
5.2kg
Power
In: 110-240V, 50/60Hz. Out: 12V DC 5A, 60W
In package
1x iWall X; 1x Power adapter; 1x UK power cord; 1x EU power cord; 1x 3.5mm audio cable, 1x
RS232 to RJ45 adapter; 1x Grounding cable
4. Wiring instructions
2.1 Connect the HDMI video cable, power supply, network cable, audio cable, and ground
line.
2.2 Each card slot of the controller is printed with "SLOT A, SLOT B, SLOT C, SLOT D...", the
slots are arranged in alphabetical order, and each one is printed with "IN" and "OUT", it can
also be distinguished according to the color of the indicators. The green one is input (IN) and
the blue is output (OUT) as shown in the following figure:
7
2.3 The output cables to the LCD videowall must correspond to the output port sequence of
the iWall X video wall controller, as shown in the figure below:
*Note: the SLOT B (to LCD 1-4) is prior to the SLOT A (to LCD 5-8) for a 2x2 videowall.
2*2 videowall diagram
8
2*4 videowall diagram
2.4 The iWall X also support LED wall. The output cables to the LED sending cards must
correspond to the output port sequence of the iWall X video wall controller, same as LCD
connections.
2.5 Connect the software (see Paragraph 5), after setting the screen output (see Paragraph
7), the wiring sequence of the outputs will be shown on the virtual screen area on the iWall
X software; follow this sequence to connect the videowall to the iWall X controller. For
example, as below: the SLOT B: 1, 2, 3 and 4 to be connected to LCD 1-4; the SLOT A: 1, 2, 3
and 4 to be connected to LCD 5-8;
9
10
5. Install the iWall X software
Copy the client software installation package iWall 3.2.7 setup to the computer, and then
double-click the file and click next to complete the installation.
6. IP setting
Connect the controller and the computer directly with a network cable or connect both to
the same switch or router.
The factory IP address of the controller is 192.168.1.250, and the computer IP must be set to
192.168.1.xx to make sure they are under the same LAN.
To change the default IP of the video wall controller, please refer paragraph 14. Change IP
Address
7. Software connection
Open the iWall X, click Connect, enter the controller IP Address, User Name (admin as default),
and the password are empty; you can also select the auto-searched IP (see the figure below)
and click Ok to login.
