Ingenico DWM-55 Bedienungsanleitung

Payment Terminals

Satellite Terminals

From an extended range of check and contactless payment card readers to dedicated

networking and communications devices, Ingenico’s range of Satellite products extend the

functionality of its already comprehensive payment solutions portfolio. In common with

the entire Ingenico portfolio, all Satellite terminal products are fully certified, ensuring

merchants and banks can rapidly add additional payment functionality and connectivity to

support existing terminal investments with complete peace of mind.

Ingenico’s Telium Pass range of contactless readers provides merchants the opportunity to

add additional payment ‘touch-points’ through stores, while its check readers deliver

additional security for non-electronic payment.

The Network Communication Control (NCC) Blade and SmartBox router offers connectivity

beyond conventional PSTN telephony, helping to build the networks of tomorrow by enabling

secure transaction over IP and WiFi routing across the Local and Wide Area Networks.

Satellite Terminals

External Contactless Reader Check Reader Comm nication Device

NAME

Telium Pass One

Telium Pass

Telium Pass Plus

i2200 ELC 930 NCC Blade SmartBo DWM-55

Mode transparent transparent intelligent

Processor Type ARM 7 ARM 7 ARM 7 ARM 7 ARM 7 IXP420 IXP420 Wavecom Q24Plus

Speed 50 MIPS 50 MIPS 50 MIPS 50 MIPS 50 MIPS 200 MIPS 200 MIPS

Memory 96 KB / 512 KB 96 KB / 512 KB 96 KB / 512 KB 32 M + 32 M 32 M + 32 M

Contactless Protocol ISO 14443 A B l l

Contactless Card Reading

MasterCard (Mag sripe)

possible certification

with contactless

applications in P S

certified

Visa (Mag sripe) certified

One Smart PayPass certified

Paywave certified

eExpress Pay

Zip Discover

Mifare l l l

MICR Reading CMC7

E13B CMC7

Display 128 x 64 l l

Backlit l l

Connections

RS232 optional optional optional 2 1 + 1 (optional) 1 l

USB l l l 1 1 2 x Host, 1 x Device option

Ethernet 4 x LAN, 1 x WAN

B zzer l l l

Printer Silent inkjet new generation l l

One line of 80 characters l l

Power

USB 5 Volts l l l 100-240 Volts /

50-60 Hz

100-240 Volts /

50-60 Hz

100-270 Volts /

50-60 Hz

External Power supply optional

(RS232 only)

optional

(RS232 only)

optional

(RS232 only) 24V DC 1.0 A 8V DC 3.0 A 9V DC 5 to 36V DC

Horizontal or vertical positioning ll

Size (in mm) 145 x 109 x 19 145 x 109 x 19 145 x 109 x 19 295 x 135 x 80 213 x 98 x 56 483 x 176 x 313 165 x 81 x 255

Weight (in gr) 170 170 170 900 500 8300 500

SAM 4

C stomization landing zone landing zone landing zone sticker

Environment Operating temperature +5°C to +45°C +5°C to +45°C +5°C to +45°C +5°C to +40°C +5°C to +45°C 0°C to +40°C 0°C to +40°C

Relative humidity, non condensing 85% HR at +40°C 85% HR at +40°C 85% HR at +40°C 15% to 90% 85% at +40°C 85% at +40°C 85% at +40°C

Reliability Number of transactions 100 000 100 000

S pported Com Chanel

PSTN V22Bis to V34 option

GSM/GPRS option Quad Band

iFi option

ISDN E1 2 x E1 per chassis

TCP/IP Uplink & Downlink embedded

www.ingenico-us.com

E-BR-SATELLITE TERMINALS-USA-JAN09

Performance

ith high performance guaranteed, Ingenico’s reliable and

secure Satellite Terminal products are designed to deliver

maximum payment speed and versatility in any retail or

financial transaction environment. Providing a way to adopt

innovative technologies fast – before integration is possible,

together with assured security, Ingenico makes it easy to keep

up with fast-paced change.

The choice of Satellite communication devices supports the cost-

efficient traffic gathering from any network – PSTN, GPRS or IP –

for data aggregation.

Design/Ergonomics

Easy to configure and install, our Satellite Terminal devices let

you add the widest choice of payment options or communication

protocols to your existing terminal estate for any sector, from

multi-lane retailing to hospitality, forecourt, or transportation

applications. Our user-friendly range of contactless and check

readers combine the cutting-edge design and advanced

functionality expected from the market leader in payment

solutions.

Communication

ith faultless 24/7 communications a must, Ingenico’s Satellite

Terminal communication solutions deliver transaction integrity

and security through the widest variety of connectivity

interfaces. Equipped with an unparalleled array of communication

technologies, the NCC Blade and Smart Box feature fast modem,

Et h ernet , LAN, AN and GPRS for increased transaction

performance and convenience, while our contactless readers

integrate seamlessly with the Ingenico terminal range.

Security

A world leader in secure transaction and payment systems,

Ingenico’s Satellite Terminal devices adhere to industry

standards to provide the assurance of secure support for any

point of sale payment or value added service.

Software development

By enabling the integration of a host of additional applications

and service into its terminals - including loyalty programs, pre-

paid, and language or currency options - Ingenico allows

merchants and banks to generate significant incremental revenues.

In addition to offering world’s most extensive library of value

added applications - over 800 - our uniquely scalable operating

system creates the ideal environment on which to rapidly build

and deploy EMV e-payment solutions as well as bespoke new

solutions, tailored specifically to the customer’s needs.

Field Services

To reduce total cost of ownership and enable merchants and

banks to maximize their terminals investments, Ingenico provides

a comprehensive range of terminal and software update and

management services…both remotely and in the field. Fully

certified professions and local language helpdesk personnel

operate in every one of our regions, ensuring Ingenico is on

hand to support customers 24 hours a day, seven days a week,

365 days of the year.

Satellite Terminals

Telium

Pass One

Telium

Pass

Telium

Pass Plus

i2200

ELC 930

NCC Blade

SmartBox

D M 55
