InFocus SP4805 Bedienungsanleitung

User’s Guide

InFocus Corporation

In the Americas:

27700B SW Parkway Avenue

Wilsonville, Oregon 97070-9215

1-800-294-6400 •503-685-8888

Fax: 503-685-8887

http://www.infocus.com

[ English • Français • Deutsch • Español • Italiano • Norsk • Nederlands]

User’s Guide ScreenPlay 4805

In Europe:

InFocus International B.V.

Strawinskylaan 585

1077 XX Amsterdam

The Netherlands

Phone: +31 20 579 2000

Fax: +31 20 579 2999

In Asia:

238A Thomson Road

#18-01/04 Novena Square

Singapore 307684

Telephone: (65) 6334-9005

Fax: (65) 6333-4525

ScreenPlay 4805 ScreenPlay 4805

6786SP4805_UG.qxd 4/19/04 9:18 AM Page 1

Declaration of Conformity

Manufacturer: InFocus Corporation, 27500 SW Parkway Ave. Wilsonville, Oregon

97070 USA

European Office: Strawinskylaan 585, 1077 XX Amsterdam, The Netherlands

We declare under our sole responsibility that this projector conform to the following

directives and norms:

EMC Directive 89/336/EEC, Amended by 93/68/EEC

EMC: EN 55022

EN 55024

EN 61000-3-2

EN 61000-3-3

Low Voltage Directive 73/23/EEC, Amended by 93/68/EEC

Safety: EN 60950: 2000

March, 2004

Trademarks

Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple

Computer, Inc. IBM is a trademark or registered trademark of International Business

Machines, Inc. Microsoft, PowerPoint, and Windows are trademarks or registered

trademarks of Microsoft Corporation. Adobe and Acrobat are trademarks or

registered trademarks of Adobe Systems Incorporated. Digital Light Processing is a

trademark or registered trademark of Texas Instruments. Faroudja, DCDi, and

TrueLife are trademarks or registered trademarks of Faroudja. InFocus and

ScreenPlay are trademarks or registered trademarks of InFocus Corporation. InFocus,

ProjectorManager, ProjectorNet, and LP are trademarks or registered trademarks of

InFocus Corporation.

FCC Warning

Note: This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

--Consult the dealer or an experienced radio/TV technician for help.

Canada

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Agency Approvals

UL, cUL, TUV, GOST

Other specific Country Approvals may apply. Please see product certification label.

InFocus reserves the right to alter product offerings and specifications at any time

without notice.

Table of Contents

Introduction 4

Positioning the projector 6

Projector and Device Connector Guide 7

Computer connections 7

Video connections 7

Connecting a computer source 10

Required computer connections 10

Optional computer connections 10

Displaying a computer source image 11

Adjusting the image 12

Using the projector with Windows 98 for the first time 13

Connecting a video device 15

Video device connections 16

Composite (RCA) video connection 16

S-video connection 16

Component (RCA) connection 17

DVI connection 17

Displaying video 18

Adjusting the image 18

Shutting down the projector 20

Troubleshooting your setup 20

Using the remote control 28

Using the audio 29

Using the keypad buttons 30

Optimizing computer images 31

Optimizing video images 31

Customizing the projector 31

Using the menus 32

Picture menu 33

Settings menu 38

Maintenance 40

Cleaning the Lens 40

Replacing the Projection Lamp 40

Cleaning the Lamp Housing Screens 42

Using the security lock 42

Appendix 43

Projected Image Size 43

Red LED Behavior and Projector Errors 44

If you are experienced in setting up projection systems, use the Quick Setup

card that is included with the projector. For complete details on connecting

and operating the projector, refer to this User’s Guide. Electronic versions of

this User’s Guide in multiple languages are available on our website.

The website also has technical specifications (an interactive image size cal-

culator, laptop activation commands, connector pin outs, a glossary, the

product data sheet), a web store to buy accessories, and a page for online

registration.

Important Operating Considerations for Safety

• Place the projector in a horizontal position no greater than 15 degrees

off axis.

• Locate the projector in a well-ventilated area without any obstructions

to intake or exhaust vents. Do not place the projector on a tablecloth or

other soft covering that may block the vents.

• Locate the projector at least 4' (1.2 m) away from any heating or cooling

vents.

• Use only InFocus-approved ceiling mounts.

• Use only the power cord provided. A surge-protected power strip is

recommended.

• Refer to this manual for proper startup and shutdown procedures.

• In the unlikely event of the lamp rupturing, discard any edible items

placed in the surrounding area and thoroughly clean the area along all

sides of the projector. Wash hands after cleaning the area and handling

the ruptured lamp. This product has a lamp which contains a very

small amount of mercury. Dispose of it as required by local, state or

federal ordinances and regulations. For more information see

www.eiae.org.

Follow these instructions to help ensure image quality and lamp life over

the life of the projector. Failure to follow these instructions may affect the

warranty. For complete details of the warranty, see the Warranty section at

the end of this User's Guide.

2ft(.6m)

Do not place objects or people in the 2 foot (.6m) area along the front of the projector.

For ceiling mount applications, this area should be 5 feet (1.5m).

5 ft (1.5m)

Introduction

Congratulations and thank you for your excellent choice of a superior digi-

tal image projection device. Your new InFocus® ScreenPlay™ 4805 projector

is specifically designed for home cinema applications. The ScreenPlay 4805

sets a high standard using the latest DLP™ technology and new DCDi Plus

video processing from Faroudja™. Whether you are watching movies or

High Definition broadcasts or playing the latest video game, you will enjoy

amazing image quality.

Product specifications

To read the latest specifications on your multimedia projector, be sure to

visit our website, as specifications are subject to change. Web address infor-

mation is located on the back inside cover of this User’s Guide.

Accessories

The standard accessories that came with your projector can be found on the

included packing list. Optional accessories are listed in the Accessories cata-

log that came with the projector and can also found on our website. See the

inside back cover for the Web address.

Online Registration

announcements, and registration incentives. See the inside back cover for

the Web address.

keypad

adjustable foot release

focus (thin ring)

remote control

receiver (IR)

power cord

connector

power switch

zoom (thick ring)

speaker

tethered lens cap

panel

security lock

lamp

housing

door

foot

adjustable

connector

Connector Panel

The projector provides both computer and video connection options,

including:

• DVI (M1-DA)

• Component SD/ED/HD (RCA)

• S-video

• Composite audio/video (RCA)

The projector also provides the following connectors:

• Audio out

• 12 volt DC output (see below)

12 volt DC output

The 3.5mm mini-jack trigger provides a 12 volt DC output. It provides a

constant output while the projector is on. It has numerous uses. For exam-

ple, if you connect your projection screen to the 12 volt DC output with the

cable that came with your screen, when you turn on the projector the screen

will move down; when you turn the projector off, the screen will return to

the storage position. To use the 12 volt DC output, you must first remove

the safety plug and turn Screen Trigger on in the System menu (see

page 38).

DVI S-video

12 volt audio

DC output out

RCA component

RCA audio/visual

(composite)

12 volt DC output

+12v ground

3.5mm plug

to, for example, screen relay (see screen manufacturer

for details)

Positioning the projector

To determine where to position the projector, consider the size and shape of

your screen, the location of your power outlets, and the distance between

the projector and the rest of your equipment. Here are some general guide-

lines:

• Position the projector on a flat surface at a right angle to the screen. The

projector must be at least 4.9 feet (1.49m) from the projection screen.

• Position the projector within 10 feet (3m) of your power source and

within 6 feet (1.8m) of your video device (unless you purchase exten-

sion cables). To ensure adequate cable access, do not place the projector

within 6 inches (.15m) of a wall or other object.

• If you are installing the projector on the ceiling, refer to the installation

guide that comes with the Ceiling Mount Kit for more information. To

turn the image upside down, see “Ceiling” on page 38. We recommend

using an authorized ceiling mount.

• Position the projector the desired distance from the screen. The distance

from the lens of the projector to the screen, the zoom setting, and the

video format determine the size of the projected image. The top illus-

tration to the right shows three projected image sizes. For more infor-

mation about image sizes at different distances, see “Projected Image

Size” on page 43.

• The image offset is 127.3% when the projector is in 16:9 mode. This

means that if you have an image 10’ high, the bottom of the image will

be 2.73’ above the center of the lens.

• See “Connecting a video device” on page 15 for additional information

on 16:9 mode.

3.3ft.

12.5ft.

5ft.

5 ft.7.6 ft.

18.9 ft.

bottom of image

2.73 ft above center

10 ft high


Projection angle in 16:9 mode

lens center

of lens

Projector and Device Connector Guide

The following illustration and table should help you find the connectors to use and obtain the best resolution possible from your input devices, such as com-

puters, standard VCRs, DVD players (progressive and interlaced), HDTV sources, TV and satellite tuners, camcorders, video games (progressive and inter-

laced), and laser disc players.

Computer connections

Computer connections involve attaching the VGA and USB ends of the provided computer cable to a computer and connecting the other end (M1 cable end)

to the M1-DA input on the projector. The USB part of the computer cable allows you to advance slides in a PowerPoint™ presentation via an optional remote

control. See page 10 for computer/projector setup information.

Video connections

The first step for connecting video is deciding what type of output connector you want to connect to the projector. If there is more than one output, select the

one with the highest quality. The best quality ranking, with 1being the highest and 3 being the lowest, is:

1component video (RCA)

2S-video

3audio/visual composite video (RCA)

If your video device has a VGA connector, you can use the DVI connector on the back of the projector for very high quality.

S-video

projector input connectors

composite audio/visual (RCA)

12 volt

audio out

DC output component (RCA)

DVI (M1-DA)

Video Device Video

Compatibility

If Your Device

Connector Is

Attach to Adapter

or Labeled

Connector on

Projector

For Setup Instructions, see Comments

Standard Broadcast TV (not

HDTV) via: cable, digital

cable, satellite TV, DVD, or

VCR

NTSC, PAL, and

SECAM formats

Component 480i

Composite video

or S-video

Component Video

Video or S-video

Component

Composite (RCA) video connec-

tion on page 16.

Component on page 17.

Not for progressive

(i.e. HDTV) sources.

See page 9.

Standard Video Camera

NTSC, PAL, and

SECAM formats

Component 480i

Composite video

or S-video

Component Video

Video or S-video

Component

Composite (RCA) video connec-

tion on page 16.

Component on page 17.

Not for progressive

(i.e. HDTV) sources.

See page 9.

Standard Video Game

NTSC, PAL, and

SECAM formats

Component 480i

Composite video

or S-video

Component Video

Video or S-video

Component

Composite (RCA) video connec-

tion on page 16.

Component on page 17.

Not for progressive

(i.e. HDTV) sources.

See page 9.

Video Device Video

Compatibility

If Your Device

Connector Is

Attach to Adapter

or Labeled

Connector on

Projector

For Setup Instructions, see Comments

HDTV

(High Definition TV)

1035i, 1080i, 720p

Component 1080i,

720p

DVI

Component video

M1-DA (DVI)

Component

DVI connection on page 17

Component on page 17

Progressive DVD

1035i, 1080i, 720p

Component 480i,

480p, 576i, 576p

DVI

Component video

M1-DA (DVI)

Component

DVI connection on page 17

Component on page 17

Progressive Video Game

1035i, 1080i, 720p

Component 480i,

480p, 576i, 576p

DVI

Component video

M1-DA (DVI)

Component

DVI connection on page 17

Component on page 17

Andere Handbücher für SP4805

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere InFocus Projektor Handbücher

InFocus

InFocus CEILING MOUNT LP 1000 SERIES Kurzanleitung

InFocus

InFocus IN3924 Bedienungsanleitung

InFocus

InFocus Work Big IN2102 Bedienungsanleitung

InFocus

InFocus Work Big IN35 Handbuch

InFocus

InFocus X1 Bedienungsanleitung

InFocus

InFocus IN20 Series Bedienungsanleitung

InFocus

InFocus LP425z Referenzhandbuch

InFocus

InFocus Play Big IN1 Bedienungsanleitung

InFocus

InFocus in3138hd Bedienungsanleitung

InFocus

InFocus ScreenPlay 7205 Bedienungsanleitung

InFocus

InFocus Learn Big IN37EP Bedienungsanleitung

InFocus

InFocus LP 850 Bedienungsanleitung

InFocus

InFocus LitePro 610 Bedienungsanleitung

InFocus

InFocus Play Big X10 Bedienungsanleitung

InFocus

InFocus LightPro IN1142 Bedienungsanleitung

InFocus

InFocus LiteBoard IN3902LB Bedienungsanleitung

InFocus

InFocus IN2124a Bedienungsanleitung

InFocus

InFocus LP 600 Handbuch

InFocus

InFocus IN1124 Bedienungsanleitung

InFocus

InFocus LP 815 Kurzanleitung zur Einrichtung

InFocus

InFocus SCREENPLAY 5700 5700 Bedienungsanleitung

InFocus

InFocus LP 850 Bedienungsanleitung

InFocus

InFocus LP 240 Bedienungsanleitung

InFocus

InFocus LP 240 Bedienungsanleitung

Beliebte Projektor Handbücher anderer Marken

iEmmet

iEmmet MP-312 Bedienungsanleitung

Epson

Epson VS400 Bedienungsanleitung

Sony

Sony VPL-HS10 Marketing Specifications & Features Bedienungsanleitung

Sony

Sony VPL-HW65ES Service-Handbuch

Toshiba

Toshiba TLP-791U Bedienungsanleitung

Philips

Philips LC1341 Referenzhandbuch

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Bedienungsanleitung

NEC

NEC NP600S EDU Bedienungsanleitung

BenQ

BenQ SH753P Bedienungsanleitung

Eiki

Eiki EK-623U series Bedienungsanleitung

Epson

Epson PowerLite Pro Cinema 6020UB Bedienungsanleitung

Epson

Epson PowerLite Home Cinema 705HD Bedienungsanleitung

Christie

Christie LHD700 Bedienungsanleitung

Navitar

Navitar FX Bedienungsanleitung

Sony

Sony SRX-R815P Bedienungsanleitung

Vivitar

Vivitar DP1500 X Bedienungsanleitung

Acer

Acer C20 Series Bedienungsanleitung

Asus

Asus ZenBeam Latte Bedienungsanleitung
